Amadas 9960 User manual

Model 9960
Self-Propelled
Peanut Combine
2nd Edition, Beg. Serial # 430000
MAN091
April 2005
©2005

Model 9960 Self-Propelled Peanut Combines are manufactured
by Amadas Industries:
You can find us on the Web at:
www.amadas.com
or e-mail us at:
[email protected]
P.O. Box 1833
Suffolk, VA 23439
(mailing)
1100 Holland Road
Suffolk, VA 23434
(shipping)
[phone] (Phone)
[phone] (FAX)
P.O. Box 3687
Albany, GA 31701
(mailing)
1701 South Slappey Blvd.
Albany, GA 31706
(shipping)
[phone] (Phone)
[phone] (FAX)

9960 Self-Propelled Peanut Combine Introduction
MAN091 06/03/05 i
Table of
Contents
Welcome .....................................................v
1. Safety...................................................... 1
Overview.................................................2
Safety Symbols.......................................3
Safety Guidelines ...................................5
Safety Practices.................................6
Decal Locations....................................15
2. Operator’s Station............................... 21
General Overview.................................23
Armrest Control Panel..........................24
Separator Engage............................25
Header Engage/Header Reverse....25
Automatic Header Height Control....27
Road Transport Disconnect Switch.28
Header Speed..................................28
10% Speed Reduction.....................28
Elevator Fan.....................................29
Cylinder Speed ................................30
Engine Speed ..................................31
Four Wheel Drive.............................31
Multi-Function Handle ..........................32
Multi-Function Handle Use..............33
Header Height Activation Buttons ...34
Quick Stop Switch............................34
Bin Lift Switch..................................35
Header Lift Switch............................36
Conveyor Swing Switch...................36
Unloading Conveyor Drive Button...37
COMMANDTOUCH™ Cab Corner
Post..................................................38
Active Header Control™ Display.....39
Header Height Control.....................40

Introduction 9960 Self-Propelled Peanut Combine
ii 06/03/05 MAN091
Activating Header Height
Resume.....................................41
Using Header Height Resume....42
Header Height Sensing...............43
Activating Header Height
Sensing......................................44
Using Header Height Sensing.....45
Overhead Warning Display Panel ........46
Park Brake On..................................47
Sep Drive Filter.................................47
Sep Drive Temp...............................47
Hydraulic Oil Temp...........................48
Voltage .............................................48
Eng Air Filter.....................................48
Peanut Elevator................................49
Peanut Bin Full.................................49
Hydro Charge Pressure...................49
Sep Drive Pressure..........................50
Engine Temperature ........................50
Engine Oil Pressure.........................50
Elevator Fan.....................................51
DiscSeparator..................................51
Picking Cylinders..............................51
Collection Auger...............................52
Header Auger...................................52
Overhead Controls................................53
ClimaTrak™ Automatic Temperature
Control.........................................54
Windshield Wiper Switch and Optional
Windshield Washer.....................55
Lights.....................................................56
Switches...........................................56
Dimmer.............................................57
Cab Interior Light..............................57
Warning Lights .................................58
Road Lights ......................................59
Field Lights.......................................60
Work Lights.......................................61
Exit Lighting......................................62
Operator Controls .................................63
Comfort Command™ Operator’s
Seat.............................................63
Seat Operation.................................64
Armrest and Control Console...........65
Storage Tray.....................................65
Manual Storage................................65
Cab Door Lock.................................66
Emergency Exit................................66
Cup Holder .......................................66
Auxiliary Power Outlet......................67
Cab Ladder.......................................67
Cab Landing Safety Chains .............68
Fire Extinguisher
Recommendations......................68
Landing.............................................69
Start Switch......................................70
Steering Wheel Height.....................71
Steering Column Tilt.........................71
Gear Shift Lever...............................72
Manual Parking Brake......................72
Brake Pedals....................................73
Deere-Delco AM/FM Stereo Radio.......74
Weatherband....................................76
Theft Deterrent Feature....................76
Activating THEFTLOCK®...........77
Unlock the Receiver....................77
Deactivating THEFTLOCK®.......78
Audio Operating Tips .......................78
Radio Reception...............................78
3. Monitors................................................79
Triple Display Tachometer....................80
Fuel Gauge.......................................81
Coolant Temperature Gauge...........81
Digital Display Lines.........................82
Calibration.............................................83
Elevator Fan Dampener Zero
Calibration ...................................84
Header Calibration ...........................86
Error Codes......................................91
4. Operation.............................................93
Overview..............................................94
Pre-Operation Checking......................95
Tire Checking...................................99
General Operation.............................100
Starting the Engine.........................100
Stopping the Engine.......................103
Cold Weather Operation....................104
Cold Weather Starting....................104
Antifreeze.......................................104
Antifreeze Recommendations........105
Batteries .........................................106
Coolant Heater...............................107
Hot Weather Operation......................108
Cooling System..............................108
5. Transportation...................................109
Before Transporting...........................110
Driving the Combine on Roads .........111
Towing the Combine..........................113
Using the Four Wheel Drive ..............114

