AmazonBasics B071VNCNLF Operating and safety instructions

created by: Impala Services Ltd.Page size: 139.7 x 107.95 mm
B071VNCNLF
Cylinder Bagless Vacuum Cleaner, 1.5 L, 700 W
[Energy Class A]
Aspirateur Cylindrique Sans Sac, 1,5 l, 700 W [Classe d’Énergie A]
Beutelloser Zylinder-Staubsauger, 1,5 L, 700 W [Energieklasse A]
Aspirapolvere a Cilindro Senza Sacco, 1,5L, 700 W [Classe A]
Aspirador Cilíndrico Sin Bolsa, 1,5 L, 700 W [Energía Clase A]
B071VNCNLF-AmazonBasics-Vacuum cleaner (15K)-IM-V02 (Multi).indb 1 9/8/17 4:06 PM

English ..................................... 3
Français ................................. 23
Deutsch.................................. 43
Italiano................................... 63
Español.................................. 83
B071VNCNLF-AmazonBasics-Vacuum cleaner (15K)-IM-V02 (Multi).indb 2 9/8/17 4:06 PM

3
Welcome Guide •English
Cylinder Bagless Vacuum Cleaner,
1.5 L, 700 W [Energy Class A]
Contents:
Before getting started, ensure the package contains the following components:
B071VNCNLF-AmazonBasics-Vacuum cleaner (15K)-IM-V02 (Multi).indb 3 9/8/17 4:06 PM

4
Flexible hose On/off button
Extension tube Hose intake
Top lid lock Hard floor brush function switch
Dust container Hard floor brush
Handle Dusting brush
Container release button Crevice nozzle
Cable winder button Furniture nozzle
Holder for hard floor brush Accessory holder
Power cord with power plug Tube release switch
Motor filter Release button
Wheel Suction power control
Accessories
Accessory Intended for...
Hard floor brush
Rugs, carpets
Tiles, wooden floors, linoleum
Dusting brush
Rugs, sofas, pillows, and upholstery in
general
Furniture nozzle
Removes dust and tiny pieces of fabric
from crevices, corners, cracks and other
places hard to reach, ideal e.g. for the
grating in a car
Crevice nozzle
Crevices, corners, cracks and other
places hard to reach
B071VNCNLF-AmazonBasics-Vacuum cleaner (15K)-IM-V02 (Multi).indb 4 9/8/17 4:06 PM

5
IMPORTANT SAFEGUARDS
• Read this instruction manual carefully
before using the product. It contains
important information for your safety as
well as operating and maintenance advice.
Observe all safety instructions to avoid
damage through improper use! Keep this
instruction manual for future use. Should
this product be passed on to a third party,
then this instruction manual must be
included.
• No liability will be accepted for damage
resulting from improper use or non-
compliance with these instructions.
• Before connecting the appliance to the
power supply, check that the power supply
voltage and current rating corresponds
with the power supply details shown on the
appliance rating label.
B071VNCNLF-AmazonBasics-Vacuum cleaner (15K)-IM-V02 (Multi).indb 5 9/8/17 4:06 PM

6
• This product contains no user serviceable
parts and requires little maintenance.
Leave any servicing or repairs to qualified
personnel only.
• Never use a damaged appliance!
Disconnect the appliance from the
electrical outlet and contact your retailer if it
is damaged.
• Danger of electric shock! Do not attempt
to repair the appliance yourself. In case of
malfunction, repairs are to be conducted by
qualified personnel only.
• To avoid damaging the cord, do not
squeeze, bend or chafe it on sharp edges.
Keep it away from hot surfaces and open
flames as well.
• Lay out the cord in such a way that no
unintentional pulling or tripping over it is
possible. Keep the appliance and its cord
out of reach of children.
B071VNCNLF-AmazonBasics-Vacuum cleaner (15K)-IM-V02 (Multi).indb 6 9/8/17 4:06 PM

7
• If an extension cord is used, its capacity
needs to be suitable for the power
consumed by the appliance.
• Warning! During cleaning or operation
do not immerse the electrical parts of the
appliance in water or other liquids. Never
hold the appliance under running water.
• Do not operate the appliance with wet
hands or while standing on a wet floor. Do
not touch the power plug with wet hands.
• Do not open the appliance casing under
any circumstances. Do not insert any
foreign objects into the inside of the casing.
• Never use accessories which are not
recommended by the manufacturer. They
could pose a safety risk to the user and
might damage the appliance. Only use
original parts and accessories.
B071VNCNLF-AmazonBasics-Vacuum cleaner (15K)-IM-V02 (Multi).indb 7 9/8/17 4:06 PM

