Alto-Shaam CT Express Combitherm CTX4-10E User manual

W164 N9221 Water Street • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 USA
PHONE: [phone] • 800.558.8744
USA/CANADA
FAX: [phone] • 800.329.8744
U.S.A. ONLY
www.alto-shaam.com
MN-29806 • Re v 4 • 12/14
pRiNted i N u.s.a.
Combitherm®
Combination Oven/Steamer
CTX4-10E
CTX4-10EVH
CTX4-10EC
CombiOven
STEP BY STEP
COOKING GUIDE AND
OPERATION MANUAL
shown with ExpressTouch control
Consult
instructions
for installation
and use.

INTRODUCTION ........................1
SAFETY PRECAUTIONS ..................3
EXPRESSTOUCH™ OPERATING INSTRUCTIONS
START-UP PROCEDURES .................4
MAIN MENU SCREEN ...................4
SETTINGS SCREEN ......................5
UPLOAD/DOWNLOAD SCREEN..........6
COOKING MODE SCREEN ...............7
FACTORY DEFAULT SETTINGS ...........9
OPERATION MODES
Steam.................................10
Combination ..........................12
Convection ............................14
Retherm ..............................16
Broiling Element .......................18
Core Temperature Probe ................19
Calibrating ExpressTouch Probe..........19
Core Temperature - Delta-T .............20
CombiSmoker Procedures ...............21
Ventless Hood Procedures ...............23
AUXILIARY FUNCTIONS
Preheating ............................24
Gold-n-Brown™ .......................24
Oven Cool-Down Feature ...............24
Reduced Fan Speed.....................25
Reduced Power ........................25
Multi-shelf Timer. . . . . . . . . . . . . . . . . . . . . . . 25
Steam Injection ........................25
PREPROGRAMMED RECIPES
Using Preprogrammed Recipes ..........26
Recipe Programming ...................27
Bakery Recipes.........................28
Convenience Product Recipes............29
Fish & Seafood Recipes .................31
Meat Recipes ..........................32
Miscellaneous Recipes ..................34
Poultry Recipes ........................35
Vegetable Recipes ......................36
HACCP ACCESS ........................38
SIMPLE CONTROL OPERATING INSTRUCTIONS
CONTROL PANEL IDENTIFICATION .....39
Oven Cool Down Process .................39
Fahrenheit or Celsius Format..............39
Operating Instructions ...................40
CLEANING & MAINTENANCE
Cleaning Agents .........................41
Precautions .............................41
First Aid................................41
Preventive Maintenance ..................42
Protecting Stainless Steel Surfaces..........43
Daily Gasket Cleaning....................44
Probe Usage and Cleaning ................44
Daily Oven Cleaning .....................44
Monthly Cleaning .......................44
Ventless Hood Filters.....................45
ExpressTouch with CombiClean®..........46
Simple Control with CombiClean® ........47
Cleaning without CombiClean® ...........48
TROUBLE SHOOTING
Emergency Operation Mode ..............49
Error Codes .............................50

EXPRESSTOUCH OPERATING INSTRUCTIONS
MN-29806 (Rev. 3) •CT EXPRESS STEP BY STEP OPERATION MANUAL • 1
INTRODUCTION
ECOSMART®TECHNOLOGY
The Alto-Shaam CT Express Combitherm
combination oven/steamer employs
Ecosmart operating efficiencies in the
design and application of all operating
and programming functions. Ecosmart
operational characteristics include the use of a
water barrier to close the oven compartment to the
outside air. While maintaining a non-pressurized
atmosphere, the primary purpose of the Ecosmart
system is to prevent the steam and heat generated
within the oven compartment from freely escaping
to the outside.
The Ecosmart design displaces the air within the
cooking compartment and achieves a higher level
of steam saturation that offers quick-steaming at
temperatures above 212°F (100°C).
This guide is provided as an operational aid with
step-by-step instructions of the basic functions of
the Combitherm oven, along with the many other
additional features of the control.
SIMPLE CONTROL
The Combitherm Simple control features a simple, push button
control that commands all the oven functions. Whether you cook by
time, or cook using the optional product probe, rest assured you will
be able to bake, roast, steam, poach, grill, broil, proof, braise and oven
fry with con dence.
LED display - Easy to read display indicates temperature settings,
time remaining, and various instructions.
STEAM MODE
COMBINATION MODE
CONVECTION MODE

