Altinex Tilt 'N Plug 100 Series User manual

www.altinex.com
Copyright 2018
Table Top
Interconnect
Guide
Doc. #: 626-0019-003
Pop 'N Plug
400 Series
Pop 'N Plug
500 Series
Tilt 'N Plug
300 Series
Tilt 'N Plug
500 Series
Tilt 'N Plug
100 Series
Cable Nook
200 Series
Cable Nook
202 Series
The Edge
Under Table Table Buddy

ALTINEX has been the leading, ISO 9001 certified manufacturer of modular audiovisual
signal management solutions™ since 1993. We manufacture a complete line of computer
video interfaces, distribution amplifiers, switchers, matrix switchers, special application
products, cables and related accessories, software, and a large variety of furniture
connectivity products.
About ALTINEX
Signal management solutions are used to handle the routing of computer video, broadcast
video, audio, and control signals in presentation systems which can range from a small
meeting room to a multi-faceted large boardroom or conference room. The current product
line includes a full array of designer solutions, interfaces, distribution amplifiers, switchers,
matrix switchers, converters, special application products, cables, and accessories.
Notes:

Altinex Inc. www.altinex.com Call us: 1-714-990-2300 or 1-800-ALTINEXCopyright 2018
Guide to Customization
Select Cables
Select Bezel Shape & Color
Select your Table Top Style and Size
Select Face Plate or Plate Inserts
Each unit has the available
bezel shapes and colors on its
product page.
Select the sectional plate or
build a custom plate using a
variety of plate inserts.
Select Snap-in
or D-sub cables
from our wide
variety of
choices (see
pages 17 & 18
for full list of
cables).
Pop N' Plug® Tilt N' Plug® Cable Nook® Table Buddy®
To start customizing your next project, visit our our website www.altinex.com
AC401-362
CNK200 CABLE NOOK HARDWARE MOUNTINGK IT
AC401-363
CNK221 CABLE NOOK JR HARDWARE MOUNTING KIT
CNK-IP-110
INSERT PLAT E WITH
1 VGA & 1 AUDIO
CNK-IP-111
INSERT PLA TE WIT H 1 VGA,
1 AUDIO& 2 EMPTY SNAP-INS
CNK-IP-112
INSERT PLA TE WIT H 1 HDMI,
1 AUDIO& 2 EMPTY SNAP-INS
CNK-IP-113
INSERT PLA TE WIT H
1 HDMI& 1 AUDIO
CN5102US
DUAL AC POWER MODULE (9.5FT)
CN5110RB
RETAINING BRACK ET
CN6101EP
2 EMPTY SNAP -INP ORTS
CNK-IP-101
INSERT PLA TE FOR 6 SNAP-IN CONNECTORS
CNK-IP-105
INSERT PLA TE FOR 2 EMPTY S NAP-IN PORTS
CNK261
2 POWER & GROMMETS
ASSEMBLY REQUIRED
CNK261S
2 POWER & GROMMETS
ASSEMBLY REQUIRED
CNK321
TABLET OP W DISPLAY SELECT (EMPT Y),USED WIT H UT260-052
CNK341
2 POWER OUTLET , BRACKET S,
DISPLAY SE LECT,USE D WITH
UT260-052. ASS EMBLY REQUIRED
CNK221
INTERCONNECT BOX (EMPTY),
CNK221S
INT ERCONNECT BOX (EMPTY)
CNK241
2 POWER & RE TAINING BRA CKET S
ASSEMBLY REQUIRED
CNK241S
2 POWER & RE TAINING BRA CKET S
ASSEMBLY REQUIRED
Cable Nooks Jr. (CNK22X/3XX)
CM12432
B EZEL BRUS HED ALUMINUM
CM12428
BEZEL, BLACK A NODIZED
CM11265
TOP COVER, BRUSHED A LUMINUM
CM12395
ROUNDBE ZEL, BLACK ANODIZED
CM12396
ROUNDBE ZEL, CLEAR ALUMINUM
CM12462
CNK/TNP JR. 2 P ORT
STACKAB LE FRAME
CM12463
CNK/TNP JR. 3 P ORT
STACKAB LE FRAME
CM12464
CNK/TNP JR. 4 P ORT
STACKAB LE FRAME
(Black)
(Black)
(Black)
(Black) (Black)
(Silver) (Silver)
(Silver)
9
CM12472
(Black)
(Silver)
(Black)
(Silver)
CM12473 CM12474
(Black)
(Silver)
CM12461
CNK/TNP JR.
S TACKABL E BEZEL
CM12471
(Black)
(Silver)
Customizable Uni ts
Stackable Bezels & Frames
Bezels Acces sories
Plate Inserts
CNK221C
INT ERCONNECT B OX (EMPTY)
WITH CUST OMIZABLEB EZEL
(Custom)
Page Layout
Table top units
Available bezels
Available plate
inserts
1

Altinex Inc. www.altinex.com Call us: 1-714-990-2300 or 1-800-ALTINEXCopyright 2018
Guide to Customization - Stackables
Select Cables
Select Bezel Shape & Color
Select your Table Top Style and Size
Select number of units you
want to combine.
Select Snap-in or D-sub
cables from our wide variety
of choices to insert into your
custom plate.
See pages 17 & 18 for full list
of cables.
2
Stackable
Bezel 2 Units 3 Units 4 Units
Example: Two Tilt 'N Plugs are combined with Cable Nook.

