Amantii TD-190038-1 Owner's manual

INSTALLATION AND OPERATION INSTRUCTIONS FOR
INSTALLER: LEAVE OWNER’S MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN OWNER’S MANUAL FOR FUTURE REFERENCE.
SAFETY INFORMATION
WARNING
Fo you safety, always comply with all
wa nings and safety inst uctions
contained in this manual to p event
pe sonal inju y o p ope ty damage.
Do not store or use gasoline or other flammable vapors
and li uids in the vicinity of this appliance.
TRD-26
TRD-30
TRD-33
TRD-38
TRD-44
TRD-48
(TD-190026-1)
(TD-190030-1)
(TD-190033-1)
(TD-190038-1)
(TD-190044-1)
(TD-190048-1)
TRD SERIES
Version:202308

2
TABLE OF CONTENTS
Please read and carefully follow all of the instruction found in this manual. The instructions
included here will assure that you have many years of dependable and enjoyable service
from your Amantii Electric Fireplace.
IMPORTANT INSTRUCTIONS ......................................................................................................................................... 3
FCC CAUTIONS .................................................................................................................................................................. 4
UNPACKING AND TESTING THE APPLIANCE .......................................................................................................... 5
GROUNDING THE APPLIANCE ...................................................................................................................................... 5
LOCATING THE FIREPLACE ........................................................................................................................................... 5
TRD-26 (TD-190026-1) ....................................................................................................................................................... 6
TRD-30 (TD-190030-1) .......................................................................................................................................................
TRD-33 (TD-190033-1) ....................................................................................................................................................... 8
TRD-38 (TD-190038-1) ....................................................................................................................................................... 9
TRD-44 (TD-190044-1) ..................................................................................................................................................... 10
TRD-48 (TD-190048-1) ..................................................................................................................................................... 11
OUTDOOR INSTALLATION ........................................................................................................................................... 12
MANTEL CLEARANCE ................................................................................................................................................... 12
INSTALLATION ................................................................................................................................................................ 13
HARDWIRE INSTALLATION ........................................................................................................................................ 1
MEDIA OPTIONS .............................................................................................................................................................. 18
DECORATIVE MEDIA INSTALLATION ...................................................................................................................... 18
OPERATION ....................................................................................................................................................................... 19
MANUAL OPERATION ................................................................................................................................................... 19
REMOTE CONTROL OPERATION ................................................................................................................................ 20
WIFI OPERATION ............................................................................................................................................................. 23
REPLACEMENT PARTS .................................................................................................................................................. 26
EXPLODED VIEW ............................................................................................................................................................ 2
TROUBLE SHOOTING ..................................................................................................................................................... 29
SERVICE HISTORY .......................................................................................................................................................... 30
WARRANTY ...................................................................................................................................................................... 31
WIRING DIAGRAM .......................................................................................................................................................... 28
QR Code

IMPORTANT INSTRUCTIONS
PLEASE RETA N TH S USER GU DE FOR FUTURE REFERENCE
When using electrical appliances, basic precautions should always be followed to reduce the
risk of fire, electric shock, and injury to persons, including the following:
1) Read all instructions before using this fireplace
2) The fireplace is hot when in use. To avoid burns, do not let bare skin touch hot surfaces.
Keep combustible material such as furniture, cushions, bedding, paper, clothes, curtains
at least 3 feet from the front of the unit
3) Extreme caution is necessary when any heater is used near children and whenever the
unit is left operating and unattended.
4) Do not operate a fireplace with a damaged cord or plug, or if the heater has
malfunctioned, the fireplace has drooped or damaged in any manner
5) Not all fireplaces are suitable for use in bathrooms or laundry facilities. Please consult
with individual product literature to confirm suitability
6) Do not run the cord under carpeting. Do not cover cord with throw rugs, runners or the
like. Arrange the cord away from traffic area and where it will not be tripped over
7) Do not modify this fireplace. Use it as described in the manual. Any other use not
recommended by the manufacture may cause fire, shock or injury to persons
8) Do not use this heater with programmer, timer, separate remote-control system or any
other device that switches the heater on automatically, since a fire risk exists if the heater
is covered or positioned incorrectly
9) Disconnect all power supply before cleaning, maintenance or relocation of the fireplace
10) Keep the heater clean. Do not allow any objects to enter any ventilation or exhaust
opening as this may cause electric shock, fire or damage to the heater
11) Do not immerse the cord, plug or any part of the appliance in water or any other liquid
12) n order to avoid a hazard due to inadvertent resetting of the thermal cut-out, this
appliance must not be supplied through an external switching device
3
CAUTION: Procedures and techniques, which, if not carefully followed, will result in damage to
the equipment.
WARNIN : Procedures and techniques, which, if not carefully followed, will expose the user to
the risk of fire, serious injury, illness or death.
Consult with professional electrician and adhere to all code requirements for
installations in bathrooms
SAVE THESE INSTRUCTIONS

