Ansul AUTOPULSE IQ-396X User manual

OPERATION AUTOPULSE®IQ-396X
MANUAL ANALOG
ADDRESSABLE
ALARM/RELEASE
CONTROL SYSTEM
ANSUL

WARNING: This equipment generates, uses, and can radiate radio frequency
energy and if not installed and used in accordance with the instruction manual, may
cause interference to radio communications. It has been tested and found to comply
with the limits for class A computing device pursuant to Subpart B of Part 15 of FCC
Rules, which is designed to provide reasonable protection against such interference
when operated in a commercial environment. Operation of this equipment in a
residential area is likely to cause interference, in which case the user will be required
to correct the interference at his own expense.
Installation Precautions - Adherence to the following will aid in problem-free installation with long-term reliability:
WARNING - Several different sources of power can be connected to the fire alarm
control panel. Disconnect all sources of power before servicing. Control unit and
associated equipment may be damaged by removing and/or inserting cards,
modules, or interconnecting cables while the unit is energized. Do not attempt to
install, service, or operate this unit until this manual is read and understood.
CAUTION - System Reacceptance Test after Software Changes: To ensure
proper system operation, this product must be tested in accordance with NFPA 72-
1993 Chapter 7 after any programming operation or change in site-specific software.
Reacceptance testing is required after any change, addition or deletion of system
components, or after any modification, repair or adjustment to system hardware or
wiring.
All components, circuits, system operations, or software functions known to be
affected by a change must be 100% tested. In addition, to ensure that other
operations are not inadvertently affected, at least 10% of initiating devices that are
not directly affected by the change, up to a maximum of 50 devices, must also be
tested and proper system operation verified.
This system meets NFPA requirements for operation at 0-49OC and at a
relative humidity of 85% RH (non-condensing) at 30O C. However, the useful life
of the system's standby batteries and the electronic components may be
adversely affected by extreme temperature ranges and humidity. Therefore, it is
recommended that this system and its peripherals be installed in an environment
with a nominal room temperature of 60-80OF.
Verify that wire sizes are adequate for all initiating and indicating device loops.
Most devices cannot tolerate more than a 10% I.R. drop from the specified device
voltage.
Like all solid state electronic devices, this system may operate erratically or can
be damaged when subjected to lightning induced transients. Although no system is
completely immune from lightning transients and interferences, proper grounding will
reduce susceptibility. Overhead or outside aerial wiring is not recommended, due to
an increased susceptibility to nearby lightning strikes. Consult with the Technical
Services Department if any problems are anticipated or encountered.
Disconnect AC power and batteries prior to removing or inserting circuit boards.
Failure to do so can damage circuits.
Remove all electronic assemblies prior to any drilling, filing, reaming, or punching
of the enclosure. When possible, make all cable entries from the sides or rear.
Before making modifications, verify that they will not interfere with battery,
transformer, and printed circuit board location.
Do not tighten screw terminals more than 9 in-lbs. Over tightening may damage
threads, resulting in reduced terminal contact pressure and difficulty with screw
terminal removal.
This system contains static-sensitive components. Always ground yourself with a
proper wrist strap before handling any circuits so that static charges are removed
from the body. Use static suppressive packaging to protect electronic assemblies
removed from the unit.
Follow the instructions in the installation, operating, and programming manuals.
These instructions must be followed to avoid damage to the control panel and
associated equipment. FACP operation and reliability depend upon proper
installation.
Fire Alarm System Limitations While installing a fire alarm system may make lower insurance
rates possible, it is not a substitute for fire insurance!
An automatic fire alarm system - typically made up of smoke detectors, heat
detectors, manual pull stations, audible warning devices, and a fire alarm control
with remote notification capability can provide early warning of a developing fire.
Such a system, however, does not assure protection against property damage or
loss of life resulting from a fire.
Any fire alarm system may fail for a variety of reasons:
Smoke detectors may not sense fire where smoke cannot reach the detectors such
as in chimneys, in walls, or roofs, or on the other side of closed doors. Smoke
detectors also may not sense a fire on another level or floor of a building. A second
floor detector, for example, may not sense a first floor or basement fire. Further-
more, all types of smoke detectors - both ionization and photoelectric types, have
sensing limitations. No type of smoke detector can sense every kind of fire caused
by carelessness and safety hazards like smoking in bed, violent explosions,
escaping gas, improper storage of flammable materials, overloaded electrical
circuits, children playing with matches, or arson.
IMPORTANT! Smoke detectors must be installed in the same room as the
control panel and in rooms used by the system for the connection of alarm
transmission wiring, communications, signaling, and/or power. If detectors are
not so located, a developing fire may damage the alarm system, crippling its
ability to report a fire.
Audible warning devices such as bells may not alert people if these devices are
located on the other side of closed or partly open doors or are located on another
floor of a building.
A fire alarm system will not operate without any electrical power. If AC power fails,
the system will operate from standby batteries only for a specified time.
Rate-of-Rise heat detectors may be subject to reduced sensitivity over time. For
this reason, the rate-of-rise feature of each detector should be tested at least once
per year by a qualified fire protection specialist.
Equipment used in the system may not be technically compatible with the control.
It is essential to use only equipment listed for service with your control panel.
Telephone lines needed to transmit alarm signals from a premise to a central
monitoring station may be out of service or temporarily disabled.
The most common cause of fire alarm malfunctions, however, is inadequate
maintenance. All devices and system wiring should be tested and maintained by
professional fire alarm installers following written procedures supplied with each
device. System inspection and testing should be scheduled monthly or as required
by National and/or local fire codes. Adequate written records of all inspections should
be kept.
FCC Warning
Canadian Requirements
This digital apparatus does not exceed the Class A limits for radiation noise
emissions from digital apparatus set out in the Radio Interference Regulations of the
Canadian Department of Communications.
Le present appareil numerique n'emet pas de bruits radioelectriques depassant les
limites applicables aux appareils numeriques de la classe A prescrites dans le
Reglement sur le brouillage radioelectrique edicte par le ministere des Communica-
tions du Canada.
Technical Publishing Document PRECAULG.PM6 7/12/96

