Amica AWC151 User guide

AWC151
AWC301
AWC601
Wine coolers
Use and maintenance

2| Instruction Manual
Contents
3 Important information
6 Before first use
8 Use and controls
13 Bottle Storage
15 Care and cleaning
17 Troubleshooting
19 Installing the wine cooler
23 Reversing the door
23 Adjusting the plinth
24 Electrical information
25 How to connect an alternative plug
26 Energy eciency information

Instruction Manual | 3
Important
The CDA Group Ltd cannot be held responsible for injuries or
losses caused by incorrect use or installation of this product.
Please note that The CDA Group reserve the right to invalidate the
guarantee supplied with this product following incorrect installation
or misuse of the appliance or use in a commercial environment.
This appliance is not designed to be used by people (including
children) with reduced physical, sensorial or mental capacity, or
who lack experience or knowledge about it, unless they have
had supervision or instructions on how to use the appliance by
someone who is responsible for their safety.
Under no circumstances should any external covers be
removed for servicing or maintenance except by suitably
qualified personnel.
Do not use the appliance if the plug, the mains cord or the
appliance itself is damaged. If the mains cord is damaged, you
must have it replaced by the manufacturer, or an authorised
service centre or similarly qualified persons in order to avoid a
hazard.
Children should be supervised to ensure that they do not play
with the appliance. Keep the mains cord out of the reach of
children. Do not let the mains cord hang over the edge of the
table or worktop on which the appliance stands.
This refrigeration appliance is intended for use as a built-in
appliance.

4| Instruction Manual
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist Customer Care in the event of a fault with your
appliance and to register your appliance for guarantee purposes.
Appliance model
Serial number
EU Declarations of Conformity:
This appliance has been designed, constructed and marketed in
compliance with safety requirements of EU Directive 2014/35/EU
(Low voltage) and requirements of Directive 2014/30/EU (EMC).
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EU.
Please render the appliance unusable before disposal. This
includes removing the plug and breaking the door fixings to
prevent children being trapped inside the appliance during play, or
any other risk of injury.
At the end of its working life, the product must not be disposed
of as urban waste. It must be taken to a special local authority
dierentiated waste collection centre or to a dealer providing this
service.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health deriving
from inappropriate disposal and enables the constituent materials
to be recovered to obtain significant savings in energy and
resources. As a reminder of the need to dispose of household
appliances separately, the product is marked with a crossed-out
wheeled dustbin.

Instruction Manual | 5
•Repairs carried out by unqualified persons may seriously
endanger the appliance user
•Pursuant to Commission Regulation (EU) 2019/2019, The
minimum availability period for spare parts necessary to
repair the appliance is 7 or 10 years depending on the type and
purpose of the spare part
•The list of spare parts and the ordering procedure are available
on the websites of the manufacturer, importer or an authorised
representative
• The minimum warranty period for the appliance oered by the
manufacturer, importer or authorized representative is given in
the warranty card
•The warranty shall be void if you make any independent
adaptations or alterations, tamper with seals or other appli-
ance safety devices or its parts or interfere with the appliance
contrary to operating instructions
For more information about the product, please refer to the EU
EPREL Product Database at https://eprel.ec.europea.eu.
Alternatively you can use your mobile device to scan the QR code
on the energy label or enter the product model listed on the
energy label in the EPREL search engine.

6| Instruction Manual
Before first use
You must allow the appliance to settle for at least twenty four
hours prior to switching the power on.
It is recommended that you remove all internal and external
packaging and clean the interior of the appliance prior to first use.
We recommend that you use a solution of bicarbonate of soda and
warm water and then thoroughly dry the interior.
The appliance may have an odour to it at first use. This will
disappear as the appliance cools.
Please note:
• The appliance will work continuously until it gets to the correct
temperature. Continuous noise from the compressor and
refrigeration system is normal
• If the appliance is switched o, you should allow five minutes
before switching it on again to prevent the risk of unnecessary
damage to the compressor
•The LED display may not show the selected temperature whilst
the appliance first gets to the correct temperature. This is
normal, and the display will be corrected automatically once the
appliance has run for a few hours
• If the appliance does not have a freezer compartment ( )
it is not suitable for freezing foodstus.

Instruction Manual | 7
Use
• Only store wine in sealed containers
• Do not overload the cabinet
• Only open the door when necessary
• Do not cover the shelves with aluminium foil or anything else that
will prevent air from circulating around the cabinet
• To prevent damage to the door seal, ensure the door is fully
open before removing the shelves
• This is a self-defrosting appliance. The compressor will not run
during the thirty minute defrost cycle
•Do not pull the shelves beyond the anti-stop position
(approximately one third out) when fully loaded
•This appliance is intended to be used exclusively for the storage
of wine
•In the event of a power failure, leave the door closed as much
as possible to maintain the internal working temperature. Should
the power failure continue for a prolonged period, you should
take steps to protect the contents of the wine cooler against a
rise in temperature. The wine cooler will remember the selected
temperature settings and revert to these settings once the power
is restored
This appliance is suitable for use in an extended temperature
climate (ST) and has a normal operating ambient temperature of
16-38°C. Use of the appliance below 10°C may cause performance
issues that are not indicative of a fault. Normal operation will
resume once the appliance is within the specified range.

