amiad SAF-6000 Manual

AMIAD Water Systems Ltd.
SAF-6000 FILTER
Serial number:
Order number:
Catalog number:
Filtration degree:
Tested by:
Installation, Operation and
Maintenance Instructions
07-2019 Ref: 910101-000107 /
Original Instructions

SAF 6000 910101-000107 07.2019 Page 2 of 28
AMIAD Water Systems Ltd.
SAF-6000 FILTER - User Manual
Disclaimer:
Copyright © 2018 Amiad Water Systems Ltd. All rights reserved.
The contents of this document, including without limitation all information and materials, images, illustrations, data, drawings, names
and any other such materials that appear in this document are the sole property of Amiad Water Systems Ltd., including any intellectual
property rights, whether registered or not, and all know-how contained or embodied therein. Amiad may alter, remove or change the
Content without any further notice. You may not reproduce, copy, modify, create derivative works from, sell or participate in any sale of,
or exploit in any way, in whole or in part, any of this document or its content.
The confidential nature of and/or privilege in the file enclosed is not waived or lost as a result of a mistake or error in this file.If you
received this file in error, please notify Amiad immediately at [email protected] .
This document does not replace any certified drawing, procedure or information provided by Amiad in reference to a specific customer,
site or project.
Amiad assumes that all users understand risks involved within this file and/or its attached materials.This document is given in good faith
and is not intended to impose any obligation to Amiad. While every effort has been made to ensure the information in this manual is
accurate and complete, we would appreciate if you can bring any errors or omissions to the knowledge of Amiad or consult Amiad
experts or its authorized representatives if you have any questions.
Amiad Water Systems Ltd. D.N. Galil Elyon 1, 1233500, Israel Tel: [phone] | Fax: [phone] Email: [email protected]

SAF 6000 910101-000107 07.2019 Page 3 of 28
TABLE OF CONTENTS
AMIAD Water Systems Ltd. ............................................................................................................................... 1
SAF-6000 FILTER ................................................................................................................................................ 1
Installation, Operation and Maintenance Instructions ..................................................................................... 1
AMIAD Water Systems Ltd. ............................................................................................................................... 2
SAF-6000 FILTER - User Manual......................................................................................................................... 2
Technical Specifications..................................................................................................................................... 4
General ........................................................................................................................................................... 4
Flushing data .................................................................................................................................................. 4
Control and electricity.................................................................................................................................... 4
Construction materials................................................................................................................................... 4
Standard filtration degrees ............................................................................................................................ 4
Safety Instructions............................................................................................................................................. 5
General Safety Instructions............................................................................................................................ 5
Installation...................................................................................................................................................... 5
Commissioning ............................................................................................................................................... 6
Operation and Control ................................................................................................................................... 6
Maintenance................................................................................................................................................... 7
Dimensional Drawing......................................................................................................................................... 8
Description of Filter Operation.......................................................................................................................... 9
Installation ....................................................................................................................................................... 11
Maintenance.................................................................................................................................................... 13
Troubleshooting............................................................................................................................................... 15
Dismantling and Assembling the Filter Components ...................................................................................... 16
Parts Schedule –SAF-6000 Filter Section 1 ..................................................................................................... 19
Parts Drawing Section 1................................................................................................................................... 21
Parts Drawing Section 1 (Page 2)..................................................................................................................... 22
Parts Schedule Section 2.................................................................................................................................. 23
Parts Drawing Section 2................................................................................................................................... 24
Parts Schedule & Drawing Section 3 (Page 1) Suction Scanner- SLN Type..................................................... 25
Parts Schedule & Drawing Section 3 (Page 2) Suction Scanner- Std. Type ..................................................... 26
Amiad Limited Warranty ................................................................................................................................. 27
With any inquiry please quote Filter Serial Number, located on the filter housing.

