USER'S MANUAL
Of
AMD 740G Chipset
&
AMD SB700 Chipset Based
M/B for Socket AM2+ 64-bit Quad Core
AMD Processor
No. G03-PA74M2-F
Rev: 2.0
Release date: Aug. 2008
Trademark:
* Specifications and information contained in this documentation are furnished for information use only, and are
subject to change at any time without notice, and should not be construed as a commitment by manufacturer.


ii
CHAPTER 1 INTRODUCTIONOF AMD 740G MOTHERBOARD SERIES
1-1 FEATURES OF MOTHERBOARD.................................................................................... 1
1-1.1 SPECIAL FEATURES OF MOTHERBOARD.................................................... 2
1-2 SPECIFICTION................................................................................................................... 
1-3 ITEM CHECKLIST..............................................................................................................4
1-4 LAYOUT DIAGRAM ........................................................................................................... 4
CHAPTER 2 HARDWARE INSTALLATION
2-1 INSTALL SOCKET AM2/AM2+ SUPPORTED AMD PROCESSOR............................ 5
2-2 INSTALL MEMORY............................................................................................................ 5
2-3 EXPANSION CARDS........................................................................................................... 6
CHAPTER 3 CONNCTORS, HEADERS & JUMPERS SETTING
3-1 CONNECTORS..................................................................................................................... 7
3-2 HEADERS.............................................................................................................................. 9
3-3 JUMPER SETTING.............................................................................................................. 11
CHAPTER 4 USEFUL HELP
4-1 HOW TO UPDATE BIOS..................................................................................................... 12
4-2 TROUBLE SHOOTING....................................................................................................... 12
Environmental Protection Announcement
Do not dispose this electronic device into the trash while discarding. To minimize pollution
and ensure environment protection of mother earth, please recycle.
TABLE OF CONTENT


1
Chapter 1
Introduction of AMD 740G Motherboard Series
1-1 Features of motherboard
The AMD 740G Series motherboards are based on the latest AMD 740G Chipset and
SB700 chipset which supports Socket AM2+ dual core and quad core AMD Phenom™
processors and 64-bit AMD Socket AM2+/AM2 multi-tasking Socket AM2 Athlon64 X2
processors and Sempron Processors. With an integrated low-latency high-bandwidth DDR2
memory controller and the highly-scalable Hyper Transport technology-based system bus
which is up to 1000 MHZ, AMD 740G Platform Processor Chipset motherboard series deliver
the outstanding system performance and professional desktop platform solution with the
advantages of 64-bit AMD Socket AM2+/AM2 AMD Phenom™ processors, Athlon64 X2
processors and the fully compatibility of the next generation operation system.
The AMD 740G Series motherboards support new generation Socket AM2 processors with an
integrated DDR2 memory controller which provides with 266MHz / 333MHz/ 400MHz
memory clock frequency for Dual channel DDR2 533 / DDR2 667 / DDR2 800/DDR2 1066
(Sempron processor of AM2 socket only supports up DDR2 667) DDR2 Module up to 4 GB.
The whole motherboard series are embedded with SB700 chipset that provides one ULTRA
ATA 133 connectors and Serial ATA2 with RAID 0, 1, 5 and RAID 10 functions which
support up to two IDE devices and six Serial ATA2 devices to accelerate hard disk drives and
guarantee the data security without failure in advanced computing performance.
The 740G series motherboards provide 10/100/1000 LAN functions with Realtek RTL8102E
PCI-E Gigabit LAN which supports 10/100/1000 Mbps data transfer rate. And the embedded
Azalia 6-channel Audio CODEC is fully compatible with Sound Blaster Pro®standards that
offer you with the home cinema quality and satisfying software compatibility.
The motherboards offer one PCI-Express x16 graphics slot of 4Gbyte/sec data transfer rate at
each relative direction which gets 3.5 times of bandwidth more than AGP 8X and it’s up to a
peak concurrent bandwidth of 8Gbyte/sec at full speed to guarantee the ultimate GPU
computing performance. Two 32-bit PCI slots guarantee the rich connectivity for the I/O of
peripherals; the motherboards are designed of tackling the profuse multimedia requirements
nowadays.
Embedded USB controller as well as capability of expanding to 8 of USB2.0 functional ports
delivering 480Mb/s bandwidth and rich connectivity, these motherboards meet the future
USB demands which are also equipped with hardware monitor function on system to monitor
and protect your system and maintain your non-stop business computing.
Some special features---CPU Thermal Throttling /CPU Smart Fan// CPU Vcore X-shift /
OC-CON this motherboard are designed for power user to use the over-clocking function in
more flexible ways. But please be caution that the over-clocking may cause the fails in system
reliabilities. This motherboard provides the guaranteed performance and meets the demands
of the next generation computing. But if you insist to gain more system performance with
variety possibilities of the components you choose, please be careful and make sure to read


