An automatic fire alarm system–typically made up of smoke
detectors, heat detectors, manual pull stations, audible warn-
ing devices, and a fire alarm control with remote notification
capability–can provide early warning of a developing fire.
Such a system, however, does not assure protection against
property damage or loss of life resulting from a fire.
The Manufacturer recommends that smoke and/or heat detec-
tors be located throughout a protected premise following the
recommendations of the current edition of the National Fire
Protection Association Standard 72 (NFPA 72),
manufacturer's recommendations, State and local codes, and
the recommendations contained in the Guide for Proper Use
of System Smoke Detectors, which is made available at no
charge to all installing dealers. A study by the Federal Emer-
gency Management Agency (an agency of the United States
government) indicated that smoke detectors may not go off in
as many as 35% of all fires. While fire alarm systems are de-
signed to provide early warning against fire, they do not guar-
antee warning or protection against fire. A fire alarm system
may not provide timely or adequate warning, or simply may not
function, for a variety of reasons:
Smoke detectors may not sense fire where smoke cannot
reach the detectors such as in chimneys, in or behind walls, on
roofs, or on the other side of closed doors. Smoke detectors
also may not sense a fire on another level or floor of a build-
ing. A second-floor detector, for example, may not sense a
first-floor or basement fire.
Particles of combustion or "smoke" from a developing fire
may not reach the sensing chambers of smoke detectors be-
cause:
• Barriers such as closed or partially closed doors, walls, or
chimneys may inhibit particle or smoke flow.
• Smoke particles may become "cold," stratify, and not reach
the ceiling or upper walls where detectors are located.
• Smoke particles may be blown away from detectors by air
outlets.
• Smoke detectors may be drawn into air returns before
reaching the detector.
The amount of "smoke" present may be insufficient to alarm
smoke detectors. Smoke detectors are designed to alarm at
various levels of smoke density. If such density levels are not
created by a developing fire at the location of detectors, the
detectors will not go into alarm.
Smoke detectors, even when working properly, have sensing
limitations. Detectors that have photoelectronic sensing
chambers tend to detect smoldering fires better than flaming
fires, which have little visible smoke. Detectors that have ion-
izing-type sensing chambers tend to detect fast-flaming fires
better than smoldering fires. Because fires develop in differ-
ent ways and are often unpredictable in their growth, neither
type of detector is necessarily best and a given type of detec-
tor may not provide adequate warning of a fire.
Smoke detectors cannot be expected to provide adequate
warning of fires caused by arson, children playing with
matches (especially in bedrooms), smoking in bed, and violent
explosions (caused by escaping gas, improper storage of
flammable materials, etc.).
Heat detectors do not sense particles of combustion and
alarm only when heat on their sensors increases at a prede-
termined rate or reaches a predetermined level. Rate-of-rise
heat detectors may be subject to reduced sensitivity over time.
For this reason, the rate-of-rise feature of each detector
should be tested at least once per year by a qualified fire pro-
tection specialist.
Heat detectors are designed to protect
property, not life.
IMPORTANT! Smoke detectors must be installed in the
same room as the control panel and in rooms used by the sys-
tem for the connection of alarm transmission wiring, communi-
cations, signaling, and/or power. If detectors are not so lo-
cated, a developing fire may damage the alarm system, crip-
pling its ability to report a fire.
Audible warning devices such as bells may not alert people
if these devices are located on the other side of closed or
partly open doors or are located on another floor of a building.
Any warning device may fail to alert people with a disability or
those who have recently consumed drugs, alcohol or medica-
tion. Please note that:
•Strobes can, under certain circumstances, cause seizures
in people with conditions such as epilepsy.
•Studies have shown that certain people, even when they
hear a fire alarm signal, do not respond or comprehend the
meaning of the signal. It is the property owner's responsibil-
ity to conduct fire drills and other training exercise to make
people aware of fire alarm signals and instruct them on the
proper reaction to alarm signals.
•In rare instances, the sounding of a warning device can
cause temporary or permanent hearing loss.
A fire alarm system will not operate without any electrical
power. If AC power fails, the system will operate from standby
batteries only for a specified time and only if the batteries
have been properly maintained and replaced regularly.
Equipment used in the system may not be technically com-
patible with the control. It is essential to use only equipment
listed for service with your control panel.
Telephone lines needed to transmit alarm signals from a
premise to a central monitoring station may be out of service
or temporarily disabled. For added protection against tele-
phone line failure, backup radio transmission systems are rec-
ommended.
The most common cause of fire alarm malfunction is inade-
quate maintenance. To keep the entire fire alarm system in
excellent working order, ongoing maintenance is required per
the manufacturer's recommendations, and UL and NFPA stan-
dards. At a minimum, the requirements of Chapter 7 of NFPA
72 shall be followed. Environments with large amounts of
dust, dirt or high air velocity require more frequent mainte-
nance. A maintenance agreement should be arranged
through the local manufacturer's representative. Maintenance
should be scheduled monthly or as required by National and/
or local fire codes and should be performed by authorized pro-
fessional fire alarm installers only. Adequate written records
of all inspections should be kept.
While a fire alarm system may lower insurance
rates, it is not a substitute for fire insurance!
Fire Alarm System Limitations

