Anritsu MX269012A User manual

MX269012A
W-CDMA/HSPA Uplink
Measurement Software
Operation Manual
Operation
Sixth Edition
•
For safety and warning information, please read this
manual before attempting to use the equipment.
•Additional safety and warning information is provided
within the MS2690A/MS2691A/MS2692A Signal
Analyzer Operation Manual (Mainframe Operation) or
MS2830A Signal Analyzer Operation Manual
(Mainframe Operation). Please also refer to this
document before using the equipment.
•Keep this manual with the equipment.
ANRITSU CORPORATION
Document No.: M-W3060AE-6.0

Safety Symbols
To prevent the risk of personal injury or loss related to equipment malfunction, Anritsu Corporation uses the
following safety symbols to indicate safety-related information. Ensure that you clearly understand the meanings of
the symbols BEFORE using the equipment. Some or all of the following symbols may be used on all Anritsu
equipment. In addition, there may be other labels attached to products that are not shown in the diagrams in this
manual.
Symbols used in manual
DANGER This indicates a very dangerous procedure that could result in serious injury or
death if not performed properly.
WARNING This indicates a hazardous procedure that could result in serious injury or death if
not performed properly.
CAUTION This indicates a hazardous procedure or danger that could result in light-to-severe
injury, or loss related to equipment malfunction, if proper precautions are not taken.
Safety Symbols Used on Equipment and in Manual
The following safety symbols are used inside or on the equipment near operation locations to provide information
about safety items and operation precautions. Ensure that you clearly understand the meanings of the symbols and
take the necessary precautions BEFORE using the equipment.
This indicates a prohibited operation. The prohibited operation is indicated
symbolically in or near the barred circle.
ii
This indicates an obligatory safety precaution. The obligatory operation is
indicated symbolically in or near the circle.
This indicates a warning or caution. The contents are indicated symbolically in or
near the triangle.
This indicates a note. The contents are described in the box.
These indicate that the marked part should be recycled.
MX269012A
W-CDMA/HSPA Uplink Measurement Software
Operation Manual Operation
30 January 2008(First Edition)
7 November 2011 (Sixth Edition)
Copyright © 2008-2011, ANRITSU CORPORATION.
All rights reserved. No part of this manual may be reproduced without the prior written permission of the
publisher.
The contents of this manual may be changed without prior notice.
Printed in Japan

iii
Equipment Certificate
Anritsu Corporation guarantees that this equipment was inspected at
shipment and meets the published specifications.
Anritsu Warranty
•During the warranty period, Anritsu Corporation will repair or exchange
this software free-of-charge if it proves defective when used as described
in the operation manual.
•The warranty period is 6 months from the purchase date.
•The warranty period after repair or exchange will remain 6 months
from the original purchase date, or 30 days from the date of repair or
exchange, depending on whichever is longer.
•This warranty does not cover damage to this software caused by Acts
of God, natural disasters, and misuse or mishandling by the customer.
In addition, this warranty is valid only for the original equipment
purchaser. It is not transferable if the equipment is resold.
Anritsu Corporation shall assume no liability for injury or financial loss of
the customer due to the use of or a failure to be able to use this equipment.
Anritsu Corporation Contact
In the event that this equipment malfunctions, contact an Anritsu
Service and Sales office. Contact information can be found on the last
page of the printed version of this manual, and is available in a separate
file on the CD version.

Notes On Export Management
This product and its manuals may require an Export License/Approval by
the Government of the product's country of origin for re-export from you
r
country.
Before re-exporting the product or manuals, please contact us to confirm
whether they are export-controlled items or not.
When you dispose of export-controlled items, the products/manuals need
to be broken/shredded so as not to be unlawfully used for military purpose.
iv