SAF 6000 910101-000107 07.2019 Page 4 of 28
Technical Specifications
General
Maximum flow rate
150-300 m3/h
Consult manufacturer for optimum flow
according to filtration degree and water
quality
Min. working pressure
2.0 bar
30 psi
Max. working pressure
10 bar
150 psi
Filter area
6000 cm2
930 in2
Inlet/Outlet diameter
150-200 mm
6"-10"
Filter housing diameter
350 mm
14"
Max. working temp.
60C
140F
Weight
315 Kg
695 lb.
Flushing data
Exhaust valve
50 mm
2"
Flushing cycle time
40 seconds
40 seconds
Flushing water per cycle
280 liter
74 gallon
at 2 bar (30 psi)
Minimum flow for flushing
25 m3/h
110 USgpm
at 2 bar (30 psi)
Control and electricity
Control voltage
24V AC / 24V DC
Electric motor
1/3 HP 50 / 60 Hz, 35 / 42 Gear output R.P.M.
Rated operation voltage
3 phase 220 / 380 / 440 V, 50 / 60 Hz
Current consumption
0.8 Amp. (with 3 phase 380 / 440 V)
Construction materials
Filter housing and lid
Coated Carbon Steel 37-2
Screens
Stainless Steel 316
Cleaning mechanism
Stainless Steel 316, POM
Exhaust valve
Ductile Iron
Seals
NBR
Control system
Nylon, Brass , Aluminum
Standard filtration degrees
Stainless Steel Weave Wire Screen
micron
500
300
200
130
100
80
50
40
30
20
10
mm
0.5
0.3
0.2
0.13
0.1
0.08
0.05
0.04
0.03
0.02
0.01

SAF 6000 910101-000107 07.2019 Page 5 of 28
Safety Instructions
General Safety Instructions
➢Amiad filtration products always operate as components in a larger system. It is essential for the system designers, installers and
operators to comply with all the relevant safety standards.
➢Prior to installation, operation, maintenance or any other type of action carried out on the filter, read carefully the safety, installation and
operation instructions.
➢During installation, operation or maintenance of the filter all conventional safety instructions should be observed in order to avoid
danger to the workers, the public or to property in the vicinity.
➢Please note: The filter enters into a flushing mode automatically, without prior warning.
➢No change or modification to the equipment is permitted without a written notification given in advance by the manufacturer or by its
representative, on the manufacturer’s behalf.
➢Always observe standard safety instructions and good engineering practices whilst working in the filter’s vicinity.
➢Use the filter only for its intended use as designed by Amiad, any misuse of the filter may lead to undesired damage and may affect your
warranty coverage. Please consult with Amiad prior to any non-regular use of this equipment.
Installation
General
➢Install the filter according to the detailed Installation Instructions provided with the filter by the manufacturer and according to the
description given in this manual.
➢Make sure to leave enough clearance so as to enable easy access for future treatments and safe maintenance operations.
➢The user should arrange suitable lighting at the area of the filter to enable good visibility and safe maintenance.
➢The user should arrange suitable platforms, ladders and safety barriers to enable easy and safe access to the filter without climbing on
pipes and other equipment. The user should verify that any platform, barrier, ladder or other such equipment is built, installed and used
in accordance with the relevant local authorized standards.
➢Check and re-tighten all bolts during commissioning and after the first week of operation.
➢Use only appropriate standard tools and equipment operated by qualified operators when installing, operating and maintaining the filter.
➢When installation is required in hazardous environment sites, underground or high above ground, make sure that the site design and the
auxiliary equipment are appropriate and that installation procedures are carried out in accordance with the relevant standards and
regulations.
➢Ensure walking areas about the installation are slip free when wet.
Shipment and transporting
➢Shipping and transporting the filter must be done in a safe and stable manner and in accordance with the relevant standards and
regulations.
➢For shipping, lifting and positioning the filter, use only approved lifting equipment and authorized employees and contractors.
Electricity
➢Electric wiring should be performed by an authorized electrician only, using standardized and approved components.
➢Install a lockable main power cut-off switch close to the control panel.
➢If due to site constraints, the control panel is installed without a clear line-of sight of the filter, an additional lockable power disconnect
cut-off switch should be installed near each filter unit.
➢Installation of the filter should be performed so as to avoid direct water splashing on the electrical components or on the control panel.

