AmazonBasics B0716T5FW2 User manual

created by: Impala Services Ltd.Page size: 139.7 x 107.95 mm
B0716T5FW2
3.0L Vacuum Cleaner (12M) with Bag
Aspirateur (12M) De 3,0 l Avec Sac
3,0L Staubsauger (12M) mit Beutel
Aspirapolvere (12M) Con Sacco Da 3,0 L
Aspirador (12M) Con Bolsa, 3,0L
B0716T5FW2-AmazonBasics-Vacuum cleaner (12M)-V03 (Multi).indb 1 9/4/17 10:55 AM

English ..................................... 3
Français ................................. 19
Deutsch.................................. 35
Italiano................................... 51
Español.................................. 67
B0716T5FW2-AmazonBasics-Vacuum cleaner (12M)-V03 (Multi).indb 2 9/4/17 10:55 AM

3
Welcome Guide •English
3.0L Vacuum Cleaner (12M) with Bag
Contents:
Before getting started, ensure the package contains the following components:
B0716T5FW2-AmazonBasics-Vacuum cleaner (12M)-V03 (Multi).indb 3 9/4/17 10:55 AM

4
Hose intake Flexible hose
Front cover Power suction control 2
Dust bag Extension metal tube
Cable winder switch Tube release switch
Power suction control 1 Hard floor brush
HEPA filter Hard floor brush function switch
On/off button Dusting brush
Power cord with power plug Furniture nozzle
Motor filter Crevice nozzle
Dust bag capacity indicator Accessory stand
Handle
Accessories
Accessory Indicated for...
Hard floor brush
Rugs, carpets
Tiles, wooden floors, linoleum
Dusting brush
Rugs, sofas, pillows, and upholstery in
general
Furniture nozzle
Removes dust and tiny pieces of fabric
from crevices, corners, cracks and other
places hard to reach, ideal e.g. for the
grating in a car
Crevice nozzle
Crevices, corners, cracks and other
places hard to reach
B0716T5FW2-AmazonBasics-Vacuum cleaner (12M)-V03 (Multi).indb 4 9/4/17 10:55 AM

5
IMPORTANT SAFEGUARDS
• Read this instruction manual carefully before using the
product. It contains important information for your safety
as well as operating and maintenance advice. Observe
all safety instructions to avoid damage through improper
use! Keep this instruction manual for future use. Should
this product be passed on to a third party, then this
instruction manual must be included.
• No liability will be accepted for damage resulting from
improper use or non-compliance with these instructions.
• Before connecting the appliance to the power supply,
check that the power supply voltage and current rating
corresponds with the power supply details shown on the
appliance rating label.
• This product contains no user serviceable parts and
requires little maintenance. Leave any servicing or repairs
to qualified personnel only.
• Never use a damaged appliance! Disconnect the
appliance from the electrical outlet and contact your
retailer if it is damaged.
• Danger of electric shock! Do not attempt to repair the
appliance yourself. In case of malfunction, repairs are to
be conducted by qualified personnel only.
B0716T5FW2-AmazonBasics-Vacuum cleaner (12M)-V03 (Multi).indb 5 9/4/17 10:55 AM

6
• To avoid damaging the cord, do not squeeze, bend or
chafe it on sharp edges. Keep it away from hot surfaces
and open flames as well.
• Lay out the cord in such a way that no unintentional
pulling or tripping over it is possible. Keep the appliance
and its cord out of reach of children.
• If an extension cord is used, its capacity needs to be
suitable for the power consumed by the appliance.
• Warning! During cleaning or operation do not immerse
the electrical parts of the appliance in water or other
liquids. Never hold the appliance under running water.
• Do not operate the appliance with wet hands or while
standing on a wet floor. Do not touch the power plug
with wet hands.
• Do not open the appliance casing under any
circumstances. Do not insert any foreign objects into the
inside of the casing.
• Never use accessories which are not recommended by
the manufacturer. They could pose a safety risk to the
user and might damage the appliance. Only use original
parts and accessories.
B0716T5FW2-AmazonBasics-Vacuum cleaner (12M)-V03 (Multi).indb 6 9/4/17 10:55 AM

7
• This appliance can be used by children aged from
8years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
• Regularly check the power plug and power cord for
damage. If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
• Do not pull the power plug out of the electrical outlet by
the power cord and do not wrap the power cord around
the appliance.
• Disconnect the power plug from the electrical outlet
when not in use, before any maintenance and before
cleaning.
• This product is classified as protection class II. This
means the product is equipped with reinforced or double
insulation between the mains supply circuit and the
output voltage or the casing. Therefore it does not require
a safety connection to an electrical earth (ground).
B0716T5FW2-AmazonBasics-Vacuum cleaner (12M)-V03 (Multi).indb 7 9/4/17 10:55 AM