FCC CAUTIONS
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: 1) This device may not cause harmful interference, and 2) this device must
accept any interference received, including interference that may cause undesired
operation.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
4

UNPACKING AND TESTING APPLIANCE
Carefully remove the appliance from the box.
Prior to installing the appliance, test to make sure the appliance operates properly by
plugging the power supply cord into a conveniently located 120 olt grounded outlet.
Test all aspects of its operation (manual switches, remote and heater) to make sure all
components operate correctly.
As with most electronic devices, your electric fireplace has been designed to operate at
temperatures between 5 ℃ (41℉) and 35℃ (95℉). During the cold winter months, allow the
fireplace to reach room temperature before turning it on.
GROUNDING APPLIANCE
This appliance is for use on 120 volts. The cord has a plug as shown in (A). An adapter as
shown in (C) is available for connecting three-blade grounding type plugs to two-slot
receptacles. The green grounding lug extending from the adapter must be connected to a
permanent ground such as a properly grounded outlet box. The adapter should not be used if
a three-slot grounded receptacle is available.
To disconnect appliance, turn controls to off, then remove plug from outlet.
CHOOSING A LOCATION FOR THE FIREPLACE
Plan where to place and frame the fireplace. Before installation consider the following:
1. The location of the fireplace must allow for wall and ceiling clearances.
2. Consider a location where the fireplace screen will not be exposed to direct sunlight from
windows or doors.
3. A 15 ampere, 120 olt, 60 Hz branch circuit with proper ground must be available at the
location. A dedicated branch circuit should be provided to avoid circuit breakers to trip or
fuses to blow.
NOTE: There may be trace odor during the irst ew minutes o initial use. This is
harmless, normal, and will never occur again.
5
Note : Adaptor are NOT for use in Canada

This appliance has been tested in
accordance with the UL Standard 2021
for fixed and location dedicated
electric room appliances in the United
States and Canada. If you need
assistance during installation, please
contact your local dealer.
NOTE: Th s appl ance must be
electr cally w red and grounded n
accordance w th local codes. In the
absence of local codes, use the
current CSA C22.1 Canad an Electr cal
Code n Canada or the ANSI/NFPA 70
Nat onal Electr cal Code n the Un ted
States.
Description ELECTRIC FIREPLACE
Voltage 120V AC 60Hz
MOTOR HEATER 19W
Appliance Width 25 9/32" or 64.2 cm
Appliance Height 16 23/32" or 42.5 cm
Appliance Depth 11 11/32" or 28.78 cm
Gross Weight 57.32 lbs or 26 kgs
Plug Location Left side
Cord Length 70 7/8” or 180 cm
Rough Wall Opening
TRD - 26 (TD-190026-1)
BTU 4095
Size
26 1/4" x 16 27/32"
66.74 cm x 42.78 cm
Watts 1200W Max
NO HEATER 15W
275
16" [694mm]
233
8" [594mm]
171
8" [435mm]
13 3
16" [335mm]
1623
32" [425mm]
1111
32" [287.8mm]
25 9
32" [642mm]
12 1
32" [305.8mm]
6

This appliance has been tested in
accordance with the UL Standard 2021
for fixed and location dedicated
electric room appliances in the United
States and Canada. If you need
assistance during installation, please
contact your local dealer.
NOTE: Th s appl ance must be
electr cally w red and grounded n
accordance w th local codes. In the
absence of local codes, use the
current CSA C22.1 Canad an Electr cal
Code n Canada or the ANSI/NFPA 70
Nat onal Electr cal Code n the Un ted
States.
TRD - 30 (TD-190030-1)
Description ELECTRIC FIREPLACE
Voltage 120V AC 60Hz
Watts 1200W Max
MOTOR HEATER 19W
Appliance Width 29 13/32" or 74.7 cm
Appliance Height 19 3/32" or 48.5 cm
Appliance Depth 11 11/32" or 28.78 cm
Plug Location Left side
Cord Length 70 7/8” or 180 cm
Rough Wall Opening
BTU 4095
Size
30 3/8" x 19 7/32"
77.24 cm x 48.81 cm
NO HEATER 16W
3115
32" [799mm]
191
2" [495mm]
159
16" [395mm]
2717
32" [699mm] 1111
32" [287.8mm]
19 3
32" [485mm]
2913
32" [747mm]
12 1
32" [305.8mm]
7
Gross Weight 68.34 lbs or 31 kgs

