Amantii BI-SLIM Series Operating instructions

INSTALLATION /OWNER’S MANUAL
BI-SLIM SERIES
BI-40-SLIM (BI-S190040-01) BI-50-SLIM (BI-S190050-01)
BI-60-SLIM (BI-S190060-01) BI-72-SLIM (BI-S190072-01)
BI-88-SLIM (BI-S190088-01)
INSTALLER: LEAVE OWNER’S MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN OWNER’S MANUAL FOR FUTURE REFERENCE.
SAFETY INFORMATION
WARNING
For yo r safety, always comply with all
warnings and safety instr ctions
contained in this man al to prevent
personal inj ry or property damage.
Do not store or use gasoline or other flammable vapors
and li uids in the vicinity of this appliance.
Version:202108

2
TABLE OF CONTENTS
Please read and carefully follow all of the instruction found in this manual. The instructions
included here will assure that you have many years of dependable and enjoyable service
from your Amantii product.
IMPORTANT INSTRUCTIONS ......................................................................................................................................... 3
FCC CAUTIONS .................................................................................................................................................................. 4
UNPACKING AND TESTING THE APPLIANCE .......................................................................................................... 5
GROUNDING THE APPLIANCE ...................................................................................................................................... 5
LOCATING THE FIREPLACE ........................................................................................................................................... 5
BI-40-SLIM (BI-S190040-01) .............................................................................................................................................
BI-50-SLIM (BI-S190050-01) ............................................................................................................................................. 7
BI- 0-SLIM (BI-S1900 0-01) ............................................................................................................................................. 8
BI-72-SLIM (BI-S190072-01) ............................................................................................................................................. 9
BI-88-SLIM (BI-S190088-01) ........................................................................................................................................... 10
SAFETY DRILL SCREW AREA ..................................................................................................................................... 11
OUTDOOR INSTALLATION ........................................................................................................................................... 11
MANTEL CLEARANCE ................................................................................................................................................... 12
FOR BATHROOM USE .................................................................................................................................................... 12
HARDWARE INSTALLATION ....................................................................................................................................... 13
INSTALLATION ................................................................................................................................................................ 14
PANORAMA COVER INSTALLATION ........................................................................................................................ 19
MEDIA OPTIONS .............................................................................................................................................................. 20
MEDIA INSTALLATION ................................................................................................................................................. 20
OPERATION ....................................................................................................................................................................... 21
MANUAL OPERATION ................................................................................................................................................... 21
REMOTE CONTROL OPERATION ................................................................................................................................ 22
WIFI OPERATION ............................................................................................................................................................. 24
REPLACEMENT PARTS .................................................................................................................................................. 27
EXPLODED VIEW ............................................................................................................................................................ 28
TROUBLE SHOOTING ..................................................................................................................................................... 29
SERVICE HISTORY .......................................................................................................................................................... 30
WARRANTY ...................................................................................................................................................................... 31

IMPORTANT INSTRUCTIONS
PLEASE RETA N TH S USER GU DE FOR FUTURE REFERENCE
When using electrical appliances, basic precautions should always be followed to reduce the
risk of fire, electric shock, and injury to persons, including the following:
1) Read all instructions before using this fireplace
2) The fireplace is hot when in use. To avoid burns, do not let bare skin touch hot surfaces.
Keep combustible material such as furniture, cushions, bedding, paper, clothes, curtains
at least 3 feet from the front of the unit
3) Extreme caution is necessary when any heater is used near children and whenever the
unit is left operating and unattended.
4) Do not operate a fireplace with a damaged cord or plug, or if the heater has
malfunctioned, the fireplace has drooped or damaged in any manner
5) Not all fireplaces are suitable for use in bathrooms or laundry facilities. Please consult
with individual product literature to confirm suitability
6) Do not run the cord under carpeting. Do not cover cord with throw rugs, runners or the
like. Arrange the cord away from traffic area and where it will not be tripped over
7) Do not modify this fireplace. Use it as described in the manual. Any other use not
recommended by the manufacture may cause fire, shock or injury to persons
8) Do not use this heater with programmer, timer, separate remote-control system or any
other device that switches the heater on automatically, since a fire risk exists if the heater
is covered or positioned incorrectly
9) Disconnect all power supply before cleaning, maintenance or relocation of the fireplace
10) Keep the heater clean. Do not allow any objects to enter any ventilation or exhaust
opening as this may cause electric shock, fire or damage to the heater
11) Do not immerse the cord, plug or any part of the appliance in water or any other liquid
12) n order to avoid a hazard due to inadvertent resetting of the thermal cut-out, this
appliance must not be supplied through an external switching device
3
CAUTION: Procedures and techniques, which, if not carefully followed, will result in damage to
the equipment.
WARNIN : Procedures and techniques, which, if not carefully followed, will expose the user to
the risk of fire, serious injury, illness or death.
Consult with professional electrician and adhere to all code requirements for
installations in bathrooms
SAVE THESE INSTRUCTIONS

