AnyTone AT-D578UV Setup guide

COPYRIGHT BY CONNECT SYSTEMS INC. PERMISSION IS GRANTED TO DISTRIBUTE OR POST
1
SETTING THE AT-D578UV RADIO TO THE DESIRED MODE
When you get the AnyTone mobile radio it might be set to a band you don’t really
want. You might want to use it commercially with FCC Part 90 certification, so you
set it to Mode 0 or 1. If you want to be triband, then set it to mode 18. This lesson
will explain how to set it to the desired band.
AnyTone Defines the bands to be used as follows:
Mode Use
0 European Commercial
1 U.S. Commercial
3 European Amateur
4 Band 4
5 Band 5
7 U.S. Amateur
8 Commercial
10 Canada/Australia Amateur
13 Commercial
16 Thailand Amateur
17 Thailand Commercial
18 Band 19 (US Amateur Tri-band)

COPYRIGHT BY CONNECT SYSTEMS INC. PERMISSION IS GRANTED TO DISTRIBUTE OR POST
2
The following is the frequency allocation of the bands available in the AnyTone
AT-D578UV
Mode # VHF Frequency UHF Frequency 220 Band Tx/Rx
0 136-174 400-480 Tx
136-174 400-480 Rx
1 136-174 400-480 Tx
136-174 400-480 Rx
3 144-146 430-440 Tx
136-174 400-480 Rx
4 144-146 434-438 Tx
144-146 434-438 Rx
5 144-146 434-437 Tx
144-146 434-437 Rx
7 144-148 420-450 Tx
136-174 400-480 Rx
8 136-174 400-470 Tx
136-174 400-470 Rx
10 144-148 430-450 Tx
136-174 400-480 Rx
13 136-174 403-470 Tx
136-174 400-480 Rx
16 144-147 430-440 Tx
144-147 430-440 Rx
17 136-174 Off Tx
136-174 430-440 Rx
18 144-148 420-450 222-225 Tx
136-174 400-480 220-225 Rx

COPYRIGHT BY CONNECT SYSTEMS INC. PERMISSION IS GRANTED TO DISTRIBUTE OR POST
3
To change bands, go through the following steps:
1. Connect radio to power, turn on power supply and turn off radio. The radio
should look like the following:
2. Press the P4 Key, Press the Channel Selector Switch, and press the power
switch in that order. Keep those three keys pressed.
3. In a short time, the screen should look like this:

COPYRIGHT BY CONNECT SYSTEMS INC. PERMISSION IS GRANTED TO DISTRIBUTE OR POST
4
4. Keep the keys pressed and in a short time, the screen should look like this:
5. Now let go of the three keys and the screen should look like the following:

COPYRIGHT BY CONNECT SYSTEMS INC. PERMISSION IS GRANTED TO DISTRIBUTE OR POST
5
6. A short time later the screen will change to the following:
7. Use the channel selector switch to change the mode from 00001 to 000018.
When you get your desired mode, press the menu key and you are finished.
8. Now attach your radio to your computer, activate the CPS, and read the
radio. Then click the “Model” pull down menu and you should get the
following:
9. The mode here should correspond to the mode you set the radio to.
