AnyTone AT-318UV User manual

A1.140814

DUAL BAND HANDHELD RADIO
INSTRUCTION MANUAL
AT-318UV

THANK YOU!
transceiver will provide you with reliable, clear and efficient communication service. The
transceiver introduces innovative DSP digital signal processing technology, high degree integration, it is
including kinds of professional function, best stability and great reliability as well as exterior smooth lines,
novel, fashionable, sturdy and durable.
The transceiver is including plenty of TX, RX channels, as well as UU, VV, UV, mono U or Mono V standby
modes, the transceiver realized dual PTT functions and 51 groups of CTCSS encode/decode and 1 group of
user-dened CTCSS encode/decode, 1024 groups of DCS encode/decode, DTMF encode/decode, built-in
FM radio functions, etc..
It is a meticulous build functional and Multi frequency band radio for radio amateur.
MODELS APPLY TO THIS MANUAL
AT-318UV FM Transceiver
Programming software: QPS318UV_1.01
PROGRAM CAUTIONS
When programming the transceiver, read the factory initial data rst, then rewrite the frequency and signaling
etc., other wise errors may occur because of different frequency band etc.

CAUTIONS
transceiver is excellent designed with advanced technology. The following tips will be helpful for you in
performing your obligation under warranty and understanding the safety of transceiver usage.
1.Keep the transceiver and accessories away from children.
2.Please do not try to open or modify the transceiver without permission, non-professionals operation may also cause
damage.
3.Please use assorted battery and charger to avoid damage.
4.Please use assorted antenna to ensure the communication distance.
5.Please avoid exposing the radio under the sunshine for a long time or storing it in too hot places. High temperature will
shorten the life of electronic devices.
6.Please avoid storing the radio in the dusty, dirty and damp areas.
7.Please keep the radio dry. Do not wash radio with ardent chemicals and detergents.
8.Do not transmit without antenna.
9.When using this transceiver, we recommend transmitting for 1 minute then receiving for 4 minutes. continuously
transmitting for long time or working in high power will heat the back of the transceiver. Do not place the transceiver's hot
back close to any plastics.
10.If any abnormal smell or smoke coming from the transceiver, please turn off the power instantly and take off the battery
and its case. Then contact local dealers.
NOTE：
All the above tips apply for your transceivers' accessories. If any device can not operate
normally, please contact with local dealers.
If you use any accessories made by other companies, company does not guarantee the
operability and safety of the transceiver.

I
TABLE OF CONTENTS
UNPACKING ................................................................................................................................................................................................ 01
Supplied Accessories ......................................................................................................................................................................... 01
STANDARD ACCESSORIES/ADDITIONAL ACCESSORIES............................................................................... 02
Standard Accessories.......................................................................................................................................................................... 02
Additional Accessories........................................................................................................................................................................ 02
BATTERY INFORMATION................................................................................................................................................................. 03
Charging Operation .............................................................................................................................................................................. 03
Battery Charger Type........................................................................................................................................................................... 03
Notice for Charging Battery .............................................................................................................................................................. 03
How to Charge........................................................................................................................................................................................ 04
PREPARATION.......................................................................................................................................................................................... 05
Installing/Removing the Battery...................................................................................................................................................... 05
Installing/Removing the Antenna ................................................................................................................................................... 05
Installing/Removing the Belt Clip................................................................................................................................................... 06
Installing the additional Speaker/Microphone.......................................................................................................................... 06
GETTING ACQUAINTED ................................................................................................................................................................... 07
LCD Display ............................................................................................................................................................................................. 07
BASIC OPERATIONS........................................................................................................................................................................... 10
Turn the Radio On & OFF ................................................................................................................................................................. 10
Adjusting Volume................................................................................................................................................................................... 10
Switch between Main band and Sub band ............................................................................................................................... 10
Switch between Channel mode and VFO mode.................................................................................................................... 11
Channel Adjusting ................................................................................................................................................................................. 11
Frequency Adjusting............................................................................................................................................................................. 11
FM Channel Searching....................................................................................................................................................................... 12

