ANTAIRA IMP-C1000-SFP-bt Series User manual

Antaira Technologies - Industrial Media Converter
IMP-C1000-SFP-bt Series User Manual V1.0
i
IMP-C1000-SFP-bt Series
Compact Industrial Gigabit IEEE 802.3bt Ethernet-to-Fiber Media
Converter, 1*10/100/1000Tx (90W/Port) to 1*100/1000 SFP Slot
Version 1.0
User Manual

Antaira Technologies - Industrial Media Converter
IMP-C1000-SFP-bt Series User Manual V1.0
ii
© Copyright 2020 Antaira Technologies, LLC.
All Rights Reserved
This document contains information, which is protected by copyright. Reproduction, adaptation or translation
without prior permission is prohibited, except as allowed under the copyright laws.
Trademark Information
Antaira is a registered trademark of Antaira Technologies, LLC., Microsoft Windows and the Windows logo are
the trademarks of Microsoft Corp. All other brand and product names are trademarks or registered trademarks of
their respective owners.
Disclaimer
Antaira Technologies, LLC. provides this manual without warranty of any kind, expressed or implied, including but
not limited to the implied warranties of merchantability and fitness for a particular purpose. Antaira Technologies,
LLC. may make improvements and/or changes to the product and/or specifications of the product described in
this manual, without prior notice. Antaira Technologies, LLC. will not be liable for any technical inaccuracies or
typographical errors found in this guide. Changes are periodically made to the information contained herein and
will be incorporated into later versions of the manual. The information contained is subject to change without prior
notice.

Antaira Technologies - Industrial Media Converter
IMP-C1000-SFP-bt Series User Manual V1.0
iii
FCC Notice
This equipment has been tested and found to comply with the limits for a Class-A digital device, pursuant to Part
15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy. It may cause
harmful interference to radio communications if the equipment is not installed and used in accordance with the
instructions. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications not expressly approved by the grantee of this device could void the user's
authority to operate the equipment.
CE Mark Warning
This is a Class-A product. In a domestic environment, this product may cause radio interference in which case
the user may be required to take adequate measures.
Industrial Ethernet Media Converters
User Manual (May 2020)
This manual supports the following models:
•IMP-C1000-SFP-bt
•IMP-C1000-SFP-bt-T
Please check our website (www.antaira.com) for any updated manual or contact us by e-mail
([e-mail]).

Antaira Technologies - Industrial Media Converter
IMP-C1000-SFP-bt Series User Manual V1.0
ii
Table of Contents
1. Overview.............................................................. 1
1.1 Key Features.............................................. 1
1.2 Package Contents...................................... 2
1.3 Safety Precaution....................................... 2
2. Hardware Description......................................... 3
2.1 Physical Dimensions .................................. 3
2.2 Front Panel................................................. 4
2.3 Top View.................................................... 4
2.4 LED Indicators............................................ 5
2.5 DIP-Switch Setting...................................... 5
2.6 Ethernet Ports ............................................ 6
2.7 Cabling....................................................... 6
2.8 Wiring the Power Inputs.............................. 9
3. Mounting Installation........................................ 10
3.1 DIN-Rail Mounting.................................... 10
3.2 Wall Mounting........................................... 12
4. Hardware Installation........................................ 13
4.1 Installation Steps...................................... 13
5. Trouble Shooting .............................................. 14
6. Technical Specifications .................................. 15

