AP&T AP-AB1208 User manual

Shanghai Anping Static Technology Co.,Ltd
3/F, Building 27, No.69, Guiqing Road, Shanghai, China
Tel：[phone]
Fax：[phone]
www.ap-static.cn
Air Source AC Pulse Ion Bar
AP-AB1208
User Manual
Shanghai Anping Static Technology Co.,Ltd

2
Static removing
performance decline
obviously
Pollute or damage of
discharge pin
Clean or replace discharge pin
Electrode pad not tightly
screwed
Be sure the electrode pad screwed
tightly
Improper installation
position
Confirm the optimum installation
position
3
Static removing
performance decline
There are conductor or
other ion bar around
Remove conductor or other ion bar
4
HV Alarm
Electromagnetic disturb
Switch off and reset
Abnormal discharge
Check installation position and be
away from conductors
Pollute or damage of
discharge pin
Send back to manufacturer
5
Smoking or burning
Pollute or damage of
discharge pin or electrode
pad insulator
Send back to manufacturer
6. Maintenance **************************************
(1) User should clean and maintain timely to ensure the good performance of
the product according to working environment and requirement of ESD
protection. Clean the carbon materials on electrode tip, discharge pad and
metal discharge body with static brush or clean cloth with ethanol can
obviously improve the performance.
Caution：
A、Must be done after the power is shut done for 10 minutes
B、Restart must wait till alcohol completely volatilized after cleaning by
clean cloth with ethanol. Any other organic solution is not allowed
to be used to clean the rod.
(2) Stop using when POS/NEG working indication keeps off. Re-use after
check and repair by professionals.
7. Accessories ***************************************
1. Installation bracket 2. Power adapter 3. Power cord 4. Three-core power cord
1、General *************************************
AP-AB1208 Air source AC pulse ion bar is the newest developed bar type
static eliminator for static removing.
It can be widely used in electronics, textile, optical and other industries.
2、Features ***********************************
(1) Bar shaped and cross over static eliminator
(2) Manufactured by using the latest patented technology of static removing.
(3) Fast speed of static removing, low ion balance and high safety.
(4) LCD on bar body indicates working status for easy use and maintenance
(5) Output voltage adjustable, fit for different static environment.
(6) With alarm function of ion volume, electrode tip cleaning and high voltage
fault.
3、Parameter ***************************************
Model
AP-AB1208
Output voltage
AC±5KV
Output frequency
5，30Hz（default）
Duty factor
10%-90%
Power
10W
Working distance
100－1000mm
Ion balance
≤|±30V| ( AVE )
Discharge time
≤2S（adjust）
Working temperature
0℃-50℃
Working humidity
＜70%
Air pressure scope
0.1-0.6MPa
Cord length
2.5m
Bar length
380mm,410mm,460mm,510mm……2510mm(spacing distance 50mm)

4. Notice on use and safety warning *********************
(1) Read this manual carefully before installing and using of the device.
(2) Be sure the device reliable ground connected during use, otherwise may
cause bar body burn.
(3) Touching of electrode tip during use strictly prohibited.
(4) Do not use this device in the environment where the humidity is greater
than 75%.
(5) Input air must be clean and filled air without water, oil and dust particle
(6) It is strictly prohibited to use this equipment in combustible and explosive
environment.
(7) Internal maintenance and repair must be carried out by professionals
5. Installation guide **********************************
(1) Installation
a. Choose optimal location for discharge and fix the bar and power supply
steadily.
b. Connect earth to earth connect end on ion bar.
c. Insert one end of the power cord into power adapter and the other end into
power port.
d. Connect air connector to air supply device with tube and turn on the air
switch.
e. Turn on the power switch and adjust proper air pressure.
(2) Outline dimensional drawing
POW ER
POS N EG
40 50
63.5
35
78.5
24
5.1 8
48
28
⑥
⑤
⑧
⑦
①② ③ ④
①Power outlet ②Add ③Power alarm ④HV alarm ⑤Bar body
⑥Installation base ⑦Discharge electrode socket ⑧End cover
(3) Positioning
a. Caution
b. Ion bar should be installed within the working area of static removing
and installation angle should be perpendicular to the surface of the
charged body
c. The discharge electrode of ion bar should stay away from metal
conductor, metal grounding, rods must be reliable ground connected.
d. Trouble shooting
N
O
Error
Possible reason
Solution
1
Power port indication
LED off
Poor contact of power
cord
Check status and stable connection
of power cord
Power supply mismatch
Check power supply specification
（INPUT：100—240VAC
50/60Hz；OUTPUT：24VDC
1000mA）
