Alto-Shaam AR-6G User manual

AR-6G
GAS ROTISSERIE
D U E T O O N G O I N G P R O D U C T D E V E L O P M E N T,S P E C I F I C AT I O N S A R E S U B J E C T T O C H A N G E W I T H O U T N O T I C E . #53 - 06/08
ITEM NO. _______________________
Large capacity single compartment gas rotisserie with black porcelain enamel or stainless steel exterior. The
rotisserie has interior illumination for maximum merchandising effect. The unit is supplied with six (6)
removable, stainless steel skewers, each with 37" (940mm) of usable length, along with one (1) stainless steel
drip tray with drain. The tempered glass doors include a magnetic latch closure, heavy duty hinges, cool touch
handles and door stops.
The unit is furnished with a motor activator switch for skewer rotation, an ambient lamp switch, a 2-hour cook
timer and an emergency shut-off button. The rotisserie is equipped with three (3) cooking zones: top, middle,
and bottom. Each zone includes gas regulators controlling three (3) direct flame burners which are separated
by cast iron heat tiles. The burners offer a full range of heating from low to high flame.
The rotisserie base includes six (6) adjustable casters 4-1/4" - 5-1/4" (108mm - 133mm) — two (2) are locking.
■■MODEL AR-6G: Gas Rotisserie
● Advanced European Styling and Design combined
with heavy duty construction
● Illuminated cooking chamber to maximize product
merchandising as well as illuminated "Rotisserie" sign
● Visible open flame high yield gas burners
— Three independently controlled adjustable thermostats
with low, medium, and high settings
— Heavy cast iron radiant heat tiles
● Independently controlled rotating skewer drive
system powered by electric geared motors
● Emergency shut-off safety feature
● Hinged tempered glass doors
— Stay closed during operation
— Clear visibility
● Quick and easy cleaning
— Easy part assembly
— Detachable grease drip tray with drain
■■Alternate Burner Orifice
Required for installation sites at
elevations of 3,000 feet (914m)
above sea level
●When ordering, please specify
local gas type
■■Natural Gas
■■Propane
● Panel Color Choices
➥Specify color choice:
■■Black Porcelain Enamel
■■Stainless Steel
FACTORY INSTALLED OPTIONS
ANSI/NSF4
P R I N T E D I N U .S.A.
W164 N9221 Water Street • P.O. Box 450 • Meno onee Falls, Wisconsin 53052-0450 • U.S.A.
PHONE: [phone].558.8744 U.S.A./C ANA DA FAX: [phone].329.8744 U.S.A. ONLY
www.alto-shaa .co

O P T I O N S & A C C E S S O R I E S
■■Drip Tray, Stainless Steel 1006805
■■Heavy Duty “V” Skewer 5005514
■■Multi-Purpose Basket SI-27510
■■Roasting Tray 1008581
■■Shank Basket, Stainless Steel SI-27506
■■Whole Product Skewer SI-27508
78-7/8" (2003mm)
8-7/16"
(213mm)
18-3/16"
(461mm)
54-5/8" (1387mm)
50-7/8" (1292mm)
TO POWER CORD
31-7/16" (798mm)
TO GAS LINE
62-15/16" (1599mm)
78-1/8" (1983mm)
16-3/4 " (425mm)
TO DRIP TRAY
32-5/8" (828mm) 6-1/2" (165mm)
TO POWER CORD
5-5/8" (142mm)
TO GAS LINE
9-3/4"
(247mm)
TO GAS LINE
78-1/8" (1983mm)
50" (1193mm)
CAVITY WIDTH
23-1/2" (597mm)
DOOR WIDTH
49-5/8" (1260mm)
DOOR HEIGHT
53-3/4" (1365mm)
CAVITY HEIGHT
12-11/16"
(321mm)
CAVITY DEPTH
D U E T O O N G O I N G P R O D U C T D E V E L O P M E N T, S P E C I F I C AT I O N S A R E S U B J E C T T O C H A N G E W I T H O U T N O T I C E .
P R O D U C T \ PA N C A PA C I T Y
36 to 42* whole chickens
6 stainless steel skewers
*Capacities shown are based on the use of
2-1/4 to 2-1/2 pound chickens (1,02 to 1,13 kg)
CLEARANCE REQUIREMENTS
BO TH S I DE S:18" (457mm)
BACK :4" (102mm)
TO P:20" (508mm) FOR AIR MOVEMENT
I N S TA L L AT I O N R E Q U I R E M E N T S
— Exhaust ventilation hood with grease filter
— Installation on a non-combustible surface only
— Surrounding wall construction must be non-combustible
W E I G H T
NET: 974 lb (442 kg)
SHIPPING (2-PCS): UNIT: 1133 lb (514 kg) HEAT TILES: 252 lb (114 kg)
CRATE DIMENSIONS: UNIT: 75" x 41" x 86" (1905mm x 1041mm x 2184mm)
(HXWXD)GRID TILES: 28" x 24" x 20" (711mm x 610mm x 508mm)
E L E C T R I C A L
VOLTAGE PHASE CYCLE/HZ AMPS W
120 1 60 5.83 0.7
#53 - 06/08
AR-6G
GAS ROTISSERIE
INTERIOR
Skewer Usable Length - 37" (940mm)
Space Between Skewers - 8-1/2" (216mm)
1 Stainless Steel Drip Tray
78-7/8" (2003mm)
8-7/16"
(213mm)
18-3/16"
(461mm)
54-5/8" (1387mm)
50-7/8" (1292mm)
TO POWER CORD
31-7/16" (798mm)
TO GAS LINE
62-15/16" (1599mm)
78-1/8" (1983mm)
16-3/4 " (425mm)
TO DRIP TRAY
32-5/8" (828mm) 6-1/2" (165mm)
TO POWER CORD
5-5/8" (142mm)
TO GAS LINE
9-3/4"
(247mm)
TO GAS LINE
78-1/8" (1983mm)
50" (1193mm)
CAVITY WIDTH
23-1/2" (597mm)
DOOR WIDTH
49-5/8" (1260mm)
DOOR HEIGHT
53-3/4" (1365mm)
CAVITY HEIGHT
12-11/16"
(321mm)
CAVITY DEPTH
N AT U R A L G A S O R P R O PA N E
Hook-Up: 0.75" NPT
Connected Energy Load: 195,000 Btu/hr
Minimum Connected Pressure: 7 In. W.C. (Natural Gas)
11 In. W.C. (Propane)
Maximum Connected Pressure: 14 In. W.C. (Natural Gas)
14 In. W.C. (Propane)
NEMA 5-15P
15A, 125V PLUG
DIMENSIONS (HXWXD)
EXTERIOR: 78-1/8" x 62-15-16" x 32-5/8"
(1983mm x 1599mm x 828mm)
INTERIOR: 53-3/4" x 50" x 12-11/16"
(1325mm x 1193mm x 321mm)