AUTOPULSE IQ-396X Operations Doc. 50403:B 07/22/96 iii
1. Introduction
2. Using the Control Panel
Contents
Overview..................................................................................................... 1
Operating Features ..................................................................................... 1
Components ............................................................................................... 1
IQ-396X Controls and Indicators ............................................................... 2
System Status Indicator LEDs ..................................................................... 2
Control Keys ............................................................................................... 3
Normal Operation ...................................................................................... 4
Trouble Operation ...................................................................................... 4
Fire Alarm ................................................................................................... 5
Supervisory Signal ...................................................................................... 5
Non-Alarm Point Operation........................................................................ 6
Trouble Monitor Point Operation .............................................................. 6
Notification Appliance Circuit Operation ................................................... 6
Control-By-Event Operation ....................................................................... 6
Releasing Functions .................................................................................... 7
Overview ............................................................................................... 7
Cross Zoning Options ........................................................................... 7
Intelligent Detector Functions ................................................................... 8
Pre-Alarm Operation (AWACS) .................................................................... 9
Operating Time Functions........................................................................ 10
Overview ............................................................................................. 10
Time Functions.................................................................................... 10
Operating Coding Functions .................................................................... 10
Presignal/Positive Alarm Signal (PAS) Operation ...................................... 11
Special System Timers .............................................................................. 11
Waterflow Circuits Operation ................................................................... 11
Disable/Enable Operation ........................................................................ 11
Style 6 Operation...................................................................................... 11
Read Status ............................................................................................... 12
Overview ............................................................................................. 12
How to enter Read Status ................................................................... 12
Read Status Options ............................................................................ 12
Read Status for Points and Zones........................................................ 12
Read Status for Zones.......................................................................... 13
Read History ........................................................................................ 14
Presignal Delay .................................................................................... 15
Releasing Zones................................................................................... 15
Time Control Zones ............................................................................ 15
Holiday Zones ..................................................................................... 16
NAC Coding Zones .............................................................................. 16
Pre-Alarm Zone .................................................................................... 16
System Parameters............................................................................... 17
Annunciator Display Selections ........................................................... 18
Example of Annunciator Display Selections ........................................ 18
Continued on the next page...
3. Operating Modes

iv AUTOPULSE IQ-396X Operations Doc. 50403:B 07/22/96
Overview................................................................................................... 19
Operating Features ................................................................................... 19
How it Works ............................................................................................ 19
In this Section........................................................................................... 19
Before You Begin ...................................................................................... 19
AMG-1/AMG-E Audio Message Generator................................................. 20
AMG-1/AMG-E Overview...................................................................... 20
AMG-1/AMG-E Messages ...................................................................... 20
AMG-1/AMG-E Operating Components............................................... 21
AMG-1 Operating Instructions ............................................................ 21
Selecting AMG Group Functions .............................................................. 22
Selecting Factory-Programmed Messages (VROM) .............................. 22
Recording Custom Messages (VRAM option) ...................................... 22
Selecting AMG Tones and Messages .................................................... 23
Setting the AMG DIP Switch (SW2) ..................................................... 23
AMG-1 and AMG-E Tone and Message Selections (SW2=Off) ............ 24
AMG-1 and AMG-E Tone and Message Selections (SW2=On) ............ 25
ATG-2 Audio Tone Generator ................................................................... 26
ATG-2 Overview ................................................................................... 26
ATG-2 Front Panel ............................................................................... 27
How to Operate the ATG-2.................................................................. 27
Selecting Tones for the ATG-2 .................................................................. 28
Selecting a Primary (Evac) Channel Tone ............................................ 28
Selecting a Secondary (Alert) Channel Tone ....................................... 29
Select Operating Mode ........................................................................ 29
Fire Fighter's Telephones (FFT-7/FFT-7S) ................................................. 30
Overview ............................................................................................. 30
FFT-7 Operating Components
How to Operate the FFT-7 .................................................................. 30
Audio Amplifiers ....................................................................................... 31
Overview ............................................................................................. 31
Audio Amplifier Features..................................................................... 31
AA-30 Components ............................................................................. 32
AA-100/AA-120 Components ............................................................... 33
How to Adjust the Audio Gain Level ................................................... 34
Selecting the AA-100/AA-120 Backup Tone .......................................... 34
Overview................................................................................................... 35
Installation................................................................................................ 35
Appendix A: AMG Voice
Message Options
4. Voice Alarm Systems

AUTOPULSE IQ-396X Operations Doc. 50403:B 07/22/96 v
NFPA 12 CO2 Extinguishing Systems
NFPA 12A Halon 1301 Extinguishing Systems
NFPA 12B Halon 1211 Extinguishing Systems
NFPA 13 Sprinkler Systems
NFPA 15 Water Spray Systems
NFPA 16 Foam/Water Deluge and Foam/Water Spray Systems
NFPA 17 Dry Chemical Extinguishing Systems
NFPA 17A Wet Chemical Extinguishing Systems
NFPA 72 Central Station Fire Alarm Systems (Automatic, Manual and Water-
flow) Protected Premises Unit (requires Notifier UDACT).
NFPA 72 Local (Automatic, Manual, Waterflow and Sprinkler Supervisory) Fire
Alarm Systems.
NFPA 72 Auxiliary (Automatic, Manual and Waterflow) Fire Alarm Systems
(requires 4XTM).
NFPA 72 Remote Station (Automatic, Manual and Waterflow) Fire Alarm
Systems (requires 4XTM or NOTIFIRE 911A DACT).
NFPA 72 Proprietary (Automatic, Manual and Waterflow) Fire Alarm Systems
(Protected Premises Unit).
NFPA 2001 Clean Agent Fire Extinquishing Systems
NFPA 72 Initiating Devices for Fire Alarm Systems
NFPA 72 Inspection, Testing and Maintenance for Fire Alarm Systems
NFPA 72 Notification Appliances for Fire Alarm Systems
UL 38 Manually Actuated Signaling Boxes
UL 217 Smoke Detectors, Single and Multiple Station
UL 228 Door Closers - Holders for Fire Protective Signaling Systems
UL 268 Smoke Detectors for Fire Protective Signaling Systems
UL 268A Smoke Detectors for Duct Applications
UL 346 Waterflow Indicators for Fire Protective Signaling Systems
UL 464 Audible Signaling Appliances
UL 521 Heat Detectors for Fire Protective Signaling Systems
UL 864 Standard for Control Units for Fire Protective Signaling Systems
UL 1481 Power Supplies for Fire Protective Signaling Systems
UL 1971 Visual Signaling Appliances
UL 1076 Proprietary Burglar Alarm Systems
Standard CAN/ULC-S527-M87
EIA-485 and EIA-232 Serial Interface Standards
NEC Article 300 Wiring Methods
NEC Article 760 Fire Protective Signaling Systems
Applicable Local and State Building Codes
Requirements of the Local Authority Having Jurisdiction
This Fire Alarm Control Panel
complies with the following
NFPA standards
The installer should be
familiar with the following
documents and standards.
Underwriters
Laboratories
Underwriters
Laboratories
of Canada (ULC)
Other
Documents
associated with the
control panel
eltiTtnemucoD tnemucoD
.oNecnerefeR
.coDlusnA
.oNtraP
rotaicnunnAseireSMDLehT58851096714
yalpsiDlatsyrCdiuqiL08-DCLlusnAehT82005786714
tnemucoDytilibitapmoCeciveDlusnAehT45005120814
yaleRlortnoCrotaicnunnAR8-MCAehT
eludoM 24351196714
srotaicnunnAseireSSCAehT24851986714
rotaicnunnAA61-MFAehT70251886714
ytilitUgnimmargorP004eriFireV92551314914
launaMTCADUehT05005414914
launaMmetsySegasseMmralAecioVehT09851514914

