Amphenol SurLock Plus C10-752785 Series User manual

CABLE ASSEMBLY WORK INSTRUCTION
5.7 & 8.0mm SurLok Plus™Connector Inline Type
Mang and Unmang Work Instrucon
5.7mm & 8.0mm SL+
8.0mm SurLok Plus Connector:
Plug: C10-731951-()
Receptacle: C10-754488-()
5.7mm SurLok Plus Connector:
Plug: C10-752785-()
Receptacle: C10-762231-()

24
Part 1: Keyway Descripon
Minor KeywayMinor Keyway
Master Keyway
ReceptaclePlug
Note: Aempt to unmate the plug and receptacle (without pressing lock buon) by hand to conrm they are properly mated.
Master Keyway
Part 2: Mang Operaon
1. Inial mang: Align the master keyway of the receptacle and plug (skip this step if there is no keyway/key opon), and
push the plug vercally into the receptacle as shown in the diagram.
2. Connue mang plug into receptacle, unl you hear an audible "click" to indicate that the plug and receptacle are fully
mated.

25
Part 3: Unmang Operaon
1. Aer shung down the eleccal current, press the buon and pull the plug horizontally from the receptacle, in the
direcon shown below.
Note: For end use, the separaon acve space required is 129mm minimum, this does not include the acve space for hand
or tool operaon.
Note: This product is not suitable for live mang and unmang. At the same me, it is recommended to add a protecon
mechanism to the equipment to prevent accidental unplugging.
2. Do not deviate from the axis direcon of the receptacle unl unmang is complete in order to eliminate potenal
damage to the connectors.
Buon
129 mm
Axis
Axis

ASSEMBLY WORK INSTRUCTION
8.0 mm Surlok Plus Plug
Part Number:
C10-765467-( )