MN-29806 (Rev. 3) •CT EXPRESS STEP BY STEP OPERATION MANUAL • 2
EXPRESSTOUCH OPERATING INSTRUCTIONS
EXPRESSTOUCH™CONTROL
The Combitherm ExpressTouch control features a simple,
graphics-based control panel that commands all the
oven functions. Access up to 250 of your titled recipes.
Manual cooking by time and temperature also are
easily accomplished.
Intuitive interface - The Alto-Shaam ExpressTouch offers
a simple interface that commands all of the Combitherm’s
cooking functions. As the name
implies, it is fully operable by touch.
Graphic controls - The highly visual
graphic-based control with logical
procedures ensure that correct steps
are followed every time.
An excellent memory - Access up to
250 of your titled recipes. The
CT Express with ExpressTouch also
comes standard with more than
100 pre-programmed recipes
covering most commonly prepared
food items.
HACCP data access (option) -
The CT Express with ExpressTouch
offers a downloadable
HACCP function.
Six levels of Gold-n-Brown™ - Six precise and consistent
browning levels are standard with the ExpressTouch. The
exclusive Gold-n-Brown feature gives the operator the
ability to achieve the ideal cooking environment for the
ideal nish.
Superior baking - The two-speed fan provides consistent
baking results. A moisture injection feature provides
perfect sheen and crust on breads and pastry items.
Multi-shelf timers - Track cooking
time of different food items in the same
oven with multi-shelf timers. Time is
tracked in minutes and seconds.
On-board diagnostics - The
ExpressTouch system includes
on-board diagnostic functionality
with results displayed right on the
touch screen.
Reduced energy setting -
ExpressTouch features
an interactive control display with
reduced energy setting.
STEAM MODE
COMBINATION MODE
CONVECTION MODE
BROILER MODE
RETHERM MODE
INTRODUCTION
NOTE: In a food service application, the catalytic converter technology does have limitations that are specic to
recommended use (product type and volume of food produced). Application, both menu type and production, are
limited. Overproduction and overcooking may result in exceeding conversion capability of the catalytic system and
proper use should be exercised. Additionally, the catalytic converter system will not capture steam emission (during
normal steam and/or combination cooking modes) from the oven cavity when the oven door is opened.
This product conforms to the ventilation recommendations set forth by NFPA96 using EPA202 test method. The oven
shall be used for the cooking or warming of pizza, bread, bakery products, or similar items only. No raw animal protein
products (skin-on poultry, ground meats, bacon, sausage, steak, etc) shall be cooked in the equipment unless mechanical
ventilation is provided. Precooked foods such as animal, sh, or skinless poultry protein products may be reheated in
the oven. The oven must be operated in a well-ventilated area approved for food preparation. If cooking fatty proteins,
it is recommended that the local HVAC codes and authorities are consulted to ensure compliance with ventilation
requirements. Ventless allowance is subject to and dependent upon local jurisdictional approval and some jurisdictions
may not recognize the NSF/UL certication or application.

EXPRESSTOUCH OPERATING INSTRUCTIONS
MN-29806 (Rev. 3) •CT EXPRESS STEP BY STEP OPERATION MANUAL • 3
NOTE: Automatic steam venting is a standard safety
feature built into all Combitherm oven models.
This feature vents all steam from the oven
compartment immediately before cooking time
expires or set probe temperature is reached.
This function is provided in all programmed
and timed production when operating in any
Steam, Combination, Convection, and Retherm
cooking mode. Automatic steam venting does
not function if the oven door is opened before
time expires or when the oven has been set to
continuous operation.
NOTE: Use authorized combitherm oven cleaner only.
unauthorized cleaning agents may discolor or
harm interior surfaces of the oven. Read and
understand label and material safety data sheet
before using the oven cleaner.
FOR OPERATOR SAFETY
NOTE AND OBSERVE ALL SAFETY PRECAUTIONS
LOCATED THROUGHOUT THIS GUIDE
IMPORTANT SAFETY PRECAUTIONS
CAUTION
METAL PARTS OF THIS EQUIPMENT
BECOME EXTREMELY HOT WHEN
IN OPERATION. TO AVOID BURNS,
ALWAYS USE HAND PROTECTION
WHEN OPERATING THIS APPLIANCE.
DANGER
AT NO TIME SHOULD THE INTERIOR
OR EXTERIOR BE STEAM CLEANED,
HOSED DOWN, OR FLOODED WITH
WATER OR LIQUID SOLUTION OF
ANY KIND. DO NOT USE WATER JET
TO CLEAN.
SEVERE DAMAGE OR
ELECTRICAL HAZARD
COULD RESULT.
WARRANTY BECOMES VOID IF
APPLIANCE IS FLOODED
HOT STEAM CAUSES BURNS
ROTATE THE DOOR HANDLE TO THE FIRST OPEN
ROTATION POSITION ONLY. WAIT UNTIL THE
STEAM IS VENTED BEFORE FULLY OPENING THE
DOOR.
DO NOT HANDLE PANS CONTAINING LIQUID
OR SEMILIQUID PRODUCTS POSITIONED
ABOVE THE EYE LEVEL OF THE OPERATOR.
SUCH PRODUCTS CAN SCALD AND CAUSE
SERIOUS INJURY.
DO NOT USE THE ATTACHED HAND-HELD
HOSE TO SPRAY ANYTHING OTHER THAN
THE INTERIOR OF THE COMBITHERM OVEN
COMPARTMENT.
DO NOT USE THE SPRAY HOSE ON
THE SURFACE OF A HOT COOKING
COMPARTMENT. ALLOW THE OVEN TO COOL
TO A MINIMUM OF 150°F (66°C).
LA-22026
LA-22026
INTRODUCTION

MN-29806 (Rev. 3) •CT EXPRESS STEP BY STEP OPERATION MANUAL • 4
EXPRESSTOUCH OPERATING INSTRUCTIONS
MAIN MENU SCREEN Cleaning Mode (optional)
Four (4) cleaning levels are available:
rinse, light, normal, and heavy-duty cleaning.
Download/Upload Files and
HACCP Access (optional)
Download all preprogrammed recipes (factory
default and user-programmed) and HACCP data to a
USB memory stick.
Settings
Change factory default settings. See next page for
more information.
Service Mode (password protected)
This mode is only available to qualied
service technicians.
START-UP PROCEDURES
When the oven is powered on, the ExpressTouch screen
illuminates. “Loading” indicates that the software
is booting up. The screen will also indicate what level
of progress has been made as the software becomes
fully operational.