Antaira Technologies - Industrial Media Converter
IMP-C1000-SFP-bt Series User Manual V1.0
1
1.Overview
Antaira Technologies’ IMP-C1000-SFP-bt series is a compact IP30 rated gigabit Ethernet-to-fiber
media converter featuring a 10/100/1000TX Ethernet port that supports IEEE 802.3bt high power
PoE that can supply up to 90 watts, and a dual rate 100/1000 SFP slot. It is perfectly designed to
fulfill industrial applications that require distance extension and high bandwidth capabilities. This
small form factor is ideal for saving space in outdoor applications such as factory automation,
security, ITS transportation, power/utility, water wastewater treatment plants, and any other
extreme ambient weather environments.
The IMP-C1000-SFP-bt series has a built-in “Link Fault Pass Through” (LFP) and “PD Remote
Reset Technology” (PRRT) function with 48~55VDC redundant power inputs with reverse polarity
and overload current protection. This product series supports DIN-rail as well as wall mountable
orientations. There are two operating temperature range models in STD: -10°C to 65°C and EOT: -
40°C to 75°C.
1.1 Key Features
◼System Interface/Performance
•RJ-45 ports support the auto MDI/MDI-X function
•Embedded 1*10/100/1000Tx (PSE 90W) and 1*100/1000 SFP Slot
•Store-and-forward switching architecture
•8K MAC address table size
•Supports 10Kbytes jumbo frame
•1Mbit memory buffer
◼Power Input
•DC 48~55V redundant power with a 4-pin removal terminal block
•Max. current: 1.85A
•Max. PoE output: 90W
[Note] For IEEE802.3bt applications, power supply not less than 53V is recommended.
◼Certification
•FCC, CE
◼Operating Temperature
•Standard operating temperature model: -10°C ~ 65°C
•Extended operating temperature model (–T): -40°C ~ 75°C
◼Case/Installation
•IP-30 protection
•DIN-Rail and wall mount design

Antaira Technologies - Industrial Media Converter
IMP-C1000-SFP-bt Series User Manual V1.0
2
1.2 Package Contents
•1 - Quick Installation Guide
•1 - IMP-C1000-SFP-bt(-T)
•1 - Wall mounting bracket set with screws
•1 - DC cable - 18 AWG & DC jack 5.5x2.1mm
1.3 Safety Precaution
Attention: If the DC voltage is supplied by an external circuit, please use a protection device
on the power supply input. The industrial Ethernet media converter’s hardware
specs, ports, cabling information, and wiring installation will be described within this
user manual.

Antaira Technologies - Industrial Media Converter
IMP-C1000-SFP-bt Series User Manual V1.0
3
2. Hardware Description
2.1 Physical Dimensions
Figure 2.1, below, shows the physical dimensions of Antaira Technologies’ IMP-C1000-SFP-bt
series.
(W x D x H) is 30mm x 95mm x 75mm
Figure 2.1
Physical Dimensions

Antaira Technologies - Industrial Media Converter
IMP-C1000-SFP-bt Series User Manual V1.0
4
2.2 Front Panel
The front panel of the IMP-C1000-SFP-bt series can be seen below (Figure 2.2).
2.3 Top View
Figure 2.3, below, shows the top panel of the IMP-C1000-SFP-bt series media converter that
is equipped with one 4-pin removal terminal block connector for dual DC power inputs
(48~55VDC).
Figure 2.2
Front Panel
Figure 2.3
Top Panel View
4-Pin Removal Terminal Block (Power Input)
SFP Port –100/1000Fx
Grounding Screw
LED for PWR, AT PoE, and BT PoE
LED for RJ45 Network Speed Status
10/100Mbps
RJ45 Port –10/100/1000Tx
LED for SFP Link/Activity
DIP Switch
LED for RJ45 Network Speed Status
1000Mbps

Antaira Technologies - Industrial Media Converter
IMP-C1000-SFP-bt Series User Manual V1.0
5
2.4 LED Indicators
There are LED light indicators located on the front panel of the industrial Ethernet media
converter that displays the power and network status. Each LED indicator has a different color
and has its own specific meaning, see below in Table 2.1.
LED
Color
Description
Power
Green
On
Power input 1 or 2 is active
Off
Power input 1 and 2 are inactive
AT PoE
Green
On
IEEE 802.3af/at connection
Off
No powered-device attached or power supplying fails
BT PoE
Blue
On
IEEE 802.3bt connection
Flashing
(1 time/s)
1. PoE over current or cable short
2. Invalid connection check signature or connection-
check error is detected
Off
No powered-device attached or power supplying fails
RJ45 Port
(Upper LED)
Green
On
Linked to network at 1000Mbps
Flashing
Networking is active
Off
Not connected to network
RJ45 Port
(Lower LED)
Green
On
Linked to network at 10/100Mbps
Flashing
Networking is active
Off
Not connected to network
SFP Port
Link/Act
Green
On
Connected to network, 100/1000Mbps
Flashing
Networking is active
Off
Not connected to network
2.5 DIP-Switch Setting
There are 3‐sets of DIP‐switches on the front panel that are responsible for the settings
of PRRT (PD Remote Reset Technology) function, LFP (Link Fault Pass) function, and SFP
transmission rate (see below in Table 2.2).
DIP-Switch Number
ON
OFF
1
PRRT Enabled
PRRT Disabled
2
LFP Enabled
LFP Disabled
3
SFP 100Fx
SFP 1000Fx
Table 2.1
LED Indicators
Table 2.2
Note: After any DIP switch changes have been made, it is required to power cycle
the unit for the changes to take effect.