8
• This appliance can be used by children
aged from 8years and above and
persons with reduced physical, sensory or
mental capabilities or lack of experience
and knowledge if they have been given
supervision or instruction concerning use of
the appliance in a safe way and understand
the hazards involved. Children shall not
play with the appliance. Cleaning and user
maintenance shall not be made by children
without supervision.
• Regularly check the power plug and
power cord for damage. If the supply cord
is damaged, it must be replaced by the
manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
• Do not pull the power plug out of the electrical
outlet by the power cord and do not wrap the
power cord around the appliance.
• Disconnect the power plug from the
electrical outlet when not in use, before any
maintenance and before cleaning.
B071VNCNLF-AmazonBasics-Vacuum cleaner (15K)-IM-V02 (Multi).indb 8 9/8/17 4:06 PM

9
• This product is classified as protection
class II. This means the product is
equipped with reinforced or double
insulation between the mains supply circuit
and the output voltage or the casing.
Therefore it does not require a safety
connection to an electrical earth (ground).
• Never operate the appliance with any
air openings blocked. Keep ventilation
openings free from the accumulation of lint,
dust, and loose cloth.
Vacuum Cleaner Warnings
• Before vacuuming, remove any large, sharp
or sharp edged objects to avoid damage to
the filters and / or appliance.
• Do not vacuum any hot or incandescent
objects, liquids, chemicals or flammable
materials.
• Never use the vacuum cleaner without filter
inserts. The appliance may be damaged.
B071VNCNLF-AmazonBasics-Vacuum cleaner (15K)-IM-V02 (Multi).indb 9 9/8/17 4:06 PM

10
SAVE THESE INSTRUCTIONS
FOR FUTURE REFERENCE.
Legend
Danger Indicates a hazardous situation which, if not avoided, will result
in death or serious injury. This signal word is to be limited to the
most extreme situations.
Warning Indicates a hazardous situation which, if not avoided, could result
in death or serious injury.
Caution Indicates a hazardous situation which, if not avoided, could result
in minor or moderate injury.
Notice Indicates a practical tip, advice or practice not related to personal
injury.
B071VNCNLF-AmazonBasics-Vacuum cleaner (15K)-IM-V02 (Multi).indb 10 9/8/17 4:06 PM

11
Intended Use
• This appliance is only intended for vacuuming of dust, lint and general dirt on soft and hard
surfaces. Do not use it for vacuuming ashes, sharp objects e.g. glass or to suck up liquids or
other flammable substances.
• The appliance is intended for private indoor use only.
• Use the appliance only as described in this manual.
• No liability will be accepted for damage resulting from improper use or non-compliance with
this manual.
Before First Use
• Carefully remove all packaging materials and retain for future use.
• Check for transport damages.
• Clean the appliance ( Cleaning and Maintenance).
• Check whether the dust container is correctly in place ( Cleaning and Maintenance).
• WARNING - DANGER OF SUFFOCATION! Children should not play with the packaging
materials, as they pose a risk of swallowing and suffocation!
Assembly
Step 1:
• Insert the flexible hose into the hose intake at the front of the appliance. There should
be a click sound when the hose is correctly inserted.
B071VNCNLF-AmazonBasics-Vacuum cleaner (15K)-IM-V02 (Multi).indb 11 9/8/17 4:06 PM

12
Assembly
Step 2:
• Insert the handle of the flexible hose into the wider end of the extension tube .
Step 3:
• Push the tube release switch while pulling out the inner part of the extension tube to adjust
the length.
B071VNCNLF-AmazonBasics-Vacuum cleaner (15K)-IM-V02 (Multi).indb 12 9/8/17 4:06 PM

13
Assembly
Step 4:
• Insert the extension tube into the connector of the hard floor brush (or one of the other
accessories).
• Note: The accessories can be attached directly to the flexible hose.
Operation
Step 1:
• Pull out the power cord until the yellow marking on the cord appears. Pull no further.
• Connect the power plug to a suitable electrical outlet.
B071VNCNLF-AmazonBasics-Vacuum cleaner (15K)-IM-V02 (Multi).indb 13 9/8/17 4:06 PM

