AMX AXD-MSP16 User manual

softwire keypads
AMX Softwire Keypads combine attractive design, two-way AXLink control
and simplified installation. Three models are available—MSP8 with 8
buttons, 1 bargraph; MSP16 with 16 buttons, 2 bargraphs and MSP32, 32
buttons, 3 bargraphs. All are styled to match Decora™ wall plates and other
AMX wall panels. Perfect for any surface-mount application, Softwire
Keypads will fit within most US-style gang wall boxes.
The Softwire Keypads include enhancements for the user, designer, and
installer. The LED indicators are located at the left of each button, allowing
the user to see the status while pressing a button. Each panel contains the
full set of switches and LEDs, so the panel can be customized — just change
the keypads.

AXD-MSP8 : SOFTWIRE 8-BUTTON KEYPAD
(FG790-08,-09)
•Provides up to 8 control buttons with LED
feed back and one horizontal 8-segment LED
bargraph display
•Includes custom engraving, button layout,
and overlay
•Mounts into most US-style single-gang wall boxes
•Connects to AXLink control network
WIRING
4-pin AXLink terminal
POWER
12 VDC, 47 mA
DIMENSIONS (HWD)
4.7" x 2.9" x 1.9"
119 mm x 74 mm x 48 mm
WEIGHT
3 oz (90 g)
BEZEL COLORS
White and black
AXD-MSP16 : 16-BUTTON KEYPAD (FG790-16, -17)
•Provides up to 16 control buttons with LED feedback
and two horizontal 8-segment LED bargraph displays
•Includes custom engraving, button layout, and overlay
•Mounts into most US-style two-gang wall boxes
•Connects to AXlink control network
WIRING
4-pin AXlink terminal
POWER
12 VDC, 85 mA
DIMENSIONS (HWD)
4.7" x 4.8" x 1.9"
119 mm x 121 mm x 48 mm
WEIGHT
5 oz (130 g)
BEZEL COLORS
White and black
AXD-MSP32 : 32-BUTTON KEYPAD (FG790-32, -33)
• Provides up to 32 control buttons with LED feed
back and three horizontal 8-segment LED
bargraph displays
•Includes custom engraving, button layout,
and overlay
•Mounts into most US-style three-gang wall boxes
•Connects to AXlink control network
WIRING
4-pin AXlink terminal
POWER
12 VDC, 130 mA
DIMENSIONS (HWD)
4.7" x 6.6" x 1.9"
119 mm x 170 mm x 48 mm
WEIGHT
6 oz (170 g)
Bezel Colors
White and black
softwire keypads
ARGENTINA • AUSTRALIA • BELGIUM • BRAZIL • CANADA • CHINA • ENGLAND • FRANCE • GERMANY • GREECE • HONG KONG • INDIA • INDONESIA • ITALY • JAPAN
LEBANON • MALAYSIA • MEXICO • NETHERLANDS • NEW ZEALAND • PHILIPPINES • PORTUGAL • RUSSIA • SINGAPORE • SPAIN • SWITZERLAND • THAILAND • TURKEY • USA
ATLANTA • BOSTON • CHICAGO • CLEVELAND • DALLAS • DENVER • INDIANAPOLIS • LOS ANGELES • MINNEAPOLIS • PHILADELPHIA • PHOENIX • PORTLAND • SPOKANE • TAMPA
3000 RESEARCH DRIVE, RICHARDSON, TX 75082 • 800.222.0193 • 469.624.8000 • +1.469.624.7400 • 469.624.7153 fax • www.amx.com
100-019-2891 © 2005 AMX Corporation. All rights reserved. AMX and the AMX logo are all trademarks of AMX Corporation. AMX reserves the right to alter specifications without notice at any time.
4.745
[120.5 MM]
[118.7 MM]
4.68
[7.7 MM]
.30
WALL
FROM
[36.1 MM]
1.42
DEPTH
MAX
2.93
4.68
[118.7 MM]
[74.4 MM]
WALL
FROM
.30
[7.7 MM] [36.1 MM]
DEPTH
MAX
1.42
[118.7 MM]
4.68
[166.4 MM]
6.550
[7.7 MM]
FROM
WALL
.30
[36.1 MM]
MAX
DEPTH
1.42
AXD-MSP16
AXD-MSP8
AXD-MSP32
2.93
(74.4MM)
4.745
(120.5MM)
4.68
(118.7MM)
.30
(7.7MM)
from wall
1.42
(36.1MM)
max depth
6.550
(166.4MM)
4.68
(118.7MM)
.30
(7.7MM)
from wall
1.42
(36.1MM)
max depth
4.68
(7.7MM)
from wall
1.42
(36.1MM)
max depth
4.68
(118.7MM)