v
Software End-User License Agreement (EULA)
Please read this Software End-User License Agreement (hereafter this EULA) carefully before using
(includes executing, copying, registering, etc.) this software (includes programs, databases, scenarios,
etc., used to operate, set, etc., Anritsu electronic equipment). By reading this EULA and using this
software, you are agreeing to be bound by the terms of its contents and Anritsu Corporation (hereafter
Anritsu) hereby grants you the right to use this Software with the Anritsu-specified equipment
(hereafter Equipment) for the purposes set out in this EULA.
1. Grant of License and Limitations
1. Regardless of whether this Software was
purchased from or provided free-of-charge by
Anritsu, you agree not to rent, lease, lend, or
otherwise distribute this Software to third
parties and further agree not to disassemble,
recompile, reverse engineer, modify, or create
derivative works of this Software.
2. You may make one copy of this Software for
backup purposes only.
3. You are not permitted to reverse engineer
this software.
4. This EULA allows you to install one copy of
this Software on one piece of Equipment.
2. Disclaimers
To the extent not prohibited by law, in no
event shall Anritsu be liable for personal
injury, or any incidental, special, indirect or
consequential damages whatsoever,
including, without limitation, damages for
loss of profits, loss of data, business
interruption or any other commercial
damages or losses, arising out of or related
to your use or inability to use this Software.
3. Limitation of Liability
a. If a fault (bug) is discovered in this Software,
preventing operation as described in the
operation manual or specifications whether
or not the customer uses this software as
described in the manual, Anritsu shall at its
own discretion, fix the bug, or exchange the
software, or suggest a workaround,
free-of-charge. However, notwithstanding
the above, the following items shall be
excluded from repair and warranty.
i) If this Software is deemed to be used for
purposes not described in the operation
manual or specifications.
ii) If this Software is used in conjunction with
other non-Anritsu-approved software.
iii) Recovery of lost or damaged data.
iv) If this Software or the Equipment has been
modified, repaired, or otherwise altered
without Anritsu's prior approval.
v) For any other reasons out of Anritsu's direct
control and responsibility, such as but not
limited to, natural disasters, software virus
infections, etc.
b. Expenses incurred for transport, hotel, daily
allowance, etc., for on-site repairs by Anritsu
engineers necessitated by the above faults
shall be borne by you.
c. The warranty period for faults listed in
article 3a above covered by this EULA shall
be either 6 months from the date of purchase
of this Software or 30 days after the date of
repair, whichever is longer.

vi
4. Export Restrictions
You may not use or otherwise export or
re-export directly or indirectly this Software
except as authorized by Japanese and
United States law. In particular, this
software may not be exported or re-exported
(a) into any Japanese or US embargoed
countries or (b) to anyone on the Japanese or
US Treasury Department's list of Specially
Designated Nationals or the US Department
of Commerce Denied Persons List or Entity
List. By using this Software, you warrant
that you are not located in any such country
or on any such list. You also agree that you
will not use this Software for any purposes
prohibited by Japanese and US law,
including, without limitation, the
development, design and manufacture or
production of missiles or nuclear, chemical or
biological weapons of mass destruction.
5. Termination
Anritsu shall deem this EULA terminated if
you violate any conditions described herein.
This EULA shall also be terminated if the
conditions herein cannot be continued for
any good reason, such as violation of
copyrights, patents, or other laws and
ordinances.
6. Reparations
If Anritsu suffers any loss, financial or
otherwise, due to your violation of the terms
of this EULA, Anritsu shall have the right to
seek proportional damages from you.
7. Responsibility after Termination
Upon termination of this EULA in
accordance with item 5, you shall cease all
use of this Software immediately and shall
as directed by Anritsu either destroy or
return this Software and any backup copies,
full or partial, to Anritsu.
8. Dispute Resolution
If matters of dispute or items not covered by
this EULA arise, they shall be resolved by
negotiations in good faith between you and
Anritsu.
9. Court of Jurisdiction
This EULA shall be interpreted in
accordance with Japanese law and any
disputes that cannot be resolved by
negotiation described in Article 8 shall be
settled by the Japanese courts.

Cautions against computer virus infection
•Copying files and data
Only files that have been provided directly from Anritsu or generated
using Anritsu equipment should be copied to the instrument.
A
ll other required files should be transferred by means of USB or
CompactFlash media after undergoing a thorough virus check.
•Adding software
Do not download or install software that has not been specifically
recommended or licensed by Anritsu.
•Network connections
Ensure that the network has sufficient anti-virus security protection in
place.
vii

CE Conformity Marking
Anritsu affixes the CE conformity marking on the following product(s) in
accordance with the Council Directive 93/68/EEC to indicate that they
conform to the EMC and LVD directive of the European Union (EU).
CE marking
1. Product Model
Software: MX269012A W-CDMA/HSPA Uplink
Measurement Software
2. Applied Directive and Standards
When the MX269012A W-CDMA/HSPA Uplink Measurement
Software is installed in the MS2690A/MS2691A/MS2692A or
MS2830A, the applied directive and standards of this unit conform to
those of the MS2690A/MS2691A/MS2692A or MS2830A main frame.
PS: About main frame
Please contact Anritsu for the latest information on the main frame
types that the MX269012A can be used with.
viii