9960 Self-Propelled Peanut Combine Introduction
MAN091 06/03/05 iii
Four Wheel Drive...........................115
6. Performance...................................... 117
Controls and Adjustments.................118
Picking Control Board....................118
Breast Spring Bars.........................119
Cleaning Air Control.......................120
10% Speed Reduction...................121
Cylinder Speed ..............................121
Header Speed Control...................122
Header Height Control...................123
Elevator Fan...................................124
Dual Speed Picking Cylinder
Drive............................................125
Variable Speed Picking Cylinder
Drive............................................126
Performance Troubleshooting...........127
7. Engine................................................ 131
Engine Compartment........................132
Cleaning Engine Compartment.....132
Belt Shield......................................132
Fuel System........................................133
Fuel Tank, Cap, and Breather.......134
Electric Fuel Pump.........................135
Water Separator............................136
Fuel Filter.......................................136
Cooling System ..................................137
Cooling System Maintenance........137
Radiator..........................................139
Cool System Winterizing...............140
Belts ..................................................141
Engine Fan Belt .............................141
Rotary Screen Belt.........................142
Rotary Screen.....................................143
Rotary Screen Door.......................143
Rotary Screen Maintenance..........144
Rotary Screen Knife Comb............145
Rotary Screen Rake Bar................145
Air Cleaner Filters...............................146
Element...............................................147
Element Inspection........................147
Element Cleaning ..........................147
Washing Element...........................148
8. Electrical System.............................. 149
General Information............................150
Electrical Connectors.....................150
Circuit Relays and Fuses...................151
Lights ..................................................152
Bulb Part Numbers........................153
Cab Head Light..............................154
Warning Light.................................155
Front Turn Signal, Tail and Side
Lights...........................................155
Dome and Console Lights.............155
Turn Signal Indicator......................156
COMMANDTOUCH™Corner
Post Monitor................................157
Warning Display Panel..................158
Batteries..............................................159
Battery Cables ...............................161
Battery Charging............................162
Specific Gravity Check..................163
Booster Batteries...........................164
Starter/Alternator................................165
Starter............................................165
Alternator and Voltage Regulator..165
Radio Installation................................166
FM Radio.......................................166
9. Hydraulic System............................. 169
General Information ..........................170
Components...................................170
System Cleanliness.......................171
Header Drop Rate.............................172
Change Drop Rate.........................172
Change Drop Rate for AHC...........172
Accumulator......................................173
10. Air Conditioner/Heater.................... 175
SystemOverview ..............................176
Filters.................................................177
Fresh Air Filter and Tray................178
Precleaner......................................179
Recirculating Filter.........................179
Evaporator Filter............................180
General Maintenance........................181
Cab Roof Inlet Panel......................181
Condenser.....................................182
Compressor Drive Belt ..................183
Refrigerant Level...........................183
11. Ground Drive and Rear Axle.......... 185
Tires and Wheels..............................186
Care and Service of Tires..............186
Inflation Pressure...........................187
Using Liquid Weight ...................... 188
Tire Loading Decal.........................189
Transporting...................................190
Drive Wheel Starter Stud...............190
Rear Wheel Bolt Torque................190