SAF 6000 910101-000107 07.2019 Page 6 of 28
Pneumatics
➢Install a lockable main cut-off switch, featured with a pressure release mechanism, on the compressed air supply line close to the
control panel.
➢If the control panel is installed far away and there is no eye contact with the filter, a lockable compressed air cut-off switch, featured
with a pressure release mechanism, should be installed near each filter unit.
➢The user should make sure that the compressed air supplied to the filter never exceeds the maximum designated pressure for this filter.
An air-pressure reduction valve should be installed on the compressed air supply line upstream of the filter’s pneumatic inlet port.
Hydraulics
➢Extra safety devices should be installed on hot water applications to avoid skin burn danger.
➢The user should install a manual Water Cut-off Valve next to the filter’s inlet port.
➢In cases where the downstream piping network downstream of the filter is pressurized an additional manual Water Cut-off Valve should
be installed next to the filter outlet port.
➢The user should make sure that the system includes a Pressure Release / Drainage Valve to enable release of residual pressure prior to
any maintenance procedure performed on the filter.
➢The user should make sure that the filter is never exposed to water pressure exceeding the maximum designated pressure for this filter,
if needed a Pressure Reduction Valve should be installed upstream of the filter’s water inlet port.
➢Please note that the maximum working pressure indicated at the filter’s specifications table includes the pressure caused by fluid
hammer and pressure surge effects.
Civil Engineering
➢Make sure that the filter installation is done by Amiad qualified technicians.
➢Make sure that any civil engineering work at the installation site such as construction, lifting, welding, etc. is done by qualified workers /
technicians / contractors and in accordance with the relevant local standards.
➢While using lifting equipment, make sure that the filter or the lifted part is chained securely and in
a safe manner.
➢Do not leave lifted equipment if there is no necessity. Avoid working below lifted equipment.
➢Wear a safety helmet while using lifting equipment.
➢Make sure that the flooring is sloped for drainage and to avoid accumulation of liquids.
Commissioning
➢Read carefully the Commissioning and the First Start-up Operation instructions prior to any attempt to operate the filter.
➢In order to achieve maximum performance and smooth operation of the filter it is crucial to perform the Startup and First Operation
procedures exactly as described in this manual.
➢Commissioning the filter should be done by an authorized Amiad technician, do not attempt to commission the filter unaccompanied
since this may lead to undesired damage and may affect your warranty coverage.
Operation and Control
➢Do not operate the filter before reading carefully and being familiar with its operation instructions.
➢Observe the safety stickers on the filter and never perform any operation contradicting the instructions given.
➢Never operate or use the filter for purposes other than its original design and operational envelope.

SAF 6000 910101-000107 07.2019 Page 7 of 28
Maintenance
Before any maintenance or non-regular operation please read the following:
➢Servicing the filter should be done only by technicians authorized by Amiad.
➢Disconnect the filter from the power supply and lock the Main Power Switch.
➢Disconnect the compressed air supply, release the residual pressure and lock the Pneumatics Main Valve.
➢Disconnect the filter from the water system by closing and securing the Manual Inlet Valve. In cases where the downstream piping
network is pressurized, close and secure the Manual Outlet Valve also.
➢Release the residual water pressure by opening the Pressure Release / Drainage Valve.
➢Empty the filter by opening the Drainage Valve.
➢In hot water systems wait till the filter components cool off to a safe temperature.
➢Place warning signs around the work area as required by the local standards and procedures.
➢Inspect the filter’s safety stickers and replace any damaged or faded sticker.
Mechanical
➢When working on the filter use only appropriate standard tools.
➢Always open and close valves slowly and gradually.
➢Remove grease and fat material residues in order to avoid slipping.
➢Before disconnecting the filter from the water supply, electricity and pneumatics and before releasing the filter’s residual pressure do
NOT:
oloosen or unscrew bolts
oremove any protection cover
oopen any service port flange
➢Avoid splashing and water leakage so as to minimize slippage, electrification or damage to the equipment, caused by moisture.
➢While using lifting equipment, make sure that the filter or the lifted part is chained securely and in
a safe manner.
➢Do not leave lifted equipment if there is no necessity. Avoid working below lifted equipment.
➢Wear a safety helmet, goggles, gloves, and any other personal safety equipment required by the local standards and regulations.
➢Human entry into a filter must be done in accordance with the relevant local safety instructions, standards and regulations for working in
hazardous environment.
➢Manual cleaning of filter media using high water pressure or steam should be performed in accordance with the cleaning system
instructions, the local standards and regulations and without endangering the operator or the vicinity
➢Manual cleaning of filter element using acid or other chemical agents should be performed in accordance with the relevant material
safety instructions, the local standards and regulations and without endangering the operator or his vicinity.
Before returning to regular operation
➢Re-assemble any protection covers or protection mechanisms removed during service or maintenance operations.
➢Make sure that all the tools, ladders, lifting devices, etc. used during the maintenance procedures are taken away from the filter area and
stored
➢In order to return the filter to regular operation, follow the First Start-up Operation instructions as detailed in your user manual.
➢For filters used in potable water systems it is required to disinfect the filter according to the local water authority standards and
regulations before putting it back to service.