Altinex Inc. www.altinex.com Call us: 1-714-990-2300 or 1-800-ALTINEXCopyright 2018
PNP400
PNP400C
EMPTY ENCLOSURE
6 SLOTS PER SIDE
EMPTY ENCLOSURE
6 SLOTS PER SIDE
PNP402C
6 x SNAP-INs, 1 x 3.5mm AUDIO,
2 x D-SUB, 2 x POWER
Pop 'N Plug (PNP40X series)
PNP402
3 x RCA , S-Video, 2 x VGA,
3.5mm AUDIO, RJ-45, RJ-1, 2 x POWER
PNP408 PNP408S
SP1003BL
3 SLOT PLATE-BLANK
SP1004BL
4 SLOT PLATE-BLANK
SP1001BL
1 SLOT PLATE-BLANK
SP1002BL
2 SLOT PLATE-BLANK
SP2102US SP2501SA
POWER OUTLET
SOUTH AFRICA
(3 SLOTS)
SP1100SC
6 SNAP-INS,
2 D-SUBS,
1 AUDIO, 2 POWER
SP2201UK
POWER OUTLET
U.K./ SINGAPORE/
HONG KONG
(3 SLOTS)
2 x USB 3.0, 2 x RJ-45, HDMI,
3.5mm AUDIO, VGA, 2 x POWER
SP3102EP
DUAL EMPTY
SNAP-IN PORT
(1 SLOT)
SP3201AV
1 VGA & 1 AUDIO
PLATE
(1 SLOT)
SP3202AV
VGA F/F GENDER
CHANGER, 1 AUDIO
(1 SLOT)
SP3103EP
DUAL EMPTY
ORTRONICS-ONLY
SNAP-IN PORT (1 SLOT)
(Black) (Black) (Black) (Silver)
Dual sided
Shipped fully assembled
Specify any Snap-In connector (see pages 17 & 18 for Snap-In connectors)
Specify Black or Silver bezel and cover
Configure unit online, using AVSnap or send us your sketch.
Table cut-out templates are available online
Bezel size: 7.86" x 6.53"
Depth below 1 inch table: 4.75"
2 x POWER OUTLET
(NORTH AMERICA)
9FT POWER CABLE
(2 SLOTS)
SP3210AV
HDMI® SECTIONAL
PLATE (1 SLOT)
AC401-303
REPLACEMENT
GAS SPRING
AC401-354
HARDWARE
MOUNTING KIT
SP3212AV
4 EMPTY SNAP-INS,
2 D-SUBS, 2 AUDIO
(3 SLOTS)
PS5594UB
5V, 4 PORTS USB LOW
PROFILE AC POWER
SUPPLY (U.S)
3
Factory Configured Insert Plates and Accessories (can be field upgraded)
Factory Configured to Your Specification
PNP400 Series
SP2601UN
AC POWER
OUTLET,
UNIVERSAL
(3 SLOTS)
Shipped Fully Assembled

Altinex Inc. www.altinex.com Call us: 1-714-990-2300 or 1-800-ALTINEXCopyright 2018
Pop 'N Plug (PNP41X series)
PNP415
CUSTOMIZABLE TOWER
SURFACE TABLE TOP,
TWO SIDED,4 EMPTY
SLOTS PER SIDE
PNP417
TOWER FOR WOOD
COVER,TWO SIDED W/ TWO
STANDARD SECTIONAL
PLATES DS901-120
PNP417C
CUSTOM SURFACE COVER,TWO
SIDED W/ TWO CUSTOM
SECTIONAL PLATES DS901-121
SP2109US
DUAL AC POWER
OUTLET FOR U.S. &
CANADA (2 SLOTS)
AC401-304
REPLACEMENT
GAS SPRING
AC401-355
HARDWARE
MOUNTING KIT
SP3102EP
DUAL EMPTY
SNAP-IN PORT
(1 SLOT)
SP3201AV
1 VGA &
1 AUDIO PLAGE
(1 SLOT)
SP3202AV
VGA F/F GENDER
CHANGER, 1 AUDIO
(1 SLOT)
SP3210AV
HDMI SECTIONAL
PLATE (1 SLOT)
Shipped Fully Assembled
SP2501SA
POWER OUTLET
SOUTH AFRICA
(3 SLOTS)
SP2201UK
POWER OUTLET
U.K./ SINGAPORE/
HONG KONG (3 SLOTS)
SP3212AV
4 EMPTY SNAP-INS,
2 D-SUBS, 2 AUDIO
(3 SLOTS)
- See pages 17 & 18 for
Snap-In connectors
- Table cut-out template is
available online
- Bezel size: 5.25" Circle
- Depth below 1inch table:
7.00 in (178mm)
SP1003BL
3 SLOT PLATE-BLANK
SP1004BL
4 SLOT PLATE-BLANK
SP1001BL
1 SLOT PLATE-BLANK
SP1002BL
2 SLOTs PLATE-BLANK
PS5594UB
5V, 4 PORTS USB LOW
PROFILE AC POWER
SUPPLY (U.S)
4
PNP415 Series
Factory Configured Insert Plates and Accessories (can be field upgraded)
SP2601UN
AC POWER OUTLET
UNIVERSAL
(3 SLOTS)
PNP418
POP 'N PLUG TOWER FOR WOOD
COVER,TWO SIDED W/ TWO
DS901-138 STANDARD SECTIONAL
PLATES