2
the detailed descriptions of these value added product features, please get them in the coming
section.
1-1.1 Special Features of Motherboard
CPU Thermal Throttling Technology--- (The CPU Overheat Protection Technology)
To prevent the increasing heat from damage of CPU or accidental shutdown while at high
workload, the CPU Thermal Throttling Technology will force CPU to enter partially idle
mode from 87.5% to 12.5% according to preset CPU operating temperature in BIOS (from 40
to 90). When the system senses the CPU operating temperature reaching the preset
value, the CPU operating bandwidth will be decreased to the preset idle percentage to cool
down the processor. When at throttling mode the beeper sound can be optionally selected to
indicate it is in working.
CPU Smart Fan---( The Noise Management SystemOnly support 4-pin CPU cooler)
It’s never been a good idea to gain the performance of your system by sacrificing its acoustics.
CPU Smart Fan Noise Management System is the answer to control the noise level needed for
now-a-day’s high performance computing system. The system will automatically increase the
fan speed when CPU operating loading is high, after the CPU is in normal operating condition,
the system will low down the fan speed for the silent operating environment. The system can
provide the much longer life cycle for both CPU and the system fans for game use and
business requirements.
CPU Vcore X-Shift--- (Shift to Higher Performance)
The CPU voltage can be adjusted up by 15 steps for the precisely over-clocking of extra
demanding computing performance.
OC-CON ---High-polymer Solid Electrolysis Aluminum Capacitors
The working temperature is from 55 degrees Centigrade below zero to 125 degrees
Centigrade, OC-CON capacitors possess superior physical characteristics that can be while
reducing the working temperature between 20 degrees Centigrade each time, intact extension
10 times of effective product operation lives, at not rising degrees Centigrade of working
temperatures each time a relative one, life of product decline 10% only too.


3
1-2 Specification
Spec Description
Design ∗Micro ATX form factor 4 layers PCB
∗size: 24.5 cm x20.0cm
Chipset ∗AMD 740G Chipset and AMD SB700 Chipset
CPU Socket AM2+
∗Support 64bit AMD AM2 940-Pin package utilizes Flip-Chip Pin Grid
Array package compatible processor
∗Support for HTT 1GHz dual core and quad core AMD Phenom
processors
∗Support HTT 1GHz AMD Athlon 64 X2 processor and Athlon 64, and
HTT 800MHz Sempron Processors
Memory Socket
∗240-pin DDR2 Module socket x 2
∗Support 2 pcs DDR2 533 / DDR2 667 / DDR2 800 /DDR 1066 Modules
Expandable to 4 GB
Expansion Slot
∗PCI-Express x16 slot 1pcs delivers up to 8 GB/s of concurrent
bandwidth.
∗32-bit PCI slot x 2 pcs
Integrate IDE and
Serial ATA2 RAID
∗One IDE controllers support PCI Bus Mastering, ATA PIO / DMA and
the ULTRA DMA 33/66/100/133 functions that deliver the data transfer
rate up to 133 MB/s.
∗Four Serial ATA2 ports provide 300 MB/sec data transfer rate with
RAID 0, 1, 5 and 10 functions.
Integrated VGA ∗Integrated with ATI Radeon 2100 Graphic
LAN
∗Integrated Realtek RTL8102E PCI-E gigabit LAN chip
∗Supports Fast Ethernet LAN function provide 10/100/1000 Mb /s data
transfer rate
Audio ∗6-channel Realtek ALC662 Azalia HD Audio Codec integrated
∗Audio driver and utility included
BIOS ∗Award 8MB SPI Flash ROM
Multi I/O
∗PS/2 keyboard and PS/2 mouse connectors
∗VGA port x1
∗DVI port x1
∗USB2.0 port x 4 and headers x 2
∗Audio connector (Line-in, Line-out, MIC)
∗Floppy disk drive connector x1
∗Front panel audio header x 1
∗Serial port header x 1
∗HDMI-SPDIF header x 1
∗CDIN header x 1