Antaira Technologies - Industrial Media Converter
IMP-C1000-SFP-bt Series User Manual V1.0
6
2.6 Ethernet Ports
◼RJ-45 Ports
RJ-45 Ports (Auto MDI/MDIX): The RJ-45 port is auto-sensing for 10/100Base-Tx or 1000Base-
Tx device connections. Auto MDI/MDIX means that the media converter can connect to another
switch or workstation without changing the straight-through or crossover cabling. See the figures
shown below for the straight-through and crossover cabling schematics.
Figure 2.4: RJ-45 Ethernet Port Pin
2.7 Cabling
◼Twisted-pair segments can be connected with an Unshielded Twisted Pair (UTP) or Shielded
Twisted Pair (STP) cable. The cable between the equipment and the link partner (media
converter, switch, hub, workstation, etc.) must be less than 100 meters (328 ft.) long.
◼The Small Form Factor pluggable (SFP) is a compact optical transceiver used in optical
communications for both telecommunication and data communication applications.
Figure 2.5 Figure 2.6
Straight-Through Cables Schematic Crossover Cables Schematic

Antaira Technologies - Industrial Media Converter
IMP-C1000-SFP-bt Series User Manual V1.0
7
▪To connect the transceiver and LC cable, please follow the steps below:
oStep 1 - Insert the SFP transceiver module into the SFP slot as shown below in
Figure 2.7. Notice that the triangle mark is at the bottom of the SFP slot.
Figure2.8shows the SFP transceiver module was inserted.
oStep 2 - Insert the fiber cable of the LC connector into the transceiver as shown
below in Figure 2.9.
Figure 2.7 - Transceiver to the SFP Slot
Figure 2.8 - Transceiver Inserted
Figure 2.9 - LC Connector to the Transceiver

Antaira Technologies - Industrial Media Converter
IMP-C1000-SFP-bt Series User Manual V1.0
8
▪To remove the LC connector from the transceiver, please follow the steps shown below:
oStep 1 - Press the upper side of the LC connector from the transceiver and pull it
out to release as shown below in Figure 2.10.
oStep 2 - Push down the metal clasp and pull the transceiver out by the plastic part
as shown below in Figure 2.11.
Figure 2.10 –Remove LC Connector
Figure 2.11 –Pull Out from SFP Slot

Antaira Technologies - Industrial Media Converter
IMP-C1000-SFP-bt Series User Manual V1.0
9
2.8 Wiring the Power Inputs
Please follow the steps below to insert the power wire.
1. Insert the positive and negative wires into the PWR1 (V1+, V1-) and PWR2 (V2+, V2-)
contacts on the terminal block connector as shown below in Figure 2.12.
2. Tighten the wire-clamp screws to prevent the wires from loosening, as shown below in Figure
2.13.
**Note:
•Only use copper conductors, 125°C, tighten to 5 lbs.
•The wire gauge for the terminal block should range between 18~20 AWG.
Figure 2.13
Power Terminal Block
Figure 2.12
Power Terminal Block

Antaira Technologies - Industrial Media Converter
IMP-C1000-SFP-bt Series User Manual V1.0
10
3.Mounting Installation
3.1 DIN-Rail Mounting
The DIN-Rail is pre-installed on the industrial Ethernet media converter from the factory. If the
DIN-Rail is not on the industrial Ethernet media converter, please refer to Figure 3.1 to learn how
to install the DIN-Rail on the media converter.
Figure 3.1
The Rear Side of the Media Converter and DIN-Rail Bracket