Introduction 9960 Self-Propelled Peanut Combine
iv 06/03/05 MAN091
Drive Wheel Bolt Torque................191
Brake System.....................................192
Brakes ............................................192
Brake Fluid Reservoir.....................192
Adjustments.......................................193
Gearshift Linkage Adjustment........193
Hydro Linkage Adjustment.............194
Cleaning Hydrostatic Oil Cooler.....195
Rear Axle Adjustment....................196
Miscellaneous....................................198
Pulling Combine Out of Mud..........198
Jacking Locations...........................199
12. Unloading Conveyor........................201
Before Using the Conveyor ...............202
Conveyor Safety.............................202
Using the Conveyor...........................203
Conveyor Tracking.............................205
Conveyor Maintenance......................206
Conveyor Troubleshooting ................207
Conveyor Timing................................208
13. Maintenance.....................................209
Safety.................................................210
Cylinder ..........................................210
Maintenance and Lubrication
Schedule.........................................212
8 Hours or Daily..............................213
50 Hours or Weekly........................215
200 Hours.......................................217
400 Hours or Yearly .......................219
800 Hours or Every Two Years......224
2000 Hours.....................................225
As Required....................................228
Cleaning Comb..................................229
Maintenance Troubleshooting...........230
14. Combine Storage .............................233
Preparing Combine for Storage.........234
Prepare the Air Conditioner ...........234
Prepare the Engine ........................235
Prepare the Combine.....................236
Removing Combine from Storage.....237
Appendices...........................................A -1
A. Identification Plate........................A –2
Engine Gearcase........................A –3
Engine Serial Number.................A –3
Hydrostatic Drive Unit Pump.......A –3
Hydrostatic Drive Unit Motor.......A –3
Cam Lobe 4-Wheel Drive Motor.A –3
B. Help Prevent Crime......................A –4
Record Identification Numbers...A –4
Keep Proof of Ownership............A –4
Park Indoors................................A –5
Park Outdoors.............................A –6
Reduce Vandalism......................A –6
Report Thefts ..............................A –7
C. Torque Values..............................A –8
Metric Bolt and Cap Screw
Torque Values..........................A –9
Unified Inch Bolt and Cap
Screw Torque Values ............A –10
D. Circuit Code Listing....................A –11
Circuit Code Colors...................A –11
Power Circuits.......................A –12
Engine Control Circuits .........A –13
Propulsion Control Circuits ...A –14
Separator Control Circuits.....A –14
Header Control Circuits.........A –15
Lighting Circuits.....................A –16
Speed Sensor Circuits..........A –17
Level Sensor Circuits............A –17
Pressure Sensor Wires.........A –18
Position Sensor Wires...........A –19
Visiontrak Wires....................A –19
Accessory Wires....................A –20
E. Hydraulic Hose Routing .............A –21
Form 0340..................................A –22
Form 0341..................................A –36
F. Schematics.................................A –46
Warranty Statement

9960 Self-Propelled Peanut Combine Introduction
MAN091 06/03/05 v
Welcome
To
AMADAS
Industries
With origins dating back to 1963, AMADAS
Industries and its predecessors have a long
history of providing high quality, reliable,
and innovative equipment for the farming
industry. AMADAS equipment is currently
at work throughout the United States and in
many other countries. This equipment
ranges from the Magnum Fource Peanut
Combine, Tree Bark Processing and
Packaging Machinery, Hi-Speed Cotton
Stalk Puller/Chopper, Reel Rain Traveler
Irrigation Systems, to the 9960 Self-
Propelled Peanut Combine.
Thank you for choosing AMADAS
Industries. We are strongly committed to
your satisfaction and safety. Our goal is for
you to be satisfied with our machinery for
many years and it is our hope that you will
choose AMADAS again for your equipment
needs.
One of the most important factors to both
safety and maximum performance is for
every machine operator to thoroughly
understand the safe operation of this
equipment. Please invest the time to read
this manual to ensure that injuries are
prevented and to receive the maximum
productivity from your AMADAS machine.