Precau-Lg.p65 01/18/2000
WARNING - Several different sources of power can be con-
nected to the fire alarm control panel.
Disconnect all sources
of power before servicing. Control unit and associated equip-
ment may be damaged by removing and/or inserting cards,
modules, or interconnecting cables while the unit is energized.
Do not attempt to install, service, or operate this unit until this
manual is read and understood.
CAUTION -
System Reacceptance Test after Software
Changes. To ensure proper system operation, this product
must be tested in accordance with NFPA 72 Chapter 7 after
any programming operation or change in site-specific soft-
ware. Reacceptance testing is required after any change, ad-
dition or deletion of system components, or after any modifica-
tion, repair or adjustment to system hardware or wiring.
All components, circuits, system operations, or software func-
tions known to be affected by a change must be 100% tested.
In addition, to ensure that other operations are not inadvert-
ently affected, at least 10% of initiating devices that are not
directly affected by the change, up to a maximum of 50 de-
vices, must also be tested and proper system operation veri-
fied.
This system meets NFPA requirements for operation at
0-49°C/32-120°F and at a relative humidity of 85% RH (non-
condensing) at 30°C/86°F. However, the useful life of the
system's standby batteries and the electronic components
may be adversely affected by extreme temperature ranges
and humidity. Therefore, it is recommended that this system
and all peripherals be installed in an environment with a nomi-
nal room temperature of 15-27°C/60-80°F.
Verify that wire sizes are adequate for all initiating and
indicating device loops. Most devices cannot tolerate more
than a 10% I.R. drop from the specified device voltage.
Like all solid state electronic devices, this system may
operate erratically or can be damaged when subjected to light-
ning-induced transients. Although no system is completely
immune from lightning transients and interferences, proper
grounding will reduce susceptibility.
Overhead or outside
aerial wiring is not recommended, due to an increased sus-
ceptibility to nearby lightning strikes.
Consult with the Techni-
cal Services Department if any problems are anticipated or
encountered.
Disconnect AC power and batteries prior to removing or in-
serting circuit boards. Failure to do so can damage circuits.
Remove all electronic assemblies prior to any drilling, filing,
reaming, or punching of the enclosure. When possible, make
all cable entries from the sides or rear. Before making modifi-
cations, verify that they will not interfere with battery, trans-
former, and printed circuit board location.
Do not tighten screw terminals more than 9 in-lbs.
Over-tightening may damage threads, resulting in reduced
terminal contact pressure and difficulty with screw terminal
removal.
Though designed to last many years, system components
can fail at any time. This system contains static-sensitive
components. Always ground yourself with a proper wrist strap
before handling any circuits so that static charges are re-
moved from the body. Use static-suppressive packaging
to protect electronic assemblies removed from the unit.
Follow the instructions in the installation, operating, and
programming manuals. These instructions must be followed
to avoid damage to the control panel and associated
equipment. FACP operation and reliability depend upon
proper installation by authorized personnel.
Adherence to the following will aid in problem-free
installation with long-term reliability:
WARNING: This equipment generates, uses, and can
radiate radio frequency energy and if not installed and
used in accordance with the instruction manual, may
cause interference to radio communications. It has
been tested and found to comply with the limits for class
A computing device pursuant to Subpart B of Part 15 of
FCC Rules, which is designed to provide reasonable
protection against such interference when operated in a
commercial environment. Operation of this equipment in
a residential area is likely to cause interference, in which
case the user will be required to correct the interference
at his own expense.
Canadian Requirements
This digital apparatus does not exceed the Class A
limits for radiation noise emissions from digital
apparatus set out in the Radio Interference Regulations
of the Canadian Department of Communications.
Le present appareil numerique n'emet pas de bruits
radioelectriques depassant les limites applicables aux
appareils numeriques de la classe A prescrites dans le
Reglement sur le brouillage radioelectrique edicte par le
ministere des Communications du Canada.
FCC Warning
Installation Precautions