This appliance has been tested in
accordance with the UL Standard 2021
for fixed and location dedicated
electric room appliances in the United
States and Canada. If you need
assistance during installation, please
contact your local dealer.
NOTE: Th s appl ance must be
electr cally w red and grounded n
accordance w th local codes. In the
absence of local codes, use the
current CSA C22.1 Canad an Electr cal
Code n Canada or the ANSI/NFPA 70
Nat onal Electr cal Code n the Un ted
States.
TRD - 33 (TD-190033-1)
Description ELECTRIC FIREPLACE
Voltage 120V AC 60Hz
Watts 1200W Max
MOTOR HEATER 19W
Appliance Width 31 25/32" or 80.74 cm
Appliance Height 22 1/4" or 56.5 cm
Appliance Depth 11 3/8" or 28.8 cm
G
Plug Location Left side
Cord Length 70 7/8” or 180 cm
Rough Wall Opening
BTU 4095
Size
32 3/4" x 22 3/8"
83.24 cm x 56.83 cm
NO HEATER 17W
3327
32" [859.4mm]
225
8" [575mm]
1811
16" [475mm]
2929
32" [759.4mm]
3125
32" [807.4mm]
1111
32" [287.8mm]
221
4" [565mm]
12 1
32" [305.8mm]
Gross Weight 77.16 lbs or 35 kgs

This appliance has been tested in
accordance with the UL Standard 2021
for fixed and location dedicated
electric room appliances in the United
States and Canada. If you need
assistance during installation, please
contact your local dealer.
NOTE: Th s appl ance must be
electr cally w red and grounded n
accordance w th local codes. In the
absence of local codes, use the
current CSA C22.1 Canad an Electr cal
Code n Canada or the ANSI/NFPA 70
Nat onal Electr cal Code n the Un ted
States.
TRD - 38 (TD-190038-1)
Description ELECTRIC FIREPLACE
Voltage 120V AC 60Hz
Watts 1200W Max
MOTOR HEATER 19W
Appliance Width 37 5/32" or 94.4 cm
Appliance Height 27 7/32" or 69.1 cm
Appliance Depth 12 5/16" or 31.28 cm
G
Plug Location Left side
Cord Length 70 7/8” or 180 cm
Rough Wall Opening
BTU 4095
Size
38 1/8" x 27 11/32"
96.94 cm x 69.45 cm
NO HEATER 18W
27 7
32" [691mm]
39 7
32" [996mm]
35 9
32" [896mm]
2719
32" [701mm]
2321
32" [601mm]
125
16" [312.8mm]
37 5
32" [944mm]
13 1
32" [330.8mm]
9
Gross Weight 101.41 lbs or 46 kgs

This appliance has been tested in
accordance with the UL Standard 2021
for fixed and location dedicated
electric room appliances in the United
States and Canada. If you need
assistance during installation, please
contact your local dealer.
NOTE: Th s appl ance must be
electr cally w red and grounded n
accordance w th local codes. In the
absence of local codes, use the
current CSA C22.1 Canad an Electr cal
Code n Canada or the ANSI/NFPA 70
Nat onal Electr cal Code n the Un ted
States.
TRD - 44 (TD-190044-1)
Description ELECTRIC FIREPLACE
Voltage 120V AC 60Hz
Watts 1200W Max
MOTOR HEATER 19W
Appliance Width 43 7/32" or 109.8 cm
Appliance Height 31 5/8" or 80.3 cm
Appliance Depth 13 11/16" or 34.78 cm
G
Plug Location Left side
Cord Length 70 7/8” or 180 cm
Rough Wall Opening
BTU 4095
Size
44 1/4" x 31 3/4"
112.34 cm x 80.65 cm
NO HEATER 18W
32" [813mm]
28 1
16" [713mm]
45 9
32" [1150mm]
4111
32" [1050mm] 1311
16" [347.8mm]
315
8" [803mm]
43 7
32" [1098mm]
1413
32" [365.8mm]
10
Gross Weight 132.28 lbs or 60. kgs