8
• Never operate the appliance with any air openings
blocked. Keep ventilation openings free from the
accumulation of lint, dust, and loose cloth.
Vacuum Cleaner Warnings
• Before vacuuming, remove any large, sharp or sharp
edged objects to avoid damage to the filters and / or
appliance.
• Do not vacuum any hot or incandescent objects, liquids,
chemicals or flammable materials.
• Never use the vacuum cleaner without filter inserts. The
appliance may be damaged.
SAVE THESE INSTRUCTIONS
FOR FUTURE REFERENCE.
Legend
Danger Indicates a hazardous situation which, if not avoided, will result
in death or serious injury. This signal word is to be limited to the
most extreme situations.
Warning Indicates a hazardous situation which, if not avoided, could result
in death or serious injury.
Caution Indicates a hazardous situation which, if not avoided, could result
in minor or moderate injury.
Notice Indicates a practical tip, advice or practice not related to personal
injury.
B0716T5FW2-AmazonBasics-Vacuum cleaner (12M)-V03 (Multi).indb 8 9/4/17 10:55 AM

9
Intended Use
• This appliance is only intended for vacuuming of dust, lint and general dirt on soft and hard
surfaces. Do not use it for vacuuming ashes, sharp objects e.g. glass or to suck up liquids or
other flammable substances.
• The appliance is intended for private indoor use only.
• Use the appliance only as described in this manual.
• No liability will be accepted for damage resulting from improper use or non-compliance with
this manual.
Before First Use
• Carefully remove all packaging materials and retain for future use.
• Check for transport damages.
• Clean the appliance ( Cleaning and Maintenance).
• Check whether the dust bag is correctly in place ( Cleaning and Maintenance).
• WARNING - DANGER OF SUFFOCATION! Children should not play with the packaging
materials, as they pose a risk of swallowing and suffocation!
Assembly
Step 1:
• Insert the flexible hose into the hose intake at the front of the appliance.
• Press the hose connector and turn it clockwise till it is locked securely.
B0716T5FW2-AmazonBasics-Vacuum cleaner (12M)-V03 (Multi).indb 9 9/4/17 10:55 AM

10
Assembly
Step 2:
• Insert the handle of flexible hose into the extension metal tube .
Step 3:
• Push the tube release switch while pulling out the bottom part of the extension metal
tube to adjust the length.
B0716T5FW2-AmazonBasics-Vacuum cleaner (12M)-V03 (Multi).indb 10 9/4/17 10:55 AM

11
Assembly
Step 4:
• Insert the extension metal tube into the connector of the hard floor brush (or other
attachment as needed).
Operation
Step 1:
• Pull out the power cord .
• Connect the power plug to an electrical outlet.
B0716T5FW2-AmazonBasics-Vacuum cleaner (12M)-V03 (Multi).indb 11 9/4/17 10:55 AM

12
Operation
Step 2:
• Set the power suction control to MIN.
• Press the on/off button to power on the appliance.
Step 3:
• Use the power suction control on the main unit or flexible hose handle / to increase/
decrease suction power.
B0716T5FW2-AmazonBasics-Vacuum cleaner (12M)-V03 (Multi).indb 12 9/4/17 10:55 AM

13
Operation
Step 4:
• After cleaning has been completed, press the on/off button to power off the appliance.
• Then press the cable winder switch to roll back the power cable.
Notice Hold the power cable with one hand and slowly accompany it while
it is being rolled back into storage.
Cleaning and Maintenance
Warning Always disconnect the power plug from the electrical outlet
before cleaning or storing.
Cleaning
• Remove any accessory attached to the extension metal tube or flexible hose .
• Clean the appliance and accessories with a slightly moistened cloth. Do not allow any liquid
enter the appliance’s interior.
• Never use corrosive detergents, wire brushes, abrasive scourers, metal or sharp utensils to
clean the appliance or accessories.
• Carefully dry the appliance and accessories after cleaning.
B0716T5FW2-AmazonBasics-Vacuum cleaner (12M)-V03 (Multi).indb 13 9/4/17 10:55 AM

14
Replacing the Dust Bag
Notice When the dust bag full indicator turns red, the dust bag must be
replaced.
• Open the front cover.
• Remove the dust bag from its holder and remove it from the dust bag compartment.
Paper dust bag
(Disposable)
– Dispose of the old bag.
– Replace with a new one (provided) of the same type.
Fabric dust bag (Not
disposable)
– Empty to a plastic bag or a trash bin.
– Put it back in place.
– Note: Fabric dust bags (provided) can also be purchased
separately.
B0716T5FW2-AmazonBasics-Vacuum cleaner (12M)-V03 (Multi).indb 14 9/4/17 10:55 AM

