Assembly Instructions-C75 Amphenol®
MCX
STRAIGHT CONNECTORS FOR SEMI-RIGID CABLE
Step 1 Prepare cable according to diagram. Remove burrs from
outer/inner conductors of cable.
Step 2 Solder center contact “a” to inner conductor of cable using
Sn60 solder. Contact must butt on dielectric of cable as
shown.
Step 3 Insert contact into body assembly “b” as shown. Holding
body and cable firmly, apply heat as shown and feed solder
(Sn-60) as indicated. Allow to cool. The dimension from the
contact tip to the end of the body should be .006 ±.007.
Contact Connector Body
APPLY HEAT
FEED SOLDER HERE
CONTACT MUST BUTT HERE
c
d
a b
Amphenol Connector Cable Stripping Dimensions, inches (mm)
Number Type RG-/U
cd
919-114J-51SX Straight Jack .086 Semi-Rigid .118 .039
919-120P-51SX Straight Plug .086 Semi-Rigid .100 –