This appliance has been tested in
accordance with the UL Standard 2021
for fixed and location dedicated
electric room appliances in the United
States and Canada. If you need
assistance during installation, please
contact your local dealer.
NOTE: Th s appl ance must be
electr cally w red and grounded n
accordance w th local codes. In the
absence of local codes, use the
current CSA C22.1 Canad an Electr cal
Code n Canada or the ANSI/NFPA 70
Nat onal Electr cal Code n the Un ted
States.
TRD - 48 (TD-190048-1)
Description ELECTRIC FIREPLACE
Voltage 120V AC 60Hz
Watts 1200W Max
NO HEATER 21W
MOTOR HEATER 19W
Appliance Width 47 1/4" or 120 cm
Appliance Height 41 5/8" or 105.7 cm
Appliance Depth 13 11/16" or 34.78 cm
G
Plug Location Left side
Cord Length 70 7/8” or 180 cm
Rough Wall Opening
BTU 4095
Size
48 1/4" x 41 3/4"
122.54 cm x 106.05 cm
42" [1067mm]
38 1
16" [967mm]
49 9
32" [1252mm]
4511
32" [1152mm] 1311
16" [347.8mm]
415
8" [1057mm]
471
4" [1200mm]
1413
32" [365.8mm]
11
Gross Weight 169.75 lbs or 77 kgs

OUTDOOR INSTALLATIONS
The TRD series of electric fireplaces are suitable for installation in outdoor areas protected
from direct water impingement. In addition to maintaining the listed mantel and
combustibles clearances, a rain protection overhang factor of 1/2 shall be constructed to the
front and to each side of the installed appliance. See illustration below. All wiring connections
to line power shall be in accordance with local building code requirements. Inquires
about local codes and regulations must be done prior to installation.
12
The overhang (A) must extend at least 1/2 the roof-line height (B). Height is measured from the base of the
fireplace.
For example: if the roof-line (B) is 8' above the base of the fireplace, the overhang (A) must be at least 4'.
MANTEL CLEARANCE
The clearance to the mantel should be 1” minimum when a mantel is applied (Measurement
is taken from the glass front).
1"
Fireplace
Mantel
Wall
Floor
Fireplace

INSTALLATION- BUILT-IN
NOT
E: Due to the many different materials used to build walls, it is highly
you
consult your local builder before you install this appliance on a wall.
Preparation
1. Sel
ect a location that is not prone to moisture and is located at least 0.91m or 3 feet away
fro
m combustible materials such as curtains, drapes, fur
2. Mar
k the desired location on the floor and store the appliance in a safe, dry and dust free
place.
3. Pre
pare a wall with a framed opening to accommodate the size of your unit. Leave at least
1/4
” (6mm) around the edge of the appl
wit
h local and national codes and other applicable regulations.
Pri
or to installing, test the appliance to make sure the appliance is fully operational by
plu
gging the power supply cord into a 120 olt groun
INSTALLATION
1. ake
the trim. (NOTE: Keep hold of the front glass as it may fall
im is removed.)
NOTE: Due to the many different materials used to build walls, it is highly
recommended that
you consult your local builder before you install t
his appliance on a wall.
Select a location that is not prone to moisture and is located at least 0.91m or 3 feet away
from combustible materials such as curtains, drapes, fur
nit
ure, bedding, paper, etc.
Mark the desired location on the floor and store the appliance in a safe, dry and dust free
Prepare a wall with a framed opening to accommodate the size of your unit. Leave at least
1/4” (6mm) around the edge of the appl
ian
ce. Any new wiring must be done in compliance
with local and national codes and other applicable
regulations.
Prior to installing, test the appliance to make sure the appliance is fully operational by
plugging the power supply cord into a 120 olt grou
nded outlet.
ake o lass as it may fall
down automatically when the
glass is not secured. Use extreme caution when removing the glass to prevent damage
reco
mmended that
Select a location that is not prone to moisture and is located at least 0.91m or 3 feet away
niture, bedding, paper, etc.
Mark the desired location on the floor and store the appliance in a safe, dry and dust free
Prepare a wall with a framed opening to accommodate the size of your unit. Leave at least
iance. Any new wiring must be done in compliance
Prior to installing, test the appliance to make sure the appliance is fully operational by
ake off the trim. (NOTE: Keep hold of the fron
Unscrew 4 screws and t offff the trim. (CAUTION: Once the trim has been removed the
Screws located here
Magnetic stones located here
The
rough wall opening size of the fireplace:
The rough wall opening size of the fireplace:
Fireplace removal should be a simple process. The reason for removal of a fireplace
may vary and include changing the PCB, heater and fan.
NOTE:
Take note of the air intake vent located at the bottom and behind the front trim.
)
13
W(“) D(“) H(“)
TRD-26 (TD-190026-1) 26 1/4 12 3/8 16 7/8
TRD-30 (TD-190030-1) 30 3/8 12 3/8 19 1/4
TRD-33 (TD-190033-1) 32 3/4 12 3/8 22 3/8
TRD-38 (TD-190038-1) 38 1/8 13 3/8 27 3/8
TRD-44 (TD-190044-1) 44 1/4 14 3/4 31 3/4
TRD-48 (TD-190048-1) 48 1/4 14 3/4 41 3/4