4Autopulse-442R 50098:F 05/24/2001
This control panel complies with the following NFPA standards:
• NFPA 12 CO2 Extinguishing Systems (High Pressure Only)
• NFPA 12A Halon 1301 Extinguishing Systems
• NFPA 12B Halon 1211 Extinguishing Systems
• NFPA 72 Central Station Signaling Systems (Automatic, Manual, and Waterflow). Protected Premises Unit
(Requires 411UDAC or NOTI•FIRE 911AC DACT or MS-5012 Slave Communicator)*
• NFPA 72 Local (Automatic, Manual, Waterflow and Sprinkler Supervisory) Fire Alarm Systems
• NFPA 72 Auxiliary (Automatic, Manual, and Waterflow) Fire Alarm Systems. (Requires 4XTM)
• NFPA 72 Remote Station (Automatic, Manual, and Waterflow) Fire Alarm Systems. Requires (4XTM or
411UDAC DACT or NOTI•FIRE 911AC DACT*)
• NFPA 72 Proprietary (Automatic, Manual, and Waterflow) Fire Alarm Systems. (Requires Potter #EFT-C
McCulloh Transmitter)*
• NFPA 2001 Clean Agent Fire Extinguishing Systems
* Applications which require the 411UDAC, the NOTI-FIRE 911AC, or the Potter EFT-C are not FM approved
NFPA Standards
•NFPA 72 Automatic Fire Detectors
•NFPA 72 Installation, Maintenance, and Use of Notification Appliances for Fire Alarm Systems
•NFPA 72 Testing Procedures for Signaling Systems
•NFPA 2001 Clean Agent Fire Extinguishing Systems
Underwriters Laboratories Documents:
•UL 38 Manual Actuated Signaling Boxes
•UL 217 Smoke Detectors, Single and Multiple Station
•UL 228 Door Closers - Holders for Fire Alarm Systems
•UL 268 Smoke Detectors for Fire Alarm Systems
•UL 268A Smoke Detectors for Duct Applications
•UL 346 Waterflow Indicators for Fire Alarm systems
•UL 464 Audible Signaling Appliances
•UL 521 Heat Detectors for Fire Alarm Systems
•UL 864 Standard for Control Units for Fire Alarm Systems
•UL 1481 Power supplies for Fire Alarm Systems
•UL 1638 Visual Signaling Appliances
•UL 1971 Signaling Devices for the Hearing Impaired
•CAN/ULC-S524-M91 Standard for Installation of Fire Alarm Systems
•CAN/ULC-S527-M87 Standard for Control Units for Fire Alarm Systems
Other:
•NEC Article 300 Wiring Methods
•NEC Article 760 Fire Alarm Systems
•Applicable Local and State Building Codes
•Requirements of the Local Authority Having Jurisdiction
•Ansul Device Compatibility Document, 50054.
•ADA Americans with Disabilities Act
Before proceeding, the installer should be familiar with the following documents.

Autopulse-442R 50098:F 05/24/2001 5
1 Product Description ..........................................................................................6
1.1: Features ....................................................................................................6
1.2: Circuits......................................................................................................6
1.3: Optional Boards ......................................................................................9
1.4: Remote Annunciator .................................................................................10
1.5: Optional Meters.........................................................................................11
1.6: Specifications ............................................................................................11
2 Installation Procedure ......................................................................................13
2.1: Cabinet Mounting .....................................................................................13
2.2: UL Power-limited Wiring Requirements .................................................14
2.3: Power Feed Wiring....................................................................................14
2.4: Initiating Device Circuits..........................................................................15
2.5: Four-Wire Smoke Detector Connections ..................................................16
2.6: Output Circuits..........................................................................................17
2.7: Powering External Devices .......................................................................18
2.8: Voltmeter/Ammeter ..................................................................................19
2.9: Optional Modules ....................................................................................20
2.10: Setting Mode of Operation .....................................................................24
2.11: Power-Up Procedure ...............................................................................26
3 System Operation .............................................................................................28
3.1: System Status LEDs .................................................................................28
3.2: Control Switches.......................................................................................29
3.3: Zone Status LEDs ....................................................................................29
3.4: Piezo..........................................................................................................30
3.5: Supervisory Service .................................................................................30
3.6: Zone Disable ............................................................................................30
3.7: Last Event Recall .....................................................................................31
3.8: Non-Silenceable Service ..........................................................................31
3.9: Sprinkler Supervisory Tracking ...............................................................31
3.10: System Events.........................................................................................31
Appendix A: Power Calculations .......................................................................33
Appendix B: NFPA Standard-Specific Requirements .....................................35
Appendix C: Testing & Maintenance .................................................................42
Index ......................................................................................................................44
Table of Contents