Introduction 9960 Self-Propelled Peanut Combine
vi 06/03/05 MAN091
Model 9960
Self-Propelled
Peanut
Combine
Congratulations on your purchase of an
AMADAS Model 9960 Self-Propelled
Peanut Combine. The 9960 SP is the
culmination of years of intensive research
and development in a combined effort by
AMADAS Industries and John Deere.
AMADAS Industries’ aggressive design
capabilities joined forces with John Deere’s
drive train expertise to produce the world’s
first eight-row self-propelled peanut
combine. The 9960 SP employs innovative
technology along with the industry’s largest
thrashing and separation capacity to make it
the leader in peanut combines.
Benefits
A high-capacity, self-propelled combine is
the best machine for harvesting peanuts.
Your AMADAS combine will optimize your
peanut harvest by providing the following
benefits:
•Reduced crop damage and loss. Up
to 15% less crop is lost or damaged
than with the use of a pull-type combine.
•Reduced overall harvest costs. You
need fewer machines, fewer people,
and less fuel, which results in more
profit.
•Increased harvesting capacity. The
9960’s harvesting capacity is over 33%
greater than that of a comparable pull-
type combine.
•Higher crop yield. Because the 9960
allows you to plant narrow row widths,
you will have higher crop yield.
•Superior harvesting capability in
adverse conditions. The 9960 is
unsurpassed in performance in wet,
muddy, and windblown conditions.
Standard Features
The following items are just some of the
features that come standard on the
AMADAS Model 9960 Self-Propelled
Peanut Combine.
•Turbocharged, air-to-air after cooled, 6-
cylinder, 245 HP engine
•Hydraulic, variable 3-speed ground drive
•7,500 lb (3,400 kg) capacity peanut bin
•5-cylinder separation system
•Two-speed primary picking system
•Variable speed secondary picking
system
•12” diameter collection auger.
Options
The following options are available with the
Model 9960:
•Two-or four-wheel drive
•Off-loading Conveying System (OCS) or
dump basket
•6 or 8 row header.

9960 Self-Propelled Peanut Combine Introduction
MAN091 06/03/05 vii
Specifications (NOTE: Dimensions shown are for a dump basket equipped combine.)
Dimension Length
Inches (CM) Width Inches (CM) Height Inches (CM) Weight Pounds (KG)
Combine 281 (714) 203 (516) 174 (442) 31,500 (14,300)
Shipping 281 (714) 144 (366) 140 (355) 28,300 (12,800)
6/8 row header 227 (576) 52 (132) 51 (130) 2,600 (1,200)
8/10 row header304 (772) 52 (132) 51 (130) 3,400 (1,550)
Basket 203 (516) 96 (244) 77 (195) 3,200 (1,450)
Engine
Type.....Turbocharged, air-to-air after cooled
Cylinders......................................................6
Displacement..........................................6.8L
Horsepower................245 HP @ 2400 RPM
High Speed Idle............................2540 RPM
Mid Idle.........................................1850 RPM
Low Idle........................................1300 RPM
Ground Drive
Type..................................Hydraulic variable
Transmission....................................3-speed
Tires
Main drive (front)...............30.5 x 32 (16ply)
Steering (2-wheel drive)......14.9 x 24 (8 ply)
Steering (4-wheel drive)......18.4 x 26 (6 ply)
Capacities
Fuel tank................................140 gal (530 L)
Cooling system...........................36 qt. (84 L)
Engine crankcase....................30 qt. (28.5 L)
Transmission.............................10 qt. (9.5 L)
Final Drives..................................9 qt. (8.5 L)
Engine gear case.......................17 qt. (16 L)
Hydraulic fluid.............................36 qt. (34 L)
Peanut bin .......................7,500 lb (3,400 kg)
Separation System
Type.................Disc separator supplied by a
14in. (35 cm) cross induction
fan, 5 retractable spring
overhead separator cylinders
with stripper cylinder
Threshing System
Type...........10% variable speed engine, and
2 speed sprockets for first three cylinders,
variable speed for last two cylinders, 5
spring-toothed cylinders with stripper
cylinder, adjustable retention board, and
adjustable breast spring bars
Cylinder diameter....................30 in. (76 cm)
Section width.......................103 in. (259 cm)
Collection System
Auger diameter........................12 in. (30 cm)
Pneumatic Conveyor
Area..........................84 sq. in. (0.054 sq. m)
Fan diameter...........................28 in. (71 cm)

Introduction 9960 Self-Propelled Peanut Combine
viii 06/03/05 MAN091
This page left blank intentionally.