Dimensional Drawing

SAF 6000 219168 02.2019 Page 9 of 28
Description of Filter Operation
Filtering process:
The SAF-6000 is a sophisticated yet easy-to-operate automatic filter, with a self-cleaning mechanism driven by an electric motor. The
SAF-6000 is designed to work with various types of screens in filtration degrees from 10 to 500 micron, and is available in 6", 8" and 10"
inlet/outlet diameter.
The water enters through the inlet pipe into the coarse screen from outside in, and through the fine screen from inside out. The
"filtration cake" accumulates on the fine screen surface and creates head loss to develop.
The coarse screen is designed to protect the cleaning mechanism from large dirt particles. Usually, it does not accumulate large
quantities of suspended solids and is not cleaned automatically.
Self-cleaning process:
The SAF-6000 initiates the self-cleaning process when either the pressure differential across the screen reaches a pre-set value or the
flush timer reaches its preset timed interval.
The fine screen filter element is cleaned by the suction scanner, which rotates in a spiral movement while removing the filtration cake
from the screen, and expels it out through the exhaust valve.
A 2-way (fwd/rev) drive unit that is attached to the scanner by a threaded shaft rotates the scanner and provides the linear movement.
The exhaust valve is activated for the duration of the cleaning cycle by a 3-way solenoid. During the 20 seconds self-cleaning process,
filtered water continues to flow downstream.

SAF 6000 910101-000107 07.2019 Page 10 of 28
System Operation modes:
The filtration system may be found in one of the following modes:
1. Filtering mode: This is the normal operating status. The flush mode is idle and the power light on the control board is lit.
2. Flush mode: The motor and exhaust valve activate according to the previously described self-cleaning process.
3. Continuous flushing mode: It is possible to activate the self-cleaning mechanism continuously by setting the SW1 switch in the
control board to "CONT." position.
4. Malfunction mode: If the filter malfunctions, the self-cleaning operation stops, the malfunction light on the control board is turned
on and a 24V AC external output is activated.
The filtration system enters a malfunction mode under any of the following conditions:
1st. A continuous signal from the pressure differential switch longer than the PD fault time-out (default value=15 minutes) indicates
that the filter is unable to clean itself.
2nd. The motor Over Load protector was activated, either manually or due to actual over load.
3rd. Limit Switch malfunction - (usually, simultaneous activation of both limit switches).
Initiation of self-cleaning:
The filter initiates the self-cleaning process under any one of the following conditions:
1. PD flush - The Pressure Differential Switch (PDS) closes a free potential contact signal when the pressure differential across the
screen reaches the pre-set value (usually 0.5 bar =7 psi). The control board registers the signal and activates the flushing cycle.
2. Test flush - Manually pressing the "TEST" push button on the control board door activates a single flushing cycle.
3. Timed flush - SW1 must be in the DP/Time position. The T1 timer in the control panel activates the flushing cycles at time intervals,
regardless of the pressure differential. The timer resets after every flushing cycle. The PD flush mode is active in this mode as well.
4. Continuous flush - SW1 must be in cont position. In this mode the filter flush continuously. This mode is for use in extraordinary
circumstances and for a limited time. Please consult with the manufacturer regarding the uses of this mode.
Control system:
Two types of control boards are available: PLC Type and Relay Type. See Appendix A or B for details.

