ANTAIRA LNX-C800 Series User manual




LNX-C800 Series
8-Port Compact Industrial Unmanaged Ethernet Switch, with 8*10/100Tx

Hardware Manual

Version 2.0
(September 2020)
 

Antaira Technologies - Industrial Ethernet Switches
LNX-C800 Series - Hardware Manual - v2.0

© Copyright 2020 Antaira Technologies, LLC
All rights reserved
This document contains information, which is protected by copyright. Reproduction, adaptation, or
translation without prior permission is prohibited, except as allowed under the copyright laws.

Trademark Information
Antaira is a registered trademark of Antaira Technologies, LLC, Microsoft Windows and the Windows logo
are the trademarks of Microsoft Corp. NetWare is the registered trademark of Novell Inc. WMM and WPA
are the registered trademarks of Wi-Fi Alliance. All other brand and product names are trademarks or
registered trademarks of their respective owners.

Notice: Copyrights © 2020 by Antaira Technologies, LLC. All rights reserved. Reproduction, adaptation, or
translation without prior permission of Antaira Technologies, LLC is prohibited, except as allowed under
the copyright laws.

Disclaimer
Antaira Technologies, LLC provides this manual without warranty of any kind, expressed or implied,
including but not limited to the implied warranties of merchantability and fitness for a particular purpose.
Antaira Technologies, LLC may make improvements and/or changes to the product and/or specifications
of the product described in this manual, without prior notice. Antaira Technologies, LLC will not be liable
for any technical inaccuracies or typographical errors found in this guide. Changes are periodically made
to the information contained herein and will be incorporated into later versions of the manual. The
information contained is subject to change without prior notice.

FCC Warning
This equipment has been tested and found to comply with the limits for a Class-A digital device, pursuant
to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy. It may cause harmful interference to radio communications if the equipment is not installed and
used in accordance with the instructions. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:

Antaira Technologies - Industrial Ethernet Switches
LNX-C800 Series - Hardware Manual - v2.0

●Reorient or relocate the receiving antenna.
●Increase the separation between the equipment and receiver.
●Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
●Consult the dealer or an experienced radio/TV technician for help.

Caution: Any changes or modifications not expressly approved by the grantee of this device could void
the user’s authority to operate the equipment.

Avertissement FCC
Cet équipement a été testé et déclaré conforme aux limites d'un appareil numérique de classe A,
conformément à la partie 15 des règles de la FCC. Ces limites sont conçues pour fournir une protection
raisonnable contre les interférences nuisibles dans une installation résidentielle. Cet équipement génère,
utilise et peut émettre de l'énergie radiofréquence. Cela peut provoquer des interférences nuisibles aux
communications radio si l'équipement n'est pas installé et utilisé conformément aux instructions.
Cependant, il n'y a aucune garantie qu'aucune interférence ne se produira dans une installation
particulière. Si cet équipement provoque des interférences nuisibles à la réception radio ou télévision, ce
qui peut être déterminé en éteignant puis en rallumant l'équipement, l'utilisateur est encouragé à essayer
de corriger les interférences par une ou plusieurs des mesures suivantes:
●Réorientez ou déplacez l'antenne de réception.
●Augmentez la distance entre l'équipement et le récepteur.
●Connectez l'équipement à une prise sur un circuit différent de celui auquel le récepteur est
connecté.
●Consultez le revendeur ou un technicien radio / TV expérimenté pour obtenir de l'aide.

CE Mark Warning
This is a Class-A product. In a domestic environment this product may cause radio interference in which
case the user may be required to take adequate measures.

Avertissement de marque CE
Ceci est un produit de classe A. Dans un environnement domestique, ce produit peut provoquer des
interférences radio, auquel cas l'utilisateur peut être amené à prendre des mesures adéquates.

Antaira Technologies - Industrial Ethernet Switches
LNX-C800 Series - Hardware Manual - v2.0

Industrial Ethernet Switches
Industrial Grade Unmanaged Ethernet Switches

Hardware Manual
Version 2.0 (September 2020)

The manual supports the following models:
●LNX-C800
●LNX-C800-T

This document is the current official release hardware manual. Please check our website
(www.antaira.com) for any updated manual or contact us by e-mail ([email protected]). 