15
Cleaning the Motor Filter
• Open the front cover and remove the dust bag.
• Pull the motor filter with its cover upwards to remove them.
• Pull the filter out of the frame.
• Rinse the filter with tap water to remove dust build-up and other residue.
• Let the filter dry. Do not expose it to direct sunlight.
• Place the filter back into the cover and slide it back in.
Cleaning the HEPA Filter
• Lift the exhaust grid to remove it.
• Take out the HEPA filter .
• Rinse the filter under cold water.
• Dry it afterwards.
• Refit it to its original position.
• Reinstall the exhaust grid until it clicks in place.
Notice Never use the appliance without filters installed. This can cause
power loss or damage to the appliance.
B0716T5FW2-AmazonBasics-Vacuum cleaner (12M)-V03 (Multi).indb 15 9/4/17 10:55 AM

16
Troubleshooting
Problem Solutions
The appliance does not start. – Connect the power plug properly.
– Check if the electrical outlet is powered.
– Check if the on/off switch is on.
Weak suction power. – Check if the flexible hose, extension tube or any of
the accessories are obstructed.
– Remove and clean the filters.
Motor is abnormally noisy. – Stop using the appliance immediately.
– Check if the hose, tube or any of the accessories
are obstructed.
– Remove the obstruction.
– If the noise continues, power off the appliance
and disconnect the power plug.
– Contact your service agents.
B0716T5FW2-AmazonBasics-Vacuum cleaner (12M)-V03 (Multi).indb 16 9/4/17 10:55 AM

17
Specications
Operating voltage: 220-240V~, 50/60Hz
Power consumption: 700W
Capacity: 3L
Sound power level: ≤76dB(A)
Dimensions: 310 x 420 x 430mm
Weight: 5kg
Protection class: Class II
Annual energy consumption: A
Dust pick up on carpet: C
Dust pick up on hard floor: A
Dust re-emission: A
Operational motor lifetime: 550
Disposal
Devices marked with this symbol must be disposed of separately from your household
waste, as they contain valuable materials which can be recycled. Proper disposal
protects the environment and human health. Your local authority or retailer can provide
information on the matter.
Warranty Information
To obtain a copy of the warranty for this product:
Visit amazon.com/AmazonBasics/Warranty
— or —
Contact Customer Service at 1-866-216-1072
B0716T5FW2-AmazonBasics-Vacuum cleaner (12M)-V03 (Multi).indb 17 9/4/17 10:55 AM

18
Feedback
Love it? Hate it?
Let us know with a customer review.
AmazonBasics is committed to delivering customer-driven products that live up to your high
standards. We encourage you to write a review sharing your experiences with the product.
Please visit: amazon.com/review/review-your-purchases#
For further services:
Visit amazon.com/gp/help/customer/contact-us
— or —
Contact Customer Service at 1-866-216-1072
B0716T5FW2-AmazonBasics-Vacuum cleaner (12M)-V03 (Multi).indb 18 9/4/17 10:55 AM

19
Guide de Bienvenue •Français
Aspirateur (12M) De 3,0 l Avec Sac
Contenu:
Avant de commencer, veuillez vous assurer que l’emballage contient les composants
suivants:
B0716T5FW2-AmazonBasics-Vacuum cleaner (12M)-V03 (Multi).indb 19 9/4/17 10:55 AM

20
Orifice du flexible d’aspiration Flexible d’aspiration
Capot avant Commande de la puissance
d’aspiration 2
Sac à poussière Tube télescopique en métal
Interrupteur d’enroulement du cordon Interrupteur de déverrouillage du tube
Commande de la puissance d’aspiration 1 Brosse pour sols durs
Filtre HEPA Interrupteur de la fonction brosse
pour sols durs
Bouton On/Off (Marche/Arrêt) Brosse à poussière
Cordon d’alimentation muni d’une fiche secteur Buse pour meubles
Filtre du moteur Suceur pour fentes
Indicateur de la capacité du sac à poussière Support pour accessoires
Poignée
Accessoires
Accessoire Conçu pour...
Brosse pour sols durs
Moquettes, tapis
Carrelage, parquets, linoléum
Brosse à poussière Moquettes, canapés, oreillers et rembourrage
de façon générale
Buse pour meubles
Retire la poussière et les minuscules
morceaux de tissu des fissures, des coins,
des fentes et des autres endroits difficiles
d’accès; idéale par exemple pour le passage
de l’aspirateur dans une voiture
Suceur pour fentes Fissures, coins, fentes et autres endroits
difficiles d’accès
B0716T5FW2-AmazonBasics-Vacuum cleaner (12M)-V03 (Multi).indb 20 9/4/17 10:55 AM