EXPRESSTOUCH OPERATING INSTRUCTIONS
MN-29806 (Rev. 3) •CT EXPRESS STEP BY STEP OPERATION MANUAL • 5
SETTINGS SCREEN
Fahrenheit or Celsius Function - Choose
temperature format.
Note: After choosing your format, return to
the Main Menu screen and then Press Oven
Power switch off.
Language Choice - English, Spanish, Mandarin,
French, German, Korean and Russian are
available.
Multi-shelf Timer Number of Shelves -
Choose the default number of items in the oven
to be used by the multi-shelf timer.
°C
°F
10
7
100%
T
123
4 5 6 7 8 9 10
S M T W T F S
11 12 13 14 15 16 17
18 19 20 21 22 23 24
25 26 27 28 29 30 31
12
6
39
°C
°F
10
7
100%
T
123
4 5 6 7 8 9 10
S M T W T F S
11 12 13 14 15 16 17
18 19 20 21 22 23 24
25 26 27 28 29 30 31
12
6
39
Default Memo - Revert time/temperature
setting to factory defaults when switching
modes or keep the last user setting.
°C
°F
10
7
100%
T
123
4 5 6 7 8 9 10
S M T W T F S
11 12 13 14 15 16 17
18 19 20 21 22 23 24
25 26 27 28 29 30 31
12
6
39
Sound/Alarm Settings - Change alarm sounds
and volume.
°C
°F
10
7
100%
T
123
4 5 6 7 8 9 10
S M T W T F S
11 12 13 14 15 16 17
18 19 20 21 22 23 24
25 26 27 28 29 30 31
12
6
39
Touchscreen Brightness - Adjust brightness
of display screen.
°C
°F
10
7
100%
T
123
4 5 6 7 8 9 10
S M T W T F S
11 12 13 14 15 16 17
18 19 20 21 22 23 24
25 26 27 28 29 30 31
12
6
39
Lock/Unlock Recipes - Password protect
preprogrammed recipes.
°C
°F
10
7
100%
T
123
4 5 6 7 8 9 10
S M T W T F S
11 12 13 14 15 16 17
18 19 20 21 22 23 24
25 26 27 28 29 30 31
12
6
39
Set/Change Date & Time - Set or change oven
time and date settings.
°C
°F
10
7
100%
T
123
4 5 6 7 8 9 10
S M T W T F S
11 12 13 14 15 16 17
18 19 20 21 22 23 24
25 26 27 28 29 30 31
12
6
39
Calibrate Product Probe (optional)
°C
°F
10
7
100%
T
123
4 5 6 7 8 9 10
S M T W T F S
11 12 13 14 15 16 17
18 19 20 21 22 23 24
25 26 27 28 29 30 31
12
6
39
Software update - Upload new control software
to the oven using a USB drive.
°C
°F
10
7
100%
T
123
4 5 6 7 8 9 10
S M T W T F S
11 12 13 14 15 16 17
18 19 20 21 22 23 24
25 26 27 28 29 30 31
12
6
39
Return to Previous Screen - Return to previous
screen when  nished adjusting settings.

MN-29806 (Rev. 3) •CT EXPRESS STEP BY STEP OPERATION MANUAL • 6
EXPRESSTOUCH OPERATING INSTRUCTIONS
UPLOAD/DOWNLOAD SCREEN
ADD ALL
RECIPES
Download Recipes
Copy all recipes from USB memory stick
to oven. This will replace and overwrite
existing recipes.
Upload Recipes
Copy all recipes from oven control to USB
memory stick.
Add All Recipes
Copy all recipes from USB memory stick to the
oven control. This will add the recipes to the
beginning of the existing recipe list.
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCPHACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCP
HACCP Data (optional)
Download data to a USB drive for review in a
.txt  le format.
DOWNLOAD
RECIPES
DOWNLOAD
HACCP INFO
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCPHACCP
HACCP
GO TO
PREVIOUS
SCREEN
UPLOAD
RECIPES
Powerful tool - The ExpressTouch control plays an important
part in our continuous improvement process. New features
and abilities can be uploaded to your oven as they become
available. Visit our website’s download link at:
http://alto-shaam.sites.hubspot.com/expresstouch-software
Or simply call our Service Department for assistance.
DOWNLOAD
LINK