2. W
hen the trim is removed, take off the front glass panel.
When the trim is removed, take off the front glass
panel.
Inner side panels
3. Unscrew the s
crews located on each
screws located on each
s
ide and take off the inner side steel panels.
side and take off the inner side steel panels.
14

4. P
ut the trim back onto the appliance and fasten with screws.(NOTE: This step is to make
s
ure that the fireplace fits the wall opening well and there is no gap between the trim and the
wall after installation)
5. P
ut the fireplace into the wall opening and fix it to the wall by screwing 2 screws each side.
Put the trim back onto the appliance and fasten with screws.(NOTE: This step is to make
sure that the fireplace fits the wall opening well and there is no gap between the trim and the
Put the fireplace into the wall opening and fix it to the wall by screwing 2 screws each side.
Put the trim back onto the appliance and fasten with screws.(NOTE: This step is to make
sure that the fireplace fits the wall opening well and there is no gap between the trim and the
Put the fireplace into the wall opening and fix it to the wall by screwing 2 screws each side.
Secure the appliance onto the wall
15

6. R
emove the trim following STEP 1. Screw back the inner side steel panels.
and screw back the trim after you finish the media decoration.
Remove the trim following STEP 1. Screw back the inner side steel panels.
e e media decoration.
Remove the trim following STEP 1. Screw back the inner side steel panels.
el and screw back the trim after you finish
7. Put back the front glass panel and screw back the trim after you finish the media installation.
16

and let cool before servicing. Only a ualified
ric appliance.
I
f it is necessary to hard wire this appliance, a ualified electrician must remove the cord connection,
and wi
re the appliance directly to the house hold wiring.
T
his appliance must be electrically connected and grounded in accordance with local codes, if hard
w
ired. In the absence of local codes, use the current CSA C22.1 CANADIAN ELECTRICAL CODE in
Canada or th
e current ANSI/NFPA 70 NATIONAL ELECTRICAL CODE in the United States.
1. R
emove the cover plate from the left side of the appliance by removing the two screws, as
shown below. U
nscrew and remove power
2. Attach t
he wiring to the junction block. Pl
n
eutral wire into "N" and the ground wire into
3. Replace the steel plate a
nd screws
Turn off the appliance completel
should service and repair this ele
If it is necessary to hard wire this appliance, a
u
alified electrician must remove the cord connection,
ire the appliance directly to the household wiring
.
This appliance must be electrically connected and g
r
ounded in accordance with local codes, if hard
wired. In the absence of local codes, use the curre
n
t CSA C22.1 CANADIAN ELECTRICAL CODE in
he current ANSI/NFPA 70 NATIONAL ELECTRICAL CODE in
the United States.
Remove the cover plate from the left side of the ap
p
liance by removing the two screws, as
Unscrew and remove power
cord.
the wiring to the junction block. Pl
ease make s
ure the live wire goes into the "L", the
neutral wire into "N" and the ground wire into
"G".
and screws
.
Turn off the appliance completely and let cool before servicing. Only a ualifi
HARDWIRE INSTALLATION
Turn off the appliance completely and let cool before servicing. Only a qualified
should service and repair this electric fireplace.
technician
If it is necessary to hard wire this appliance, a ualified electrician must remove the cord connection
This appliance must be electrically connected and grounded in accordance with local codes, if hard
wired. In the absence of local codes, use the current CSA C22.1 CANADIAN ELECTRICAL CODE in
he current ANSI/NFPA 70 NATIONAL ELECTRICAL CODE in the United States.
Remove the cover plate from the left side of the appliance by removing the two screws, as
sure the live wire goes into the "L", the
17