Antaira Technologies - Industrial Ethernet Switches
LNX-C800 Series - Hardware Manual - v2.0

Table of Contents
1 Overview 1
1.1 Product Hardware Features 1
1.2 Package Contents 1
1.3 Safety Precaution 2
2 Hardware Description 3
2.1 Physical Dimensions 3
2.2 Front View Panel 4
2.3 Top View Panel 4
2.4 LED Indicators 5
2.5 Ethernet Ports 5
2.6 Cabling 6
2.7 Wiring the Power Inputs 6
2.8 Wiring the Fault Alarm Contact 7
2.9 Grounding Note 8
3 Mounting Installation 9
3.1 DIN-Rail Mounting 9
3.2 Wall Mounting 10
4 Hardware Installation 12
4.1 Installation Steps 12
4.2 Maintenance and Service 13
4.3 Troubleshooting 13
5 Technical Specifications 15


Antaira Technologies - Industrial Ethernet Switches
LNX-C800 Series - Hardware Manual - v2.0

1 Overview
Antaira Technologies’ LNX-C800 series is a compact 8-port industrial unmanaged Ethernet switch
embedded with 8*10/100Tx Ethernet ports. The small form factor of this metal IP30 rated industrial
switch is 30% smaller allowing for a more versatile implementation. The industrial-grade design and
compact size of the LNX-C800 series make this the ideal unit for integration into projects or other
applications that need a small footprint. This product series supports DIN-Rail as well as wall mountable
orientations. There are also two wide operating temperature models for either a standard temperature
range (STD: -10°C to 65°C) or an extended temperature range (EOT: -40°C to 75°C).
1.1 Product Hardware Features
System Interface and Performance
- All RJ45 ports support Auto MDI/MDI-X Function
- Embedded 8*10/100Tx RJ45 ports
- Store-and-forward switching architecture
- 1K MAC address table
Product Input
- DC 12~48V redundant, with a 6-pin removal terminal block
- The power input specification is complied with the requirements of SELV (Safety Extra Low
Voltage) and the power supply should be complied with UL 61010-1 & UL 61010-2-201
Operating Temperature
- LNX-C800: -10°C to 65°C
- LNX-C800-T: -40°C to 75°C
Case / Installation
- IP30 protection metal housing
- DIN-Rail and wall mount design
1.2 Package Contents
- LNX-C800(-T)
- Quick Installation Guide
- Wall mounting bracket set with screws
- DC cable- 18AWG & DC jack 5.5 x 2.1mm
- RJ45 dust cover set
1

Antaira Technologies - Industrial Ethernet Switches
LNX-C800 Series - Hardware Manual - v2.0

1.3 Safety Precaution
Attention: If the DC voltage is supplied by an external circuit, please use a protection device on the power
supply input. The industrial Ethernet switch’s hardware specs, ports, cabling information, and wiring
installation will be described within this hardware manual.

Attention: Si la tension CC est fournie par un circuit externe, veuillez utiliser un dispositif de protection sur
l'entrée d'alimentation. Les spécifications matérielles, les ports, les informations de câblage et
l'installation du câblage du commutateur Ethernet industriel seront décrits dans ce manuel d'utilisation.


Warning Labels
The caution label means that you should check the certain information on the user manual when working
with the device. (Shown in Figure 1.1)

Étiquettes d'avertissement
L'étiquette d'avertissement signifie que vous devez vérifier certaines informations sur le manuel
d'utilisation lorsque vous travaillez avec l'appareil. (Montré dans la figure 1.1)
Figure 1.1 - Caution Label
Figure 1.1 - Étiquette de mise en garde
Figure 1.2 - Hot Surface Warning Label
Figure 1.2 - Étiquette d'avertissement de surface chaude
 
2

Antaira Technologies - Industrial Ethernet Switches
LNX-C800 Series - Hardware Manual - v2.0

2 Hardware Description
2.1 Physical Dimensions
Figure 2.1, below, shows the physical dimensions of this product series:

(W x D x H) is 40mm x 70mm x 95mm
Figure 2.1 - Physical Dimensions
 
3

Antaira Technologies - Industrial Ethernet Switches
LNX-C800 Series - Hardware Manual - v2.0

2.2 Front View Panel
Figure 2.2, below, shows the front panel of the product series:
Figure 2.2 - Front View Panel
2.3 Top View Panel
Figure 2.3, below, shows the top panel of the product series:
Figure 2.3 - Top View Panel
4

Antaira Technologies - Industrial Ethernet Switches
LNX-C800 Series - Hardware Manual - v2.0

2.4 LED Indicators
There are LED light indicators located on the front panel of the industrial Ethernet switch that display the
power status and network status. Each LED indicator has a different color and has its own specific
meaning, see below in Table 2.1.