EXPRESSTOUCH OPERATING INSTRUCTIONS
MN-29806 (Rev. 3) •CT EXPRESS STEP BY STEP OPERATION MANUAL • 7
COOKING MODE SCREEN
6
5
4
3
2
1
345°F
225°F
1:4345
STEAM
MODE
TEMPERATURE TIME
CORE
TEMPERATURE
(OPTIONAL)
REDUCED
POWER MODE
GO TO
PREVIOUS
SCREEN
FAN SPEED
MULTI-SHELF
TIMER
FIND RECIPE
ADD RECIPE
GOLD-N-BROWN
MODE
CONVECTION
MODE
RETHERM
MODE
COMBINATION
MODE
DELAYED
START TIMER
START
CLEANING
COOL
DOWN
PREHEAT
BROILER
MODE
(OPTIONAL)
SMOKER MODE
(OPTIONAL)

MN-29806 (Rev. 3) •CT EXPRESS STEP BY STEP OPERATION MANUAL • 8
EXPRESSTOUCH OPERATING INSTRUCTIONS
MAIN MENU ICONS
Power ON key
Activates power to the oven and automatically lls the
steam generator equipped models with water that will
heat to a stand-by mode temperature of 188°F (77°C).
Power OFF key
Press once to initiate power shut down sequence to the
oven. Note: Oven will not shut down during a cooking
cycle. You may need to press harder due to the material
thickness. Firmly press and hold the OFF key for 10
seconds to power down the oven ONLY IF the control has
locked and is unresponsive.
6
5
4
3
2
1
345°F
225°F
1:4345
Steam Mode
The oven will operate in the steam mode at a temperature
range of 85°F to 250°F (30°C to 121°C).
• Automatic steaming at 212°F (100°C)
factory-set default.
• Quick steaming between 213°F and 250°F (101°C
and 121°C).
• Low temperature steaming between 85°F and 211°F
(29°C and 99°C).
6
5
4
3
2
1
345°F
225°F
1:4345
Combination Mode
Selection key for cooking with a combination of steam
and convection heat. Can be set between 212°F to 485°F
(100°C and 252°C).
6
5
4
3
2
1
345°F
225°F
1:4345
Convection Mode
Selection key for convection cooking without steam at a
temperature range of 85°F to 485°F (29°C to 252°C).
6
5
4
3
2
1
345°F
225°F
1:4345
Broiler Mode (optional)
Quickly and efciently toast or broil sandwiches, nachos,
soups, and desserts with the top shelf broiling element.
6
5
4
3
2
1
345°F
225°F
1:4345
Retherm Mode
Food rethermalization or reheating mode will operate
with automatic steam injection at a temperature range of
245°F to 320°F (120°C to 160°C).
Temperature
Used to set the required cooking temperature, to recall
the set cooking temperature, or to check the actual
oven temperature.
Time
Used to set the required cooking time or recall the set
cooking time.
Core Temperature (optional)
Used to set the required internal product temperature,
to recall the internal product temperature set by the
operator, or to display the current internal temperature of
the product.
6
5
4
3
2
1
345°F
225°F
1:4345
Preheat Mode
Preheats the oven cavity to a temperature set by user.
6
5
4
3
2
1
345°F
225°F
1:4345
Cool Down Mode
Lowers temperature of the oven cavity at an accelerated
pace to temperature set by user.
6
5
4
3
2
1
345°F
225°F
1:4345
Delayed Start Time
Quick and simple way to begin preheating your oven
while you’re away, and ready to go when you are.
Start/Stop
Initiates all cooking mode functions and programmed
procedures stored in memory. Stops an activated cooking
mode or programmed procedure currently in progress.
COOKING MODE SCREEN IDENTIFICATION

EXPRESSTOUCH OPERATING INSTRUCTIONS
MN-29806 (Rev. 3) •CT EXPRESS STEP BY STEP OPERATION MANUAL • 9
EXPRESSTOUCH FACTORY DEFAULT SETTINGS
COOKING MODE OVEN TEMPERATURE CORE TEMPERATURE COOKING TIME
Steam 212°F
(100°C)
160°F
(70°C) 25 minutes
Combination Steam 350°F
(175°C)
160°F
(70°C) 70 minutes
Convection 350°F
(175°C)
160°F
(70°C) 30 minutes
Broiler/Finishing (optional) ____°F N/A —— : ——
Retherm (available on
ExpressTouch only)
275°F
(135°C)
160°F
(70°C) 5 minutes
AUXILIARY FUNCTION ICONS
6
5
4
3
2
1
345°F
225°F
1:4345
Reduced Power Mode
Used to reduce kitchen power peaks and
energy consumption.
6
5
4
3
2
1
345°F
225°F
1:4345
6
5
4
3
2
1
345°F
225°F
1:4345
6
5
4
3
2
1
345°F
225°F
1:4345
6
5
4
3
2
1
345°F
225°F
1:4345
6
5
4
3
2
1
345°F
225°F
1:4345
6
5
4
3
2
1
345°F
225°F
1:4345
6
5
4
3
2
1
345°F
225°F
1:4345
Gold-N-Brown Mode
This indicator will illuminate when the browning
function is set by the operator in a timed or programmed
cooking cycle in any mode. Level 1 provides least amount
of browning, level 6 the most.
6
5
4
3
2
1
345°F
225°F
1:4345
6
5
4
3
2
1
345°F
225°F
1:4345
Fan Speed
This indicator will illuminate whenever the operator sets
a reduced fan speed to protect products affected by high-
velocity air movement.
6
5
4
3
2
1
345°F
225°F
1:4345
Return to Previous Menu
6
5
4
3
2
1
345°F
225°F
1:4345
Add Recipe
Used to create, change, duplicate, and delete
programmed menus.
6
5
4
3
2
1
345°F
225°F
1:4345
Find Recipe
Access a menu list of all stored cooking programs.
6
5
4
3
2
1
345°F
225°F
1:4345
Multi-shelf Timer
Use separate timers for one or more shelves in the oven
compartment (only visible in time mode).
6
5
4
3
2
1
345°F
225°F
1:4345
Steam Injection (not shown on illustration)
Press to add moisture in any cooking mode. Steam will
inject into the cavity as long as the icon is touched.
6
5
4
3
2
1
345°F
225°F
1:4345
Delta-T Core Temperature (optional) - only visible
in certain modes Cook by probe. Mode automatically
adjusts cooking temperature in proportion to the internal
temperature of the product.
6
5
4
3
2
1
345°F
225°F
1:4345
Smoking Mode (optional) - only visible in
convection mode or combination mode. This indicator
will illuminate when the smoking function is set by the
operator in a timer, probe or programmed cooking cycle.

