Anetic Aid 10233 User manual

Document No. 992040. Issue 4 –22.03.21
Page 1
1. Introduction
These instructions are intended to assist you with the use and maintenance of the
extended arm table. It is important that these instructions are read thoroughly before
using the equipment. The device will be adversely affected and its life expectancy
reduced if the following instructions are not observed.
NOTE: If the extended arm table is damaged or faulty it must be taken out of use with
immediate effect and the fault reported to Anetic Aid, your authorised dealer or
maintenance department. The extended arm table must not be used until the damage
or fault has been repaired.
1.1. Warnings & Cautions
Various warnings and cautions are made throughout these operating instructions.
A WARNING is given when the personal safety of the patient or user may be
affected and when disregarding this information could result in injury.
A CAUTION is given when special instructions must be followed. Disregarding
this information could result in permanent damage being caused to the trolley.
1.2. Intended Use & Contraindications
This product is intended for use within a theatre environment when special access is
required to the arm or hand of the patient.
1.3. Equipment Classification
The equipment referenced in this document is CE marked and has been classified as a
Class 1 Medical Device under the scope of both the Medical Devices Directive 93/42/EEC
and the Medical Device Regulation 2017/745.
1.4. Putting the Extended Arm Table –Light Weight into Service
It is important that the extended arm table is cleaned and disinfected before it is put
into service. Use this manual to check all the functions and refer to the ‘Cleaning and
Disinfecting’ instructions.

Document No. 992040. Issue 4 –22.03.21
Page 2
2. Product Specifications
Key to Fig. 1
1.
Adjustable Support Leg
2.
Adjustable Support Leg Locking Mechanism
3.
Location Boss for Support Leg
4.
Locking Clamp Handles
Dimensions:
Product dimensions
L685mm x W450mm x D165mm
Product weight
6kg
Weight Limit:
Safe working load
25kg (55lbs)
WARNING: Exceeding the maximum specified weight limits could result in
failure of the extended arm table and injury to the user.

Document No. 992040. Issue 4 –22.03.21
Page 3
3. Direct-on Attachment
The extended arm table attaches ‘direct-on’to the trolley by hooking onto the side bar,
see Fig.2. It is designed to fit both British and Euro side rail. To secure the arm table,
rotate the locking clamp handles 90° either clockwise or anti-clockwise; (A) Fig.3.
WARNING: It is recommended both locking clamp handles are in the locked
position before using the product to prevent any possible movement during
surgery.
4. Using the Adjustable Support Leg
The adjustable leg is stored in the clips on the underside of the arm table and can be
used to add extra stability during surgery (item 1, Fig.1).
First, insert the leg into the location boss until it ‘clicks’ into place (item 3, Fig.1). Grasp
the adjustable leg just below the locking mechanism (item 2, Fig.1), and using your
thumb lift the mechanism to release the lock. In a controlled manner lower the leg until
it meets the floor and release the lock. To remove the leg from the location boss, grip
the leg by the locking mechanism and pull firmly; failure to pull from the locking
mechanism will cause the leg to extend.
WARNING: The adjustable support leg must be removed or reduced in length
before lowering the table, failure to do so will result in damage to the arm
table, the trolley and possible injury to the patient and user.
5. Cleaning and Disinfecting
It is recommended that only CE marked cleaning products are used in the cleaning of
this device. Cleaning and Disinfection should be carried out by hand only.
Clean the light weight extended arm table with warm water and neutral detergent and
dry the surfaces thoroughly using a soft cloth. Suitable disinfectants are: quaternary
ammonium compounds, isopropyl alcohol & chlorine bleach up to 1% (10,000 ppm).
Apply disinfectant by cloth, spray or disinfectant wipe. Following disinfection, wash off
the all surfaces with clean warm water and dry thoroughly using a soft cloth.
The product will be adversely affected and its life expectancy reduced if the following
cautions are not observed;
CAUTION:
Do not steam clean or jet wash any area of this device.
Do not soak or immerse the device.
Do not use concentrated bleaching disinfectant solutions, organic solvent or
abrasive powders in the cleaning or disinfection of this product.
Dilute all disinfectants in accordance with the manufacturer’s guidelines.
Disinfectant products are corrosive in nature; failure to properly wash and
dry the product surface could leave a corrosive residue which may cause
damage to the product.

Document No. 992040. Issue 4 –22.03.21
Page 4
6. Product Maintenance
The extended arm table does not require servicing. However, before use, visually
inspect the product for any loose or damaged parts. Every six months we recommend
the arm table is inspected by a competent person, i.e. an Anetic Aid service engineer, to
ensure that it is safe to use; contact Anetic Aid for further details.
NOTE: If the light weight extended arm table is damaged or faulty it must be taken out
of use with immediate effect and the fault reported to Anetic Aid, your authorised
dealer or maintenance department; it must not be used until the damage or fault has
been repaired.
CAUTION: In line with the MHRA Device Bulletin DB2006(5), maintenance work
should only be conducted by suitably trained personnel following
manufacturer’s guidelines.
7. Product Warranty
The product, when new, is guaranteed to be free from defects in materials and
workmanship and to perform in accordance with the manufacturer’s specification for a
period of five years from the date of purchase from Anetic Aid Ltd or their approved
Distributor. Anetic Aid Ltd will repair or replace, at their discretion, any components
found to be defective or at variance with the manufacturer’s specification within this
time at no cost to the purchaser. The warranty will take effect from the date of
purchase, subject to the purchaser registering the product with Anetic Aid to confirm its
receipt, installation date and product details.
The warranty does not provide cover for breakage or failure due to tampering, misuse,
neglect, accidents, modifications or shipping. The warranty is also void if the product is
not used in accordance with the manufacturer’s instructions or is repaired during the
warranty period by any persons other than Anetic Aid or its appointed agent. No other
expressed or implied warranty is given.
For details of our extended warranty packages please contact Anetic Aid or your
authorised dealer.
8. Label Identification
The following list is a description of all the labels used on the trolley;
Safe Working Load; indicates the safe
working load of light weight arm table
is 25kg (55lbs).
WARNING label; informing user to
read the instructions for use
document.
The mattress screen printed Anetic Aid
brand logo with multiple information
symbols; ‘K8 Pressure Care’ technology,
CE marked, refer to the instructions for
use, mattress is x-ray translucent, and
latex free.