vi AUTOPULSE IQ-396X Operations Doc. 50403:B 07/22/96

AUTOPULSE IQ-396X Operations Doc. 50403:B 07/22/96 1
The IQ-396X is a modular, intelligent Fire Alarm Control Panel (FACP) with an
extensive list of powerful features. The CPU module, power supply module, and
cabinet combine to create a complete fire control system for most applications.
Optional modules mount to the chassis to provide additional output circuits.
 Alarm Verification selection per point, with tally.
 Positive Alarm Sequence (PAS) and Presignal per NFPA 72.
 Silence Inhibit timer and Auto Silence timer.
 March time/temporal code for Notification Appliance Circuits (NACs).
 Zone coding for NACs if using an optional UZC-256.
 Remote Acknowledge/Alarm Silence/System Reset/Alarm Activate functions
through MMX monitor modules.
 Automatic time-of-day and day-of-week control functions, with holiday option.
 User-defined password and key-protected nonvolatile memory.
 AWACS (Advanced Warning Addressable Combustion Sensing) with nine field-
adjustable Pre-Alarm levels with programmable Control-by-Event (CBE)
 Operate automatic smoke or heat detector sounder base on action Pre-Alarm
level, with general evacuation on alarm level.
 Security alarm point option with separate audible signal code.
 Centralized voice paging and audible alarm signaling options.
 Programmable Control-by-Event control of outputs from individual alarm or
supervisory addressable devices.
Figure 1 shows IQ-396X components used for operating the control panel.
1. Introduction
80-character
(2 x 40) Liquid Crystal
Display (LCD)
System Status
LED Indicators
Programming Keypad
Control
Keys
EIA-485 Terminal Mode Port
EIA-485 ACS Port
EIA-232
Printer Port
EPROM
EIA-232 PC/
Terminal Port
Flip-down door
(covers the
Programming Keypad)
Overview
Operating
Features
Components
Figure 1: IQ-396X Control Panel

2AUTOPULSE IQ-396X Operations Doc. 50403:B 07/22/96
2. Using the Control Panel
Figure 2: IQ-396X Controls and Indicators
System Status
Indicator LEDs The control panel contains eight LED indicators with labels as follows:
IQ-396X ANALOG FIRE PANEL
ALL SYSTEMS NORMAL 11:00 MON 12/25/95
The IQ-396X control panel contains the following controls and indicators:
 System Status Indicator LEDs;
 Control keys;
 80-character (2x40) LCD display with a long-life LED backlight; and
 Panel sounder with a piezo that provides unique sounds for alarm, trouble and
supervisory/security conditions.
The flip-down door covers the programming keypad and switches.
Control Keys
rotacidnIroloC...evitcanehW...ffonrutoT
rewoPCAneerGCAyramirpreporpehtnehwsthgiL
.deilppasirewop
.rewopCAffonruT
mralAeriFdeRdegdelwonkca-nonanehwsehsalF
retfaylidaetssthgiL.stsixemralAeriF
.mralaehtegdelwonkcauoy
mralaehtraelC
ehtteserdnanoitidnoc
.metsys
mralA-erP
gninraW
wolleYdegdelwonkca-nonanehwsehsalF
retfaylidaetssthgiL.stsixemralA-erP
.mralaehtegdelwonkcauoy
mralaehtraelC
-erPnoitcA(.noitidnoc
metsysaseriuqermralA
).teser
ytiruceS
mralA
eulBdegdelwonkca-nonanehwsehsalF
ylidaetssthgiL.stsixemralAytiruceS
.mralaehtegdelwonkcauoyretfa
mralaehtraelC
ehtteserdnanoitidnoc
.metsys
yrosivrepuS
langiS
wolleYdegdelwonkca-nonanehwsehsalF
sthgiL.stsixemralAyrosivrepuS
ehtegdelwonkcauoyretfaylidaets
.mrala
.langisehtraelC
eriuqerstupnirepmaT(
).tesermetsysa
metsyS
elbuorT
wolleYdegdelwonkca-nonanehwsehsalF
sthgiL.stsixemralAelbuorTmetsyS
ehtegdelwonkcauoyretfaylidaets
.mrala
mralaehtraelC
.noitidnoc
delbasiD
stnioP
wolleYmetsyseromroenonehwsthgiL
.delbasiderasecived
ehtevomerroelbanE
.eciveddelbasid
mralA
decneliS
wolleYsrucconoitidnocmralanaretfasthgiL
.>ecneliSmralA<gnisserpretfadna
>etavitcAmralA<sserP
.>teseRmetsyS<ro
IQ-396X Controls and
Indicators
LCD Display
System Status
Indicator LEDs
Programming
Keypad