6Autopulse-442R 50098:F 05/24/2001
Section 1 Product Description
The Autopulse-442R/442RE Fire Alarm Control Panel has been designed as a control center for
use in automatic fire suppression systems. The Autopulse-442R/442RE is a feature-packed
control unit suitable to perform detection and control functions associated with the release of
gaseous agent/special hazard fire protection systems. The panel is designed for maximum
reliability with 100% solid state circuitry and isolated relay contacts for outside interfacing. The
panel features programmable options to allow on-site customization of the unit for various
operating configurations.
The Autopulse-442R/442RE is supplied complete with backbox, hinged door, control switches,
and indicator LEDs. The Autopulse-442R is a 120 VAC fire alarm control panel. The
Autopulse-442RE is an export version of the Autopulse-442R that runs on 220/240 VAC. The
Autopulse-442RC is a 120 VAC control unit that functions according to the requirements of
Underwriters Laboratories of Canada (ULC). An integral standby battery system, with charger,
is provided. In case of commercial AC power interruption, automatic switchover to the battery
system will provide power to the panel for a minimum of 24 hours.
)HDWXUHV
* Applications which require the 411UDAC, the NOTI-FIRE 911AC, or the Potter EFT-C are not
FM approved.
&LUFXLWV
,QSXW&LUFXLWV
Detector Zone 1, Style D (Class A)/Style B (Class B)
Detector Zone 2, Style D (Class A)/Style B (Class B)
Abort, Style D (Class A)/Style B (Class B)
Manual Release, Style D (Class A)/Style B (Class B)
•Microprocessor-controlled
•Power-limited on all circuits except
Municipal Box output and Releasing
Circuits
•Alarm and trouble resound
•Four Style D (Class A) / Style Y (Class B)
Initiating Device Circuits
•Two Style Z (Class A) / Style Y (Class B)
Notification Appliance Circuits
•Two Style Y (Class B) Releasing Circuits
•General alarm and trouble relays
•Optional module for 4 zone/function
relays (4XZM)
•Optional transmitter module (4XTM).
•Optional volt/amp meter module (4XMM)
•Optional supervised remote annunciator
(RZA-4X) Requires LED Interface
Module (4XLM)
•Optional digital communicator
(411UDAC)
•Supervisory Input Option
•Delay timer (adjustable)
•Three abort function options
•Designed for suppression standards
•Disable/enable controls per initiating zone
•Last Event Recall
•Battery/Earth fault supervision
•Fuse protection on all Notification/Release
Circuits
•RMS regulated output power, 2.25 amps
•7 amp-hour (AH) to 18 AH battery
options, up to 90 hours standby
•Resettable and nonresettable regulated
power outputs
•Extensive transient protection
•Watchdog timer to supervise
microprocessor
•Output circuits protected against false
activations
•Slide-in zone identification labels
•Steel cabinet 14.5 in (368.3 mm) wide by
16 in (406.4 mm) high by 5 in (127 mm)
deep
•Dead-front dress panel option (DP-4X)
(Required for Canadian applications)
•Trim ring for flush mount between 16 in
(406.4 mm) center studs (TR-4XR)
•Abort and manual release circuits
•Cross-zone option

Autopulse-442R 50098:F 05/24/2001 7
2XWSXWFLUFXLWV
*Optional auxiliary relay module 4XZM tracks these four circuits.
Notification Appliance Circuit 1, Style Z (Class A)/Style Y (Class B)
Notification Appliance Circuit 2, Style Z (Class A)/Style Y (Class B)
Releasing Circuit 1, Style Y (Class B)
Releasing Circuit 2, Style Y (Class B)/Supervisory Input, Style B (Class B)
)URQW3DQHO&RQWURO6ZLWFKHV
Switch 1 Tone Silence
Switch 2 Alarm Silence
Switch 3 Alarm Activate
Switch 4 System Reset

Product Description
8Autopulse-442R 50098:F 05/24/2001
-
-
-
-
24 VVU RMS-Regulated 24 VR Regulated Resettable 24 VNR Regulated Nonresettable
1234
Notification
Appliance Circuits
(Supervised/Power-Limited)
Style Z (Class A)
Style Y (Class B)
Releasing
Circuits Relays
Trouble
Contacts
Alarm
Contacts 1234
Micro Fail LED
Abort
Abort
Delay Timer
Cross Zone
Supervisory
Delay Timer
Ground
Fault LED
Battery Fail LED
Batteries
Optional Ammeter
Connection
Optional Voltmeter
Connection
;53DFGU
Ground
Neutral
Hot
AC Circuit Breaker
Transformer
AC Power
Figure 1.1 Autopulse-442R Installation Diagram
Initiating Device
Circuits
Supervised/Power-Limited
Style D (Class A)
Style B (Class B)
Abort
Switch
Supervised
& Power-
Limited
Manual
Release
Supervised
& Power-
Limited
4XTM
or
4XZM
Note: If a module is
installed in this position,
cut jumper “OPT1”
on the main board.
4XTM
or
4XLM
or
4XZM
Note: If a module is
installed in this position,
cut jumper “OPT2”
on the main board.
=21( 
=21( 
$%257
0$18$/
5(/($6(
$& 32:(5
6<67(0 $/$50
5(/($6(
683(59,625<
6<67(0
7528%/(
&,5&8,7
7528%/(
$/$50
6,/(1&('
32:(5
7528%/(