C-tick Conformity Marking
Anritsu affixes the C-tick mark on the following product(s) in accordance
with the regulation to indicate that they conform to the EMC framework
of Australia/New Zealand.
C-tick marking
1. Product Model
Software: MX269012A W-CDMA/HSPA Uplink
Measurement Software
2. Applied Directive and Standards
When the MX269012A W-CDMA/HSPA Uplink Measurement
Software is installed in the MS2690A/MS2691A/MS2692A or
MS2830A, the applied directive and standards of this unit conform to
those of the MS2690A/MS2691A/MS2692A or MS2830A main frame.
PS: About main frame
Please contact Anritsu for the latest information on the main frame
types that the MX269012A can be used with.
ix

x

About This Manual
Organization of Operation Manuals
The operation manuals for the MX269012A W-CDMA/HSPA Uplink
Measurement Software are organized as shown below.
MX269012A W-CDMA/HSPA Uplink Measurement Software
Operation Manual (Operation)
MX269012A W-CDMA/HSPA Uplink Measurement Software
Operation Manual (Remote Control)
MS2690A/MS2691A/MS2692A
Signal Analyzer Operation Manual
(Main Frame Operation)
MS2690A/MS2691A/MS2692A and MS2830A
Signal Analyzer Operation Manual (Main Frame Remote Control)
MS2830A Signal Analyzer Operation
Manual
(Main Frame Operation)
Or
Mainframe Operation
Mainframe Remote Control
These manuals describe the basic operating methods, maintenance
procedures, common functions, and common remote control of the signal
analyzer mainframe.
MX269012A W-CDMA/HSPA Uplink Measurement Software Operation
Manual (Operation) <This document>
This manual describes the operating methods of the MX269012A
W-CDMA/HSPA Uplink Software.
MX269012A W-CDMA/HSPA Uplink Measurement Software Operation
Manual (Remote Control)
This manual describes remote control of the MX269012A W-CDMA/HSPA
Uplink Measurement Software.
Convention Used in This Manual
Throughout this document, the use of MS269x Series is assumed unless
otherwise specified. If using MS2830A, change MS269xA to read
MS2830A.
I

II
Table of Contents
About This Manual........................................ I
Chapter 1 Overview.................................... 1-1
1.1 Product Overview.......................................................... 1-2
1.2 Product Configuration ................................................... 1-3
1.3 Specifications................................................................ 1-3
Chapter 2 Before Use................................. 2-1
2.1 Part Names ................................................................... 2-2
2.2 Signal Path Setup ......................................................... 2-11
2.3 Application Startup and Selection................................. 2-12
2.4 Initialization and Calibration.......................................... 2-13
Chapter 3 Measurement ............................ 3-1
3.1 Basic Operation ............................................................ 3-2
3.2 Setting Frequency......................................................... 3-5
3.3 Setting Level ................................................................. 3-6
3.4 Setting Common Items ................................................. 3-7
3.5 Setting Measurement Items.......................................... 3-8
3.6 Modulation Analysis ...................................................... 3-13
3.7 Code Domain Analysis.................................................. 3-27
3.8 Setting Trigger .............................................................. 3-46

III
1
2
3
4
5
Appendix Index
Chapter 4 Performance Test ..................... 4-1
4.1 Overview of Performance Test ..................................... 4-2
4.2 Performance Test Items................................................ 4-3
Chapter 5 Other Functions........................ 5-1
5.1 Selecting Other Functions............................................. 5-2
5.2 Setting Title ................................................................... 5-2
5.3 Erasing Warmup Message ........................................... 5-2
Appendix A Error Messages....................... A-1
Appendix B Initial Value List ...................... B-1
Index .......................................................... Index-1

IV.

Chapter 1 Overview
1-1
1
Overview
This chapter provides an overview of the MX269012A W-CDMA/HSPA
Uplink Measurement Software and describes the product configuration.
1.1 Product Overview ...................................................... 1-2
1.2 Product Configuration................................................ 1-3
1.2.1 Standard configuration .................................. 1-3
1.2.2 Applicable parts............................................. 1-3
1.3 Specifications............................................................. 1-3

Chapter 1 Overview
1-2
1.1 Product Overview
The MS269x Series or MS2830A Signal Analyzer enables high-speed,
high-accuracy, and simple measurements of transmission characteristics
of base stations and mobile stations for various types of mobile
communications. The MS2690A/MS2691A/MS2692A or MS2830A is
equipped with high-performance signal analyzer and spectrum analyzer
functions as standard, with optional measurement software allowing
modulation analysis functionality supporting various digital modulation
modes.
The MX269012A W-CDMA/HSPA Uplink Measurement Software
(hereinafter referred to as “MX269012A”) is a software option for
measuring the RF characteristics of W-CDMA/HSPA (FDD) uplink
specified by 3GPP.
The MX269012A provides the following measurement features.
•Modulation accuracy measurement
•Carrier frequency measurement
•Transmitter power measurement
•Code domain measurement
MS2830A-006/106 is required to use the MX269012A on MS2830A.