4
1-3 Item Checklist
5AMD 740G Platform Processor Chipset based motherboard
5AMD 740G Platform Processor Chipset motherboard User’s Manual
5CD for motherboard utilities
5I/O Shield Panel
5Cable for IDE Connector
5Cable for Serial ATA Connector
1-4 Layout Diagram
8 MBit Flash ROM BIOS
Front Panel Connector
ATA 133 IDE
Conn.(IDE1)
Clear CMOS (JBAT)
CPU Socket AM2
AMD Phenom™ Ready
ATX Power Conn.
Serial-ATAII Connector
(SATA II 1, 2,3,4)
PCI Slots
PS2 KB/Mouse Port
CPU FAN
Audio Connector
USB Port
Front Panel Audio
DDRII Socket x 2
SFAN1
ATX 12V Power Connecto
r
Realtek ALC662
Audio Decode CDIN
Realtek RTL8102E Gigabit
LAN chip
Speaker Connector
USB Port
(USB1, USB2)
SYSFAN1
PCI Express x16
Power LED Connector
COM
Connector
AMD 740G Chipset
AMD SB700
Keyboard/USB
Power on (JP1)
VGA Connecto
r
DVI Connecto
r
SPDIF
-
Out Header
RJ45 over USB
Connector
Floppy Connector
SYSFAN2


5
Chapter 2
Hardware Installation
2-1 Install Socket AM2/AM2+ Supported AMD Processor
This motherboard provides a 940-pin surface mount, Zero Insertion Force (ZIF) socket,
referred to as the mPGA940 socket supports AMD Athlon64 processor in the 940 Pin package
utilizes Flip-Chip Pin Grid Array package technology.
The CPU that comes with the motherboard should have a cooling FAN attached to prevent
overheating. If this is not the case, then purchase a correct cooling FAN before you turn on
your system.
WARNING! Be sure that there is sufficient air circulation across the processor’s
heatsink and CPU cooling FAN is working correctly, otherwise it may
cause the processor and motherboard overheat and damage, you may install
an auxiliary cooling FAN, if necessary.
To install a CPU, first turn off your system and remove its cover. Locate the ZIF socket and
open it by first pulling the level sideways away from the socket then upward to a 90-degree
angle. Insert the CPU with the correct orientation as shown below. The notched corner
should point toward the end of the level. Because the CPU has a corner pin for two of the
four corners, the CPU will only fit in the orientation as shown.
CPU ZIF mPGAB Socket
Colden Arrow
Socket AM2
When you put the CPU into the ZIF socket， No force require to insert of the CPU, then press
the level to Locate position slightly without any extra force.
2-2 Install Memory
The motherboards provide two 240-pin DDRII DUAL INLINE MEMORY MODULES
(DIMM) slots for DDRII memory expansion available from minimum memory size of
128MB to maximum memory size of 4 GB DDRII SDRAM.
Valid Memory Configurations of 2-DIMM Design Motherboard
Bank 240-Pin DIMM PCS Total Memory
Bank 0, 1 (DIMM1) DDRII533/DDRII667/DDRII800/DDRII1066 X1 128MB∼2 GB
Bank 2, 3 (DIMM2) DDRII533/DDRII667/DDRII800/DDRII1066 X1 128MB∼2 GB
Total System Memory (Max. 4GB) 2 128MB∼4 GB
Recommend DIMM Module Combination
1. One DIMM Module ----Plug in DIMM1
2. Two DIMM Modules---Plug in DIMM1 and DIMM2 for Dual channel function
For Dual channel Limited!