FCC CAUTIONS
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: 1) This device may not cause harmful interference, and 2) this device must
accept any interference received, including interference that may cause undesired
operation.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
4

UNPACKING AND TESTING APPLIANCE
Carefully remove the appliance from the box.
Prior to installing the appliance, test to make sure the appliance operates properly by
plugging the power supply cord into a conveniently located 120 Volt grounded outlet.
Test all aspects of its operation (manual switches, remote and heater) to make sure all
components operate correctly.
NOTE: There may be trace f d r during the first few minutes f initial use. This is
harmless, n rmal and will never ccur again.
GROUNDING APPLIANCE
This appliance is for use on 120 Volts. The cord has a plug as shown in (A). An adapter as
shown in (C) is available for connecting three-blade grounding type plugs to two-slot
receptacles. The green grounding lug extending from the adapter must be connected to a
permanent ground such as a properly grounded outlet box. The adapter should not be used if
a three-slot grounded receptacle is available.
To disconnect appliance, turn controls to off, then remove plug from outlet.
LOCATING THE FIREPLACE
Plan where to locate and frame the fireplace. This will save time and money later when you
install the fireplace. Before installation consider the following:
1. Where the fireplace is located must allow for wall and ceiling clearances
2. Consider a location where the fireplace screen will not be exposed to direct sunlight from
windows or doors.
3. A 15 ampere, 120 Volt, 60 Hz branch circuit with proper ground must be available at the
location. Preferably a dedicated branch circuit should be provided to avoid circuit
breakers to trip of fuses to blow.
As with most electronic devices, your new electric fireplace has been designed to operate at
temperatures between 5 ℃ (41℉) and 35 ℃ (95℉). During the cold winter months, allow the
fireplace to reach room temperature before turning it on.
5
Note : Adaptor are NOT for use in Canada

Description Built-inAppliance
Voltage 120V AC60Hz
Watts 1500WMax
NOHEATER 15W
MOTOR HEATER 19W
ApplianceWidth 38 5/8”or98.1 cm
ApplianceHeight 23 5/8”or60 cm
ApplianceDepth 6 3/4”or17.2 cm
Gross Weight 88 lbsor40kg
PlugLocation Left side
Cord Length 707/8”or180 cm
RoughWall OpeningSize 40”25“or
101.6 cm 63.5 cm
BTU 5118
This appliance has been tested in
accordance with the UL Standard 0 1 for
fixed and location dedicated electric room
appliances in the United States and Canada.
If you need assistance during installation,
please contact your local dealer.
NOTE: This appliance must be
electrically wired and grounded in
accordance with local codes. In the
absence of local codes, use the current
CSA C22.1 Canadian Electrical Code in
Canada or the ANSI/NFPA 70 National
Electrical Code in the United States.
BI-40-SLIM (BI-S190040-01)
6

ModelNumber BI-50-SLIM
Voltage 120V AC60Hz
Watts 1500WMax
NOHEATER 17.4W
MOTOR HEATER 19W
ApplianceWidth 48 5/8”or123.5cm
ApplianceHeight 23 5/8”or60 cm
ApplianceDepth 6 3/4”or17.2 cm
Gross Weight 105.6 lbsor48kg
PlugLocation Left side
Cord Length 707/8”or180 cm
RoughWall OpeningSize 50”25“or
127 cm 63.5 cm
BTU 5118
BI-50-SLIM (BI-S190050-01)
This appliance has been tested in
accordance with the UL Standard 0 1 for
fixed and location dedicated electric room
appliances in the United States and Canada.
If you need assistance during installation,
please contact your local dealer.
NOTE: This appliance must be
electrically wired and grounded in
accordance with local codes. In the
absence of local codes, use the current
CSA C22.1 Canadian Electrical Code in
Canada or the ANSI/NFPA 70 National
Electrical Code in the United States.
7