Altinex Inc. www.altinex.com Call us: 1-714-990-2300 or 1-800-ALTINEXCopyright 2018
DS901-131
4 AC POWER, 5 BLANK
SNAP-INS, 2 AUDIO, &
2 D-SUBS
PNP515
CUSTOMIZABLE TABLE TOP
TOWER, NO PLATES
PNP517C
CUSTOMIZABLE TABLE TOP
WITH 10 SNAP-INS, 8 AC
POWER, 2 AUDIO, & 2 D-SUBS
AC401-305
GAS SPRING FOR PNP515 SERIES
AC401-356
PNP415 HARDWARE MOUNTING
KIT
Pop 'N Plug (PNP5XX series)
PS5594UB
5V, 4 PORTS USB LOW
PROFILE AC POWER SUPPLY (U.S)
5
See pages 17 & 18 for Snap-In connectors
Table cut-out template is available online
Bezel size: 5.85" x 5.65"
Depth below 1 inch table: 8.75 in
PNP515 Series
Factory Configured to Your Specification
Factory Configured Insert Plates and Accessories (can be field upgraded)
Shipped Fully Assembled

Altinex Inc. www.altinex.com Call us: 1-714-990-2300 or 1-800-ALTINEXCopyright 2018
TNP328/TNP328S
AUDIO, VGA, HDMI,
RJ45, 2 POWER
TNP358/TNP358S
2 POWER, 2 USB,
HDMI, AUDIO
TNP421
GERMANY TABLETOP WITH
VGA, 3.5 AUDIO, 2 RJ45, &
POWER
TNP431
U.K. TABLETOP WITH VGA,
3.5 AUDIO, 2 RJ45, & POWER
TNP461
INDIA TABLETOP WITH VGA, HDMI,
USB, 3.5 AUDIO, RJ45, & POWER
TNP421C
GERMANY POWER WITH
2 SNAP-IN CONNECTORS,
1 D-SUB, & 1 AUDIO
TNP431C
U.K. POWER WITH
2 SNAP-IN CONNECTORS,
1 D-SUB, & 1 AUDIO
TNP461C
INDIA POWER WITH
2 SNAP-IN CONNECTORS,
1 D-SUB, & 1 AUDIO
TNP329C
CUSTOMIZABLE TABLE TOP WITH
2 POWER, 3 SNAP-IN CONNECTORS,
1 D-SUB, 1 AUDIO
TNP355C
2 POWER, 2 POWERED USB
TNP358C
2 POWER, 2 POWERED USB,
CUSTOMIZABLE D-SUB AND AUDIO
Tilt 'N Plug (TNP3XX/4XX series)
AC401-307
GAS SPRING
AC401-358
TNP HARDWARE MOUNTING KIT
PS5594UB
5V, 4 PORTS USB LOW
PROFILE AC POWER SUPPLY (U.S)
(Black/Silver) (Black/Silver)
(Black) (Black) (Black)
See pages 17 & 18 for Snap-In connectors | Table Cut-out template is available online
Bezel size: 5.7" x 5.2" | Depth below 1inch table: 2.9 in (98mm)
(Chrome plated)
6
Standard Units (Brushed Aluminum Bezel)
Factory Configured to Your Specification
Standard International Units
Factory Configured International Units
Accessories
TNP329/TNP329S
AUDIO, VGA, HDMI,
RJ45, USB, 2 POWER
(Black/Silver)
TNP328C
CUSTOMIZABLE TABLE TOP WITH
2 POWER, 2 SNAP-IN CONNECTORS,
1 D-SUB, 1 AUDIO
TNP327
(Black)
2 HDMI, 2 USB,
2 RJ-45, 2 POWER
TNP327C
CUSTOMIZABLE TABLE TOP WITH
2 POWER, 6 SNAP-IN CONNECTORS