SAF 6000 910101-000107 07.2019 Page 11 of 28
Installation
Design recommendations:
1. Often, flow increases and pressure drop dramatically during fill-up of a water system. In this case, a pressure-sustaining valve
installed downstream of the filter will ensure the minimum required pressure for the filter and a controlled filling-up of the line.
2. If constant water flow is required even during maintenance, it is recommended that a manual or automatic by-pass be installed.
Isolating valves will be used to isolate each filter unit.
3. In applications where the water quality periodically worsens, it is possible to operate an emergency flush program. In order to do so,
an automatic Down Stream valve must be installed. For details, please consult the manufacturer.
Installation instructions:
1. Install the filter horizontally in a manner that will allow convenient access and enough space to dismantle the filter for maintenance
purposes.
2. Check the direction of flow according to the arrows marked on the filter housing.
3. It is recommended to install a mechanical non-return valve downstream of the filter.
4. The exhaust line (minimum 2” diameter) should be designed so that it creates minimal resistance to flow of 11 m3/h (50 USgpm).
5. If the system is designed to operate with working pressure higher than 6 bar (85 psi), it is recommended that a manual throttling
valve be installed on the exhaust line, in order to enable regulation of the flushing flow rate.
6. The user should arrange suitable lighting at the area of the filter to enable good visibility and safe maintenance.
7. The user should arrange suitable platforms and safety barriers to enable easy access to the filter without climbing on pipes and other
equipment.
IMPORTANT !!
Prevent static back-pressure or reverse flow through the filter.
Install a manual or a hydraulic valve downstream of the filter.
Electric wiring
1. Install the control board in a dry and protected place (It is possible to order a special control board for severe out-door installation).
For single phase or DC power supply, please refer to the electrical drawing inside the control board.
2. Power connection to the control board:
a. Connect a three-phase power source through a semi-automatic switch, or 16 Amp. fuse to the L1 L2 L3 connectors at the terminal
strip in the control board.
b. Ground the control board.
3. Power connection to the motor Connect the drive unit to the control panel by means of a cable of 4 x 1.5mm2 for a distance of up to
5m. For distance of up to 10m a cable of 4 x 2.5mm2 should be used.
Use a long enough cable to allow the drive unit to be removed and placed near the filter for maintenance, without having to
disconnect it from the cable. (It is recommended that this installation meets or exceeds local or national electrical codes, this is a
"high" voltage connection).
4. Control wiring: Connect the terminals between the junction box and the control panel using 6 x 1.5 mm (16 AWG) wires in flex-
conduit. The numbers on the terminals in the board correspond with those in the junction box.

SAF 6000 910101-000107 07.2019 Page 12 of 28
Start-up and first operation
1. Make sure all the electric wiring is correct, according to the enclosed drawings.
2. Turn on control power and 24VAC but leave OL protector off. Verify that the limit switches are wired correctly by manually toggling
them. Monitor the appropriate inputs according to the wiring diagram accompanying the control panel. Proceed to next step only
after verifying correct wiring of all limit switches in the system.
3. CHECK ROTATION: The suction scanner shaft should turn clockwise (CW) and move towards the filter housing until it reaches limit
switch "A". If the motor rotates in the opposite direction (CCW), turn off the electricity immediately and change the direction of
the motor rotation by changing between two phases.
4. The motor must stop when the limit switch plate reaches limit switch "A" (opening the NC circuit).
5. Operate a "dry" flushing cycle by pressing on the "TEST" push button. Check that the flushing cycle runs as described in the “Self-
cleaning process” paragraph in this manual.
6. Open the inlet valve to the filter, leaving the outlet valve closed or with an open by-pass valve (This will keep the flow through the
filter to a minimum), and operate a flushing cycle.
7. Check that the exhaust valve opens and all stages of the flushing cycle perform properly. Attend to leakage, if any.
8. Close the 1/4" valve at the low pressure sensing port of the pressure differential switch for 5 seconds. The PDS hand will move to
the red area and the filter will start the flushing process. Re-open the 1/4" valve.
9. Gradually open the outlet valve and/or close the by-pass valve. Operate the filter under the designed hydraulic conditions.
10. Set the flushing interval timer (T1) for 6-8 hours.
11. Check and re-tighten all bolts after the first week of operation.
* When using Control board type "C" (Relay type) it is necessary to press the "Test" push button in order to start the motor operation for
the first time.