1.2 Product Configuration
1-3
1
Overview
1.2 Product Configuration
1.2.1 Standard configuration
Table 1.2.1-1 lists the standard configuration of the MX269012A.
Table 1.2.1-1 Standard configuration
Item Model
Name/Symbol Product Name Q’ty Remarks
Application MX269012A W-CDMA/HSPA Uplink
Measurement Software 1
Accessory ―Installation CD-ROM 1
Application software,
operation manual CD-ROM
1.2.2 Applicable parts
Table 1.2.2-1 lists the applicable parts for the MX269012A.
Table 1.2.2-1 Applicable parts
Model
Name/Symbol Product Name Remarks
W3060AE
MX269012A W-CDMA/HSPA Uplink
Measurement Software Operation
Manual (Operation)
English,
printed version
W3061AE
MX269012A W-CDMA/HSPA Uplink
Measurement Software Operation
Manual (Remote Control)
English, Printed
Version
1.3 Specifications
Table 1.3-1 lists the specifications for the MX269012A.
When MS2830A is used, this software’s specification is specified by the
condition below, unless otherwise noted.
Attenuator Mode: Mechanical Atten Only
Table 1.3-1 Specifications
Item Specification
Common Specifications
Channel bandwidth 5 MHz
Target signal Uplink
Modulation/Frequency Measurement
Measurement frequency
ranges 400 to 3000 MHz

Chapter 1 Overview
1-4
Table 1.3-1 Specifications (Continued)
Measurement level range −15 to +30 dBm (at Pre-Amp Off, or Pre-Amp not installed.)
−30 to +10 dBm (at Pre-Amp On)
Carrier frequency
measurement accuracy
After CAL execution at 18 to 28°C
For a signal of EVM = 1%
MS269x Series :
±(accuracy of reference crystal oscillator ×carrier frequency + 5 Hz)
MS2830A :
± (accuracy of reference crystal oscillator × carrier frequency + 6 Hz)
Residual EVM
After CAL execution at 18 to 28°C, the signal measured is within the
measurement level range and less than or equal to Input Level.
MS269x Series :
≤1.0% (rms)
MS2830A : ≤1.2% (rms)
Transmitter power
measurement accuracy
After CAL execution, input attenuator ≥10 dB, at 18 to 28°C, the
signal measured is within the measurement level range and less than
or equal to Input Level.
MS269x Series
±0.6 dB (at Pre-Amp Off, or Pre-Amp not installed.)
±1.1 dB (at Pre-Amp On)
MS2830A
±0.6 dB (at Pre-Amp Off, or Pre-Amp not installed.)
Transmitter power measurement accuracy is calculated from an RSS
(root summed square) error of the absolute amplitude accuracy and
the in-band frequency characteristics.
Code Domain Measurement
Code domain power
measurement Accuracy
After CAL execution, input at 18 to 28°C, the signal measured is
within the measurement level range and less than or equal to Input
Level.
MS269x Series : ±0.02 dB (code power ≥−10 dBc)
±0.05 dB (code power ≥−20 dBc)
±0.10 dB (code power ≥−30 dBc)
MS2830A : ±0.02 dB (Code Power ≥–10 dBc)
±0.10 dB (Code Power ≥–20 dBc)
±0.15 dB (Code Power ≥–30 dBc)
Residual code domain error MS269x Series : ≤−46 dB
MS2830A : ≤–42 dB
Code domain error
measurement accuracy
±0.3 dB (for code domain error of −30 dBc)
±1.0 dB (for code domain error of −40 dBc)

1.3 Specifications
1-5
1
Overview
Table 1.3-1 Specifications (Continued)
Adjacent Channel Power Measurement
Measurement method Execution of the adjacent channel power measurement function of the
Spectrum Analyzer or Signal Analyzer
Occupied Bandwidth Measurement
Measurement method Execution of the occupied bandwidth measurement function of the
Spectrum Analyzer or Signal Analyzer
Channel Power Measurement
Measurement method Execution of the channel power measurement function of the Spectrum
Analyzer or Signal Analyzer
Spectrum Emission Mask Measurement
Measurement method Execution of the spectrum emission mask measurement function of the
Spectrum Analyzer

Chapter 1 Overview
1-6.