AUTOPULSE IQ-396X Operations Doc. 50403:B 07/22/96 3
Acknowledge Step  Use the <Acknowledge/Step> key to respond to new
alarm or trouble signals. Pressing <Acknowledge/Step> causes the control
panel to do the following:
 silence the control panel sounder;
 change all indicators from flashing to steady;
 send an Acknowledge message to the history file, an optional printer, and
an optional LCD-80; and
 send a signal to silence the sounder on the LCD-80 and ACS annunciators.
You can also press the <Acknowledge/Step> key to display multiple alarms
or troubles. If more than one alarm or trouble exists, the control panel
displays the next alarm or trouble for 3 seconds (or until you press <Ac-
knowledge/Step>), then displays the next alarm or trouble.
Alarm Silence  Use the <Alarm Activate> key to silence the control panel
sounderas well as sounders connected to Notification Appliance Circuits.
Pressing <Alarm Silence> causes the control panel to do the following:
 turn off the control panel sounder;
 turn off all silenceable output circuits;
 light the Alarm Silenced LED; and
 send an Alarm Silenced message to the history file, optional printer, and
an optional LCD-80.
System Reset  Use the <System Reset> key to reset the control panel.
Press <System Reset> and the control panel does the following:
 turns off all alarm-activated CMX modules and NAC circuits;
 breaks resettable power to four-wire detectors; and
 sends an All Systems Normal message to the history file, optional
printer, and an optional LCD-80.
Any alarm or trouble that exists after a System Reset reactivates NACs,
control outputs, and panel audio and visual indicators.
Control Keys
Alarm Activate  Use the <Alarm Activate> key to test notification appli-
ances. Press and hold the Alarm Activate switch for 2 seconds (to prevent
accidental activation). The control panel does the following:
 turns on all silenceable NACs;
 turns off the Alarm Silenced LED; and
 sends a Manual Evacuate message to the history file, optional printer,
and an optional LCD-80.
Lamp Test  Use the <Lamp Test> key to test the control panel LEDs and
sounder. Press and hold <Lamp Test> and the control panel does the
following:
 lights all control panel LEDs;
 turns on the control panel sounder; and
 lights all segments of the LCD display.
The control panel provides five control keys, Acknowledge/Step, Alarm
Silence, Alarm Activate, System Reset, and Lamp Test.

4AUTOPULSE IQ-396X Operations Doc. 50403:B 07/22/96
The system operates in Normal mode when no alarms or troubles exist. In
Normal mode, the control panel displays a system message as follows:
3. Operating Modes
In Normal mode, the control panel does the following functions at regular
intervals:
 Polls all Signaling Line Circuit (SLC) devices and the four NACs to check for
valid replies, alarms, troubles, circuit integrity, and so on.
 Checks power supply troubles and batteries every 10 seconds.
 Sends a supervisory query on the LCD-80 and verifies proper response.
 Refreshes the LCD and the optional LCD-80 display and update time.
 Scans the keypad for a System Reset or an Enter key press.
 Performs a detector automatic test operation.
 Tests system memory.
The system goes into Trouble mode when the control panel detects an electrical
or mechanical fault. With no alarms, a control panel in Trouble mode does the
following:
 produces a pulsed audible tone;
 flashes the System Trouble LED;
 activates the trouble relay (MPS-400, TB3); and
 sends a message to the LCD display, an optional LCD-80, an optional printer,
and the history file. Figure 4 shows a typical Trouble message:
1) Press <Acknowledge/Step> to silence the panel sounder and switch the
System Trouble LED from flashing to steadyregardless of the number of
troubles, alarms, and supervisory signals.
2) Pressing <Acknowledge/Step> while at least one new alarm or trouble
exists, causes the control panel to send an Acknowledge message to the
history file and an optional printer.
If the trouble clearsbefore or after pressing <Acknowledge/Step>the
control panel sends a Clear Trouble message to the printer. Figure 5 shows a
sample Trouble Message:
Addressable CMX
modules report both
open and short circuit
messages.
If all troubles clear and no supervisory or fire conditions exist, the control panel
does the following:
 returns to Normal mode;
 sends an All Systems Normal message to the LCD display, the history file, an
optional LCD-80, an optional printer; and
 restores troubles automatically even if troubles are not acknowledged.
Figure 4: Trouble Message
Trouble Operation
Normal Operation
YOUR CUSTOM FORTY CHARACTER MESSAGE HERE
ALL SYSTEMS NORMAL 11:30A TUE 06/10/95
TROUBL PULL STATION I.C.U. WEST WING
Z1 INVALID REPLY 11:45PM TUE 10/31/95
Type of trouble
Type of device
Type of event
(trouble)
Software zone
assigned (Zone 1)
Custom descriptor for
this device location
Time and date
TROUBL CONTROL MODULE ADDRESS 21 Z00 OPEN CIRCUIT 08:10A 08/20/95 M21
TROUBL CONTROL MODULE ADDRESS 22 Z00 OPEN CIRCUIT 08:12A 08/20/95 M22
Figure 5: Sample Trouble Message
Figure 3: All Systems Normal Message