Altinex Inc. www.altinex.com Call us: 1-714-990-2300 or 1-800-ALTINEXCopyright 2018
TNP510
CUSTOMIZABLE,6 EMPTY
SLOTS
TNP528
DUAL HDMI, VGA, AUDIO,
RJ45, US POWER,BLACK
BRUSHED ALUMINUM
TNP528S
2 RJ45, 1 USB, 2 HDMI,
AUDIO, 2 VGA, 2 AC POWER
CLEAR BRUSHED ALUMINUM
TNP530
VGA & HDMI RETRACTABLE
CABLE, AUDIO, RJ45, 2 USB
BLACK BRUSHED ALUMINUM
TNP530S
VGA & HDMI RETRACTABLE
CABLE, AUDIO, RJ45, 2 USB
CLEAR BRUSHED ALUMINUM
TNP601
10 CUSTOMIZABLE
SECTIONAL PLATES
TNP602
TILT 'N PLUG TNP600
WITH DS801-429
TNP602C
4 POWER, 10 SNAP-INS
CONNECTORS, 2 D-SUB, &
2 AUDIO
TNP530C
2 POWER, 4 SNAP-IN
CONNECTORS, &
2 RETRACTABLE CABLES
Tilt 'N Plug (TNP5XX/6XX series)
TNP510C
6 EMPTY SLOTS
TNP528C
2 POWER, 6 SNAP-IN
CONNECTORS,
2 D-SUBS, & 1 AUDIO
AC401-351
TNP500 HARDWARE
MOUNTING KIT
AC401-359
TNP600
HARDWARE
MOUNTING KIT
SP3102EP
DUAL EMPTY Keystone SNAP-IN
PORT(1 SLOT)
SP3201AV
VGA & AUDIO
SECTIONAL PLATE
(1 SLOT)
SP3210AV
HDMI SECTIONAL
PLATE (1 SLOT)
SP3212AV
4 SNAP-INS, 2 AUDIO &
2 D-SUBS SECTIONAL PLATE
(3 SLOTS)
SP3501SC
2 RJ45, 1 USB, 2 HDMI,
AUDIO, 2 VGA, 2 AC POWER
(3 SLOTS)
SP1003BL
3 SLOT PLATE-BLANK
SP1004BL
4 SLOT PLATE-BLANK
SP1001BL
1 SLOT PLATE-BLANK
SP1002BL
2 SLOT PLATE-BLANK
AC401-307
TNP600 GAS SPRING
(Black) (Black) (Silver) (Black) (Silver)
7
Standard Units (Brushed Aluminum Bezel, Leaf Spring)
Customizable Units (Brushed Aluminum Bezel, Leaf Spring)
Customizable UnitsStandard Units
Insert Plates and Accessories
TNP601C
10 CUSTOMIZABLE
SECTIONAL PLATES
SP3502SC
2 RJ45, 2 USB, 1 HDMI,
AUDIO, 1 VGA, 2 AC POWER
(3 SLOTS)
SP2301CE
AC POWER OUTLET
FOR CONTINENTAL
EUROPE (3 SLOTS)
SP2601UN
AC POWER OUTLET,
UNIVERSAL (3 SLOTS)
SP2102US
DUAL AC POWER
OUTLET, FOR U.S.
& CANADA (2
SLOTS)

Altinex Inc. www.altinex.com Call us: 1-714-990-2300 or 1-800-ALTINEXCopyright 2018
AC401-350
TNP HARDWARE MOUNTING KIT
TNP121/122/125/128/142/151/152/162/221
PS5594UB
5V, 4 PORTS USB LOW
PROFILE AC POWER SUPPLY (U.S)
AC401-302
GAS SPRING FOR TNP JR.
TNP120C
2 SNAP-IN PORTS,
1 D-SUB, 1 AUDIO
TNP150C
2 SNAP-IN CONNECTORS,
2 POWER
TNP151
2 RJ45 & 2 POWER
TNP151S
2 RJ45 & 2 POWER
TNP155
2 USB & 2 POWER
TNP155S
2 USB & 2 POWER
TNP128
HDMI, VGA, AUDIO,
RJ45, POWER
TNP128S
HDMI, VGA, AUDIO,
RJ45, POWER
TNP125
HDMI, USB,
RJ45, POWER,
TNP125S
HDMI, USB,
RJ45, POWER
CM12393
TNP JR. TOP + ROUND BEZEL,
BLACK ANODIZED FINISH
CM12394
TNP JR. TOP + ROUND BEZEL,
SILVER
CM12461
CNK/TNP JR.
STACKABLE BEZEL
CM12462
CNK/TNP JR. 2 PORT
STACKABLE FRAME
CM12463
CNK/TNP JR. 3 PORT
STACKABLE FRAME
CM12464
CNK/TNP JR. 4 PORT
STACKABLE FRAME
Tilt 'N Plug Jr. (TNP1XX series)
(Black) (Black)(Silver) (Silver)
(Silver) (Silver) (Black) (Black)
8
See pages 17 & 18 for Snap-In connectors
Table Cut-out template is available online
Bezel size: 4.6" x 4.9"
Depth below 1inch table: 2.5 in (90mm)
CM12471 CM12472 CM12473 CM12474
(Black)
(Silver)
(Black)
(Silver)
(Black)
(Silver)
(Black)
(Silver)
Stackable Bezels & Frames
Accessories
Customizable Units
Standard Units (Brushed Aluminum Bezel)
Bezels