LED
Color
Description
P1
Green
On
Power Input 1 is active
Off
Power Input 1 is inactive
P2
Green
On
Power Input 2 is active
Off
Power Input 2 is inactive
Fault
Red
On
Power Input 1 or 2 is inactive
Off
Power Input 1 and 2 are both functional
LAN Port 1~8
(Upper LED)

Green
On
Connected to network, 100Mbps
Flashing
Networking is active
Off
Not connected to network
LAN Port 1~8
(Lower LED)

Green
On
Connected to network, 10Mbps
Flashing
Networking is active
Off
Not connected to network
Table 2.1 - LED Indicators

Note: “P1” is the abbreviation for “Power 1”, “P2” is for “Power 2”, “LNK” is for “Link”, and “ACT” is for
“Activity”.
2.5 Ethernet Ports
●RJ45 Ports
RJ45 Ports (Auto MDI/MDI-X): The RJ45 ports are auto-sensing for 10/100Base-T or 100Base-TX
connections. Auto MDI/MDI-X means that the switch can connect to another switch or workstation
without changing the straight-through or crossover cabling. See the figures below for straight-through and
crossover cabling schematics.
●RJ45 Pin Assignments
5

Antaira Technologies - Industrial Ethernet Switches
LNX-C800 Series - Hardware Manual - v2.0

Crossover Cable
Straight Through Cable
Pin Number / Signal
Pin Number / Signal
Pin Number / Signal
Pin Number / Signal
1 / RX+
3 / TX+
1 / RX+
1 / TX+
2 / RX-
6 / TX-
2 / RX-
2 / TX-
3 / TX+
1 / RX+
3 / TX+
3 / RX+
6 / TX-
2 / RX-
6 / TX-
6 / RX-
Table 2.2 - 10/100Base-T(X) RJ45 Pin Assignments

Note: “+” and “-” signs represent the polarity of the wires that make up each wire pair.
2.6 Cabling
Use the four twisted-pair, category 5e, or the above cabling for the RJ45 port connections. The cable
between the switch and the link partner (switch, hub, workstation, etc.) must be less than 100 meters (328
ft.) in length.
2.7 Wiring the Power Inputs
Caution: Please follow the steps below when inserting the power wire.
Attention: Veuillez suivre les étapes ci-dessous lors de l'insertion du câble d'alimentation.

1. Insert the positive and negative wires into the PWR1 (V1+, V1-) and PWR2 (V2+, V2-) contacts on the
terminal block connector as shown below in Figure 2.4.
Figure 2.4 - Power Terminal Block

2. Tighten the wire-clamp screws to prevent the wires from loosening, as shown below in Figure 2.5.
6

Antaira Technologies - Industrial Ethernet Switches
LNX-C800 Series - Hardware Manual - v2.0

Figure 2.5 - Power Terminal Block

Caution:
Only use copper conductors, 125°C, tighten to 5 lbs.
The wire gauge for the terminal block should range between 18~20 AWG.

Attention:
Utilisez uniquement des conducteurs en cuivre, 125°C, serrez à 5 lb.
Le calibre des fils du bornier doit être compris entre 18 et 20 AWG.
2.8 Wiring the Fault Alarm Contact
The fault alarm contact is in the middle of the terminal block connector as the picture shows below in
Figure 2.6. By inserting the wires, it will detect the fault status including power failure or port link failure
(managed industrial switch only) and form a normal open circuit. An example is shown below in Figure
2.6.
Figure 2.6 - Wiring the Fault Alarm Contact
 
7

Antaira Technologies - Industrial Ethernet Switches
LNX-C800 Series - Hardware Manual - v2.0

Caution:
The wire gauge for the terminal block should range between 12 ~ 24 AWG.
If only using one power source, jumper Pin 1 to Pin 5 and Pin 2 to Pin 6 to eliminate power fault
alarm.