AUTOPULSE IQ-396X Operations Doc. 50403:B 07/22/96 5
Trouble Operation,
continued Pressing <Alarm Silence> when only troubles exist, gives the same result as
pressing <Acknowledge/Step>. The Alarm Silenced LED does not light
unless an alarm exists in the system.
If multiple trouble conditions exist in the system, the optional LCD and
optional LCD-80 displays automatically step through each trouble event
every 3 seconds in the following order:
1) Alarms, in order of address;
2) Supervisory, in order of address; or
3) Troubles, in order of address.
Press <Acknowledge/Step> and the display stops on the current trouble
event for 1 minute. Press <Acknowledge/Step> to continue.
The system goes into Fire Alarm mode when the control panel detects a fire
alarm. During Fire Alarm mode, the control panel does the following:
 produces a steady audible tone;
 activates the System Alarm relay (MPS-400, TB3) and flashes the System
Alarm LED;
 displays Alarm in the status banner on the LCD display;
 latches alarms so they cannot clear until the alarm initiating device
returns to its normal condition and the operator resets the control panel;
 initiates any Control-by-Event actions;
 starts timers (Silence Inhibit, Auto Silence); and
 activates the general alarm zone (Z00).
Fire Alarm
Supervisory signals cause the control panel to do the following:
 produce a warbling audible tone;
 turn on the Supervisory relay (MPS-400, TB5) and flash the Supervisory
LED;
 display Active in the status banner on the control panel.
 turn off the panel sounder for all Silenced alarms; and
 prevent timers from starting.
Figure 7: Typical Supervisory Signal display
Supervisory Signal
 Supervisory signalslike fire alarmscan use CBE actions.
 Supervisory signals do not sound alarms or reactivate silenced alarm
CBEs.
 Supervisory circuits can also cause circuit troubles, which operate like
trouble signals.
Figure 6: Fire Alarm Display
ALARM:PULL STATION I.C.U. WEST WING
VISITORS LOUNGE 11:58PM 10/31/95 M101
Status banner Alarm
You can program
Supervisory signals as
Tracking or Latching.
ACTIVE TAMPER I.C.U. WEST WING
VISITORS LOUNGE 12:01A 11/01/95 M101
Status banner Active

6AUTOPULSE IQ-396X Operations Doc. 50403:B 07/22/96
Non-Alarm Point Operation Non-Alarm points are MMX addressable modules that activate Control-by-
Event. These points do not activate the System Alarm LED or the panel
sounder. Non-Alarm points use three type codes: Non-Fire, Hazard Alert,
and Fire Control.
Figure 8: Non-Alarm Points
Trouble Monitor-type MMX modules monitor remote power supplies or
other external equipment. These types of MMX modules operate like
troublesbut with the following differences:
 the LCD display status banner displays Active;
 the type code is Trouble Mon;
 the modules latchuntil the troubles are returned to normal condition
and an operator resets the control panel; and
 MMX modules can have Control-by-Event.
The four NACs (integral to the control panel) have Control-by-Event and
trouble functions like CMX addressable modules on the SLC loop. NAC
circuits differ from CMX modules in the following ways:
 addresses (last three characters in LCD field) are B01, B02, B03, or B04;
 the default type code field is Bell Circuit; and
 control panel NACsexcept those controlled with CMX modulescan be
used for coded functions (March Time, California Code, Temporal, and
Two-stage).
Control-by-event (CBE) control is done through 99 software zones. Each
input point (detector, MMX) and output point (CMX, NAC) can be pro-
grammed to list up to five software zones. Non-Alarm or Supervisory points
do not activate software zone Z00 (general alarm). You can list zone Z00 for
output points, but you do not need to list Z00 for input points.
Input and output devices with listed software zones work as follows:
 Inputs  When an input device (detector or MMX) activates, so do all
listed software zones listed to the input device.
 Outputs  When a software zone activates, the output device (an OR
function).
CBE Example
Detector D102 lists zone 05. NAC1 lists zone F05 and zone Z07.
1) Detector D102 activates.
2) Zone Z05 activates.
3) Bell (B02) wired to NAC1 activates.
Notification Appliance
Circuit (NAC) Operation
Trouble Monitor Point
Operation
Control-By-Event
Operation
edoCepyT...sihtseoD...rofdesU
erif-noN
)gnikcarT(
.ylnotnevE-yb-lortnoCsetavitcAtnemeganamygrenE
erif-nonrehtoro
.snoitautis
trelAdrazaH
)dehctaL(
DCLehtotegassemasdneS
dna,retnirp,elifyrotsih,yalpsid
dna,)evitcAsutats(08-DCL
rofnoitcelesedocsedirrevo
8Fenozehtfosseldrager,sCAN
.noitcelesgnidoc
lacitircgnirotinoM
rehtorosessecorp
,snoitautissuodrazah
.odanrotasahcus
lortnoCeriF
)gnikcarT(
,DCLehtotsegassemsdneS
.08-DCLdnaretnirp,elifyrotsih
reldnahriA
dednetni,nwodtuhs
citamotuaedirrevoot
Zones F0-F9 are reserved for
special functions such as
cross-zoning (refer to the
IQ-396X Programming
Manual ).

AUTOPULSE IQ-396X Operations Doc. 50403:B 07/22/96 7
Releasing Functions
Overview
Refer to Appendix A for
more information about
releasing functions.
Cross Zoning Examples
Figure 10 contains a table showing examples of devices mapped to releasing
zones (ZR1 stands for Releasing Zone 1).
sserddAeciveDepyTeciveDgnippaMenoZ
101DekomSrotceteD10Z1RZ
201DekomSrotceteD10Z1RZ
301DekomSrotceteD20Z1RZ
401DtaeHrotceteD20Z1RZ
10B)tkCleR(tiucriCtuptuO1RZ
Figure 10: Devices Mapped to Releasing Zones
Cross Zoning Options
Zones R0-R9 are reserved for releasing zonesproviding up to ten independent
releasing operations. Each releasing zone includes the following options:
 Cross-zoning  Select one of three types of cross-zoning. Refer to Cross
Zoning Options below.
 Delay timer  Select a 060 second delay before activating a zone.
 Abort  An abort switch-type code used to abort activation of a zone.
 Manual Release  Allows immediate zone activation by overriding the abort
function, cross-zone function, and delay timer.
 Soak Timer  Automatically shuts off the releasing device. Select 0001-9999
seconds for a Soak Timer or 0000 seconds for no Soak Timer.
Cross Zoning lets you program the control panel to activate a releasing zone
and any output mapped to the releasing zone. (If not using Cross Zoning, set
CROSS= to N.) Figure 9 contains a table that summarizes the types of cross
zoning and the conditions for activating a releasing zone.
epyT...lenaplortnocehtnehwsetavitcA
Y gnisaelernetehtfoenootdeppamlla,srotcetederomroowtspirT
.)9R-0R(senoz
ZerawtfostnereffidowtotdeppamsrotcetederomroowtspirT
.)9R-0R(senozgnisaelernetehtfoenodnasenoz
H lla,rotcetedtaehenotsaeltadnarotcetedekomsenotsaeltaspirT
.)9R-0R(senozgnisaelernetehtfoenootdeppam
Figure 9: Cross Zoning Types
Only the first non-
special zone listed in the
zone map is used to
determine Cross=Z.
The following explanations apply to the examples listed in Figure 10:
Cross=N  An alarm from any detector activates the releasing circuit.
Cross=Y  An alarm from any two detectors activates the releasing circuit.
Cross=Z  Release requires the activation of two detectors mapped to differ-
ent zones: D101 and D102 cannot activate the releasing circuit because both
detectors are mapped to Z1; D101 and D103 can activate the releasing circuit
because they are mapped to different zones.
Cross=H  Release requires activation of heat detector D104 and one smoke
detector (D101, D102, or D103).