9960 Self-Propelled Peanut Combine Safety
MAN091 06/03/05 1
1.
Safety
Overview .................................................2
Safety Symbols.......................................3
Safety Guidelines....................................5
Safety Practices..................................6
Decal Locations.....................................16

Safety 9960 Self-Propelled Peanut Combine
206/03/05 MAN091
Overview
Safety is the responsibility of everyone.
Although safety features are
incorporated into the machine and
dangerous areas marked, ultimately,
careful operation is the best prevention
against accidents. To reduce the risk of
accidents, please read thoroughly and
follow the safety instructions and
messages included in this manual and
on the machine.
Safety Symbols Used
The three safety symbols used on the
machine and in this manual are shown
below. The following section explains
each of these symbols in detail.
DANGER
WARNING
CAUTION
Please familiarize yourself with each
symbol and its meaning. It is crucial
to your safety and the safety of others
that you follow the safety precautions
indicated by these symbols.
Protective Devices
Protective guards and shields have been
installed to protect the user from
hazards.
Never remove, tamper with, or modify
guards or shields. To do so could
result in serious personal injury or
death.
If it is necessary to remove a shield to
perform maintenance, it is essential
that the shield be replaced prior to
operating the combine.
Careful Lifting
Please follow safe lifting procedures when
installing or removing any component. Use a
second person as a helper when indicated by
the weight of an item.
CAUTION
It is imperative that all users read and
understand th
e safety information in this
chapter before using the combine.
Anyone who uses or works around the
combine must be familiar with th
is
information.
C
AUTION
Use extreme care when working with
hydraulic components. Escaping fluid
under pressure can penetrate the skin,
causing serious injury. Avoid the hazard
by relieving pressure before disconnecting
hydraulic or other lines. Tighten all
connection
s before applying pressure.
Search for leaks with a piece of cardboard.
Protect hands and body from high
pressure fluids.
If an accident occurs, see a doctor
immediately. Any fluid injected into the
skin must be surgically removed within a
few hours or
gangrene may result.
Doctors unfamiliar with this type of injury
may call the Deere & Company Medical
Department in Moline, Illinois, or other
knowledgeable medical source.

9960 Self-Propelled Peanut Combine Safety
MAN091 06/03/05 3
Safety Symbols
Danger
This symbol indicates an imminently hazardous
situation, which if not avoided, will result in
death or serious injury. The use of the word
DANGER is limited to the most extreme
situations. Extreme care should be taken when
you are near these areas. DANGER decals are
located at, or as near as possible to, these
areas.
DANGER
Warning
This symbol identifies areas or practices, which
if not avoided, could result in serious personal
injury. These injuries could range from minor
cuts to dismemberment. Warning decals are
located at, or as near as possible to, these
areas.
WARNING
Caution
This symbol identifies a potentially hazardous
situation, which if not avoided, may result in
minor or moderate injury. It may also be used
to alert against unsafe practices that could
cause damage to the machine. Caution decals
are located at, or as near as possible, to these
areas.
CAUTION

Safety 9960 Self-Propelling Peanut Combine
406/03/05 MAN091
Safety Alert Symbol
This symbol alerts you to possible hazards.
Follow the recommended precautions and
safe operating procedures. If you have any
questions, please contact your dealer or the
manufacturer.
Safety Instructions
Safety features have been designed into the
machine with hazardous areas marked.
Please read and follow the instructions in this
manual prior to operating, maintaining, or
servicing this machine.
Notes
Throughout the manual, information that
needs to be emphasized is set apart with
either a "NOTE!" or "IMPORTANT!" heading.
Please be sure to carefully read this
information, as it usually indicates a situation
that could cause machine damage.
Example:
NOTE!
The cab temperature sensor is
located behind the training seat. Do NOT
cover the sensor as the system may not
operate correctly in the AUTO mode
with
the sensor covered.

9960 Self-Propelled Peanut Combine Safety
MAN091 06/03/05 5
Safety Guidelines
Many accidents can be
prevented by your knowing
about safety. Prevent hazards
by reading the safety warnings
in this manual. Alert others to
potential hazards.
Remember all machinery can be
dangerous if used incorrectly.
Please operate carefully. Safety
is only a word until it is put into
practice.
This section provides you with a list of
practices you need to follow to ensure your
safety and the safety of others. It is
essential that you read this section and
follow the warnings.
Safety Signs
Carefully read all safety messages in this
manual and safety signs on your machine.
Keep safety signs in good condition; replace
missing or damaged safety signs. Be sure
new equipment components and repair
parts include the current safety signs.
Learn Your Machine
Learn how to properly operate your machine
and how to use the controls correctly. Do
NOT let anyone operate the machine
without instruction. Anyone who uses this
machine should be made aware of all safety
information contained in this manual.
Machine Function
It is crucial you maintain your machine in
proper working condition. Do NOT perform
unauthorized modifications to the machine
as these could impair the function and/or
safety of the machine and affect machine
life.