6
1. Dual channel function only supports when 2 DIMM Modules plug in either both DIMM1 &
DIMM2.
2. DIMM1 & DIMM2 must be the same type, the same size, and the same frequency for dual
channel function.
Generally, installing DDR SDRAM modules to your motherboard is very easy, you can refer
to figure 2-4 to see what a 240-Pin DDR2 533 / 667/ 800 /1066 SDRAM module looks like.
NOTE! When you install DIMM module fully into the DIMM socket the eject tab should
be locked into the DIMM module very firmly and fit into its indention on both
sides
2-3 Expansion Cards
The motherboards offer one PCI-Express x16 graphics slot of 4Gbyte/sec data transfer rate at
each relative direction which gets 3.5 times of bandwidth more than AGP 8X and it’s up to a
peak concurrent bandwidth of 8Gbyte/sec at full speed to guarantee the ultimate GPU
computing performance. Two32-bit PCI slots guarantee the rich connectivity for the I/O of
peripherals; the motherboards are designed of tackling the profuse multimedia requirements
nowadays.
PE1 / PCI-E x16 Slot
32-bit PCI Slot
Figure 2-4


7
Chapter 3
Connectors, Headers & Jumpers Setting
3-1 Connectors
(1) Power Connector (24-pinblock):
ATXPWR1
ATX Power Supply connector:
This is a new defined 24-pins
connector that usually comes with
ATX case. The ATX Power Supply
allows using soft power on
momentary switch that connect from
the front panel switch to 2-pins
Power On jumper pole on the
motherboard. When the power
switch on the back of the ATX
power supply turned on, the full
power will not come into the system
board until the front panel switch is momentarily pressed. Press this switch again will
turn off the power to the system board.
** We recommend that you use an ATX 12V Specification 2.0-compliant power supply
unit (PSU) with a minimum of 350W power rating. This type has 24-pin and 4-pin
power plugs.
** If you intend to use a PSU with 20-pin and 4-pin power plugs, make sure that the 20-pin
power plug can provide at least 15A on +12V and the power supply unit has a minimum
power rating of 350W. The system may become unstable or may not boot up if the
power is inadequate.
(2) ATX 12V Power Connector (8-pin block) : ATX12V
This is a new defined 8-pins connector that usually comes with
ATX Power Supply. The ATX Power Supply which fully
supports AM2 processor must including this connector for
support extra 12V voltage to maintain system power
consumption. Without this connector might cause system unstable because the power
supply can not provide sufficient current for system.
(3) PS/2 Mouse & PS/2 Keyboard Connector: KB
The connectors are for PS/2 keyboard and PS/2 Mouse
(4) USB Port connector: from CN5/ UL2
The connectors are 4-pin connectors that connect USB devices to the system board.
(5) LAN Port connector: from UL2
This connector is standard RJ45 connector for Network. The connector support
10M/100Mb/1000Mb s data transfer rate.
(6) Audio Line-In, Lin-Out, MIC Connector: CN3
This Connector are 3 phone Jack for LINE-OUT, LINE-IN, MIC.
Line-in : (BLUE)
Audio input to sound chip
Line-out : (GREEN) Audio output to speaker
MIC : (PINK) Microphone Connector
Pin 1
ROW1 ROW2
24-Pin
ROW1 ROW2
Pin 1
20-Pin
PIN ROW1 ROW2
1 3.3V 3.3V
2 3.3V -12V
3 GND GND
4 5V Soft Power On
5 GND GND
6 5V GND
7 GND GND
8 Power OK -5V
9 +5V (for Soft Logic) +5V
10 +12V +5V
11 +12V +5V
12 +3V GND