MN-29806 (Rev. 3) •CT EXPRESS STEP BY STEP OPERATION MANUAL • 10
EXPRESSTOUCH OPERATING INSTRUCTIONS
STEAM MODE
The Steam mode provides the operator with the ability
to steam, poach, or blanch. This mode will automatically
steam at the boiling point of water; quick-steam above the
boiling point for faster cooking results; or low temperature
steam, below the boiling point, for more delicate products
such as pâté, mousse, seafood, or custard.
PRESS ON BUTTON TO POWER OVEN ON.
Touch the STEAM MODE ICON.
TOUCH THE START ICON TO STEAM AT THE
DISPLAYED SETTINGS.
TO CHANGE THE DISPLAYED SETTINGS:
TOUCH THE DISPLAYED TEMPERATURE.
The cooking temperature will appear at the top of
the temperature selection window. Type in desired
temperature or use up and down arrows to adjust
temperature. When nished, touch the green check mark
key to conrm change.
• Automatic Steaming 212°F (100°C)
• Quick Steaming 213°F to 250°F (101°C to 121°C)
• Low Temperature Steaming 85°F to 211°F (29°C to 99°C)
TO COOK BY TIME:
TOUCH THE DISPLAYED TIME.
The cooking time will appear at the top the time selection
window. Type in desired time period or use up and down
arrows to adjust time. When nished, touch the green
check mark key to conrm change.
Or, to set Continuous Operation mode, touch the --:--
icon and touch the green check mark key
to conrm.
TO COOK BY PRODUCT CORE TEMPERATURE:
TOUCH THE PROBE ICON.
The previously set core temperature or oven control
default setting will appear highlighted within the oven
display. Touch the displayed core temperature. The
internal product core temperature will appear at the top
of the temperature selection window. Type in desired
internal product core temperature or use up and down
arrows to adjust temperature. When nished, touch the
green check mark key to conrm change.
Attach removable probe before activating core
temperature function, and insert into product.
TOUCH THE GREEN START ARROW ICON TO
BEGIN COOKING IN STEAM MODE.
• The cavity set-temperature will appear in the display.
• If cooking by probe, the actual internal product
temperature will appear next to the icon during
operation. To change the set value for core temperature,
touch the temperature next to the icon and make
changes as required.
When the cooking time has expired or the desired core
temperature has been reached, an alarm will sound
indicating the end of the operating mode.
• To stop the alarm, touch the red stop icon or open
the oven door.
TO STOP COOKING PROGRAM AT ANY TIME,
PRESS RED STOP ICON.

EXPRESSTOUCH OPERATING INSTRUCTIONS
MN-29806 (Rev. 3) •CT EXPRESS STEP BY STEP OPERATION MANUAL • 11
STEAM MODE CHEF OPERATING TIPS
This mode will steam a full or partial load of a single
product, or multiple products without transfer of avors.
When steaming multiple products, however, individual
product cooking times must be taken into consideration.
The non-pressurized atmosphere of the Combitherm
also provides the ability to open the door during the
steam mode in order to monitor products more closely
throughout the steaming process.
STEAM
Perforated, 2-1/2" deep pans (65mm)
are particularly suitable for use in
this program mode. These pans will
provide a shorter cooking time and
will prevent product over-cooking at
the bottom of the pan.
Separate ice-encrusted vegetables
before steaming to ensure
even cooking.
A variety of products can be steamed
at the same time but attention must
be paid to the different cooking times
required for each food product.
HIGH TEMP STEAM
High temperature steaming is
suitable for hearty, root-type
vegetables such as potatoes, turnips,
carrots, and cabbage.
High temperature steaming
provides a cooking time which is
approximately 10-percent shorter
than the regular steam mode
temperature of 212°F (100°C).
Set the steam cooking temperature
between 221°F (105°C) and 230°F
(110°C) for small loads and between
230°F (110°C) and 250°F (121°C) for
full loads.
LOW TEMP STEAM
The low temperature steam mode
will function whenever the oven
compartment temperature is below
212°F (100°C).
It will take longer to steam products
using the low temperature
steam mode.
Steaming sausages in low
temperature steam prevents cracked
or peeling skins.
Use low temperature steam for
delicate foods such as shrimp, sh,
seafood, and crème caramel.
For best results, low temperature
steam all delicate food items at a
temperature of 210°F (99°C)
or below.