Description Built-inAppliance
Voltage 120V AC60Hz
Watts 1500WMax
NOHEATER 19W
MOTOR HEATER 19W
ApplianceWidth 58 5/8”or148.5cm
ApplianceHeight 23 5/8”or60 cm
ApplianceDepth 6 3/4”or17.2 cm
Gross Weight 123.2 lbsor56kg
PlugLocation Left side
Cord Length 707/8”or180 cm
RoughWall OpeningSize 60”25“or
152.4 cm 63.5 cm
BTU 5118
This appliancehasbeentestedinaccordance
with theULStandard2021forfixedand
locationdedicatedelectricroomappliances
intheUnitedStatesandCanada.Ifyouneed
assistanceduringinstallation,pleasecontact
yourlocaldealer.
NOTE:Thisappliancemustbeelectrically
wiredandgroundedinaccordancewith
localcodes.Intheabsenceoflocalcodes,
usethecurrent CSAC22.1Canadian
ElectricalCodeinCanadaortheANSI/NFPA
70 NationalElectricalCodeintheUnited
States.
BI-60-SLIM (BI-S190060-01)

Description Built-inAppliance
Voltage 120V AC60Hz
Watts 1500WMax
NOHEATER 20W
MOTOR HEATER 19W
ApplianceWidth 72 1/8”or183.2cm
ApplianceHeight 23 5/8”or60 cm
ApplianceDepth 6 3/4”or17.2 cm
Gross Weight 149.6lbsor68kg
PlugLocation Left side
Cord Length 707/8”or180 cm
RoughWall OpeningSize 73 1/2”25“or
186.7 cm 63.5 cm
BTU 5118
This appliancehasbeentestedinaccordance
with theULStandard2021forfixedand
locationdedicatedelectricroomappliances
intheUnitedStatesandCanada.Ifyouneed
assistanceduringinstallation,pleasecontact
yourlocaldealer.
NOTE:Thisappliancemustbeelectrically
wiredandgroundedinaccordancewith
localcodes.Intheabsenceoflocalcodes,
usethecurrent CSAC22.1Canadian
ElectricalCodeinCanadaortheANSI/NFPA
70 NationalElectricalCodeintheUnited
States.
BI-7 -SLIM (BI-S19007 -01)
9

Description Built-inAppliance
Voltage 120V AC60Hz
Watts 1500WMax
NOHEATER 21.2W
MOTOR HEATER 19W
ApplianceWidth 88 5/8”or225.2cm
ApplianceHeight 23 5/8”or60 cm
ApplianceDepth 6 3/4”or17.2 cm
Gross Weight 187lbsor85kg
PlugLocation Left side
Cord Length 707/8”or180 cm
RoughWall OpeningSize 89 1/4”25“or
226.7 cm 63.5 cm
BTU 5118
This appliancehasbeentestedinaccordance
with theULStandard2021forfixedand
locationdedicatedelectricroomappliances
intheUnitedStatesandCanada.Ifyouneed
assistanceduringinstallation,pleasecontact
yourlocaldealer.
NOTE:Thisappliancemustbeelectrically
wiredandgroundedinaccordancewith
localcodes.Intheabsenceoflocalcodes,
usethecurrent CSAC22.1Canadian
ElectricalCodeinCanadaortheANSI/NFPA
70 NationalElectricalCodeintheUnited
States.
BI-88-SLIM (BI-S190088-01)
10

Safetydrill screwarea
(Darkarea)
OUTDOOR INSTALLATION
This electric fireplace is suitable for installation in outdoor areas protected from direct water
impingement. In addition to maintaining the listed mantel and combustibles clearances, a
rain protection overhang factor of 1/2 shall be constructed to the front and to each side of the
installed appliance. ee illustration below. All wiring connections to line power shall be in
accordance with local building code requirements. Inquires about local codes and
regulations must be done prior to installation.
SAFETY DRILL SCREW AREA
There is a safety drill screw area as show below.
Please make sure that the fix screws are in this area.


 !"#$% &&'(
)&&$*$+, -(
, .&$$% &'&/0**$+, -1
* 0(
When installed in outdoor applications, it is recommended that the BI-SLIM models use the protective
PAN-COVER.
11

Consult with professional electrician and adhere to all code requirements for
installations in bathrooms
FOR BATHROOM USE
If this unit is installed in a bathroom it must be protected by a GIF receptacle or circuit. If
receptacle is used it must be readily accessible.
To prevent electric shock, please be aware that this unit is an electrical appliance that is
NOT watertight and must be installed as to prevent water from entering unit. This must be
installed away from shows, tubs, etc. Never locate fireplace where it may fall into a bathtub
or other water container.
All wiring connections to line power shall be in accordance with local building code
requirements. Inquires about local codes and regulations must be done prior to installation.
MANTEL CLEARANCE
If this unit is installed in a bathroom it must be
The clearance to the mantel should be 4” minimum when a mantel is applied (Measurement
is taken from the trim).
12
4"
Fireplace Mantel
Wall (Combustible facing allowed)
Floor
Fireplace