Altinex Inc. www.altinex.com Call us: 1-714-990-2300 or 1-800-ALTINEXCopyright 2018
CNK210/210S
COMPLETE SP3504SC PLATE
ASSEMBLY REQUIRED
CN5003UK
U.K. AC POWER
MODULE
CN5005EU
CONTINENTAL
EUROPE AC POWER
MODULE
CN5008US
DUAL AC POWER
MODULE
CNK-IP-200
2 AC POWER AND
2 POWERED USB
CNK-IP-210
PLATE FOR CNK-IP-2XX
CNK-IP-211
6-PORT SNAP IN
PLATE
CNK-IP-212
PLATE INSERT WITH
1 HDMI, 1 VGA, 2 AUDIO
CNK-IP-213
PLATE INSERT WITH
2 VGA & 2 AUDIO
CNK-IP-215
PLATE INSERT WITH
3 GROMMET HOLES, BLACK,
& 3 GROMMET COVERS
SP3504SC
2 PWR, 2 USB, 1 HDMI
2 AUD, 1 VGA, 2 RJ45,
4 BLANK SNAP-INs
CNK-IP-214
PLATE INSERT WITH
2 HDMI & 2 AUDIO
Cable Nooks (CNK2XX series)
CN5010RB
RETAINING BRACKET FOR
CABLE-NOOK
CN5013EP
3 EMPTY SNAP-IN PORTS
INSERT PLATE
CN5014AV
1 VGA & 1 AUDIO PLATE
CN5015AV
PLATE INSERT WITH
1 HDMI & 1 AUDIO
CN5020RG
RETAINING GROMMET, ALLOWS
6 HOLES (US) OR 4 HOLES
(INTERNATIONAL)
CN5021RG
RETAINING GROMMET,
ALLOWS 3 HOLES
CNK240/240S
2 US AC POWER AND
RETAINING BRACKETS
ASSEMBLY REQUIRED
CNK260/260S
2 US AC POWER AND
9 RETAINING GROMMETS
ASSEMBLY REQUIRED
CNK200/200S
INTERCONNECT BOX
(EMPTY)
(Black/Silver) (Black/Silver)
(Black/Silver) (Black/Silver)
9
CNK-IP-216
1 VGA & 4 SNAP-IN
PORTS
CNK-IP-217
1 HDMI & 4 SNAP-IN
PORTS
Standard Units (Brushed Aluminum Bezel)
Insert Plates
CNK220/220S
CABLE-NOOK INTERCONNECT BOX
(EMPTY) WITH SLIDING COVER
(Black/Silver)
SP3506C
INTL PLATE FOR
CNK200 2 POWER + 2 EMPTY
SLOTS,UK, AU, EU, UNIVERSAL
SP3506SC
EU PLATE FOR
CNK200
2 POWER + 2 EMPTY
SLOTS
CN5016AV
2 EMPTY PORT FOR
PANEL CONNECTORS
CNK212/212S
COMPLETE CNK200 CABLE
NOOK ,4 AC POWER, 4 USB
POWER, 1 HDMI, 2 RJ-45,
2 BLANK SPACES
(Black/Silver)
COMPLETE CNK202 CABLE
NOOK WITH SP3504SC PLATE
ASSEMBLY REQUIRED
CNK202/202S
(Black/Silver)
CNK222/222S
(Black/Silver)
COMPLETE CNK202 CABLE
NOOK ,4 AC POWER, 4 USB
POWER, 1 HDMI, 2 RJ-45,
2 BLANK SPACES
CNK-IP-218
1 GROMMET & 4
SNAP-IN PORTS
AC401-362
CNK200 CABLE NOOK
HARDWARE MOUNTING KIT
Accessories
CNK-IP-101
INSERT PLATE W/ 6
EMPTY PORTS FOR
SNAP-IN CONNECTORS
CN5006IN
INDIA AC POWER
MODULE

Altinex Inc. www.altinex.com Call us: 1-714-990-2300 or 1-800-ALTINEXCopyright 2018
CNK600
Black Brushed CNK600S
Silver Brushed
Color
CNK6xx
Series
Insert Plates
SP2116SC
USA power
SP2117SC
International
Power
CNK-ASSY
Factory
Assembly
Power
Socket type
PS5808UV
Universal
PS5808UK
England
PS5808AU
Australia
PS5808GR
Europe
Keystone
Snap Ins
12
Places
Power
Socket type
USA
JAPAN
CANADA
Retractable
Cables
Keystone
Snap Ins
12
Places
RT300-121
VGA
RT300-134
AUDIO 3.5mm (M-M)
RT300-155
USB A to A (F-M)
RT300-145
RJ-45 (M-M)
RT300-125
HDMI (M-M)
Size
Bezel Cutout
10.72W x 6.59D
Power
Cord length
Standard
9.5ft Custom
3ft to 25ft
RT300-160
USB C to A
CNK600C
Custom Color
See pages 17 & 18
See pages 17 & 18
Maximum 4 places
10
Building your custom CNK600 unit