Safety 9960 Self-Propelling Peanut Combine
606/03/05 MAN091
Safety Practices
DRIVE THE COMBINE SAFELY
§Do NOT operate the combine unless all
guards and/or shields are fitted and in their
correct positions.
§Before driving away, check immediate
vicinity of machine for bystanders. Use the
horn as a warning immediately before
driving away.
§Attach the header to combine with extreme
care.
KEEP RIDERS OFF OFTHE MACHINE
§Do NOT allow riders on the machine. Only
the operator should be on the machine at
any time during operation.
§Riders are subject to injury, such as being
thrown off of the machine. They also
obstruct the operator’s view, resulting in
unsafe operating conditions.
§On machines equipped with a passenger
seat, one rider is permitted.
AVOID ELECTRICAL POWER LINES
§Secure the radio aerial and bin lip
extension in transport position before
driving on public roads.
§If equipped with unload-on-the-go, make
sure the conveyor is completely pulled in
and secured before driving on public
roads.
§AVOID electrical lines, particularly low-
hanging electrical cables.
Contact with electrical lines will cause the
operator to suffer severe electrical shock
or possibly death.
Make sure all guards and shields are in place
.

9960 Self-Propelled Peanut Combine Safety
MAN091 06/03/05 7
PARK THE COMBINE SAFELY
To park safely, always:
§Lower the header and any other equipment
to the ground before exiting the combine.
§Set the parking brake, turn off the engine,
and remove the keys.
ALWAYS OPERAT E ENGINE OUTDOORS
NEVER operate the engine in a closed
building. To do so puts you and any one in the
vicinity at risk for carbon monoxide inhalation.
HANDLE FUEL SAFELY –AVOID FIIRES
§Handle fuel with care; it is highly
flammable.
§Do NOT refuel the machine while smoking
or when near open flame or sparks.
§Always stop engine before refueling
machine.
§Fill fuel tank outdoors.
§Prevent fires by keeping machine clean of
accumulated trash,grease, and debris.
§Always clean up spilled fuel.

Safety 9960 Self-Propelling Peanut Combine
806/03/05 MAN091
PREPARE FOR EMERGENCIES
§Be prepared if a fire starts.
§Keep a first aid kit and fire extinguisher
handy.
§Keep emergency numbers for doctors,
ambulance service, hospital, and fire
department near your telephone.
WEAR SEAT BELT
Use the seat belt provided whenever operating
the combine or when riding in the combine as
an observer.
WEAR PROTECTIVE CLOTHING
§Wear close fitting clothing and safety
equipment appropriate to the job.
§Operating equipment safely requires the
full attention of the operator. Do NOT wear
radio or music headphones while operating
machine.

9960 Self-Propelled Peanut Combine Safety
MAN091 06/03/05 9
HANDLE CHEMICAL PRODUCTS SAFELY
§Direct exposure to hazardous chemicals
can cause serious injury. Potentially
hazardous chemicals used with
AMADAS/John Deere equipment include
such items as lubricants, coolants, paints,
and adhesives.
§Before you start any job using a hazardous
chemical, check the MSDS so that you are
aware of the risks and know how to
proceed safely. Carefully follow all
procedures, using only recommended
equipment.
§See your AMADAS/John Deere dealer for
MSDSs on chemical products used with
AMADAS/John Deere equipment.
STAY CLEAR OF HEADER
§Many moving parts (such as the auger)
cannot be shielded due to function. Stay
clear of all moving elements during
operation.
§Always disengage header drive, shut off
the engine and remove the key before
servicing or unclogging the header.

Safety 9960 Self-Propelling Peanut Combine
10 06/03/05 MAN091
USE SAFETY LIGHTS AND DEVICES
Slow moving tractors, self-propelled
equipment and towed implements or
attachments can create hazardswhen driven
on public roads. They are difficult to see,
especially at night.
§Whenever you drive on public roads, use
flashing lights and turn signals according to
local regulations.
§To increase visibility, use the lights and
devices provided with your machine.
§Install extra flashing warning lights on
added equipment.
§Keep safety items in good condition.
§Replace missing or damaged items.
§An “implement safety lighting”kit is
available from your AMADAS/John Deere
dealer.
TRANSPORT COMBINE WITH HEADER
SAFELY
§Before driving the combine on public
roads, remove the header.
§Attach the header securely to the header
trailer, as it may shift during transport.
Remove header for travel
.
