Anzzi SH-AZ101 Series User manual

SH-AZ101
RAINFALL SHOWER BAR
INSTALLATION
808000-792
20220222
05/10/2022

Order or Purchase #...............................................SKU or Model #.......................................

PRODUCT SIZE CHART
TOOLS AND MATERIALS
PG. 1
380
3
7

[14]
[13]
[12]
[04]
[05]
[01]
[02]
[03]
[06]
[07]
[08]
[09]
[10]
[11]
1
1
1
1
1
2
2
2
1
1
1
1
1
1
Part Description Qty.
[ 01 ] Faucet
[ 02 ] Thermostatic Cartridge
[ 03 ] Temp. Control Handle
[ 04 ] Diverter
[ 05 ] Diverter Handle
[ 06 ] Nut
[ 07 ] Cover
[ 08 ] Nipple
[ 09 ] Riser
[ 10 ] Bracket
[ 11 ] Mounting Kit
[ 12 ] Shower Hose
[ 13 ] Hand Shower
[ 14 ] Shower head
Before installation:
1. Please check the product for damage and missing parts immediately upon delivery.
Damage reported later will not be covered by our warranty.
Please handle the product with care.
2. Ensure that all supply lines are free of debris.
3. Ensure water pressure is between 20-125 PSI.
4. Make sure that the wall is strong enough to support the showerpipe.
The wall must be reinforced at the mounting points. The area where the top
mounting piece is to be installed must be flat and free of protruding grout joints, etc.
4. If you are having difficuties on installation, please contact a professional plumber .
PG. 2
COMPONENTS

INSTALLATION
STEP 1:
Ensure that the center distance of
outlets are between 5.7" - 6.1".
The Hot inlet is on the Left,
and t h e Cold inlet is on the Right.
The he ight of the inlets from the floor
is about 35.5" - 39.4". Ensure each
inlet with the same height.
STEP 2:
a. Wrap the smaller point of
Nipples [08] with water sealing tape.
b. Install the Nipples [08] and secure
by wrench.
STEP 3:
Turn on the valves and flush the hot
and cold supplies thoroughly for 30s
to 1 minute. Then turn off the valve
and seal the wall around the nipples
with waterproof sealant.
STEP 4:
Install the Covers [07] and place the
leveler on the Covers [07] and make
sure the leveler is in level condition.
Then place the leveler on the shanks.
Make sure the leveler is in level
condition and the distance between
the shanks is 5.9".
PG. 3
5.7"-6.1"
Hot Cold
1/2"
35.5"-39.4"
Floor
12
a.
b.
[08]
34
5.9"
[07]
shank
[150mm]

INSTALLATION
STEP 5:
Install the Riser [09] with washer to the
Faucet [01]. Hand tighten the nut.
STEP 6:
a. Remove the cap from the
Mounting Kit [11].
b. Install the Mounting Kit [11] to the rod
of the Riser [09] then install the
Faucet [01] and hand tighten the nuts.
c. Adjust the Mounting Kit [11] until the
screw holes of connector are aligned
vertically.
d. Make sure the Riser [09] is vertical.
e. Mark the positions of the screw holes.
f. Remove the Faucet [01] and Riser [09].
PG. 4
[09]
nut
washer
[01]
5
6
[01]
[09]
[11]
nut
b.
c.
a. cap
rod
connector

INSTALLATION
PG. 5
STEP 7:
a. Drill the holes for the Mounting Kit [11]
using a 1/4" (6 mm) bit.
b. Install the anchors.
c. Secure the Mounting Kit [11] with
screws.
d. Make sure the screw holes are aligned
vertically.
e. Slide the cap to the Mounting Kit [11].
STEP 8:
a. Install the Faucet [01]filters and
Riser [09]. Push the rod into the hole of
the Mounting Kit [11]. Hand tighten the
nuts and secure with wrench.
Do not over tighten.
Note:
Put a thin cloth between the nut
and the wrench to avoid scratching.
b. Make sure the Riser [09]is vertical.
c. Secure the rod of Riser [09]by tighten
the screws.
7
a.
b.
[11]
cap
screw
anchor
8
[01]
[09]
nut
a.
c.
[11]
rod
b.
filter

PG. 6
INSTALLATION
STEP 9:
a. Install the Shower Head [14] with
washer and secure.
b. Loose the locking handle by turning
it anti-clockwise. Then adjust the
height of Shower Head [14] to about
12.6"[320mm] above the head to get
the best shower experience.
c. Hold the shower arm still and turn
the locking handle clockwise to
secure the shower arm.
STEP 10:
a. Install and secure the Hand Shower
[13] and Shower Hose [12] to the
faucet as the figure shows and secure.
Note:
Make sure the washer and the
flow restrictor are in position.
b. Turn on hot and cold water supplies
and check all connections at arrows
for leaks. Retighten if necessary,
but do not overtighten.
c. Turn the Diverter Handle [05] to
Hand Shower [13] and Shower Head
[14] fuction to check for leakage and
flow effect. If the shower arm moves
upward when the shower head flows,
turn off the Faucet [01] and tighten
the locking handle to secure.
shower
locking
handle
[01]
[09]
9
[01]
locking
handle
shower arm
flow
restrictor
washer
10
arm
[14]
washer
[13]
[12]
[05]

OPERATION
Diverter Handle [05] in
close position.
Turn the Diverter Handle
[05] anti-clockwise for
Hand Shower [13] flow.
Turn the Diverter Handle
[05] clockwise for
Shower Head [14] flow.
Flow tempreture is set in
100 F with the button of
Temp.Control Handle [03]
pointing 100°F.
Turn the Temp. control
Handle [03] clockwise will
lower the temperature.
You can raise the
temperature by pressing
the button and turning the
Temp.Control handle [03]
anti-clockwise.
You can move the
Bracket [10] by loosing
the handle of it.
The holder of Bracket [10] can
be turned by anyi-clockwise or
clockwise to adjust the position
of Hand shower [13].
PG. 7

CLEANING & MAINTENANCE
To preserve the finish on the metallic parts of your ANZZI faucet, apply non-abrasive
wax, such as car wax. Any cleaners should be rinsed off immediately.
When there is scale build up on the nozzle of showers, you can turn on the showers
and simply rub over the spray nozzles to remove lime scale.
a. If the water flow lower than normal, please remove the faucet by loosing the
screws of the Mounting Kit [11] and the Nuts [06].
b. Clean the filters in the connectors and inspect the check valves. Replace the
check valves if necessary.
c. Remove the Thermostatic Cartridge [02] by loosing the screw under the faucet.
Rinse the cartridge with clean flowing water.
d. Install the cartridge and connectors again. Then install the faucet again and secure it.
Caution:
Check all connections for leaks. Retighten if necessary, but do not overtighten.
connector
filter & check valve
PG. 8
screw
[06]
a.
b.
c.
screw
[02]

temperature