1.
Remove the cover plate from the left side of the appliance by removing the two screws
as shown below. Unscrew and remove power cord.
2. Attach the wiring to the
junction block. Please make sure the live wire goes into the “L”, the
neutral wire into “N” and the ground wire into “G”.
3.
Return the cover plate to the left side and screw the two screws back in to fasten the
Remove the cover plate from the left side of the appliance by removing the two screws
as shown below. Unscrew and remove power cord.
junction block. Please make sure the live wire goes into the “L”, the
neutral wire into “N” and the ground wire into “G”.
Return the cover plate to the left side and screw the two screws back in to fasten the
Remove the cover plate from the left side of the appliance by removing the two screws
junction block. Please make sure the live wire goes
into the “L”, the
Return the cover plate to the left side and screw the two screws back in to fasten the
plate.
HARD IRE INSTALLATION
Turn off the appliance completely and let cool before servicing. Only a qualified
person should service and repair this electric appliance.
Turn off the appliance completely and let cool before servicing. Only a qualified
person should service and repair this electric appl
iance.
Turn off the appliance completely and let cool before servicing. Only a qualified
service
If it is necessary to hardwire this appliance, a qualified electrician must remove the cord
connection, and wire the appliance directly to the house hold wiring.
This appliance must be electrically connected and grounded in accordance with local codes,
if hardwired. In the absence of local codes, use the current C A C22.1 CANADIAN
ELECTRICAL CODE in Canada or the current AN /NFPA 70 NATIONAL ELECTRICAL
CODE in the United tates.
13

optional trim
W(“) D(“) H(“)
BI-40-SLIM
(BI-S190040-01) 40 7 25
BI-50-SLIM
(BI-S190050-01) 50 7 25
BI-60-SLIM
(BI-S190060-01) 60 7 25
BI-72-SLIM
(BI-S190072-01) 73 1/2 7 25
BI-88-SLIM
(BI-S190088-01) 89 1/4 7 25
W
D
H
W
D
H
NOTE: Due to the many different materials used to build walls, it is highly recommended that
you consult your local builder before you install this appliance on a wall.
The models are designed to be built-in. These units allow for the finishing material (drywall,
stone, tile, etc) to be built right down to the glass edge. However, that application is not
always desirable or available so the surround could be used as an alternate finish option.
Important note: The optional surround is secured with two screws. Unscrew and lift to
remove. It is recommended that two people remove the surround.
The rough wall opening size of the fireplace :
1. Take out the unit from the box. Please do the pre-test before you install the fireplace.
Unscrew to take off the optional trim from the unit as shows below.
14
INSTALLATION

framing plate
framing plate
2. Remove the framing plates from the unit.
3. Re-fix the framing plates to the unit as the picture shows.
15

4. Bend up the framing plates.
5. Put the unit into the opening.
16

framing plate
Fireplace
6. Drive the mounting screws into the framing plates on the unit and the wall studs.
7. After checking that the fireplace operates properly, cover the glass panel with protective
plastic bag and install plywood or drywall.
NOTE: In order to use the supplied trim kit, the thickness of the desired wall finish can not
exceed 1 inch.
17

Fireplace
trim
8. Decorate the plywood or drywall with glazed tile, wallpaper, etc.
9. Put back the trim that you’ve removed from the unit at TEP 1.
1

Fig 1
Fig 2
Fig 3
Fig 4
Fig 5
Make sure install the pan-cover when the fireplace used in outdoors.
Remove the cover from the packaging.
The handles will need to be attached to the
cover with the provided hardware as shown
in fig.1
First, place a plate washer and then a
spring washer on the screw as shown in
fig.2
Affix the handles to the front of the cover
using the prepared screws. Fig.3
Insert the assembled cover onto the unit as
shown in Fig. 4 and 5
19
PANORAMA COVER INSTALLATION

The media that come with BI- LIM are large
glass nuggets, clear glass, clear and blue &
white diamond shaped media.
Glass nuggets, clear glass
clear and diamond shaped media
1. Take off the front glass. There is a
bracket holding the front glass which
shows as below. Unscrew the screw and
take off the bracket. Turn around and
insert into the gap. Hook the front glass
and pull it out.
2. Installing the fire glass media. Pour the
decorative media into the tray. Feel free
to use any combination of fire glass
media that you find most appealing.
3. Put back the front glass and screw back
the bracket.
20
MEDIA OPTIONS
MEDIA INSTALLATION