MEDIA OPTIONS
CLEAR GLASS
BIRCH LOG SET
MEDIA INSTALLATION
Unscrew 4 screws and take off the trim. (NOTE: Keep hold of the front glass as it may fall
down automatically when the trim is removed.)
INSTALLING THE DECORATIVE MEDIA
Pour the fire glass media into the tray. Feel free to use any combination of the fire glass
media that you find most appealing. Put back the trim and front glass after you finish
installing the fire glass.
Screws locations
Magnetic stones locations
VERMICULITE
The media that come with this appliance are Birch Log et, “Clear glass”, Amber glass, one
(1) bag of Black Vermiculite and one (1) bag of White Vermiculite.
AMBER GLASS
1

OPERATION
Plug the fireplace into a 15 Amp wall socket.
Plug the fireplace into a 15 Amp wall socket.
The Fireplace operates by using either the touch panel located on the upper left hand corner
or by remote control.
19
MANUAL OPERATION
1.
2.
Press to turn on and off the fireplace.
Press to adjust the flame brightness. There are 6 brightness levels（L6-L1） and
an off(OF) position. Each time the flame button is pressed, the brightness of the flame
decrease.
press the flame button for 10 seconds, the timing indicator light on and will rapidly
blinks, at this time, You can use the TuyaSmart APP to connect to the fireplace.
4. Press to set the turn-off time, 30min-1h-2h-3h-4h-5h-6h-7h-8h-t0. The indicator light
the current timing. If the timing in off position, the second press will show 30. Multiple times
to set operating duration to OF, 30 min, 1h, 2h, 3h, 4h, 5h, 6h, 7h, 8h.
5. Press or the first time to display the current setting temperature，press the button
again to clear the current temperature. If the heater in off position, the second press will
show 22℃(72℉).Multiple times to set ambient temperatures at 22℃( 72℉) , 23℃
(74℉) ,24℃( 76℉) , 25℃( 78℉) , 26℃( 80℉) , 27℃( 82℉) , 28℃( 84℉) ,15℃( 52℉) ,
16℃( 54℉) , 17℃( 56℉) ,18℃( 58℉) , 19℃( 60℉) , 20℃( 62℉) , 21℃( 64℉) .
Temperature unit convert functionZ When the heater is on, press and hold the“ ”
Button for 5 seconds, current temperature unit display will convert to another temperature
unit.
3. Press to adjust the moodlight brightness. There are 11 brightness levels (d11-d2),
dynamic condition (d1), and the OFF (OF) setting you can cycle through.

20
REMOTE CONTROL OPERATION
For remote to function make sure the fireplace is plugged in and the remote has batteries.
Important: When operating the remote make sure you point the remote to the center of the
fireplace. Each time you press the button, the buzzer inside the unit will beep once. It takes
some time for the receiver to respond to the transmitter. Do not PRESS the buttons more
than once within two seconds for correct operation.
Set the current time of the remote control
Press the to activate the remote control and press to set the time and date.
When one of the “Sun” “Mon” “ Tue” “Wed” “Thu” “Fri” “Sat” is flashing, press or to
set the day of the week, press to confirm day of the week and then enter hour setting.
Press or to set the hour, press to confirm the hour and then enter minute
setting. Press or to set the minute and press to confirm the minute and
finish time setting.
Press this Power button to turn on and off the fireplace.
Press this Timer button to set the time to turn off the fireplace.
The available settings range from 3 minutes to 8 hours. As
shown in the following: :3 - 1: - 1:3 - 2: - 2:3 - 3: -
3:3 - 4: - 4:3 - 5: - 5:3 - 6: - 6:3 - 7: - 7:3 - 8: .
Once you have set the timer, the icon will be displayed
on the LCD screen of the remote control. Press this button
again to cancel the timer setting and the icon disappears.
Each time the Heater Button is pressed, the power of the
heater will change. As shown the following: H1- H2-
AUTO（22℃）- OFF（no display）
H1 means the firepalce on Low Heat/ 00W.
H2 means the fireplace on High Heat/1200W.
6