II
TABLE OF CONTENTS
Receiving................................................................................................................................................................................................... 12
Transmitting.............................................................................................................................................................................................. 12
Emergency Alarm .................................................................................................................................................................................. 13
Side Key [PF1]/[PF2] function instruction.................................................................................................................................. 13
MONI Key Function .............................................................................................................................................................................. 14
VFO Frequency Scanning Limited ............................................................................................................................................... 14
Turn On/Off FM Radio......................................................................................................................................................................... 14
CTCSS/DCS Setup .............................................................................................................................................................................. 15
CTCSS/DCS Scan................................................................................................................................................................................ 15
Offset Frequency Direction Setup................................................................................................................................................. 16
Frequency/Channel Scan.................................................................................................................................................................. 16
Channel Scan Skip ............................................................................................................................................................................... 17
Frequency Reverse .............................................................................................................................................................................. 17
TX Power selection............................................................................................................................................................................... 18
DTMF code Transmit and Enquiry ................................................................................................................................................ 18
Keypad lock.............................................................................................................................................................................................. 19
Single-band Switching......................................................................................................................................................................... 19
Function Menu Setup.......................................................................................................................................................................... 20
Display Mode Setup............................................................................................................................................................................. 26
Resume Factory Default .................................................................................................................................................................... 26
TECHNICAL SPECIFICATION....................................................................................................................................................... 28
TROUBLE SHOOTING GUIDE...................................................................................................................................................... 29

01
UNPACKING
Please carefully unpack the transceiver. We recommend that you identify the items listed in the following table
before discarding the packing material.
If any items are missing or have been damaged during shipment, please contact with dealers immediately.
Item Number Quantity
Antenna QA11UV 1
Li-ion Battery QB-43L 1
Battery Charger QBC-42L 1
AC Adaptor QPS-01 1
Belt Clip BC06 1
Instruction Manual 1
Supplied Accessories

02
STANDARD ACCESSORIES/ADDITIONAL ACCESSORIES
Standard Accessories
Additional Accessories
Antenna*1
QA11UV
155/435MHz
*1.Note: For frequency band of antenna, please refer to label indicated in the bottom of the antenna.
Li-ion Battery
QB-43L
Instruction
Manual
USB Programming
Cable PC03
Programming Software
QPS318UV_1.01
Earphone
HS03
Handheld Microphone
QHM22
Battery Charger
QBC-42L
Belt Clip
BC06
Telescopic antenna
QA10UV
AC Adaptor
QPS-01

03
BATTERY INFORMATION
Charging Operation
The battery is not charged at the factory, please charge it before use. Charge the battery for the rst time
after purchase or extended storage (more than 2 months) may not bring the battery to its normal operating
capacity. After repeating fully charge/discharge cycle for two or three times, the operating capacity will
reach the best performance. The battery life is over when its operating time decreases even though it is
fully and correctly charged. Replace the battery.
Battery Charger Type
Please use our company's designated charger, other models may cause explosion and injure people. After
installing the battery, if the radio red light twinkles and remind changing battery, please charge the battery.
Notice for Charging Battery
Do not shortcircuit our company designated charger. Never attempt to remove the casing from the▲
battery, we show no responsibility on the faulty caused by modifying freely without permission of our
factory.
The ambient temperature should be between 5▲℃ and 40℃in charging. Charging outside this range
may not fully charge the battery.
Always switch off the transceiver equipped with a battery before charging. Otherwise, it will interfere▲
with correct charging.
To avoid interfering the charging procedure, please do not cut off the power or take out the battery▲
during charging.