Product Description
Autopulse-442R 50098:F 05/24/2001 9
2YHUYLHZRI',36ZLWFK6:)XQFWLRQV
2SWLRQDO%RDU V
The control panel has mounting slots for two optional boards. Any two
of the three optional modules may be installed.
7UDQVPLWWHU0R XOH;70
The Transmitter Module provides a supervised output for local energy
municipal box transmitter (for NFPA 72 Auxiliary Fire Alarm System)
and alarm and trouble reverse polarity circuits (for NFPA 72 Remote
Station Fire Alarm System). Also included is a DISABLE switch and
disable trouble LED.
As a jumper option, the alarm reverse polarity circuit will open on
trouble if no alarm exists.
Specifications for Local Energy Municipal Box service (NFPA 72
Auxiliary Fire Alarm System)
Supervisory current: 5.0 mA
Trip current: 0.35 amps. (Subtracted from Notification Appliance power)
Coil Voltage: 3.65 VDC
Coil resistance: 14.6 ohms
Maximum allowable wire resistance between panel and trip coil: 3 ohms
Municipal Box wiring can leave the building.
Specifications for Remote Station service (NFPA 72 Remote Station Fire Alarm System)
Maximum load for each circuit: 10 mA.
Reverse polarity output voltage: 24 VDC.
Remote Alarm and Remote Trouble wiring can leave the building.
DIP 1 Cross-zone OFF NAC 1 and 2, with Zone 1 or 2
NAC 2 runs at 60ppm then steady on time-out (unless frozen by abort)
Releasing Circuit 3 activated at time-out
Releasing Circuit 4 activated at time-out if not set as supervisory
ON NAC 1 on with first alarm, off on second alarm zone
NAC 2 on with both Zone 1 and 2. 60ppm and steady after time-out. Frozen by abort.
Releasing Circuit 3 activated at time-out
Releasing Circuit 4 activated at time-out if not set as supervisory
DIP 2 Supervisory OFF NAC Circuit 4 = Releasing Circuit
ON NAC Circuit 4 = Supervisory Circuit
DIP 3,
DIP 4 Timer OFF,OFF = No delay OFF,ON = 10 second delay
ON,OFF = 20 second delay
ON,ON = 30 second delay
Note: Timer starts on Zone 1 or 2 alarm, or both Zone 1 and Zone 2 if set for cross-zone.
DIP 5,
DIP 6 Abort OFF,OFF = Standard UL abort (“Deadman”abort) OFF, ON = IRI delay timer abort
ON, OFF = NYC delay timer abort
ON, ON = Local AHJ delay timer abort
Note: See “Setting Mode of Operation”in Section 2.10 for a more detailed explanation of DIP switch functions.
[WPLVFGU

Product Description
10 Autopulse-442R 50098:F 05/24/2001
/(',QWHUIDFH0R XOH;/0
The LED Interface Module supports the RZA-4X Remote Annunciator
module. Annunciator wiring is supervised for open conditions by this
module. The Annunciator Driver Module mounts to the main board on
the J8 option connectors.
Specifications
Maximum voltage/current, each output: 27.6 V / 8 mA.
Outputs are power-limited.
=RQH5HOD\0R XOH;=0
The Zone Relay module provides Form-C contacts for the following:
•Alarm detected (either zone/mode)
•First alarm, second alarm (Cross zone mode)
•Release
•General Alarm
•System Trouble
Specifications
Dry Form-C contacts rated: 2.0 amps @ 30 VDC (resistive), 0.5 amps
@ 30 VAC (resistive)
5HPRWH$QQXQFLDWRU
5HPRWH$QQXQFLDWRU5=$;
The Remote Annunciator mounts on a standard single-gang
box, and provides LED indication of the same functions as
the zone relay module. For example with DIP 1=ON and
DIP 2=OFF:
•One zone in Alarm (red)
•Two zones in Alarm (red)
•Releasing Circuit 1 (red)
•Releasing Circuit 2 (red)
•System Trouble (yellow)
A Local Trouble Sounder and Silence Switch are also
provided. All LED wiring is supervised for open conditions.
Any open condition will cause the System Trouble LED to
illuminate.
Note: The Remote Annunciator requires the use of an LED
Interface module (4XLM).
[OPWLI[]PZPI
5]D[IUZPI

Product Description
Autopulse-442R 50098:F 05/24/2001 11
2SWLRQDO0HWHUV
9ROWDJHDQ &XUUHQW0HWHUV;00
The Meter Module provides a voltmeter to measure the
voltage across the batteries and an ammeter to measure the
charging current to the batteries. The meters are provided as
an assembly that mounts to the lower left-hand corner of the
cabinet.
6SHFLILFDWLRQV
$&3RZHU
Autopulse-442R and Autopulse-442RC: 120 VAC, 50/60 Hz, 1.2 amps
Autopulse-442RE: 220/240 VAC, 50/60 Hz, 0.6 amps
Wire size: minimum #14 AWG with 600 V insulation
%DWWHU\OHD DFL RQO\
Maximum Charging Circuit: 27.6 VDC, 1.5 amps
Maximum Battery Capacity: 18 AH. (Batteries larger than 12 AH require
Notifier BB-17 or other UL-listed external battery cabinet.)
Minimum Battery Capacity: 7 AH
,QLWLDWLQJ'HYLFH&LUFXLWV
Power-limited circuitry
Operation: Style D (Class A)/Style B (Class B)
Normal Operating Voltage: 24 VDC (ripple = 1.0 V p-p)
Alarm current: 15 mA minimum
Short circuit current: 40 mA maximum
Maximum detector current in standby: 2 mA (max) per zone
Maximum loop resistance: 100 ohms
End-of-Line Resistor: 4.7K, 1/2-Watt (part # 418334, UL listed)
Detector loop current is sufficient to ensure operation of one alarmed detector per zone.
Supervisory current: 5 mA (including End-of-Line Resistor)
1RWLILFDWLRQ$SSOLDQFHDQ 5HOHDVLQJ&LUFXLWV
Power-limited circuitry
Maximum allowable voltage drop due to wiring: 2 VDC
Normal Operating Voltage: 24 VDC
Total current available to all external devices: 2.25 amps
Maximum signaling current per circuit: 1.5 amps
End-of-Line Resistor: 4.7K, 1/2-Watt (part # 418334, UL listed)
$ODUPDQ 7URXEOH5HOD\V
Dry Form-C contacts rated: 2.0 amps @ 30 VDC (resistive), 0.5 amps @ 30 VAC (resistive). Any
power connected to these relay contacts must come from a power-limited supply. Fail-safe
operation ensures trouble relay functions under loss of both primary power (AC) and secondary
(battery).
010 20 30
DC VOLTS
0
55
DC AMPERES
[PPFGU
[$&&W%NWLI
AC Circuit Breaker

