Apevia ATXB3KL Series User manual

ATXB3KL/B3KLW Series Installation Guide
1:Unscrew the thumb screws 2.Pull the side panel back then 3:Find the motherboard stand-offs
from side panel. pull out. from the enclosed screw box.
4:Put the motherboard stand-offs 5.Sit the motherboard on the 6.Find screws in the screw box.
on the motherboard tray. motherboard tray.
7.Screw in all the screws into the 8.Same as Step 7.
motherboard stand-offs

9.Take out front panel:
Step (1): Unscrew the side panel Step (2): Take out the side Step (3): There are 4 screws attach
panel motherboard side. panel (motherboard side) the front panel to the case. Unscrew
2 screws from one side of the case.
Step (4): Unscrew the other Step (5): Pull out the front panel
2 screws from the other side. from the bottom.
10.Optional: Install case fan 11.Optional: Install case fan at 12.Take out the metal plate and
in the front(You can put up rear.(1*80mm-120mm fan) install 5.25” drives(DVD, CD-RW,
to 2*80mm fans in the front.) CD-ROM)

13.Secure the 5.25” drives 14.Slide in 3.5” FDD Drive and 15.Install 3.5” hidden drives such as
in place with screws. secure with screws. Hard Disk Drive, Zip Drive.
16.Screw all 3.5” hidden drives 17.Snap in the Front Panel. 18.Audio Cable: Take out the I/O slot
in place with screws. Screw 2 screws on each side to with a hole front the back of the case
attach the front panel to the case. .
19.Find the audio cables and 20.Put the I/O slot back. 21.Screw the I/O slot back.
bring them through the I/O slot
to outside of the back panel.

22.Connect case fans by linking 23.Find the 20-pin connector 24.Plug into your motherboard.
together all 4-pin Female and Male from Power Supply. Different M/B has different layout.
connectors of all fans. There will Please refer to your motherboard
be 1*Female & 1*Male connectors user’s manual.
left out at each end. Connect the
4-pin Male to a 4-pin Female from
power supply.
25.Find the 4-pin P4 connector 26.Plug into your motherboard. 27.Find 2*USB Cables.(USB1 & USB2)
from Power Supply.(for P4 only) (For Intel P4 motherboard only)
28.Plug USB cables to your M/B. 29.Find “HDD LED” and 30.Plug them onto your M/B.
Please refer to M/B user manual. “Reset SW” Cables. Please refer to M/B user manual.

31.Find “Power SW” and “+P LED” 32.Plug audio cables to 33.Find “Case Speaker” from
“-P LED” cables and plug onto M/B. sound Card or M/B. screw box.
Please refer to M/B user manual.
34.Install Case Speaker to M/B 35.LCD Temperature Readout: Connect 36.Remove the protective plastic
following M/B user manual. 4-pin Male connector from LCD to tube from the sensor.
a4-pinFemaleconnectorfrompower
supply.
37.This is the temperature sensor. 38.You can either tape the sensor on Hard Drive or on CPU Heat Sink
It is very fragile. Be gentle. or leave it inside the case to get the overall system temperature.

39.After installing the LCD, 40.Lay your case down and put “Case Feet” on.
the temperature readout will
show up with back lighting
when powered on.