Attention:
Le calibre des fils du bornier doit être compris entre 12 et 24 AWG.
Si vous n'utilisez qu'une seule source d'alimentation, connectez les broches 1 à 5 et les broches
2 à 6 pour éliminer l'alarme de panne de courant.
2.9 Grounding Note
Grounding and wire routing help limit the effects of noise due to Electromagnetic Interference (EMI). Run               
the ground connection from the ground screw to the grounding surface prior to connecting devices. The               
grounding screw symbol is shown below in Figure 2.7.

Figure 2.7 - Grounding screw symbol
Caution: Using a shielded cable achieves better electromagnetic compatibility.
Attention: L'utilisation d'un câble blindé permet une meilleure compatibilité électromagnétique 
8

Antaira Technologies - Industrial Ethernet Switches
LNX-C800 Series - Hardware Manual - v2.0

3 Mounting Installation
3.1 DIN-Rail Mounting
The DIN-Rail is pre-installed on the industrial Ethernet switch from the factory. If the DIN-Rail is not on the
industrial Ethernet switch, please see Figure 3.1 to learn how to install the DIN-Rail on the switch.
Follow the steps below to learn how to hang the industrial Ethernet switch:
1. Use the screws to install the DIN-Rail bracket on the rear side of the industrial Ethernet switch.
Caution: The torque for tightening the screws on the device is 3.5 in-lbs.
Attention: Le couple de serrage des vis sur l'appareil est de 3.5 pouces-livres.
2. To remove the DIN-Rail bracket, do the opposite from step 1.
3. After the DIN-Rail bracket is installed on the rear side of the switch, insert the top of the
DIN- Rail on to the track as shown below in Figure 3.2.
4. Lightly pull down the bracket on to the rail as shown below in Figure 3.3.
5. Check if the bracket is mounted tightly on the rail.
6. To remove the industrial Ethernet switch from the rail, do the opposite from the above steps.
Figure 3.1 - Rear View of the Switch and DIN-Rail
9

Antaira Technologies - Industrial Ethernet Switches
LNX-C800 Series - Hardware Manual - v2.0

Figure 3.2 - Insert the Switch on the DIN-Rail Figure 3.3 - Stable the Switch on the DIN-Rail
3.2 Wall Mounting
Follow the steps below to mount the industrial Ethernet switch using the wall mounting bracket as shown
below in Figure 3.4.
Caution: “Wall” means industrial control panel wall
Attention: “Wall” signifie mur de panneau de commande industriel
1. Remove the DIN-Rail bracket from the industrial Ethernet switch by loosening the screws.
2. Place the wall mounting brackets on the top and bottom of the industrial Ethernet switch.
3. Use the screws to screw the wall mounting bracket on the industrial Ethernet switch.
Caution: The torque for tightening the screws on the device is 3.5 in-lbs.
Attention: Le couple de serrage des vis sur l'appareil est de 3.5 pouces-livres.
4. Use the hook holes at the corners of the wall mounting bracket to hang the industrial Ethernet
switch on the wall.
5. To remove the wall mount bracket, do the opposite from the steps above.
10

Antaira Technologies - Industrial Ethernet Switches
LNX-C800 Series - Hardware Manual - v2.0

Figure 3.4 - Remove DIN-Rail bracket from the Switch
Below, in Figure 3.5 are the dimensions of the wall mounting bracket.
Figure 3.5 - Wall Mounting Bracket Dimensions

11

Antaira Technologies - Industrial Ethernet Switches
LNX-C800 Series - Hardware Manual - v2.0

4 Hardware Installation
4.1 Installation Steps
This section will explain how to install the industrial Ethernet switch:
Caution: This device is intended for indoor use.
Attention: Cet appareil est destiné à une utilisation en intérieur.

Caution: The device is intended to be installed in an industrial control enclosure and panel.
Attention: L'appareil est destiné à être installé dans une armoire de commande et un panneau
industriels.