8AUTOPULSE IQ-396X Operations Doc. 50403:B 07/22/96
Figure 11 contains descriptions for intelligent detector functions used with the
IQ-396X.
Intelligent Detector Functions
For instructions
on selecting
Intelligent
Detector Func-
tions, refer to the
IQ-396X Pro-
gramming
Manual.
Continued on the next page...
Figure 11: Intelligent Detector Functions
noitcnuFnoitpircseD
yalpsiDgolanA morfnoitamrofnigolanasyalpsiddnasdaerlenaplortnocehT
ehtfotnecrepehtswohsyalpsidehT.srotcetedgolana891eht
.rotcetedhcaerofdlohserhtmrala
ytivitisneS
tsujdA
mralarotcetedtnegilletnignittesyllaunamrofsnoitceleseniN
gnisufI.egnarLUehtnihtiwslevelsrotcetednoitazinoItcudni
.1leveLottsujdAytivitisneStes,snoitacilppa
thgiN/yaD
ytivitisneS
noitarepO
ekomsecrofyllacitamotuaotmetsysehtmargorpnacuoY
eromroF.yadehtgnirudytivitisnesmuminimotsrotceted
sihtniretalnoitarepolortnoCemiTotrefer,noitamrofni
.retpahc
ecnanetniaM
trelA
tfirdfotnuomaehtfotimilehtsehcaernoitasnepmocnehW
lenaplortnoceht,deilppaylefasebnactahtnoitasnepmoc
edoceriflanoitanrep,noitidnocelbuortlaicepsastroper
sniamerrotcetedehtfisetavitcaoslanoitidnocsihT.sdradnats
.emitdednetxenarofslevelwolyrevrohgihyrevta
tseTcitamotuA
noitarepO
rotcetedhcaefotsetcitamotuanasmrofreplenaplortnocehT
nasesuacstimiltsetehtteemoteruliaF.setunim652yreve
.elbuortLIAFTSETOTUA
edoCepyT
noisivrepuS
,XPC(sedocepytecivederawdrahsrotinomlenaplortnocehT
ralugertaeciveddellatsnihcaerof)XMCdna,XMM,XDF,XDS
llufrofsetunim03otpuekatnaclavretnina(slavretni
ehtotderapmocepytfohctamsimafI.)metsysyticapac
elbuorttniopasetareneglenaplortnoceht,sruccomargorp
.epyTdilavnIdellebal
lortnoCDEL
noitarepO
morfsDELrotcetedtneverpotnoitcelesmargorplabolgA
asinoitacilppalacipytA.noitarepolamrongnirudgniknilb
asA.elpoeptcartsidnacthgilgniknilbaerehwaeragnipeels
nonrutotsDELllaswollalenaplortnoceht,noitcnufdradnats
.mralani
mralA
dnanoitacifireV
retnuoC
noitarepO
demmargorpnonoitacifirevmralasmrofreplenaplortnocehT
noitacifirevehT.srotcetedekomstnegilletniXDSdnaXPC
hcaE.sdnoces030fonoitcelesmargorplabolgasiemit
ehtsyalpsidhcihw,retnuocnoitacifirevasedulcnirotceted
tondidtubnoitacifirevderetnerotcetedatahtsemitforebmun
.sdlohdna99otstnemercniretnuocehT.mralaottuo-emit

AUTOPULSE IQ-396X Operations Doc. 50403:B 07/22/96 9
If an SDX or CPX detector exceeds the programmed Pre-Alarm level, a
Pre-Alarm condition occurs: the panel sounder and zone F9 activate;
and the Pre-Alarm LED lights. Figure 12 shows a sample Pre-Alarm
messagesent to the LCD display, optional LCD-80, optional printer,
and history filefor a control panel programmed for an Alert Pre-Alarm.
Pre-Alarm Operation (AWACS)
Intelligent Detector Functions
Figure 12 shows a detectorprogrammed for a Pre-Alarm level of 5
that reaches 105% of the programmed Pre-Alarm level. The 105% is a
real-time display and tracks smoke levels.
If programming a control panel for an Action Pre-Alarm, the display
remains the same, but the word Action replaces Alert. The control
panel latches for Action Pre-Alarms and applies the programmed
control functions.
Figure 12: Alert Pre-Alarm message
PREALARM SMOKE (PHOTO) I.C.U WEST WING
ALERT 105%/5 12:01A 11/01/95 D101
ALERT Pre-Alarms automatically
restore.