Product Description
12 Autopulse-442R 50098:F 05/24/2001
)RXUZLUH6PRNH'HWHFWRU3RZHU
Up to 200 mA is available for powering four-wire smoke detectors.
Maximum ripple voltage: 1.0 V p-p
1RQUHVHWWDEOH3RZHU
Total DC current available from this output is up to 200 mA (subtracted from four-wire smoke
detector power). Maximum ripple voltage: 1.0 V p-p
5065HJXODWH 3RZHU
Total DC current available for powering external devices is 0.5 amp (subtracted from 2.25 amps
available to Notification Appliance Circuits).
Maximum ripple voltage: 100 mV p-p
Note: For device compatibility data, refer to the Device Compatibility Document.

Installation Procedure
Autopulse-442R 50098:F 05/24/2001 13
Section 2 Installation Procedure
&DELQHW0RXQWLQJ
Carefully unpack the system and
check for shipping damage. The
printed circuit board should be
removed to prevent damage;
set it aside carefully before
mounting cabinet and pulling
conduit.
The entire unit is housed in a
standard sheet-metal enclosure
with 1/2 in. (12.7 mm) and
3/4 in. (19.05 mm) conduit
knockouts available on the top
and bottom. Select knockouts
according to the number of
conduits required by “UL Power-
limited Wiring Requirements”in
Section 2.2.
Select a suitable location in a
clean, dry, vibration-free
environment that is not subject to
extreme temperatures. Locate the
top of the cabinet approximately
five feet above the floor with the
hinge on the left. The panel must
be easily accessible for mainte-
nance; the hinged door requires a
minimum clearance of 14 in.
(355.6 mm) to open. Securely
mount the cabinet using the
mounting holes provided. Attach
the trim ring.
WARNING: Do not apply
power to this control unit until
printed circuit board has been
reinstalled, and all connections
have been made and verified.
53&DEWULPLQJFGU
14.625 in.
(371.48 mm)
14.625 in.
(371.475 mm)
TR-4XR Trim Ring
(Red Steel, 16 Gauge)
5.375 in.
(136.53 mm)
1.5 in (38.1 mm)
14.5 in. (368.3 mm)
12.5 in. (317.5 mm)
4.750 in.
(120.65 mm)
16.125 in.
(409.58 mm)
16 in.
(406.4 mm)
9.5 in.
(241.3 mm)
1 in.
(25.4 mm)
.312 in (7.93 mm)
53&DE'LPFGU
16.125 in.
(408.79 mm)
.50 in.
(12.70 mm)
.5 in (12.7 mm)


Installation Procedure
14 Autopulse-442R 50098:F 05/24/2001
8/3RZHUOLPLWH :LULQJ5HTXLUHPHQWV
Power limited and non-power limited circuit wiring must remain separated in the cabinet. All
power limited circuit wiring must remain at least 0.25 in (6.35 mm) away from any non-power
limited circuit wiring. Furthermore, all power-limited circuit wiring and non-power-limited circuit
wiring must pass through separate knockouts and/or conduits.
3RZHU)HH :LULQJ
Disconnect the circuit breaker in the AC main breaker panel. Tag it “Out of Service”and refer to
“Power-Up Procedure”in Section 2.11 before closing AC breaker.
Determine the number of conductors required for the devices to be employed. Pull required
conductors into the box through the knockout provided.
Batteries are shipped separately and should be mounted only after the enclosure has been installed,
the conduit connected, and all wiring pulled, tested, and made ready to be terminated.
All wiring should be in accordance with the National and/or Local codes for fire alarm systems,
including “UL Power-limited Wiring Requirements”in Section 2.2.
Mount the transformer onto the studs of the left-hand side of the backbox. Reinstall the printed
circuit boards on the stand-offs provided within the enclosure. Connect the free end of the trans-
former cable to J1 on the printed circuit board.
WARNING: Do not apply Primary or Secondary power to the board
at this time.
Check to insure that release devices (i.e. solenoids) are mechanically and electrically disabled to
avoid inadvertent agent discharges.
Wire electrical circuits as described in the following sections.
Figure 2.1 UL Power-limited Wiring Requirements
USSOFGU
AC
Power
Power-limited
Circuits Power-limited Circuits
Non-Power-
limited Circuits
Power-
limited
Circuit
Non-
Power-
limited
Circuit