SAF 6000 910101-000107 07.2019 Page 13 of 28
Maintenance
General inspection
Initiate a flush cycle by closing the 1/4" valve at the low pressure sensing port of the pressure differential switch for 5 seconds. Check
that the exhaust valve opens, that the scanner moves properly, and when it reaches the limit switch - verify that the exhaust valve closes.
Weekly maintenance:
1. Check that the filter operates properly, following a general inspection.
2. Clean the 3/4" filter (close the 3/4" valve and operate a flushing cycle in order to release pressure and then open the bowl).
3. Check that there is grease on the drive shaft, and drive bushing. Add grease if necessary.
4. Take care of any leakage from the scanner shaft. If necessary, tighten the sealing nut (17 on page 24) or replace the sealing nut
internal O-ring (18 on page 24)
Changing the sealing nut internal O-ring:
1. Close the inlet valve to the filter and release the pressure.
2. If the Suction Scanner is in the outer position, operate a flushing cycle and bring it to the inner position.
3. Remove the Split pin (13) and pull out the connecting pin (12).
4. Operate a flushing cycle.
5. Stop the motor operation when the drive shaft reaches half way of its movement. The drive shaft is now separated from the
Suction Scanner.
6. Unscrew the sealing nut (17 on page 24).
7. Remove the used internal O-ring and clean the O-ring seat.
8. Insert a new O-ring (18 on page 24)
9. Tighten the sealing nut (17 on page 24).
10. Re-connect the drive shaft to the suction scanner shaft.
11. Operate the control board and open the filter inlet valve.
Maintenance prior to long term shutdown (end of season):
The following must be done if the filter will not operate for more than a month.
1. Operate flushing cycle (If possible, with a closed downstream valve).
2. Disconnect the control board from the power.
3. Release pressure from the filter.
4. Grease the drive shaft and the drive bushing.
5. Clean the 3/4" control filter.
6. Clean the coarse screen through the service port.
Maintenance prior to renewing filter operation:
1. Connect the control board to the mains.
2. Check proper operation of the filter.
3. Grease the drive shaft and the drive bushing.
4. If necessary change the sealing nut internal O-ring.
IMPORTANT!!
THE DRIVE SHAFT MUST BE LUBRICATED WITH HEAVY-DUTY, WATER RESISTANT GREASE THAT WILL NOT OXIDIZE. (SHELL, DARINA
EP-2 OR SIMILAR).

SAF 6000 910101-000107 07.2019 Page 14 of 28
Cleaning the coarse screen: (See drawing on this page)
1. Close the filter inlet valve.
2. Release pressure from the filter by operating a flushing cycle.
3. Remove the service lid (25) by disconnecting the bolts (26) from the nuts (28)
1. Clean the coarse screen:
a. To remove large particles, insert your hand into the coarse screen area.
b. To remove fine particles and organic matter, rinse the screen. Afterwards, partially open the inlet valve and let water
flow out.

SAF 6000 910101-000107 07.2019 Page 15 of 28
Troubleshooting
Before beginning any troubleshooting, carefully read the safety instructions chapter of this document and make sure that all the workers at the
filtration site are fully aware of and comply with these and any other local safety instructions.
The filtration system may enter a malfunction mode in the following cases:
Symptom
Remarks and Actions
Fault due to continuous signal from the
pressure differential switch for duration of
more than 15 minutes.
The fault indication lamp is lighted in red
This fault means that the self-cleaning process is not successful.
This fault may be caused by one of the following reasons:
A. The filter is clogged due to heavy dirt load or too high water flow rate.
Close the filter’s downstream valve.
Press the reset button to reset the fault mode. The fault indication lamp
is turned off.
Perform few consecutive manual flush cycles and monitor the PD signal.
Once the filter is clean gradually open the downstream valve and
monitor the PD and the flow-rate. Make sure that the filter doesn’t
exceed its designated flow-rate.
B. The PD switch is faulty.
Ask your qualified electrician to check the PD connections and operation.
Replace the switch if found faulty.
The motor protector was activated
The fault indication lamp is blinking in red
This fault means that the motor was operated under too high load
Note: All the following checks and actions should be done by a qualified electrician
only.
A. Check the motor power consumption when not loaded.
B. Check the limit switches for correct operation and verify that each one of
them stop the motor at its designated point.
C. Verify 3 phase 380VAC power supply to the control board and the motor.
D. Disconnect the drive unit from the suction scanner shaft and verify free
turning of the suction scanner.
Note: If during this fault a request for flushing is received (Manual, Time or DP) the
blinking lamp switches to constant red.
Malfunctioning limit switches
The fault indication lamp is blinking in red
Faulty limit switch may not stop the motor at the right point and therefore the motor
protection may be activated.
Receiving signal from both limit switches at the same time causes fault
A. Check that the limit switches are not mechanically stuck.
B. Ask your qualified electrician to check the wiring and the functionality of the
limit switched.
Note: If during this fault a request for flushing is received (Manual, Time or DP) the
blinking lamp switches to constant red.
The fault indication lamp is blinking in red
after the reset button is pressed
This means that the mechanical/electrical fault still exists. (Overload or Limit
Switches faults)