14
Operation
Step 2:
• Press the on/off button to switch on the appliance.
Step 3:
• Use the suction power control on the flexible hose handle to increase/decrease suction power.
B071VNCNLF-AmazonBasics-Vacuum cleaner (15K)-IM-V02 (Multi).indb 14 9/8/17 4:06 PM

15
Operation
Step 4:
• Press the on/off button to power off the appliance.
• Unplug the cable and press the cable winder button to wind up the power cable.
• After use, the hard floor brush can be attached to the back of the appliance using the foreseen
hard floor brush holder .
Notice Hold the power cable with one hand and slowly guide it while it rolls
back into storage.
Cleaning and Maintenance
Warning Always disconnect the power plug from the electrical outlet
before cleaning or storing.
Cleaning
• Remove any accessory attached to the extension tube or flexible hose.
• Clean the appliance and accessories with a slightly moistened cloth. Do not allow any liquid to
enter the appliance’s interior.
• Never use corrosive detergents, wire brushes, abrasive scourers, metal or sharp utensils to
clean the appliance or accessories.
• Carefully dry the appliance and accessories after cleaning.
B071VNCNLF-AmazonBasics-Vacuum cleaner (15K)-IM-V02 (Multi).indb 15 9/8/17 4:06 PM

16
• To dislodge the flexible hose from the hose intake press the release button and pull
the hose out.
Emptying the Dust Container
• Regularly empty the dust container to avoid damage to the appliance.
• Grab the dust container by its handle and press the release button to unlock it. Pull the
container out of the appliance.
B071VNCNLF-AmazonBasics-Vacuum cleaner (15K)-IM-V02 (Multi).indb 16 9/8/17 4:06 PM

17
Release
button
• Hold the dust container over a rubbish bin or bag. Press the dust release button. The bottom lid
of the dust container will automatically open, allowing you to empty the container.
• After emptying the dust container, close the bottom lid and replace the container in the
appliance. Press the container down in its original position. When you hear a click sound, the
dust container is correctly inserted.
B071VNCNLF-AmazonBasics-Vacuum cleaner (15K)-IM-V02 (Multi).indb 17 9/8/17 4:06 PM

18
Cleaning the HEPA Filter
Foam inlay
Foam inlay
• Remove the container.
• Open the top lid by pulling its lock upwards.
• Pull out the black and blue cylinder.
• Separate the cylinders from each other by rotating either one of them counter-clockwise.
• If necessary, clean the cylinders and the dust container with a damp cloth or under running
water.
• Remove the filter frame from the lid by simply pulling it out.
• Remove the foam inlay.
• Tap the filter frame to remove dust.
• If necessary, rinse the filter frame and the foam inlay under running water.
• To avoid damaging the filter, do not use any tools.
B071VNCNLF-AmazonBasics-Vacuum cleaner (15K)-IM-V02 (Multi).indb 18 9/8/17 4:06 PM

19
Cleaning the Motor filter
Grid lock
Air outlet grid
Motor filter
• We recommend to clean the Motor filter about twice a year or when it appears to be dirty.
• The filter is installed behind the air outlet grid. Push the grid lock to the left and pull out the air
outlet grid at the same time.
• Slightly press down the lock on the top side of the filter frame and pull out the filter frame.
• Rinse the filter with warm water.
• Let the filter dry completely. Do not expose it to direct sunlight.
• Put the filter back in place and reinstall the air outlet grid.
• Both filter and grid must click into place.
Notice Never use the appliance without filters installed. This can cause
power loss or damage to the appliance.
B071VNCNLF-AmazonBasics-Vacuum cleaner (15K)-IM-V02 (Multi).indb 19 9/8/17 4:06 PM

20
Troubleshooting
Problem Solutions
The appliance does not start. – Connect the power plug properly.
– Check if the electrical outlet is powered.
– Check if the on/off switch is on.
– Check if the dust container is correctly locked
in place.
Weak suction power. – Check if the flexible hose, extension tube or any of
the accessories are obstructed.
– Remove and clean the filters.
Motor is abnormally noisy. – Stop using the appliance immediately.
– Check if the hose, tube or any of the accessories
are obstructed.
– Remove the obstruction.
– If the noise continues, power off the appliance
and disconnect the power plug.
– Contact your service agents.
B071VNCNLF-AmazonBasics-Vacuum cleaner (15K)-IM-V02 (Multi).indb 20 9/8/17 4:06 PM