MN-29806 (Rev. 3) •CT EXPRESS STEP BY STEP OPERATION MANUAL • 12
EXPRESSTOUCH OPERATING INSTRUCTIONS
COMBINATION MODE
The Combination mode will prove to be the most versatile
and widely used mode the Combitherm oven has to offer.
It will produce the best possible results on the widest
variety of products — all within the shortest period of
time. The unique control function of this mode enables
the operator to roast or bake with a combination of steam
and convection heat. In addition to shorter cooking times,
this combination of steam and heat offers less product
shrinkage and more moisture retention than obtained in a
standard convection oven.
PRESS ON BUTTON TO POWER OVEN ON.
TOUCH THE COMBINATION MODE ICON.
The last set values or oven control default setting for
temperature and time will appear in the display.
TOUCH THE START ICON TO COOK AT THE
DISPLAYED SETTINGS.
TO CHANGE THE DISPLAYED SETTINGS:
TOUCH THE DISPLAYED TEMPERATURE.
The cooking temperature will appear at the top of
the temperature selection window. Type in desired
temperature or use up and down arrows to adjust
temperature. When nished, touch the green check mark
key to conrm change.
• Cooking temperature range: 212 to 485 °F (100 to 252°C)
TO COOK BY TIME:
TOUCH THE DISPLAYED TIME.
The cooking time will appear at the top the time selection
window. Type in desired time period or use up and down
arrows to adjust time. When nished, touch the green
check mark key to conrm change.
Or, to set Continuous Operation mode, touch the --:-- icon
and touch the green check mark key to conrm.
TO COOK BY PRODUCT CORE TEMPERATURE:
TOUCH THE PROBE ICON.
The previously set core temperature or oven control
default setting will appear highlighted within the oven
display. Touch the displayed core temperature. The
internal product core temperature will appear at the top
of the temperature selection window. Type in desired
internal product core temperature or use up and down
arrows to adjust temperature. When nished, touch the
green check mark key to conrm change.
Attach removable probe before activating core
temperature function, and insert into product.
TOUCH THE GREEN START ARROW ICON TO
BEGIN COOKING IN COMBINATION MODE.
• The temperature and remaining cooking time will
appear in the display.
• If cooking by probe, the actual internal product
temperature will appear next to the icon during
operation. To change the set value for core temperature,
touch the temperature next to the icon and make
changes as required.
6
5
4
3
2
1
345°F
225°F
1:4345
PRESS FOR STEAM INJECTION AT ANY TIME
DURING COOKING. Steam will inject into the cavity
as long as the icon is touched.
When the cooking time has expired or the operator set
internal temperature has been reached, an alarm will
sound indicating the end of the operating mode.
• To stop the alarm, touch the red stop icon or open
the oven door.
TO STOP COOKING PROGRAM AT ANY TIME,
PRESS RED STOP ICON.

EXPRESSTOUCH OPERATING INSTRUCTIONS
MN-29806 (Rev. 3) •CT EXPRESS STEP BY STEP OPERATION MANUAL • 13
COMBINATION MODE CHEF OPERATING TIPS
The Combination mode injects the optimum amount of
steam automatically. There is no need to select moisture
levels. Foods do not dry out. Flavors are retained with no
transfer of avors when mixing product loads.
Due to automatic steam adjustment, the door can be
opened at any time during a cooking operation. Be
certain to observe the safety warning when opening the
oven door.
The Combination mode is particularly efcient when
used for baking, broiling, grilling, stewing, braising,
and roasting.
When using the Combination mode, cooking temperatures
can be reduced 10- to 20-percent below the temperatures
used for conventional cooking methods.
Cooking time will be reduced approximately 40-percent
when cooking at the same temperature used for
convection oven cooking and up to 50- to 60-percent less
time when cooking at the same temperature used for a
conventional oven.
Food browning in the Combitherm begins at a cooking
temperature of approximately 250°F (120°C).
A higher cooking temperature results in heavier browning
but also results in greater product weight loss. To achieve
additional browning use the Moisture Vent Key or set
Gold-n-Brown into the product procedure. Gold-n-Brown
is particularly useful for adding color to high moisture
products such as chicken and other poultry items or
for additional browning of full loads and other
moist products.
The Combination mode provides even browning without
the necessity to turn the pans.
For more even cooking, do not cook in pans deeper than
4" (100mm).