Altinex Inc. www.altinex.com Call us: 1-714-990-2300 or 1-800-ALTINEXCopyright 2018
RT300-145
RJ-45 (M-M) RETRACTABLE
CABLE
RT300-134
3.5MM (M-M) AUDIO
RETRACTABLE CABLE
RT300-125
HDMI (M-M) RETRACTABLE
CABLE
RT300-121
VGA (M-M) RETRACTABLE
CABLE
RT300-155
USB (F-M TYPE A)
RETRACTABLE CABLE,F -
RETRACT/M - FIXED
Cable Nooks (CNK6XX)
SP2117SC
CUSTOMIZABLE PLATE WITH
2 AUSTRALIA POWER, 8 SNAP IN,
4 AUDIO, 4 RETRACTABLE
SP2117SC
CUSTOMIZABLE PLATE WITH
2 EUROPE POWER, 8 SNAP IN,
4 AUDIO, 4 RETRACTABLE
SP2117SC
CUSTOMIZABLE PLATE WITH
2 UK POWER, 8 SNAP IN,
4 AUDIO, 4 RETRACTABLE
SP2117SC
CUSTOMIZABLE PLATE WITH
2 UNIVERSAL POWER, 8 SNAP IN,
4 AUDIO, 4 RETRACTABLE
SP2116SC
CUSTOMIZABLE PLATE WITH
2 US POWER, 8 SNAP IN,
4 AUDIO, 4 RETRACTABLE
CNK600 CNK600S
INTERCONNECT BOX (EMPTY)
FOR USE WITH SP1106SC
Open View Closed View
(Silver)(Black)
CNK600 Series
International Plate
Retractable Cables
RT300-160
USB 2.0 A- C (M-M)
RETRACTABLE CABLE,USB C
RETRACT, USB A FIXED
11

Altinex Inc. www.altinex.com Call us: 1-714-990-2300 or 1-800-ALTINEXCopyright 2018
AC401-363
CNK221 CABLE NOOK JR
HARDWARE MOUNTING KIT
CNK-IP-110
INSERT PLATE WITH
1 VGA & 1 AUDIO
CNK-IP-111
INSERT PLATE WITH 1 VGA,
1 AUDIO & 2 EMPTY SNAP-INS
CNK-IP-112
INSERT PLATE WITH 1 HDMI,
1 AUDIO & 2 EMPTY SNAP-INS
CNK-IP-113
INSERT PLATE WITH
1 HDMI & 1 AUDIO
CN5102US
DUAL AC POWER MODULE
(9.5FT)
CN5110RB
RETAINING BRACKET
CN6101EP
2 EMPTY SNAP-IN PORTS
CNK-IP-101
INSERT PLATE FOR 6 SNAP-IN
CONNECTORS
CNK-IP-105
INSERT PLATE FOR 2 EMPTY
SNAP-IN PORTS
CNK261
2 POWER & GROMMETS
ASSEMBLY REQUIRED
CNK261S
2 POWER & GROMMETS
ASSEMBLY REQUIRED
CNK221
INTERCONNECT BOX (EMPTY),
CNK221S
INTERCONNECT BOX (EMPTY)
CNK241
2 POWER & RETAINING BRACKETS
ASSEMBLY REQUIRED
CNK241S
2 POWER & RETAINING BRACKETS
ASSEMBLY REQUIRED
Cable Nooks Jr. (CNK22X/3XX)
CM12432
BEZEL CLEAR BRUSHED
ALUMINUM
CM12428
BEZEL, BLACK BRUSHED
ALUMINUM
CM12395
ROUND BEZEL, BLACK ANODIZED
CM12396
ROUND BEZEL, CLEAR
ALUMINUM
CM12462
CNK/TNP JR. 2 PORT
STACKABLE FRAME
CM12463
CNK/TNP JR. 3 PORT
STACKABLE FRAME
CM12464
CNK/TNP JR. 4 PORT
STACKABLE FRAME
(Black)
(Black)
(Black)
(Silver)
(Silver) (Silver)
CM12472
(Black)
(Silver)
(Black)
(Silver)
CM12473 CM12474
(Black)
(Silver)
CM12461
CNK/TNP JR.
STACKABLE BEZEL
CM12471
(Black)
(Silver)
Customizable Units
Stackable Bezels & Frames
Bezels Accessories
Plate Inserts
CNK221C
INTERCONNECT BOX (EMPTY)
WITH CUSTOMIZABLE BEZEL
(Custom)
12