Antaira Technologies - Industrial Media Converter
IMP-C1000-SFP-bt Series User Manual V1.0
11
Follow the steps below to learn how to hang the industrial Ethernet media converter.
1. Use the screws to install the DIN-Rail bracket on the rear side of the industrial Ethernet media
converter.
2. To remove the DIN-Rail bracket, do the opposite from step 1.
3. After the DIN-Rail bracket is installed on the rear side of the media converter, insert the top of
the DIN-Rail onto the track as shown below in Figure 3.2.
4. Lightly pull down the bracket onto the rail as shown below in Figure 3.3.
5. Check if the bracket is mounted tightly on the rail.
6. To remove the industrial
Ethernet
media converter from the rail, do the opposite from the above
steps.
Figure 3.3
Secure on to the DIN-Rail
Figure 3.2
Insert on the DIN-Rail

Antaira Technologies - Industrial Media Converter
IMP-C1000-SFP-bt Series User Manual V1.0
12
3.2 Wall Mounting
Follow the steps below to mount the industrial
Ethernet
media converter using the wall mounting
bracket as shown below in Figure 3.4.
1. Remove the DIN-Rail bracket from the industrial media converter by loosening the screws.
2. Place the wall mounting brackets on the top and bottom of the industrial media converter.
3. Use the screws to screw the wall mounting bracket on the industrial media converter.
4. Use the hook holes at the corners of the wall mounting bracket to hang the industrial Ethernet
media converter on the wall.
5. To remove the wall mount bracket, do the opposite from the steps above.
Below, in Figure 3.5 are the dimensions of the wall mounting bracket.
Figure 3.4
Remove DIN-Rail Bracket
Figure 3.5
Wall Mounting Bracket Dimensions

Antaira Technologies - Industrial Media Converter
IMP-C1000-SFP-bt Series User Manual V1.0
13
4. Hardware Installation
4.1 Installation Steps
This section will explain how to install Antaira Technologies’ IMP-C1000-SFP-bt(-T) series.
Installation Steps
1. Unpack the industrial media converter from the original packing box.
2. Check if the DIN‐Rail bracket is screwed on the industrial media converter.
a. If the DIN‐Rail is not screwed on the industrial media converter, please refer to the
DIN‐Rail Mounting section for DIN‐Rail installation.
b. For wall mounting, please refer to the Wall Mounting section for wall mounting
installation.
3. For DIN‐Rail or wall mounting, please refer to the Mounting Installation section.
4. Power on the industrial media converter; the power LED light will turn on.
a. For wiring power, please refer to the Wiring the Power Inputs section.
b. Please refer to the LED Indicators section for LED light indication.
5. Prepare the twisted‐pair, straight‐through category 5 cable for Ethernet connection.
6. Insert one side of the RJ‐45 cable into the media converter’s Ethernet port and on the other
side into the networking device’s Ethernet port, e.g. switch PC or server. The Ethernet port’s
(RJ‐45) LED on the industrial media converter will turn on when the cable is connected to
the networking device.
a. Please refer to the LED Indicators section for LED light indication information.
7. Insert one side of the SFP cable into the media converter’s SFP port and on the other side
into the networking device’s SFP port, e.g. switch or server. The SFP port’s LED on the
industrial media converter will turn on when the cable is connected to the networking device.
a. Please refer to the LED Indicators section for LED light indication information.
8. When all connections are set and the LED lights all show normal, the installation process is
complete.

Antaira Technologies - Industrial Media Converter
IMP-C1000-SFP-bt Series User Manual V1.0
14
5. Trouble Shooting
•Always verify the right power cord or adapter is being used. Never use a power supply or
adapter with a non-compliant DC output voltage or it will burn the equipment.
•Select the proper UTP or STP cable in order to construct the network. Use an Unshielded
Twisted-Pair (UTP) or Shield Twisted-Pair (STP) cable for RJ-45 connections: 100Ω
Category 5e for 10/100/1000Mbps. Also be sure that the length of any twisted-pair
connection does not exceed 100 meters (328 feet).
•Diagnosing LED Indicators: To assist in identifying problems, the media converter can be
easily monitored with the LED indicators which help to identity if any problems exist.
oPlease refer to the LED Indicators section for LED light indication information.
•If the power indicator LED does not turn on when the power cord is plugged in, the user
may have a problem with the power cord. Check for loose power connections, power losses
or surges at the power outlet.
oPlease contact Antaira for technical support if the problem cannot be resolved.
•If the industrial media converter LED indicators are normal and the connected cables are
correct but the packets still cannot transmit, please check the system’s Ethernet devices’
configuration or status.