8| Instruction Manual
Use and controls
Key:
1. Power button
2. Light button
3. "+" button
4. "-" button
1 2 3 4
AWC601
1 2 3 4 5 6 Key:
1. Power button
2. Upper zone
“+” button
3. Upper zone
“-” button
4. Lower zone
“+” button
5. Lower zone “-”
button
6. Light button
To switch the power on/o
• Press and hold the power button for one second to switch the
wine cooler on
• Press and hold the power button for five seconds to switch the
wine cooler o
To change the temperature
• Press the “+” or “-” buttons for the appropriate zone until the
required temperature is shown on the display
• The preset temperature is 8°C/46°F for left/upper zone and
12°C/54°F for right/lower zone
AWC151 & AWC301

Instruction Manual | 9
Use
• To change the temperature display from Fahrenheit to Celsius,
or Celsius to Fahrenheit, press and hold the light button for five
seconds
• To view the set temperature, touch the appropriate “+” or “-”
button at any time and the set temperature will flash in the LED
display for five seconds
• The display shows the current internal temperatures when the
wine cooler is on
Optimal temperature selection
Whilst wine is best stored at temperatures between 13°C and 15˚C,
your wine can also be stored at drinking temperature, for red wine
this is between 15°C and 17˚C, and for white wine between 12°C
and 13˚C.
To use the internal light
• Press the light button to switch the light on or o.
Please note:
The temperature in the lower zone must be set either the same
as or higher than the temperature in the upper zone. For optimal
performance, the temperatures in the two zones should dier by at
least 4˚C.

10 | Instruction Manual
Use
Internal Humidity
The wine coolers are equipped with a humidity system to maintain
optimal humidity within the wine cooler.
Fill the humidity reservoir approximately 3/4 full with water.
Place the reservoir on the runners on the top shelf as shown in fig.4.
Ensure it is located correctly to prevent water spillage. Check the
water level regularly and refill if required.
Fig. 4
Temperature display
The temperature display will show the current internal temperature.
The display flashes:
• When a dierent temperature is being set
• If the internal temperature is +/- 5˚ away from the set temperature
This serves as a warning to prevent damage to the contents of the
appliance should the temperature be too high

Instruction Manual | 11
Use
Silent mode
Once the required temperature is reached, the appliance will run
without the fan. The wine cooler is factory set to silent mode. To
change to dynamic cooling mode, touch and hold the "-" button for
approximately five seconds (left hand “-” button on AWC601). The
wine cooler will beep five times to confirm dynamic cooling is on.
Dynamic cooling mode
The fan cycles on and o to circulate the air even after the required
temperature is reached. This ensures consistent humidity and
temperature distribution in the wine cooler, creating perfect
conditions for long term storage. Using the dynamic mode increases
the level of noise in operation. To change to silent mode, touch
and hold the "+" button for approximately five seconds (left hand "+"
button on AWC601). The wine cooler will beep three times to confirm
silent mode is on.
Sabbath mode
Sabbath mode is available for the observance of certain religious
holidays. This will switch o the displays, interior light and audible
alarms. The cooling process will continue. To switch the Sabbath
mode on, touch and hold the power and light keys simultaneously
for five seconds. The indicator light will flash four times and confirm
the Sabbath mode is on. Sabbath mode will switch o automatically
after 48 hours, but to switch the Sabbath mode o at any time,
touch and hold the power and light keys simultaneously for five
seconds.

12 | Instruction Manual
Use
Door alarm
The wine cooler is equipped with an alarm that will sound if the
door is left open for more than 60 seconds. To switch o the alarm,
press the power button. If the temperature has risen beyond the
set temperature, the display will flash until the zone has returned to
the required temperature.
Interior light
The wine cooler has two options for the interior lights. To change
from one option to the other, press the light button.
• Display mode - This mode will leave the interior light on
constantly, allowing you to see the contents of the wine cooler
at a glance at any time
• Energy saving mode - This mode only switches on the interior
light when the door is opened

Instruction Manual | 13
Bottle storage
To achieve the most eective preservation of your wine for
the longest time possible and avoiding any waste, position the
products as shown in the diagrams in this section. In addition, this
figure illustrates the layout of drawers, baskets and shelves, which
allows the most ecient use of energy.
Optimal temperature and storage conditions will extend product
shelf life and optimize electricity consumption. Optimal storage
temperature should be stated on the food product packaging.
AWC151
300.5
AWC301

