Altinex Intera Video+Audio to Twisted Pair (UTP) Transmitter... User manual

SPECIAL APPLICATION
MANUAL PART NUMBER: 400-0438-005
D
S801
-
110
INTERA
®
COMPUTER/COMPONENT
VIDEO +AUDIO
TWISTED PAIR (UTP) TRANSMITTER

SPECIAL APPLICATION
400-0438-005 1
TABLE OF CONTENTS
Page
PRECAUTIONS / SAFETY WARNINGS ............... 2
GENERAL..........................................................2
INSTALLATION .................................................2
CLEANING.........................................................2
FCC NOTICE.....................................................2
ABOUT YOUR DS801-110....................................... 3
TECHNICAL SPECIFICATIONS ............................ 3
PRODUCT DESCRIPTION...................................... 5
APPLICATION DIAGRAMS...................................... 6
DIAGRAM1: TYPICAL SETUPS........................6
DIAGRAM2: INTERNAL VIEW ..........................7
INSTALLING YOUR DS801-110............................. 8
OPERATION............................................................... 8
TROUBLESHOOTING GUIDE................................ 8
NO DISPLAY......................................................8
NO SOUND........................................................9
ALTINEX POLICIES.................................................. 9
LIMITED WARRANTY/RETURN POLICIES.......9
CONTACT INFORMATION................................9

SPECIAL APPLICATION
400-0438-005 2
PRECAUTIONS / SAFETY WARNINGS 1
Please read this manual carefully before using your
DS801-110. Keep this manual handy for future
reference. These safety instructions are to ensure
the long life of your DS801-110 and to prevent fire
and shock hazards. Please read them carefully and
heed all warnings.
1.1 GENERAL
•Qualified ALTINEX service personnel or their
authorized representatives must perform all
service.
1.2 INSTALLATION
•To prevent fire or shock, do not expose this unit
to water or moisture. Do not place the
DS801-110 in direct sunlight, near heaters or
heat-radiating appliances, or near any liquid.
Exposure to direct sunlight, smoke, or steam
can harm internal components.
•Handle the DS801-110 carefully. Dropping or
jarring can damage the unit.
•Do not pull any cables that are attached to the
DS801-110.
1.3 CLEANING
•Clean only with a dry cloth. Never use strong
detergents or solvents such as alcohol or
thinner. Do not use a wet cloth or water to clean
the unit. Do not open the unit to clean.
1.4 FCC NOTICE
•This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) This device may not cause
harmful interference, and; (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
•This equipment has been tested and found to
comply with the limits for a Class A digital device
pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable
protection against harmful interference when the
equipment is operated in a commercial
environment. This equipment generates, uses,
and can radiate radio frequency energy and if
not installed and used in accordance with the
instructions found herein, may cause harmful
interference to radio communications. Operation
of this equipment in a residential area is likely to
cause harmful interference in which case the
user will be required to correct the interference
at his own expense.
•Any changes or modifications to the unit not
expressly approved by ALTINEX, Inc. could void
the user’s authority to operate the equipment.

SPECIAL APPLICATION
400-0438-005 3
ABOUT YOUR DS801-110 2
DS801-110
Intera Video+Audio to Twisted Pair
(UTP) Transmitter
The DS801-110 provides a means of transmitting
computer video and audio signals over
Twisted Pair-type (CAT-5/6) cable when used
together with an ALTINEX UTP receiver, such as
the DS801-111 or DA1931CT.
The DS801-110 is compact and easy to use. The
DS801-110 is able to transmit computer video or
component video sources and stereo audio over
UTP cable.
The DS801-110 offers a female 15-pin HD input
with native Plug & Play compatibility. The 3.5 mm
stereo audio jack is used for audio input. The
female TP main output provides distributed drive to
the UTP cable. The Signal Detect feature shows
when a signal is present.
The latest generation of Twisted Pair devices uses
an innovative, patented technology* developed by
ALTINEX. The new signal processing technology
allows transmitting and receiving fully equalized
computer video signals, stereo, and audio signals
over long distances.
TECHNICAL SPECIFICATIONS 3
Specifications are subject to change.
See www.altinex.com for up-to-date information.
FEATURES/
DESCRIPTION DS801-110
GENERAL
Inputs
RGBHV/YPbPr 15-pin HD female (1)
Stereo Audio 3.5 mm jack (1)
Power 2-pin terminal block (1)
Output
Video+ Stereo Audio RJ-45 female (1)
Compatibility
Signal Types ALTINEX Standard for
Twisted Pair
Video Signal ResolutionsVGA through UXGA
480p through 1080i
Recommended Max.
Cable Lengths
Note: Measurements
made using ALTINEX
low-skew cable,
CB3150PV.
VGA: 640x480@60Hz
800 ft (244 m)
XGA: 1024x768@60Hz
600 ft (183 m)
SXGA: 1280x1024@60Hz
550 ft (168 m)
UXGA: 1600x1200@60Hz
500 ft (152 m)
Accessories Included
Power Adapter
(with 50 ft (15 m) cable) +9 VDC, 500 mA
Table 1. DS801-110 General
* US Patent 7,065,190