04
How to Charge
1.Plug the AC adaptor into the AC outlet(100V-240V), then plug
the cable of AC adaptor into the DC jack, the indicator lights
GREEN---waits to charge.
2.Slide the battery or transceiver with battery into the charger;
make sure the battery terminals are in contact with the charging
terminals well. LED turns into twinkling RED---charging.
3.It takes about 4 hours to fully charge the battery.
BATTERY INFORMATION
WARNING:
When keys or ornamental chains and other electric metals contact with the battery terminals, the battery
may cause damage or hurt bodies. If the battery terminal short circuit, it will generate a lot of heat, please
be careful when you bring or use the battery, please put battery or radio into insulated container. Do not put
it into metal container.
Do not recharge the battery if it is already fully charged. This may shorten the life of the battery or▲
damage the battery.
Do not charge the battery or transceiver if it is damp. Dry it before charging to avoid danger.▲

05
Installing / Removing the Battery
■ Installing the Battery
Lay the battery to face the back of the radio.1.
Press the button of battery, the latch in button of2.
transceiver locks will release. After hearing a "click"
sounds, the battery has been locked.
■ Removing the Battery
According to “ ” to push the battery lock to removing the
battery. 3
4
Installing / Removing the Antenna
■ Installing the Antenna:
Screw the antenna into the connector on the top of the
transceiver by holding the antenna at its base and turning it
clockwise until secure.
■ Removing the Antenna:
Turn the antenna anticlockwise till the antenna separates the
connector of the transeceiver to remove it.
A
FUN
D
ESC/M
B
PREPARATION

06
Installing / Removing the Belt Clip
■ Installing the Belt Clip:
Place the belt clip to the grooves on the back of the
transceiver, and then clockwise screw it.
■ Removing the Belt Clip:
Anticlockwise turn the screws to remove the belt clip.
Installing the Additional Speaker/ Microphone (Optional)
Unveil the MIC-SP jack cover and then insert the
Speaker/Microphone plug into MIC-SP jack.
Note:
The transceiver is not completely waterproof while
using the Speaker/Microphone.
PREPARATION

07
GETTING ACQUAINTED
LCD Display
On LCD display screen, you will see various icons which stand for the selected functions and sometimes
you may forget the meaning of them. Here you will nd the following table extremely useful.
Frequency
Reverse
Offset Frequency
DCS
Optional Signaling
CTCSS
FUNC Icon
The arrow points to
main channel
FM radio
TX Power
Busy Channel
VOX Function
Scan Skip
Narrow band
Battery Capacity
Function Menu
Number, Channel
Number
FM Channel Number
channel Number
Keypad Lock
NOTE:
Battery capacity indicator(full) No power, replace battery pack or charge battery
Real time display receiving signal
strength/Power Indicator
Battery capacity remnant

08
GETTING ACQUAINTED
1
7
3
2
9
10
5
11
6
12
4
A
B
C
FUN
D
ESC/M
8
13
MIC

09
GETTING ACQUAINTED
1 Antenna
2 Lamp
3Power / Volume Switch
Rotate it clockwise to turn on transceiver, rotate it anticlockwise until heard "click" to turn off the
transceiver.
When transceiver is power on, rotate it clockwise to increase volume, anticlockwise to reduce volume.
4 LCD display
Displays current frequency/channel and operations
5 Speaker
6 Keypad
Enters desired frequency/channel or operations by keypad
7 Mic
8 PF1 key
9 PTT key
Press PTT key to talk, release this key to receive.
10 PF2 key
11 MONI key
12 Speaker/Microphone jack, programming software jack
13 Belt Clip

10
Turn the Radio On & OFF
NOTE:
Press the side key programmed as Squelch Off Momentary to monitor the background noise. Turn [POWER]/
[VOLUME] to control the volume. The volume you need can be adjusted more correctly when communicating
with the other party.
BASIC OPERATIONS
Under power-off state, please turn [POWER]/[VOLUME] clockwise to turn on the
transceiver. The transceiver will announces prompt tone and displays the current
channel on screen.
Under power-on state, please turn [POWER]/[VOLUME] anticlockwise till hearing
"Click" to turn off the transceiver.
Under power-on state, turn [POWER] /[VOLUME] to adjust volume. Clockwise-up, anticlockwise -down.
When adjusting the volume, user can press the key programmed as Squelch Off to monitor current
volume rstly.
Adjusting Volume
Switch between Main band and Sub band
Under standby state, press key to switch channel between Main band and
Sub band. Arrow directs the current operational channel.