Antaira Technologies - Industrial Media Converter
IMP-C1000-SFP-bt Series User Manual V1.0
15
6. Technical Specifications
Table 6.1 has the technical specifications for Antaira Technologies’IMP-C1000-SFP-bt series.
Standards
IEEE 802.3
10BaseT Ethernet
IEEE 802.3u
100BaseTX Fast Ethernet
IEEE 802.3ab
1000BaseT Gigabit Ethernet
IEEE 802.3z
1000Base-X Gigabit Fiber
IEEE 802.3af/at/bt
Power over Ethernet
Technology
Data Process
Store and Forward
Protocol
CSMA/CD
Flow Control
IEEE 802.3x flow control, back pressure control
Memory Buffer
1Mbit
Jumbo Frame
10Kbytes
MAC Table Size
8K
Port Interface
Ethernet (RJ45) Port
1*10/100/1000Tx with IEEE 802.3bt PoE
Auto-Negotiation, Full/Half Duplex, Auto-MDI/MDI-X
PoE Pin Out
V-, V-, V+, V+, for pin 1, 2, 3, 6; V+, V+, V-, V-, for pin 4, 5, 7, 8
*Support Modes: Mode A, Mode B, 4-Pair Mode
Fiber Port
1*100/1000Fx SFP Slot
Fiber Wavelength
Refer to SFP Module
DIP Switch
DIP Switch 1: PD Remote Reset Technology (PRRT) Enable/Disable
DIP Switch 2: Link Fault Pass-Through (LFP) Enable/Disable
DIP Switch 3: 100Mbps/1000Mbps
LED Indicators
Power Status LED, IEEE 802.3af/at PoE Enabled LED, IEEE 802.3bt
Enabled LED
Ethernet Ports: On-Link/Flash-data transmitting
SFP: Link/Active
Mechanical
Characteristics
Housing
Metal IP30 protection
Dimension
30 x 95 x 75 mm
Weight
Unit Weight: 0.59 lb. Shipping Weight: 0.81 lb.
Mounting
DIN-Rail Mounting, Wall Mounting
Power
Requirement
Input Voltage
48~55VDC Redundant Input
*For IEEE802.3bt applications, power supply not less than 53V is
recommended.
Power Connection
1 removable 4-contact terminal block
Power Consumption
3W
Max. PoE Power
Budget
90W
Environmental
Limits
Operating Temperature
Standard: -10˚C to 65˚C
EOT: -40˚C to 75˚C
Ambient Relative
Humidity
5% to 95%, (non-condensing)
Storage Temperature
-40˚C to 85˚C
Regulatory
Approvals
EMI
FCC Part 15 Subpart B Class A,
CE EN55032/EN61000-6-4 Class A

Antaira Technologies - Industrial Media Converter
IMP-C1000-SFP-bt Series User Manual V1.0
16
EMS
CE EN55035/EN61000-6-2 Class A:
IEC61000-4-2 (ESD)
IEC61000-4-3 (RS)
IEC61000-4-4 (EFT)
IEC61000-4-5 (Surge)
IEC61000-4-6 (CS)
IEC61000-4-8 (Magnetic Field)
Free Fall
IEC60068-2-32
Shock
IEC60068-2-27
Vibration
IEC60068-2-6
Green
RoHS Compliant
Safety
FCC, CE
Warranty
5 Years
Table 6.1
Technical Specifications
Antaira Customer Service and Support
(Antaira US Headquarter) + 844-268-2472
(Antaira Europe Office) + 48-22-862-88-81
(Antaira Asia Office) + 886-2-2218-9733
Please report any problems to Antaira:
www.antaira.com / [e-mail]
www.antaira.eu / [e-mail]
www.antaira.com.tw / inf[email protected]m.tw
Any changes to this material will be announced on the Antaira website.