14 | Instruction Manual
AWC601
Climate Range
The information about the climate range of the appliance is
provided on the rating plate. It indicates at which ambient
temperature (that is room temperature in which the appliance is
working) is optimal for the operation of the appliance.
Climate class Allowable ambient temperature
SN Extended Temperate This refrigeration appliance is intended
for use at an ambient temperature ranging
between 10°C and 32°C
N Temperate This refrigeration appliance is intended
for use at an ambient temperature ranging
between 16°C and 32°C
ST Sub Tropical This refrigeration appliance is intended
for use at an ambient temperature ranging
between 16°C and 38°C
T Tropical This refrigeration appliance is intended
for use at an ambient temperature ranging
between 16°C and 43°C

Instruction Manual | 15
Care and cleaning
IMPORTANT:
Always disconnect the appliance from the mains electrical
supply before any cleaning or maintenance.
Removing the shelves
(Applicable to AWC301 & AWC601)
•To remove a shelf from the
wine cooler, first remove all
bottles from the shelf, then
pull the shelf forwards until
the groove on either side
of the shelf is level with the
plastic peg on either side of
the cabinet (as shown in fig 5).
Then lift the shelf up and pull forwards
•To replace the shelves, follow the steps above in reverse order
Cleaning
•Do not use abrasive products or detergents. After washing,
rinse and dry thoroughly
•The exterior of the appliance and the door seal should be
cleaned using mild soapy water and dried thoroughly
•The interior cabinet should be cleaned using a solution of
bicarbonate of soda and lukewarm water
•Clean the shelves separately by hand using soap and water. Do
not put them in the dishwasher
•Ensure that the cloth is only moist when cleaning the control
panel and electrical parts, and that all water is thoroughly
dried o before reconnecting the power
Fig. 5

16 | Instruction Manual
Care and cleaning
•Once cleaning is complete, reconnect the mains electrical
supply
• If the appliance is not to be used for prolonged periods of
time, unplug and clean the appliance thoroughly. The door
should be left slightly ajar to prevent the formation of odours or
condensation
Temperature alarm
If the temperature rises or falls outside the set temperature range,
an alarm will sound and the display will flash.
This may be because:
•The wine cooler has not yet reached the set temperature (when
first switched on)
•There has been a power failure
•The wine cooler has been overloaded
•The door is not closed properly

Instruction Manual | 17
Troubleshooting
If you have any problems with your appliance, you should check
the troubleshooting guide prior to calling Amica Customer Care
to prevent unnecessary service calls and potential cost.
If the appliance is not working, check
• There is power to the appliance
• The house fuses or circuit breakers are intact and the fuse in the
plug has not blown
• The plug socket is functioning correctly. To check this, plug
another electrical appliance in to see if the socket is working
• The ambient temperature is between 16°C to 32°C
The appliance is working, but not very well, check
• The appliance is not overloaded
• The thermostat is set to an appropriate temperature
• The door is closing properly
• The door gasket is sealing properly
• There is enough ventilation at the side and rear walls
• The ambient temperature is between 16°C to 32°C
The appliance is noisy, check
• The appliance is level and stable
• The cooling gas will make some noise, even when the
compressor is not running
• During operation, it is normal for the fan to run, even when the
compressor is not running

18 | Instruction Manual
Troubleshooting
The light does not work, check
• There is power to the appliance
• The house fuses or circuit breakers are intact and the fuse in the
plug has not blown
• The light button is not set to o
Please note:
The LED lighting cannot be replaced without a service call. If the
light fails, contact Amica Customer Care.
The door will not close properly, check
• The appliance is level and stable
• If the door has been removed, it may not have been correctly
refitted
• The door seal is dirty
•The shelves are not positioned correctly
The display shows “E1” or “E2”
•The temperature sensor has failed. Please contact Amica
Customer Care

Instruction Manual | 19
Installing the wine cooler
This appliance is intended to be installed in a space between two
units.
The minimum space required is:
AWC151 – 150mm W x 555mm D x 825mm H
AWC301 – 300mm W x 580mm D x 825mm H
AWC601 – 600mm W x 580mm D x 825mm H
Please note: When the product is installed, there should be
a small ventilation gap between the top of the unit and the
underside of the worktop (6 mm or ¼”)
These products should not be installed:
•In direct sunlight
•Adjacent to a heat source (oven or radiator)
•Below a hob unit
Where a continuous plinth is to be used, it is necessary to cut a
section out so that the ventilation slots at the front of the appliance
are not obstructed in any way as per fig 6.
fig. 6

20 | Instruction Manual
Installing the wine cooler
This appliance is designed to fit under worktops between 820 –
890mm in height, using the adjustable plinth plate to ensure that the
feet are concealed from view.
IMPORTANT: Failure to follow the instructions regarding
installation and ventilation may invalidate the warranty supplied
with your appliance.
Installing the handle
IMPORTANT: Do not overtighten the screws, and do not use
power tools to install the handle.
1. Remove the door gasket (2) on the side
you wish to install the handle - you can
see two designated holes for handle
installation.
2. Install the handle (4) tightly as shown
above with two screws (1) and flat
washers (3) provided.
3. Replace the door gasket.
IMPORTANT: Take care when installing the handle not to damage
the door. Any damage caused may not be covered by the
warranty supplied with your appliance.
fig. 7