SPECIAL APPLICATION
400-0438-005 4
MECHANICALDS801-110
Housing 0.036” Aluminum
Front Panel 0.035” Steel
Length 4.10 in (104 mm)
Width 1.38 in (35 mm)
Height 1.20 in (30 mm)
Weight 0.25 lb (0.113 kg)
T° Operating 10°C-50°C
T° Maximum 75°C
Humidity 90% non-condensing
MTBF (calc.) 38,000 hrs
Table 2. DS801-110 Mechanical
ELECTRICALDS801-110
Input
Video Analog Signal 1.0 Vp-p max.
Video Sync Level TTL
Audio Signal Level 1.0Vp-p max.
Output
Video+ Stereo Audio
Video/Sync/Audio Signals
ALTINEX Standard
Power Consumption
External Adapter: 9 VDC 310 mA (2.8 W)
Table 3. DS801-110 Electrical

SPECIAL APPLICATION
400-0438-005 5
PRODUCT DESCRIPTION 4

SPECIAL APPLICATION
400-0438-005 6
APPLICATION DIAGRAMS 5
DIAGRAM 1: TYPICALSETUPS
DS801-110
DA1931CT
DS801-110 DS801-111

SPECIAL APPLICATION
400-0438-005 7
DIAGRAM 2: INTERNAL VIEW
DETECT
SIGNAL
PS
RIGHT
LEFT
PLUG and
POWER
GREEN
BLUE
RED
VER
HOR
PAIR 2
PAIR 4
PAIR 1
PAIR 3
DS801-110
POWER
2-PIN TERM. BLOCK
9 V, 500 mA
STEREO
3.5mm3.5mm
VIDEO
15-PIN HD
SYNC
PROCESSING
AUDIO
MODULATION
CLOCK
GENERATOR
OUTPUT
PLAY
AUDIO
4TP
INPUT
RJ-45

SPECIAL APPLICATION
400-0438-005 8
INSTALLING YOUR DS801-110 6
Step 1. Determine the best location for the
DS801-110 and TP Receiver. Where
possible, locate the DS801-110 as close
to the video source as possible and the
receiver as close to the receiving
component as feasible.
Step 2. Apply power to the 2-pin terminal block on
the rear of the DS801-110. The
Power/Signal Present LED should be on
and red.
Step 3. Connect the video source to the input of
the DS801-110using a high quality video
cable. The Power/Signal Present LED
should change from red to green
indicating a signal is present.
Step 4. Connect the audio input source to the
audio jack on the DS801-110.
Step 5. Run a UTP-type (CAT-5/CAT-5e) cable
from the 4TP OUTPUT on the rear of the
DS801-110 transmitter to the 4TP INPUT
on the TP Receiver.
NOTE: Ensure good signal transmission
by routing the cable to avoid any
sharp angles, creases, or bends.
Step 6. Connect the TP Receiver per its
installation instructions.In the case of the
DS801-111, when the TP signal from the
DS801-110 is applied, the LED will turn
from red to green.
Step 7. Connect the receiver video and audio
outputsto their respective display and
amplifying devices.
Step 8. The units are now operational.
OPERATION 7
The DS801-110 requires no adjustments for
operation. Once connected, the DS801-110 will
work trouble-free with no user intervention.
TROUBLESHOOTING GUIDE 8
We have carefully tested and have found no
problems in the supplied DS801-110.However, we
would like to offer suggestions for the following:
8.1 NO DISPLAY
Cause 1: The source has a problem.
Solution: Check the source and make sure
there is a signal present and all
source connections are correct. If
the source is working and there is
still no display, see Cause 2.
Cause 2: The path has a problem.
Solution: Connect the transmitter directly to
the receiver using a UTP patch
cable. If the image is good, there is
a problem with the cable. Otherwise,
see Cause 3.
Cause 3: Cable connections are incorrect.
Solution: Make sure that cables are properly
connected. Also, make sure that the
continuity and wiring are good. If
there is still no display, see Cause 4.
Cause 4: Video equalization required.
Solution: Adjust the Video Equalizationon the
receiver starting at minimum and
slowly working your way toward
maximum.
Cause 5: The display has a problem.
Solution: Make sure the display is powered
and is turned on. If there is still no
display, call ALTINEX at
[phone].

SPECIAL APPLICATION
400-0438-005 9
8.2 NO SOUND
Cause 1: The source has a problem.
Solution: Check the source and make sure
that there is a signal present and all
source connections are correct. If
the source is working and there is
still no sound, see Cause 2.
Cause 2: The volume is too low.
Solution: Increase the gain at the source. If
there is still no sound present, see
Cause 3.
Cause 3: Cable connections are incorrect.
Solution: Make sure that cables are properly
connected. Also, make sure that the
continuity and wiring are good. If
there is still no sound, see Cause 4.
Cause 4: The receiving device has a
problem.
Solution: Make sure the receiving device is
powered and is turned on. If there
is still no sound, please call
ALTINEX at [phone].
ALTINEX POLICIES 9
9.1 LIMITED WARRANTY/RETURN POLICIES
Please see the ALTINEX website at
www.altinex.com for details on warranty and
return policies.
9.2 CONTACT INFORMATION
ALTINEX, Inc.
592 Apollo Street
Brea, CA 92821 USA
TEL: [phone]
TOLL FREE: 1-800-ALTINEX
WEB: www.altinex.com
E-MAIL: [email protected]