MN-29806 (Rev. 3) •CT EXPRESS STEP BY STEP OPERATION MANUAL • 14
EXPRESSTOUCH OPERATING INSTRUCTIONS
CONVECTION MODE
The Convection mode operates with hot circulated air
within a temperature range of 85° to 485°F (29 to 252°C).
For many applications, better results may be
achieved with the Combination mode; therefore, the
operator may want to consider using the Convection
mode on a more limited basis.
PRESS ON BUTTON TO POWER OVEN ON.
TOUCH THE CONVECTION MODE ICON.
The last set values or oven control default setting for
temperature and time will appear in the display.
TOUCH THE START ICON TO COOK AT THE
DISPLAYED SETTINGS.
TO CHANGE THE DISPLAYED SETTINGS:
TOUCH THE DISPLAYED TEMPERATURE.
The cooking temperature will appear at the top of
the temperature selection window. Type in desired
temperature or use up and down arrows to adjust
temperature. When nished, touch the green check mark
key to conrm change.
• Cooking temperature range: 85 to 485 °F (29 to 252°C)
TO COOK BY TIME:
TOUCH THE DISPLAYED TIME.
The cooking time will appear at the top the time selection
window. Type in desired time period or use up and down
arrows to adjust time. When nished, touch the green
check mark key to conrm change.
Or, to set Continuous Operation mode, touch the --:-- icon
and touch the green check mark key to conrm.
TO COOK BY PRODUCT CORE TEMPERATURE:
TOUCH THE PROBE ICON.
The previously set core temperature or oven control
default setting will appear highlighted within the oven
display. Touch the displayed core temperature. The
internal product core temperature will appear at the top
of the temperature selection window. Type in desired
internal product core temperature or use up and down
arrows to adjust temperature. When nished, touch the
green check mark key to conrm change.
Attach removable probe before activating core
temperature function, and insert into product.
TOUCH THE GREEN START ARROW ICON TO
BEGIN COOKING IN COMBINATION MODE.
• The temperature and remaining cooking time will
appear in the display.
• If cooking by probe, the actual internal product
temperature will appear next to the icon during
operation. To change the set value for core temperature,
touch the temperature next to the icon and make
changes as required.
6
5
4
3
2
1
345°F
225°F
1:4345
PRESS FOR STEAM INJECTION AT ANY TIME
DURING COOKING. Steam will inject into the cavity
as long as the icon is touched.
When the cooking time has expired or the operator set
internal temperature has been reached, an alarm will
sound indicating the end of the operating mode.
• To stop the alarm, touch the red stop icon or open
the oven door.
TO STOP COOKING PROGRAM AT ANY TIME,
PRESS RED STOP ICON.

EXPRESSTOUCH OPERATING INSTRUCTIONS
MN-29806 (Rev. 3) •CT EXPRESS STEP BY STEP OPERATION MANUAL • 15
CONVECTION MODE CHEF OPERATING TIPS
The Convection Mode can be used to roast or bake
products needing very short cooking times or for high
moisture products such as mufns, cakes, and cookies, or
for browning the surface of the product.
The Convection mode works best with foods containing
little moisture or for very moist food which require a
dryer nished product.
For baking, preheat the Combitherm at a temperature of
325°F to 375°F (163°C to 191°C). Once preheated, reset the
temperature as required.
A higher cooking temperature results in heavier browning
but also results in greater product weight loss. To achieve
additional browning use the Moisture Vent Key or set the
Browning Feature into the product procedure.

MN-29806 (Rev. 3) •CT EXPRESS STEP BY STEP OPERATION MANUAL • 16
EXPRESSTOUCH OPERATING INSTRUCTIONS
RETHERM MODE
The Retherm mode operates with hot circulated air within
a temperature range of 245° to 320°F (120° to 160°C).
PRESS ON BUTTON TO POWER OVEN ON.
TOUCH THE RETHERM MODE ICON.
The last set values or oven control default setting for
temperature and time will appear in the display.
TOUCH THE START ICON TO COOK AT THE
DISPLAYED SETTINGS.
TO CHANGE THE DISPLAYED SETTINGS:
TOUCH THE DISPLAYED TEMPERATURE.
The cooking temperature will appear at the top of
the temperature selection window. Type in desired
temperature or use up and down arrows to adjust
temperature. When nished, touch the green check mark
key to conrm change.
• Cooking temperature range: 245 to 320 °F (120 to 160°C)
TO COOK BY TIME:
TOUCH THE DISPLAYED TIME.
The cooking time will appear at the top the time selection
window. Type in desired time period or use up and down
arrows to adjust time. When nished, touch the green
check mark key to conrm change.
Or, to set Continuous Operation mode, touch the --:-- icon
and touch the green check mark key to conrm.
TO COOK BY PRODUCT CORE TEMPERATURE:
TOUCH THE PROBE ICON.
The previously set core temperature or oven control
default setting will appear highlighted within the oven
display. Touch the displayed core temperature. The
internal product core temperature will appear at the top
of the temperature selection window. Type in desired
internal product core temperature or use up and down
arrows to adjust temperature. When nished, touch the
green check mark key to conrm change.
Attach removable probe before activating core
temperature function, and insert into product.
TOUCH THE GREEN START ARROW ICON TO
BEGIN COOKING IN COMBINATION MODE.
• The temperature and remaining cooking time will
appear in the display.
• If cooking by probe, the actual internal product
temperature will appear next to the icon during
operation. To change the set value for core temperature,
touch the temperature next to the icon and make
changes as required.
6
5
4
3
2
1
345°F
225°F
1:4345
PRESS FOR STEAM INJECTION AT ANY TIME
DURING COOKING. Steam will inject into the cavity
as long as the icon is touched.
When the cooking time has expired or the operator set
internal temperature has been reached, an alarm will
sound indicating the end of the operating mode.
• To stop the alarm, touch the red stop icon or open
the oven door.
TO STOP COOKING PROGRAM AT ANY TIME,
PRESS RED STOP ICON.