SAF 6000 910101-000107 07.2019 Page 16 of 28
Dismantling and Assembling the Filter Components
Prior to opening the filter perform a flush cycle by pressing the "TEST" push button.
The Fine screen
Dismantling:
1. Close the filter inlet and outlet valves and release the pressure.
2. Press the "TEST" push button and disconnect the power when the scanner is in the middle of its track (When the limit switch disc is
half-way between the two limit switches).
3. Release the lid bolts (17) from their nuts.
4. Locate the centering sleeves, remove them from their holes and remove the lid (16).
5. Remove the seal (9) from the screen (10) and pull it out of the filter housing.
6. Remove the second seal from the screen.
Assembly:
1. Put the screen seal (9) on one end of the screen (10).
2. Insert the screen (10) into the filter housing (1). Make sure the screen is correctly positioned, all the way in.
3. Put the second seal (9) on the other end of the screen.
4. Assemble the lid on the filter housing. Make sure the screen and seal are correctly positioned in the lid seating.
5. Insert the centering sleeves into two opposite holes in the lid flange.
6. Insert bolts (17) with the discs on the lid side.
7. Place the discs and the nuts on bolts (8) on the housing side. Do not tighten them yet.
8. Tighten the bolts (17) in a controlled and balanced method.
9. Open the filter inlet and outlet valves and operate the control board.
10. Check proper operation of the filter.

SAF 6000 910101-000107 07.2019 Page 17 of 28
The suction scanner:
Dismantling:
1. Begin the dismantling procedure as per 1-6 in the chapter "dismantling the fine screen".
2. Partially release the tightening nut (17 on page 24).
3. Pull out the drive shaft connecting pin (12) by first removing the split pin (13).
4. Pull the suction scanner (11) in a spiral movement out of the filter housing.
Assembly:
1. Insert the suction scanner (11) into the screen (10). Make sure that the scanner shaft (2 on page 25) passes through the tightening
nut (17 on page 24).
2. Insert the suction shaft (2 on page 25) into the drive shaft (6 on page 24). Make sure the holes in the above shafts are parallel.
3. Insert the connecting pin (12) to the parallel hole of the suction shaft (2 on page 25) and the drive shaft (6 on page 24) and lock it
with the split pin (13).
4. Put the screen seal (9) on the end of the screen.
5. Continue to assemble the parts as per 1-10 in the chapter "Assembling the fine screen".

SAF 6000 910101-000107 07.2019 Page 18 of 28
The drive shaft housing and coarse screen:
Dismantling:
1. Close the inlet and outlet valves of the filter and release pressure.
2. Disconnect power supply from the control board.
3. Remove the cover (34) from the drive shaft housing (5) by unscrewing the wing nuts. Pull out the plug from the solenoid coil, remove
the limit switch sling (9 on page 24) from the drive shaft housing by unscrewing the bolts (14 on page 24).
4. Carefully put the limit switch sling near the filter to avoid any damage to the electrical wires.
5. Disconnect the pilot tube from the solenoid valve and connector.
6. Disconnect the drainpipe from the exhaust valve.
7. Remove the drive unit (28) from the drive shaft housing (5) by unscrewing the nuts from the bolts (29). By doing so, the drive shaft
key (27) will be pulled out.
8. Pull out the connecting pin (12) by first removing the split pin (13).
9. Turn the drive shaft (6 on page 24) using a suitable spanner in order to release it from the scanner shaft (2 on page 25).
10. Partially release the tightening nut (17 on page 24).
11. Dismantle the drive shaft housing (5) from the filter housing (1) by unscrewing the bolts (6).
12. Pull out the flushing chamber (3) and the coarse screen (2).
Assembly:
1. Insert the coarse screen (2) into its place in the filter housing.
2. Apply some grease on the O-ring and insert the flushing chamber into its place. Make sure the scanner pipe enters into its bearing.
3. Install the drive shaft housing (5) into the filter housing (1) with the bolts (6) and tighten them.
4. Connect the drive shaft (6 on page 24) to the scanner shaft by using the connecting pin (12) and split pin (13).
5. Make sure that the drive shaft key (27) is fitted properly in the gearbox. Thread the drive shaft through the drive unit and note that
the drive shaft groove is adjusted in accordance with the drive shaft key.
6. Connect the drive unit (28) to the drive shaft housing (5) with the bolts (29) and tighten them.
7. Connect the pilot tube between the solenoid valve (66) and the connector.
8. Assemble the limit switch sling in its place and push in the plug of the solenoid coil.
9. Connect the drainpipe to the exhaust valve.
10. Operate the control board and make sure the filter is operating properly.
11. Open the inlet and outlet valves and recheck filter operation.