8
(7)Floppy drive Connector (34-pin block): FDD
This connector supports the provided floppy drive ribbon cable.
After connecting the single plug end to motherboard, connect
the two plugs at other end to the floppy drives.
(8) Primary IDE Connector (40-pin block): IDE1
This connector connects to the next set of Master and Slave
hard disks. Follow the same procedure described for the primary
IDE connector. You may also configure two hard disks to be both
Masters using one ribbon cable on the primary IDE connector and
another ribbon cable on the secondary IDE connector.
•Two hard disks can be connected to each connector. The first
HDD is referred to as the “Master” and the second HDD is referred
to as the “Slave”.
•For performance issues, we strongly suggest you don’t install a
CD-ROM or DVD-ROM drive on the same IDE channel as a hard
disk. Otherwise, the system performance on this channel may drop.
(9) Serial-ATA Port connector:
SATA1 / SATA2 / SATA3/ SATA4/SATA5/SATA6
These connectors support the provided Serial ATA
and Serial ATA2 IDE hard disk cable to connecting
the motherboard and serial ATA hard disk.
(10) D-Sub 15-pin Connector: VGA1
VGA is the 15-pin D-Subminiature female connector; it is for the display devices, such
as the CRT monitor, LCD monitor and so on.
(11) Digital Visual Interface: DVI
This interface standard designed to maximize the visual quality of digital display
devices such as flat panel LCD computer displays and digital projectors.
Primary IDE Connector
Pin 1
IDE1
IDE1
Floppy Drive Connector
Pin 1
FDD
Serial-ATA1 & 2 Compatible Connectors
SATA2
SATA3
SATA1
SATA5
SATA4
SATA6
USB
PS/2
Mouse
USB
PS/2
Keyboard
Line-IN
Line-OUT
MIC-IN
VGA
DVI
RJ45 LAN Connector


9
3-2 Headers
(1) Line-Out/MIC Header for Front Panel (9-pin):
AUDIO1
These headers connect to Front Panel Line-out, MIC
connector with cable.
(2) USB Port Headers (9-pin) :
USB1 / USB2
These headers are used for connecting the
additional USB port plug. By attaching an
option USB cable, your can be provided
with two additional USB plugs affixed to
the back panel.
(3) Speaker connector: SPEAK
This 4-pin connector connects to the case-mounted
speaker. See the figure below.
(4) Power LED: PWR LED
The Power LED is light on while the system power
is on. Connect the Power LED from the system
case to this pin.
(5) IDE Activity LED: HD LED
This connector connects to the hard disk activity
indicator light on the case.
(6) Reset switch lead: RESET
This 2-pin connector connects to the case-mounted
reset switch for rebooting your computer without
having to turn off your power switch. This is a preferred method of rebooting in order
to prolong the lift of the system’s power supply. See the figure below.
(7) Power switch: PWR BTN
This 2-pin connector connects to the case-mounted power switch to power ON/OFF the
system.
(8)FAN Power Headers: SYSFAN1, SYSFAN2 (3-pin), CPUFAN (4-pin)
These connectors support cooling fans of 350mA (4.2 Watts) or less, depending on the
fan manufacturer, the wire and plug may be different. The red wire should be positive,
while the black should be ground. Connect the fan’s plug to the board taking into
consideration the polarity of connector.
USB Port Headers
Pin1
USB1
VCC
-DATA
GND
+DATA
VCC
OC
-DATA
GND
+DATA
Pin1
USB2
VCC
-DATA
GND
+DATA
VCC
OC
-DATA
GND
+DATA
System Case Connections
HDLED
RESET
VCC5
GND
VCC5 PWR LED
PWRBTN
PWRBTN
PWRLED
HDDLE
RSTSW
NC GND
JW FP
Pin 1
SPEAK
SPKR
GND
NC
VCC5
Pin 1
PWRLED
Pin 1
ALC662
Line-Out, MIC Headers
AUDIO
Pin 1
MIC2-L
LINEOUT2-L
MIC2-R
LINEOUUT2-R
SENSE-FB
AUD_GND
AUD_GND
AUD_GND
AUD_JD 9
2
9
10


10
FAN Headers
CPUFAN
1 4
GND
+12V
CPUFANIN
CPUFANOUT
SYSFAN2
1
3
SYSFAN1
1
3
(9) CD Audio-In Headers (4-pin) : CDIN1
CDIN are the connectors for CD-Audio Input signal.
Please connect it to CD-ROM CD-Audio output connector.
(10)Serial COM Port Header: COM1
COM1isthe9-pinblockpin-header.TheOn-boardserial
port can be disabled through BIOS SETUP.
(11) HDMI-SPDIF Out header: SPDIF Out
The SPDIF output is capable of providing digital audio to external speakers or
compressed AC3 data to an external Dolby digital decoder. Use this feature only when
your stereo system has digital input function. Some of the VGA Card need connect
SPDIF-IN Connector, so its HDMI Port can make sounds.
CD Audio-In Headers
CDIN 4 1
Serial COM Port 9-pin Block
Pin1
12
HDMI_SPDIF_OUT GND
SPDIF