Altinex Inc. www.altinex.com Call us: 1-714-990-2300 or 1-800-ALTINEXCopyright 2018
UT240-121S
3 EMPTY SNAP-INS, AUDIO,
1 RJ45, 1 RJ11, 1 VGA & 1
POWER
UT240-125S
3 EMPTY SNAP-INS, 1 AUDIO,
1 RJ45, 1 USB, 1 HDMI, 1 POWER
UT240-128S
3 EMPTY SNAP-INS, 1 AUDIO,
1 RJ45, 1 HDMI, 1 VGA, 1 POWER
UT240-328S
2 POWER, 2 RJ45,
2 AUDIO, 2 BLANK
SNAP-INS, 1 HDMI, 1 VGA
UT240-325S
2 POWER, 2 HDMI, 2 RJ45,
2 AUDIO, 2 BLANK SNAP-IN
THE EDGE, UNDER TABLE INTERFACES (UT240-XXX)
PS5594UB
5V, 4 PORTS USB LOW PROFILE AC
POWER SUPPLY (U.S)
Standard Units
Accessories
UT260-102
UNDER TABLE 4X1 HDMI/VGA/DP
SWITCH HDMI OUT
UT260-103
UNDER TABLE 3X1 HDMI/VGA/DP
SWITCH HDBASET OUT
UT260-104
UNDER TABLE HDMI TO
HDBASET RECEIVER
13
UT240-200S
2 AC POWER, 2 POWERED USB,
3 GROMMET HOLES FOR 3
RETRACTABLES
RT300-145
RJ-45 (M-M) RETRACTABLE
CABLE
RT300-134
3.5MM (M-M) AUDIO
RETRACTABLE CABLE
RT300-125
HDMI (M-M) RETRACTABLE
CABLE
RT300-121
VGA (M-M) RETRACTABLE
CABLE
RT300-155
USB (F-M TYPE A) RETRACTABLE
CABLE,F - RETRACT/M - FIXED
RT300-160
USB 2.0 A- C (M-M) RETRACTABLE
CABLE,USB C RETRACT, USB A FIXED
Under Table with Retractors

Altinex Inc. www.altinex.com Call us: 1-714-990-2300 or 1-800-ALTINEXCopyright 2018
TBL102
3 RCA, 1 S-VIDEO, 1 RJ11,
1, RJ45, 2 VGA,
1 AUDIO, 2 POWER
TBL108
2 POWER, 2 USB, 2
RJ45,
2 BLANK SNAP-INS,
1 HDMI, 1 AUDIO, 1 VGA
TBL100
CLAMP-ON INPUT
PLATE
TBL102C
CUSTOMIZABLE,
6 SNAP-INS, 2 D-SUBS,
1 AUDIO, 2 POWER
TBL108C
CUSTOMIZABLE,
6 SNAP-INS, 2 D-SUBS,
1 AUDIO, 2 POWER
SP1100SC SP3500SC
3 RCA, 1 S-VIDEO,
1 RJ11, 1 RJ45, 2 VGA,
1 AUDIO, 2 POWER
SP3502SC
2 POWER, 2 USB, 2 RJ45,
2 BLANK SNAP-INS,
1 HDMI, 1 AUDIO, 1 VGA
TABLE BUDDY (TBL10X series)
SP3102EP
DUAL EMPTY
KEYSTONE SNAP-IN
PORT(1 SLOT)
SP3201AV
1 VGA & 1
AUDIO PLATE
(1 SLOT)
SP3202AV
VGA F/F GENDER
CHANGER, 1 AUDIO
(1 SLOT)
SP3210AV
HDMI SECTIONAL PLATE
(1 SLOT)
SP2501SA
POWER OUTLET
SOUTH AFRICA
(3 SLOTS)
SP2201UK
POWER OUTLET
U.K., SINGAPORE,
HONG KONG (3 SLOTS)
SP3212AV
4 EMPTY SNAP-INS,
2 D-SUBS, 2 AUDIO
(3 SLOTS)
SP1003BL
3 SLOT PLATE-BLANK
SP1004BL
4 SLOT PLATE-BLANK
SP1001BL
1 SLOT PLATE-BLANK
SP1002BL
2 SLOTs PLATE-BLANK
PS5594UB
5V, 4 PORTS USB LOW
PROFILE AC POWER
SUPPLY (U.S)
6 SNAP-INS, 2 D-SUBS,
1 AUDIO, 2 POWER
SP2301CE
POWER OUTLET FOR
CONTINENTAL EUROPE
(3 SLOTS)
Standard Units Customizable Units
Plate Inserts
SP2102US
2 x POWER OUTLET
(NORTH AMERICA)
9FT POWER CABLE
(2 SLOTS)
SP2601UN
POWER OUTLET
UNIVERSAL (3 SLOTS)
14

Altinex Inc. www.altinex.com Call us: 1-714-990-2300 or 1-800-ALTINEXCopyright 2018
VP500-100
HDMI TO VGA CONVERTER
SC206-204
UNBALANCED TO BALANCED
AUDIO ADAPTER W/ LOOP
SC206-205
UNBALANCED TO BALANCED AUDIO
ADAPTER W/ LOOP (RCA TO 5p TB)
DA103-302
HDMI 1 X 2 DA W/BUILT-IN INPUT
CABLE
Additional Solutions
Distribution
Converters
TP315-101
2K HDMI OVER ANYWIRE
TRANSMITTER
TP315-102
2K HDMI OVER ANYWIRE
RECEIVER
15