EXPRESSTOUCH OPERATING INSTRUCTIONS
MN-29806 (Rev. 3) •CT EXPRESS STEP BY STEP OPERATION MANUAL • 17
RETHERM MODE CHEF OPERATING TIPS
Since plated meals consist of dissimilar products, there
are several important factors to consider in order to
produce the nest results. Product density (compactness),
thickness, quantity of product on each plate, and quantity
of plates all relate to the length of time necessary to
reheat. Again, experience is the best method to determine
reheating time. Once the time has been determined and
recorded for a specic meal, the results will be consistent
for future reheating times.
HELPFUL HINTS FOR REHEATING
ON THE PLATE
• ALL FOOD COMPONENTS ON THE PLATE SHOULD
BE OF SIMILAR DENSITIES.
• ALL FOOD COMPONENTS ON THE PLATE SHOULD
BE SIMILAR IN THICKNESS.
• ARRANGE ALL FOOD COMPONENTS EVENLY ON
THE PLATE.
• AVOID EXCESSIVE OVERLAPPING OF PRODUCT.
• SAUCES MUST BE HEATED AND ADDED TO
PRODUCT AFTER REHEATING.
• A MIXED VARIETY OF MEALS CAN BE REHEATED
AT THE SAME TIME.
À LA CARTE RETHERMALIZATION
À la carte rethermalization is designed to take a single
plate from a refrigerated temperature to serving
temperature for immediate service. Plates are prepared
in advance, covered, and refrigerated. Preheat the
Combitherm oven. Remove plate from refrigeration and
place in the oven at 275°F (135°C) for an uncovered plate
or 300°F (150°C) for a covered plate. Plates with meat
components will take more time than plates containing
all vegetable components. Follow internal temperature
requirements for reheating and allow for override time.
After reheating, remove the plate from the oven, add any
sauces, garnish, and serve. This process can be repeated
as required.
For the most efcient continuous service, it is suggested
that the Combitherm oven be dedicated to the
rethermalization process during serving hours.
RETHERMALIZING PREFABRICATED AND
VACUUM-PACKED FROZEN FOODS
For bulk product rethermalization, completely defrost
product bags in walk-in cooler. DO NOT REMOVE
PRODUCT FROM THE BAG. Load thawed bags in
preheated oven and rethermalize in the Low Temperature
Steam mode until the required internal temperature is
reached. Place rethermalized bags in a preheated
holding cabinet set at 140° to 165°F (60° to 74°C) until
ready for service.
PLATE COVERS MUST BE USED FOR ON-THE-PLATE REGENERATION.

MN-29806 (Rev. 3) •CT EXPRESS STEP BY STEP OPERATION MANUAL • 18
EXPRESSTOUCH OPERATING INSTRUCTIONS
BROILING MODE (OPTIONAL)
The Broiler mode operates with an overhead broiling
element perfect for quickly and efciently toasting or
broiling sandwiches, nachos, soups, and desserts.
PRESS ON BUTTON TO POWER OVEN ON.
6
5
4
3
2
1
345°F
225°F
1:4345
TOUCH THE BROILER MODE ICON.
The last set values or oven control default setting for
time will appear in the display. ____F will appear
in the temperature eld.
TOUCH THE START ICON TO COOK AT THE
DISPLAYED SETTINGS.
TO COOK BY TIME:
TOUCH THE DISPLAYED TIME.
The cooking time will appear at the top the time selection
window. Type in desired time period or use up and down
arrows to adjust time. When nished, touch the green
check mark key to conrm change.
Or, to set Continuous Operation mode, touch the --:-- icon
and touch the green check mark key to conrm.
TOUCH THE GREEN START ARROW ICON TO
BEGIN COOKING IN BROILER MODE.
• The temperature (____F)and remaining cooking time
will appear in the display.
When the cooking time has expired, an alarm will sound
indicating the end of the operating mode.
• To stop the alarm, touch the red stop icon or open
the oven door.
TO STOP COOKING PROGRAM AT ANY TIME,
PRESS RED STOP ICON.
6
5
4
3
2
1
345°F
225°F
1:4345
NOTE: Broiler mode does not allow the use of any auxiliary functions, such as smoking, Delta-T, water injection,
energy levels, browning levels or shelf timers. Broiler mode will default to a fan speed of 50%.