11
3-3 Jumper Setting
(1) Keyboard/USB function Enabled/Disabled: JP1
Keyboard/Mouse & USB Power On Setting
2-3 Closed KB/USB Power ON Enabled
JP1JP1
1-2 Closed KB/USB Power ON Disable (Default)
(2) CMOS RAM Clear (3-pin): JBAT
A battery must be used to retain the motherboard configuration in CMOS RAM short 1-2
pins of JPAT to store the CMOS data.
To clear the CMOS, follow the procedure below:
1. Turn off the system and unplug the AC power
2. Remove ATX power cable from ATX power connector
3. Locate JBAT and short pins 2-3 for a few seconds
4. Return JBAT to its normal setting by shorting pins 1-2
5. Connect ATX power cable back to ATX power connector
Note: When should clear CMOS
1. Troubleshooting
2. Forget password
3. After over clocking system boot fail
CMOS RAM Clear Setting
2-3 closed Clear CMOS
JBAT JBAT
1-2 closed Normal (Default)
1
3
1
3


12
Chapter 4
USEFUL HELP
4-1 How to Upgrade BIOS
Before updating the BIOS, users have to check if the “Miscellaneous Control” of BIOS SETUP has the
“Flash Part Write Protect” selection. If there is one, users have to “Disable” the “Flash Part Write
Protect” selection of the “Miscellaneous Control” in BIOS SETUP. Otherwise the system the will not
allow you to upgrade BIOS by Award Flash Utility. If there is no such selection, users can follow the 4
stepsdirectlytoupdateBIOS.
STEP 1. Prepare a boot disc. (You may make one by click START click RUN type SYS A: click OK)
STEP 2. Copy utility program to your boot disc. You may copy from DRIVER CD
X:\FLASH\AWDFLASH.EXE or download from our web site.
STEP 3. Download and make a copy of the latest BIOS for 770 SERIES motherboard series from the
web site to your boot disc.
STEP 4. Insert your boot disc into A:,
Start the computer, type “Awdflash A:\xxxxxx.BIN /SN/PY/CD/CH/WB/CC/R”
xxxxxx.BIN is the file name of latest BIOS
SN means don’t save existing BIOS data
PY means renew existing BIOS data
CD means clear DMI data after programming
CH means updateHOLE
WB means always programming BootBlock
CC means clear existing CMOS data
R means restart computer
STEP 5. Type Enter to update and flash the BIOS, then the system will restart automatically.
4-2 Trouble Shooting
Problem Solution
No power to the system to the all power light
don’t illuminate, fan inside power supply doesn’t
turn on.
1. Make sure power cable is security plugged in.
2. Replace cable. 3. Contact technical support.
System inoperative. Keyboard lights are on ,
power indicator lights are lit, and hard drive is
spinning.
Using ever pressure on both ends of the DIMM ,
press down firmly until the module snaps into
places.
System doesn’t boot from hard disk drive, can be
booted from optical drive. 1. Check cable running from disk to disk controller board. .Make sure both ends are
securely plugged in, check the drive type in the
standard CMOS setup. 2. Backing up the hard
drive is extremely important .All hard disks are
capable of breaking down at any time.
System only boots from optical drive .Hard disk
can be read and applications can be used but
booting from hard disk is impossible.
1. Back up date and applications files. 2.
Reformat the hard drive. Reinstall applications
and date using backup disks.
Screen message says “Invalid Configuration” or
“CMOS Failure” Review system ‘s equipment .Make sure correct information on is in setup.
Can not boot system after installing second hard
drive. 1. Set master /slave jumpers correctly. 2. Run SETUP program and select correct drive types.
Call the drive manufacture for compatibility with
other drives.