Installation Procedure
Autopulse-442R 50098:F 05/24/2001 15
,QLWLDWLQJ'HYLFH&LUFXLWV
=RQHV
Wire all alarm initiating devices sequentially for proper supervision. Initiating devices include
manual pull stations, waterflow alarm devices, and heat-, photoelectric-, and ionization-type
detectors. Refer to the Device Compatibility Document for compatible devices.
Notes:
1. Observe polarity when connecting polarized devices.
2. All circuits are supervised and power-limited.
3. Leave dummy load resistor (provided) on all unused circuits.
% $ $ % % $ $ % % $ $ % % $ $ %

%
        
53,'&FGU
,1  ,1  ,1  ,1 
Manual
Pull Station
Heat
Detector
Two-wire
Smoke
Detector
Style B (Class B)
Initiating Device Circuit
4.7K, 1/2-Watt (part # 418334, UL listed)
Style D (Class A)
Initiating Device Circuit
Abort Switch
4.7K, 1/2-Watt
(part # 418334,
UL listed)
Manual Release
4.7K, 1/2-Watt
(part # 418334,
UL listed)
Figure 2.2 Initiating Device Circuits

Installation Procedure
16 Autopulse-442R 50098:F 05/24/2001
)RXU:LUH6PRNH'HWHFWRU&RQQHFWLRQV
Initiating Device Circuits 1 or 2 on TB4 can
be used with either Style B (Class B) or
Style D (Class A) wiring.
A maximum of 200 mA is available from
the +24VDC four-wire smoke detector
power circuit on TB1 terminals 3 and 4.
Any power that is drawn from the +24VDC
Nonresettable Power on TB2 terminals 1
and 2 must be subtracted from available
four-wire detector power. (See “Specifica-
tions”and “Power”sections.)
Refer to the Device Compatibility
Document for suitable four-wire smoke
detectors.
Notes on Style D (Class A) and Style B
(Class B) field wiring:
1. The Power Supervision Relay coil
leads must be connected to the last
detector base 24V screw terminals.
2. Calculation of the maximum
allowable resistance in the 24 VDC
detector power wiring:
RMAX = (20.6 - VOM)
(N x IS) + (NAx IA) + (IR)
Where:
RMAX is the maximum resistance of the 24V
wires.
VOM is the minimum operating voltage of
the detector or end-of-line relay,
whichever is greater, in volts.
Nis the total number of detectors on the
24V supply loop.
ISis the detector current standby.
NAis the number of detectors on the 24V
power loop which must function at
the same time in alarm.
IAis the detector current in alarm.
IRis the end-of-line relay current.
% $ $ %
7% 7%
 
+24VR
Control Panel
Power Circuit
53[:5FGU
UL listed
24 VDC
Four-wire
Smoke
Detectors
UL listed
4.7K,
1/2-Watt
ELR
Listed
Power
Supervision
Relay
Red
Black
IN #1, 2
Class B
Initiating Device Circuit
Figure 2.3 Typical Connection for
Four-Wire Smoke Detectors

Installation Procedure
Autopulse-442R 50098:F 05/24/2001 17
2XWSXW&LUFXLWV
1RWLILFDWLRQ$SSOLDQFH&LUFXLWV
This control panel can provide two
Style Z (Class A)/Style Y (Class B)
NotificationAppliance Circuitsand
two Style Y (Class B) Releasing
Circuits (for DIP switch configu-
ration, see “Setting Mode of
Operation”in Section 2.10). Each
circuit is capable of 1.5 amps of
current. Total current drawn from
all four circuits cannot exceed
2.25 amps. Refer to the Device
Compatibility Document.
Notification Appliance Circuits are
supervised and power-limited. For
non-silenceable service on NAC#1,
see “Non-Silenceable Service”in
Section 3.8.
Note: Unused Notification
Appliance Circuits must be
connected with a dummy load as
shown.
5HOHDVLQJ&LUFXLWV
Output #4 can be configured for releasing or
supervisory circuit (see “Setting Mode of
Operation”in Section 2.10). If configured
as a releasing circuit, the circuit will be non-
power limited. If configured as a super-
visory circuit, the circuit will be power
limited. All wiring must follow the require-
ments as specified under “UL Power-limited
Wiring Requirements”in Section 2.2.
To prevent accidental discharge, connect
releasing devices after initial panel tests are
completed.
Note: Wiring must be configured to maintain a
minimum voltage of 20.4 VDC on release
circuits. Calculation of maximum allowable
resistance:
RMAX = 20.6 VDC-20.4 VDC
IS
Where:
RMAX = maximum allowable resistance of wiring
IS= solenoid current
For Canadian applications, use REL-4.7K as
shown.
Note: Unused Releasing Circuits must be wired with a dummy load as shown.
531$&RXWVFGU
OUT #1 OUT #2
Polarized
Horn
Polarized
Strobe
Polarized
Bell
Style Z
(Class A)
Style Y (Class B)
4.7K, 1/2-Watt resistor
(part #418334, UL listed)
Unused NAC Circuit
4.7K, 1/4-Watt resistor
531$&XQXVHGZPI
OUT
#3 OUT #4
Releasing Circuits
(UL listed & FM approved
Releasing Devices)
535/6RXWVFGU
535/6XQXVHGZPI
Unused
Releasing Circuit
4.7K, 1/4-Watt resistor