Installation Steps
1. Unpack the industrial Ethernet switch from the original packing box.
2. Check if the DIN-Rail bracket is screwed on the industrial Ethernet switch.
●If the DIN-Rail is not screwed on the industrial Ethernet switch, please refer to the DIN-Rail
Mounting section for DIN-Rail installation.
●If it is required to wall mount the industrial Ethernet switch, please refer to the Wall Mounting
section for wall mounting installation.
3. To hang the industrial Ethernet switch on a DIN-Rail or wall, please refer to the Mounting
Installation section.
4. Power on the industrial Ethernet switch and then the power LED light will turn on.
●For the help on how to wire power, please refer to the Wiring the Power Inputs section.
●Please refer to the LED Indicators section for LED light indication.
5. Prepare the twisted-pair, straight-through category 5 cable for Ethernet connection.
6. Insert one side of the RJ45 cable into the switch’s Ethernet port and on the other side into the
networking device’s Ethernet port, e.g. switch PC or server.
12

Antaira Technologies - Industrial Ethernet Switches
LNX-C800 Series - Hardware Manual - v2.0

●The Ethernet port’s (RJ45) LED on the industrial Ethernet switch will turn on when the cable is
connected to the networking device.
●Please refer to the LED Indicators section for LED light indication.
7. When all connections are set and the LED lights all show normal, the installation is complete.
4.2 Maintenance and Service
●If the device requires servicing of any kind, the user is required to disconnect and remove it from
its mounting. The initial installation should be done in a way that makes this as convenient as
possible.
●Voltage / Power lines should be properly insulated as well as other cables. Be careful when
handling them so as to not trip over.
●Do not under any circumstance insert foreign objects of any kind into the heat dissipation
holes located in the different faces of the device. This may not only harm the internal layout,
but might cause harm to users as well.
●Do not under any circumstance open the device for any reason. Please contact your dealer
for any repair needed or follow the instructions within the manual.
●Clean the device with dry soft cloth.
4.3 Troubleshooting
●Always verify the right power cord or adapter is being used. Never use a power supply or adapter
with a non-compliant DC output voltage or it will burn the equipment.
●Select the proper UTP or STP cable in order to construct the network. Use an unshielded
twisted-pair (UTP) or shield twisted-pair (STP) cable for RJ45 connections: 100Ω Category 5e for
10/100Mbps. Also be sure that the length of any twisted-pair connection does not exceed 100
meters (328 feet).
●Diagnosing LED Indicators: To assist in identifying problems, the switch can be easily monitored
with the LED indicators which help to identify if any problems exist.
○Please refer to the LED Indicators section for LED light indication.
13

Antaira Technologies - Industrial Ethernet Switches
LNX-C800 Series - Hardware Manual - v2.0

●If the power indicator LED does not turn on when the power cord is plugged in, the user may have
a problem with the power cord. Check for loose power connections, power losses or surges at the
power outlet.
○Please contact Antaira for technical support service if the problem still cannot be
resolved.
●If the industrial switch LED indicators are normal and the connected cables are correct but the
packets still cannot transmit, please check the system’s Ethernet devices’ configuration or status.
 
14

Antaira Technologies - Industrial Ethernet Switches
LNX-C800 Series - Hardware Manual - v2.0

5 Technical Specifications
Table 5.1 has the technical specifications for this product series.
Technology
Standards
IEEE 802.3 10T Ethernet
IEEE 802.3u 100Tx Fast Ethernet
Switch Properties
Switch Architecture
Back-Plane (Switching Fabric): 1.6Gbps
Protocols
CSMA/CD
Processing Type
Store and Forward
Flow Control
IEEE 802.3x for full duplex mode, back pressure for half duplex
mode
Transfer Rate
14,880pps for 10Base-T Ethernet
148,800pps for 100Base-TX Fast Ethernet
Packet Buffer
448Kbits
MAC Table Size
1K
Port Interface
Ethernet Port
8*10/100BaseTx
Auto negotiation speed, Full/Half duplex mode, and auto
MDI/MDI-X connection
LED Indicators
System: Power 1, Power 2, and Fault
Ethernet Ports: Link/Activity
Protection
Network Cable
10Base-T: 2-pair UTP/STP Cat. 3, 4, 5 cable; EIA/TIA-568
100-ohm (100m)
100Base-TX: 2-pair 2-pair UTP/STP Cat. 5 cable; EIA/TIA-568
100-ohm (100m)
Mechanical Characteristics
Housing
Metal, IP30 rated
Dimensions
40 x 95 x 70 mm (W x H x D)
Weight
Unit: 0.74 lbs.
15