10 AUTOPULSE IQ-396X Operations Doc. 50403:B 07/22/96
Operating Time Functions
The control panel includes a real-time clock that provides time-of-day, date,
and day-of-week. The clock includes a lithium battery backup. Time
normally displays in a 12-hour time format with month/day/year. Figure13
contains descriptions and typical uses for time functions.
emiT
noitcnuF
noitpircseDsesUlacipyT
lortnoCemiT
dnammoC
devreserera6Fdna5FsenoZ
laicepsemit-yb-lortnocrof
rofdednetni,snoitcnuf
)erif-non(yrallicna
gnithgilsahcus(snoitacilppa
,tatsomrehtagnittes,lortnoc
.)htrofosdna
senozmargorp,elpmaxeroF
enotaetavitcaot6Fdna5F
taetavitcaeddnayadfoemit
syadniatrecno,emitrehtona
anrutnacuoY.keewehtfo
dnanotnioplortnocerif-non
.6Fro5Fenozgnisuyb,ffo
thgiN/yaD
ytivitisneS
tsujdA
EBCrotcetedXDSroXPCafI
lortnoceht,6Fro5Fenozstsil
rotcetedehtsteslenap
muminimehtotytivitisnes
ro5Fenoznehwgnittes)wol(
ehtybdetavitcasi6F
stiniemit/etaddemmargorp
6Fro5FenoznehW.EBC
rotcetedeht,setavitcaed
ehtotsnruterytivitisnes
,esuytivitisnesthgin/yadroF
sa6Fdna5Fsenozredisnoc
.senozYAD
yadiloHsevreserlenaplortnocehT
yadilohgnittesrof7Fenoz
ehtnehW.)syad9otpu(setad
foynasehctametadtnerruc
eht,setadyadilohenineht
enozsetavitcalenaplortnoc
7FenozrofsesurehtO
raey-fo-yadlaicepsa:edulcni
niyadht8naro;lortnoc
dna5Fsenozgnimmargorp
.6F
Figure 13: Control Time Functions
Zone F8reserved for NAC coding functionsis only used by panel NAC
circuits listing zone F8. You can select one of the type codes in Figure 14:
edoClangiS
emiThcraM
)tluafed( )etuniMrePsesluP(MPP021
egatS-owT:langismralalareneG;MPP02langistrelA
noydaetS
ainrofilaCstaeper,ffo.ces5,no.ces01
laropmeT,ffo5.1,no5.0,ffo5.0,no5.0,ffo5.0,no5.0
Figure 14: Zone F8 Type Codes
CMX modules  Zone F8 does not work if listed in the CBE of CMX mod-
ules.
Two-Stage  When an alarm occurs, an NAC programmed for two-stage, and
not activated by another zone, pulses at 20 PPM. After 5minutes, the NAC
changes to steady on unless you press <Acknowledge/Step>. Pressing
<Alarm Activate> on the control panel changes the NAC pulse to steady.
ICM-4/ICE-4 modules do not support Two-Stage and turn on steady.
ICM-4/ICE-4 modules  To enable California Code, cut D35 on the ICM-4
modules. If D35 is not cut, ICM-4/ICE-4 modules turn on steady.
Operating Coding
Functions
Notes on using Zone F8
Overview
Time Functions

AUTOPULSE IQ-396X Operations Doc. 50403:B 07/22/96 11
Zone F0 is reserved for Presignal functions. Zone F0 can be used to delay
control points until an operator verifies an active control point. If including
zone F0 in a CMX or NAC CBE list, zone F0 overrides of all other CBE
actions. Detectors and monitor modules must list zone F0 in the CBE to be
included in the Presignal/PAS operation.
...fI...ro/dnA...0FenoZ
sruccomralanaepyttibihniSAPonsierehtdna
XMM
setavitca
mraladnocesa
setavitca
etavitcamralaehtsserpuoyro
yek
eslafseog
SAPtcelesuoysserptonoduoydna
nihtiwEGDELWONKCA
eslafseog
Figure 15: Presignal Operation
At the first alarm, a programmable 0180 second timer starts. If a Signal
Silence occurs, the timer stops. If the delay timer expires, manual activation
will activate outputs mapped to zone F0. The System Alarm relay, the 4XTM
Polarity Reversal Alarm Output, and the 4XTM Municipal Box Output delay if
PAS is selected, but do not delay for Presignal operations.
Presignal/Positive
Alarm Sequence (PAS)
Operation
The control panel can operate with special system timers: Silence Inhibit,
Auto Silence, and Alarm Verification. Figure 16 contains descriptions of how
each timer works.
Special System Timers
Disabled input points do not cause an alarm or any Control-by-Event activity.
The control panel does the following:
 holds all disabled output points in the off-state; and
 handles all disabled points as troubles, but displays DISABL in the status
banner.
If an alarm originates from a monitor point with a waterflow type code, the
control panel disables the Alarm Silence switch. Refer to the IQ-396X
Installation Manual for information on Waterflow Circuits.
The control panel will detect a trouble in an SLC wired and programmed for
Style 6 or Style 7 and drive both ends of the line to maintain communication
over the loop. The trouble latches and displays on the panel as a Style 6
trouble type until you press <System Reset>. Style 7 requires use of ISO-X
modules.
Style 6 Operation
Waterflow Circuits
Operation
Disable/Enable Operation
Figure 16: Special System Timers
remiTnoitaruD...detceleSfI
ecneliS
tibihnI
sdnoces003-0wenhcaehtiwstratserdnamralatsriftastratS
.hctiwsecneliSmralAehtselbasiD.mrala
ecneliSotuAsdnoces009-006
remiton=0(
)detceles
oT.>ecneliSmralA<sserpfisasnoitcnuF
.>etavitcAmralA<sserp,remitehttratser
mralA
noitacifireV
sdnoces03-0XDSroXPCaserongilenaplortnocehT
.emitnoitacifireVmralAehtrofrotcetedekoms
ehtgnirudsruccomralatnioprehtonafI
lenaplortnoceht,emitnoitacifireVmralA
afI.mralaehtsetavitcadnaremitehtspmud
gnitaitinieht,tsixemralanadnatuo-emit
fI.snoitcnufdradnatsllasetucexeEBCecived
ehtnistsixeregnolonmralanatuo-emitta
lenaplortnoceht,secivedgnitaitinimrala
rof)99-1(retnuocnoitacifirevastnemercni

