Apevia ATXB1KL Series User manual

ATXB1KL Series Installation Guide
1:Unscrew the Thrum Screws 2.Pull the Side Panel back then 3:Find the motherboard Stand-Offs
from Side Panel. pull out. From the enclosed Screw Box.
4:Put the motherboard Stand-Offs 5.Sit the motherboard on the 6.Find screws in the Screw Box.
on the Motherboard Tray. Motherboard Tray.
7.Screw in all the screws into the 8.Same as Step 7.
Motherboard Stand-Offs

9.Take out front panel:(Optional. Only if you want to install case fans in the front)
Step (1): Unscrew the side panel Step (2): Take out the side Step (3): There are 6 screws attach
panel motherboard side. panel (motherboard side) the front panel to the case. Unscrew
the 3 screws from inside of the case.
Step (4): Unscrew the other Step (5): Pull out the front panel Step (6): Install Case Fan in the front
3 screws from the other side. from the bottom. panel (You can put up to 2*80mm
fans).Thenscrewthefrontpanelback.
10.Optional: Install Case Fan at 11.Take out the metal plate by 12.install 5.25” drives (DVD,
rear (1*80mm-120mm fan) pushing out from inside. CD-R, CD-RW)
(you may use screw drive to
forceitout)

13.Secure the 5.25” drives 14.Push out the 3.5” metal 15.Slide in 3.5” FDD Drive and
with screws. plate from inside.(You may secure with screws.
use screw drive to force it out)
16.Install 3.5” hidden drives 17.Screw all 3.5” hidden 18.Find the 20-pin connector
such as Hard Drive, Zip Drive. Drives. fromPowerSupply
19.Plug into your motherboard. 20.Find the 4-pin P4 connector 21.Plug into your motherboard
Different M/B has different from Power Supply.(for P4 only) (For Intel P4 motherboard only)
Layout. Please refer to M/B
user’s manual.

22.Find 2*USB Cables. 23.Plug USB Cables to your M/B. 24.Find “HDD LED” and
(USB1 & USB2) Please refer to M/B User’s Manual. “Reset SW” Cables.
25.Plug them onto your M/B. 26.Find “Power SW” and “+P LED” 27.Find “Case Speaker” from
Please refer to M/B User’s Manual. “-P LED” cables and plug onto M/B. Screw Box.
Please refer to M/B User’s Manual.
28.Install Case Speaker to M/B 29.Audio Cable: Take out the 30. Find the Audio Cables and
following M/B User’s Manual. I/O slot with a hole from the Bring them through the I/O slot
back of the case to outside of the back panel.

31.Put the I/O slot back. 32.Screw the I/O slot back. 33.Find “Case Feet” in Screw Box. Lay
case down and snap “Case Feet” on.