Altinex Inc. www.altinex.com Call us: 1-714-990-2300 or 1-800-ALTINEXCopyright 2018
AnyWire™
HDMI over Power Cable
TP315-103
2K HDMI OVER POWER
EXTENSION
CABLE TRANSMITTER
TP315-104
2K HDMI OVER POWER EXTENSION
CABLE RECEIVER
AC Power
HDMI Over Power Extension Cable,
AnyWire Transmitter
Power cable
15 A, 125 V
Laptop
HDMI Over Power Extension Cable,
AnyWire Receiver
100 ft
TP315-104
TP315-103
1080p
Display
100 ft
100 ft
100 ft
TP315-104
HDMIcable
HDMIcable
Audio Amplifier Speakers
Audio Amplifier Speakers
AudioCable
AudioCable
Application Diagram
1080p
Display
HDMIcable
1080p
Display
TP315-104
HDMIcable
1080p
Display
TP315-104
HDMIcable
16
Power Cord Extensions

Altinex Inc. www.altinex.com Call us: 1-714-990-2300 or 1-800-ALTINEXCopyright 2018
CM11305
3.5MM STEREO AUDIO F/TB 6FT
SNAP-IN ASSEMBLY
CM11306
RJ-11, GREY F/M 6FT SNAP-IN
ASSEMBLY
CM11316
3.5MM STEREO AUDIO 6FT F/M
SNAP-IN ASSEMBLY
CM11318
RJ-11 6 PINS M/F SNAP-IN
ASSEMBLY
CM11319
RJ-11 6 PINS 6FT M/F BLACK
SNAP-IN ASSEMBLY
CM11351
CAT-6 RJ-45 F/M 6FT RED
SNAP-IN ASSEMBLY
CM11352
CAT-6 RJ-45 F/M 6FT BLACK
SNAP-IN ASSEMBLY
CM11353
CAT-6 RJ-45 F/M 6FT YELLOW
SNAP-IN ASSEMBLY
CM11354
CAT-6 RJ-45 F/M 6FT GREEN
SNAP-IN ASSEMBLY
Snap-in and D-sub Cables
CM11347
RIGHT ANGEL HDMI F/M ,28 AWG,
6FT BLACK SNAP-IN ASSEMBLY
CM11346
HDMI F/M 6FT BLACK SNAP-IN
ASSEMBLY
CM11342
HDMI F/M 6FT CABLE ASSEMBLY
CM11343
DISPLAY PORT F/M 6FT CABLE
ASSEMBLY
CM11355
CAT-6 RJ-45 F/M 6FT BLUE
SNAP-IN ASSEMBLY
CM11312
MOMENTARY SWITCH BLACK
6FT W/LED SNAP-IN ASSEMBLY
CM11315
RJ45 10-PIN 6FT F/M CRESTRON
PANEL SNAP-IN
17
Cables
CM11358
CAT-6 RJ-45 F/M 6FT WHITE
SNAP-IN ASSEMBLY
CM11359
CAT-6 RJ-45 F/M 6FT ORANGE
SNAP-IN ASSEMBLY
CM11364
3-PIN MINI XLR M/F 6FT SNAP-IN
ASSEMBLY
CM11366
USB "B" F / USB "A" M 6FT SNAP
IN ASSEMBLY
CM11370
USB 3.0 TYPE A F / USB A M 6FT
SNAP IN ASSEMBLY
CM11371
RCA RED F/F 6FT RIGHT ANGLE
SNAP-IN ASSEMBLY
CM11372
RCA BLACK F/F 6FT RIGHT
ANGLE SNAP-IN ASSEMBLY
CM11373
RCA YELLOW F/F 6FT RIGHT
ANGLE SNAP-IN ASSEMBLY

Altinex Inc. www.altinex.com Call us: 1-714-990-2300 or 1-800-ALTINEXCopyright 2018
Snap-in and D-sub Cables
CM11301
BLANK BLACK SNAP-IN COVER
CM11405
COVER, BLACK 3.5MM AUDIO
PANEL MOUNT
CM11401
9 OR 15 PIN D-SUB COVER -
BLACK
18
Blank Covers
CM11410
9-PIN D F/M 6FT PANEL MOUNT
CABLE ASSEMBLY
CM11380
USB C F / USB A M 6FT SNAP IN
ASSEMBLY
CM11381
USB C F / USB A M 3.0, 6FT
ASSEMBLY
CM11402
15-PIN HD F/F 6FT PANEL MOUNT
CABLE ASSEMBLY
CM11404
3.5MM STEREO F/M 6FT PANEL
MOUNT CABLE ASSEMBLY
CM11406
15-PIN HD F/M 6FT PANEL
MOUNT CABLE ASSEMBLY
SN1318-RJ45-B
RJ-45 F/F SNAP-IN CONNECTOR,
BLACK
CM11382 CM11383
USB C F / USB C M
6FT SNAP IN
ASSEMBLY
USB C F / USB C M 3.0, 6FT
PANEL MOUNT ASSEMBLY
Cables