12 AUTOPULSE IQ-396X Operations Doc. 50403:B 07/22/96
Read Status
Press <Enter>. The control panel displays the following screen:
Read Status functions do not require a password. The control panel will con-
tinue to provide fire protection while in Read Status. You can enter Read Status
while in Fire Alarm or Trouble mode. If a new alarm or trouble occurs during
these functions, the control panel automatically exits Read Status.
Overview
How to enter Read
Status
READ POINT=0 HIST=2 ALARM HIST=4 <ENTER>
PRNT POINT=1 HIST=3 ALARM HIST=5 <ENTER>
During all Read Status operations (except print operations) the control panel
starts a 2-minute timer each time you press a key. If the control panel does not
detect a key press for 2 minutes, the control panel leaves the current operation
and returns to the previous display.
 Press <Esc> to delete the previous entry.
 Press <System Reset> to abort Read Status.
Read Point options let you display point and zone status on the display, but the
information is not sent to the serial ports or the history file. To read the status
of points and zones, press <0> then <Enter> from the Read Status screen. The
control panel displays the Read Point screen (Figure 20):
Figure 20: Read Point Screen
...oT...sihtoD
tnioPdaeR sserP.1
C0
sserP.2 IJHz
.sserddaenozroecivedehtretnE.3
stnioPtnirP sserP
C1
yrotsiHdaeR sserP
C2
yrotsiHtnirP sserP
C3
yrotsiHmralAdaeR sserP
C4
yrotsiHmralAtnirP sserP
C5
Figure 19: Read Status Options
If attempting to read a
point that is not
installed, the control
panel displays NOT
INSTALLED.
ZONE=Z,AA,E DETECTOR=*,AAA,E
MODULE=#,AAA,E OUTPUT CKT=&,A-A,E
 To read a detector, press Hthen enter the detector address.
 To read a module, press Ithen enter the module address.
 To read an output circuit, press Jthen enter the output circuit address.
1=PROGRAMMING 2=READ STATUS ENTRY
(ESCAPE TO ABORT)
Figure 17: Read Status Entry Screen
Press <2> and the control panel displays the following screen:
Figure 18: Read Status Screen
To do a Read Status, follow the instructions in Figure 19.
Read Status for Points
and Zones
Read Status
Options

AUTOPULSE IQ-396X Operations Doc. 50403:B 07/22/96 13
Read Status
Read Status for a Detector, Module, or Output
From the Read Status screen, press <0>; then press <Enter>. You can then
read the status of a detector, module, or output. For example, to read the
status of a detector at D101, press H, enter the address (D101), then press
<Enter>. The control panel displays information about the detector as
shown in Figure 21:
Refer to the IQ-396X Program-
ming Manual for information on
Alarm and Pre-Alarm sensitivity.
dleiFnoitpircseD
)OTOHP(EKOMSrotcetedehtfoedocepyT
101RDDAROTCETED )10sserdda=10;1pool=1(101:lebalmotsuctluafeD
30Z:noitcelesenoztluafeD
)srotcetedtaeH(10enoZ
)srotcetednoI(20enoZ
)srotcetedotohP(30enoZ
)srotcetedresaL(40enoZ
)srotceteditluM(50enoZ
hcaerofsenozeromruofddasallewsasenozegnahcnacuoY
.EBCsrotceted
5:LA 1dnaevitisnestsaeleht9htiw,levelytivitisnesmralaehT
.evitisnestsomeht
0:AP dna0neewtebrebmunagnitteslevelmralA-erPehtswohS
:swollofsa9
mralA-erPon0
evitisnestsaeleht9htiw,levelytivitisnesmrala-erPehT
.evitisnestsomeht1dna
rotceteditluM )ffo=*(:gnittesrotceteditlumehtsetacidni)*(ksiretsatsrifehT
sinoisicedmralas'rotcetedehtA
.evobasserddatxenehthtiwdenibmoc
.wolebsserddatxenehtsesuB
txenehtfonoitanibmocehtsesuC
.sserddatsehgihtxenehtdnatsewol
noitacifreVmralA gnittesnoitacifireVmralAehtsetaccidni)*(ksiretsadnocesehT
.)ffo=*;n0=V(
Read Status for a Zone Address
From the Read Point screen, press z, then enter the zone address (01-99)
Figure 23 shows the default Read Status display for a zone:
OFF SOFTWARE ZONE FLOOR 5 MAIN BLDG
Z04
Zone status (ON or OFF)
Zone number
Figure 22: Default Read Status Values for a Detector
Figure 21: Detector Read Status Sample Screen
NORMAL SMOKE (PHOTO) DETECTOR ADDR 101
Z03 Z Z Z Z 000%A5 PA:0 ** D101
Alarm Verification
Multidetector
Read Status for Points and
Zones
Figure 23: Read Status Display for a Zones Address
 Press Lto read a point or zone
with next highest address; or
 Press Mto read a point or
zone with next lowest address.

14 AUTOPULSE IQ-396X Operations Doc. 50403:B 07/22/96
Read Status
The control panel maintains a history file of the last 800 events, each with a
time and date stamp. History events include the following:
 All alarms, troubles and operator actions, such as: Acknowledge, System
Reset, Alarm Silence, Alarm Activate, and Walk Test.
 Programming entries, along with a number (0-9) indicating the program-
ming submenu (for example, 0=Clear).
The control panel contains two event buffers: a History buffer that can store
up to 800 events (all types); and an Alarm buffer that can store up to 200
alarm events.
View Event History
From the Read Status screen, press <2>; then, press <Enter>. The control
panel displays the Event History screen (Figure 24):
Viewing and printing Hidden History is similar to Read Point. Once you
read a Hidden History, you can do the following:
 Press Lto view the next event in sequence; or
 Press Mto view the previous event in sequence.
EVENT HISTORY START
EVENTS IN HIST : 800
ALARM HISTORY START (ESCAPE TO ABORT)
ALARMS IN HIST : 200
...oT...sserP
yrotsihmralAneddiHdaeR
C6
yrotsihmralAneddiHtnirP
C7
lamroNneddiHdaeR
yrotsih
C8
lamroNneddiHtnirP
y
rotsih
C9
View or Print Hidden History
If you clear History, events remain in a shadow fileknown as a hidden
history file. To display or print a hidden history file, follow the instructions
in Figure 26. To clear the history file, refer to the instructions in the
IQ-396X Programming Manual.
Figure 24: Event History Screen
Figure 25: Alarm History Screen
Figure 26: Hidden History Selections
View Alarm History
From the Read Status screen, press <2>; then, press <Enter>. The control
panel displays the Event History screen (Figure 25):
The number of events in the
History buffer
The number of events in the
Alarm buffer
Read History