B
[&DQ5OVFGU
Releasing Circuit for Canadian Applications
REL-4.7K

Installation Procedure
18 Autopulse-442R 50098:F 05/24/2001
$ODUP5HOD\
One Form-C dry contact alarm relay is provided in the
basic panel for controlling supplementary devices. It is
rated 2 amps at 30 VDC and 0.5 amps at 30 VAC
(resistive), and non-silenceable when an alarm occurs.
See Figure 2.4 for terminal location.
7URXEOH5HOD\
One Form-C dry contact trouble relay is provided in the
basic panel for controlling supplementary devices.
It is rated 2 amps at 30 VDC and 0.5 amps at 30 VAC
(resistive) and will silence when the trouble condition is
cleared.
Note: Any power connected to these relay contacts must
come from a power-limited supply. Power may be
obtained from TB1 Terminals 1-2, TB1 Terminals 3-4,
TB2 Terminals 1-2, or a UL-listed power-limited supply.
3RZHULQJ([WHUQDO'HYLFHV
CAUTION: Several different sources of power can be connected to this panel.
Disconnect all sources of power before servicing. The panel and associated
equipment may be damaged by removing and/or inserting cards, modules, or
interconnecting cables while this unit is energized.
7%WUREFRQWDFWVZPI
Alarm Trouble
Alarm
NO NC C Trouble NO NC C
Figure 2.4 Schematic Representation
of Alarm/Trouble Coils & Contacts



7%

7%

Figure 2.5 Power Terminals
[3ZU7HUPLQDOVFGU
+24VU +24VR +24VNR
RMS-Regulated Power
24 VDC power for inductive-
type devices such as door
holders can be connected to
TB1 terminals 1 (+) and 2(-).
This output is not suitable for
powering devices requiring
filtered DC power.
Four-Wire Smoke Detector Power
24 VDC filtered, resettable power
for four-wire smoke detectors can be
obtained from TB1 Terminals 3(+) and 4(-).
The combined current draws from the
Resettable and Nonresettable outputs cannot
exceed 200 mA.
Nonresettable Power
24 VDC filtered, nonresettable
power can be drawn from TB2
Terminals 1 (+) and 2(-).
The combined current draws
from the Resettable and
Nonresettable outputs cannot
exceed 200 mA.

Installation Procedure
Autopulse-442R 50098:F 05/24/2001 19
9ROWPHWHU$PPHWHU
To monitor battery voltage and battery charging current, a 4XMM Meter Module is required. To
install the power meter module:
1. Cut the wire labeled “AMP”.
2. Connect cable assembly P2 to pin connector J2 on the main board.
3. Connect cable assembly P3 to pin connector J3 on the main board.
4. Secure the 4XMM to the backbox with the two screws provided. On some models, it will be
necessary to install the meter bracket with the nuts and bolts provided.
Figure 2.6 Connecting the Meters to the Main Board
[PPDPSFGU

Installation Procedure
20 Autopulse-442R 50098:F 05/24/2001
2SWLRQDO0R XOHV
The fire control panel has two
module connectors —J5 and J8.
Three modules are available for the
panel and they can be used in any
combination, including duplicate
modules. The corresponding option
jumper must be cut before instal-
lation of an optional module.
Note: Optional 4XLM module for
an RZA-4X Annunciator must be
installed on J8 only. The 4XTM and
4XZM modules can be installed in
either location.
Insert the two stand-offs (provided)
into the holes located on the right-
side edge of the main board.
Carefully align the pins on the main
board with J1 and/or J2 on the
optional board. Insert screw
through the optional board until it
is secured on the stand-offs.
Affix the terminal identification
labels provided with the optional
modules as shown in Figure 2.9.
B+ A+ A- B-B+ A+ A- B-
B+ A+ A- B-B+ A+ A- B-
TB4
JP 1
SUPV 2
A
LM2
NO DACT
DACT
C
-
-
-
-
237
237
4XTM
or
4XZM
4XTM
or
4XLM
or
4XZM
[2SW,QVWDOODWLRQFGU
Figure 2.7 Selecting Location & Cutting Jumpers
Note: If a
module is
installed in
this position,
cut jumper
“OPT1”on
the main
board.
Note: If a
module is
installed in
thisposition,
cut jumper
“OPT2”on
the main
board.
Optional Board
(4XZM shown)
(Part # 42050)
Stand-offs
Main
Board
;6712))FGU
Figure 2.8 Assembling Optional Modules
;2371%'FGU
Figure 2.9 Labelling Optional Modules