SAF 6000 910101-000107 07.2019 Page 19 of 28
Parts Schedule –Saf-6000 Filter Section 1
No.
Description
Qty
1
SAF-6000 Housing
1
2
Coarse Screen (SAF-6000)
1
3
Flushing Chamber Assembly SAF-6000
1
4
O-Ring P2-448 SAF-6000 Drive Unit Adaptor
1
5
Drive Shaft Assembly SAF-6000
1
6
HEX BOLT PARTIAL THR M16X65 Z.PLT C/ST
8
7
Flat Washer M16 DIN125 Zinc Plated C/St
32
8
Hex Nut M16 Zinc Plated C/St DIN934
16
9
Hydraulic Seal AM-03 NR (SAF Screen)
2
10
Weavewire St316 6000sq.cm Screen XXXmic for SAF-6000
1
11
Scanner Assembly Improved SAF-6000
1
12
Connecting Pin (SAF-6000)
1
13
Split Pin 2X20 DIN 94 S/ST304
1
14
O-Ring Seal P2-459 (SAF-6000 Lid) NBR
1
15
Centering Sleeve Housing-Lid (SAF)
2
16
SAF-6000 Lid
1
17
Hex Bolt Partial Thrd M20x80 Z.Plated c/st DIN931
12
18
Flat Washer M20 DIN125 Zinc Plated C/ST
24
19
Hex Nut M20 Zinc Plated C/ST DIN934
12
20
Upper Bearing Insert
1
21
Leading Shaft SAF-6000
1
22
O-Ring Seal P2-128 (Sealing Insert)
1
23
Tightening Plug (Leading Shaft) SAF-6000
1
24
O-Ring Seal P2-443 (6" Service Lid)Nbr
1
25
Hex Bolt Partial Thread M16X60 Z.PLT C/ST
8
26
Smooth Blind Flange 6" BSTD Coated
1
27
Drive Shaft Key (SAF)
1
28
Drive Unit SAF-6000 220/440VAC 3Ph 0.25KwX1400 RMI50 1/49 71 B5
1
29
Hex Bolt Full Thrd M8x40 Z.Plated c/st DIN933
4
30
Flat Washer M8 DIN125 Zinc Plated C/St
8
31
Spring Washer M8 DIN127 Zinc Plated C/St
4
32
Hex Nut M8 Zinc Plated C/St DIN934
4
33
Socket Head Cap Screw M8x20 S/St304 DIN912
2
34
SAF-6000 Drive Shaft Housing Cover
1
35
Drive Shaft Cover (PVC) SAF
1
36
Aluminum Amiad Nameplate, CE, EN
1
37
Rivet Blind 3x6 DIN7337 S/ST316
4

SAF 6000 910101-000107 07.2019 Page 20 of 28
No.
Description
Qty
38
Manometer Valve 1/4" W/ Drain
1
39
L-Connector 1/4"FX1/4"M Nickel Plated
2
40
T Connector 1/4"X5/16"X5/16" Brass
1
41
T-Connector 1/4" FxFxM (Brass)
1
42
L-Connector 5/16"X1/8"
4
43
Valve 3-Way 1/4"
1
44
Pressure Gauge 16 Bar 1/4" Back Inlet
1
45
Connector 5/16"x1/4"
2
46
Insrtumentation Combined Bracket SAF
1
47
Hex Bolt Full Thread M6x20 S/St304 DIN933
2
48
Flat Washer M6 DIN125 S/ST316
4
49
Spring Washer M6 DIN127 S/ST316
2
50
Hex Nut M6 S/ST316 DIN934
2
51
Phillips Pan Machine Screw M5x16 S/St304 DIN7985
4
52
Flat Washer M5 DIN125 304
4
53
Hex Nut M5 304 DIN934
4
54
Connector 5/16"x1/8"
1
55
L-Connector 3/4" F/M Galvanized
1
56
Ball Valve 3/4" M/F (BRASS)
1
57
Raccord Nipple 1/4" for 3/4" Filter
1
58
O-Ring Seal P2-112 NBR
1
59
Raccord Nut 3/4" for 3/4" Filter
1
60
L-Connector 5/16"X1/4"
2
61
Control Tube 5/16" Nylon Air Brake
1
62
Hydraulic Valve
1
63
Pressure Check Point Connector 1/4"X1/4"
1
64
Solenoid
1
65
Electrical Junction Box (SAF)
1
66
Presostat SUB-AS. Midwest W/O Fitting
1
67
3/4"Black Filter AC,W/O Valve, Nylon Screen 130 Mic
1
* Catalogue numbers may differ according to filter diameter, flange standards or electric specifications.