11
BASIC OPERATIONS
Switch between Channel mode and VFO mode
Under standby state, press key to set main band as Channel mode or frequency
mode(VFO).
Frequency Adjusting
When transceiver in VFO mode or FM radio frequency mode, rotate / to adjust frequency or input
frequency by keypad.
1.Press to increase frequency, Press to decrease frequency. Every rotate can add or reduce one
stepping value.
Channel Adjusting
When transceiver in Channel mode or FM radio channel mode, rotate 1. / to adjust channel.
Press to enter the downward channel, Press to enter the upward channel. If there is blank
channel between two channels, radio will skip blank channel into next channel.
Input channel number by keypad2.
When transceiver in Channel mode or FM radio channel mode, user can input number(000-199) to
switch into desired channel. If input channel number is not belong to unprogrammed channel, radio
will emit wrong prompt voice to return current channel. 001 means channel 1,030 is channel 30, 125
is channel 125.
NOTE: Channel step:2.5K, 5K, 6.25K, 10K, 12.5K, 20K, 25K, 30K and 50KHz in total 9 for optional. FM
radio step frequency is 50K.

12
BASIC OPERATIONS
2. Enter the desired frequency by keypad.
In VFO or FM VFO mode, you can directly input frequency by keypad.
NOTE: The frequency input of main channel or FM radio is relevant to the stepping and transceiver
frequency range. If frequency setup is beyond range or not matching with step size, the input is unavailable.
Under the FM radio mode, the frequency step size input by numeric keys is 100k.
FM Channel Searching
When transceiver in FM radio mode, press key, LCD displays " " icon, then
press to start FM searching. When one station is sought, LCD displays current
station frequency, you can listen to current station.
Receiving
When your transceiver is called by other party, the LED light will be on and the arrow icon will ash, you
can hear the calling.
NOTE: You may not receive the calling when your transceiver is set at high squelch level. If current channel
is programmed with decode signal, only the same signaling call can be heard.
Transmitting
According to [MONI] key setup in programming software, hold [MONI] key to monitor the channel to

13
BASIC OPERATIONS
NOTE: When press and hold PTT key, transceiver is transmitting if the red LED light is on, release [PTT]
key to receive calls.
ensure it is not busy, press [PTT] key and talk to speaker.
Please keep the distance between mouth and speaker to be 2.5-5CM, speak in normal tone to get the
best acoustic delity.
Emergency Alarm
Under standby state, press and hold [PF1] or [PF2] key which is programmed with ALARM function until
LCD displays "ALARM", Emergency alarm function is started. This transceiver has 4 Alarm modes for
optional, can be setup in programming software. Power off transceiver to exit Alarm.
Side Key [PF1]/[PF2] function instruction
1. VOLT: Battery capacity inquiry: Under standby, press [PF1]/[PF2] key, LCD displays current battery
capacity, press this key again to exit.
2. CALL: Transmit the prestored DTMF Encode signal in channel.
3. ALARM: Long pressing [PF1]/[PF2] key, LCD display "ALARM", transceiver will enable the preset alarm
function.
4. SUBPTT: Press [PF1]/[PF2] key, transceiver will transmit at sub-band frequency.
5. LAMP: Press [PF1]/[PF2] to turn on/off lamp.
6. Transmit tone pulse frequency: Press and hold [PTT] key, then press [PF1]/[PF2] key to transmit selected
tone pulse frequency. The tone pulse frequency can be set to 1750Hz / 2100Hz / 1000Hz / 1450Hz.
