Aplex AEx-815P User manual

AEx-8XXP(H)
15”, 15.6”, 19”, and 21.5” Full IP66 Stainless Steel Designed with M12 waterproof
connector of Panel PC Series.
User Manual
Release Date Revision
Jan. 2018 V1.0
®2018 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan
Aplex Technology, Inc.
15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan
Tel: [phone] Fax: [phone] URL: http://www.aplextec.com/zh/home.php

AEx-8XXP(H) Series User Manual
1
Revision History
Reversion
Date
Description
0.1
2017/11/24
For Preliminary Release
1.0
2018/01/02
Official version

AEx-8XXP(H) Series User Manual
2
Warning!___________________________
This equipment generates, uses and can radiate radio frequency energy and if
not installed and used in accordance with the instructions manual, it may
cause interference to radio communications. It has been tested and found to
comply with the limits for a Class A computing device pursuant to FCC Rules,
which are designed to provide reasonable protection against such interference
when operated in a commercial environment. Operation of this equipment in
a residential area is likely to cause interference in which case the user at his
own expense will be required to take whatever measures may be required to
correct the interference.
Disclaimer
This information in this document is subject to change without notice. In no event
shall Aplex Technology Inc. be liable for damages of any kind, whether incidental or
consequential, arising from either the use or misuse of information in this
document or in any related materials.
Electric Shock Hazard –Do not operate the machine with its back cover
removed. There are dangerous high voltages inside.

AEx-8XXP(H) Series User Manual
3
ATEX Instruction Guide
SAFETY INSTRUCTIONS
Read these instructions carefully, and look at the equipment to become familiar with
the device before trying to install, operate, or maintain it. The following special
messages may appear throughout this documentation or on the equipment to warn
of potential hazards or to call attention to information that clarifies or simplifies a
procedure.
PLEASE NOTE
Electrical equipment should be installed, operated, serviced, and maintained only by
qualified personnel. No responsibility is assumed by Digital Electronics Corporation
for any consequences arising out of the use of this material. A qualified person is one
who has skills and knowledge related to the construction and operation of electrical
equipment and its installation, and has received safety training to recognize and
avoid the hazards involved.
SCOPE
This present document applies when AEx-8XXP(H) Series bears marking. They
are supplied only with DC 9~36 V. This documentation has to be kept and always
refer to those instructions for installation, operation, maintenance or evolution of
your system.
Permitted zones of application
Refer to the section titled "Markings" to get information about the permitted zones
of protection and the types of protection.
•AEx-8XXP(H) Series is installed in zones 2 hazardous areas must be certified and
bear the marking.
•Ensure with the marking that the terminals are compatible with the conditions
permitted for the hazardous area at the site where it is being used.
This is the safety alert symbol. It is used to alert you to potential personal injury
hazards. Obey all safety messages that follow this symbol to avoid possible injury
or death.

AEx-8XXP(H) Series User Manual
4
Notice
1. Under certain extreme circumstances, the label may generate an
ignition-capable level of electrostatic charge. Therefore the equipment shall not
be installed in a location where the external conditions are conducive to the
build-up of electrostatic charge on the label. In addition, the label shall only be
cleaned with a damp cloth.
2. Warning –in locations where high external humidity and internal temperature
variations (e.g. frequent on-off cycles) may cause condensation inside the
equipment, the interior should be periodically inspected.
3. When the device is mounted in a hazardous area, connection and
disconnection of external connectors while live is only permitted if the potentially
explosive atmosphere is shown to be absent.
4. The “9-36” Vdc rated supply shall be protected such that transients are limited
to a maximum of 119 V; no such protection is required for the signal lines.
5. Equipotential bonding facilities on the outside of enclosure are assessed as
providing effective connection of a conductor with a cross-sectional area of at least
4 mm2, 10AWG, 600V wire
6. The equipment is suitable for use in class I, division 2, groups A, B, C, D OR
non-hazardous locations only.
7. Warning- Do not use USB while the circuit is live unless the area is known to
be non-hazardous.
Markings
ATEX and markings, applied to the AEx-8XXP(H) Series Graphic Operator Interface,
are as follows:
AEx-8XXP(H) Series
WARNING: Do not disconnect while circuit is live. Potential
electrostatic charges. Wipe the front panel of the terminal with a
damp cloth before turning on.
II 3G Ex nA ic IIC T4 Gc and CID2 IP66
Temperature < 135°C
Power Input Voltage: DC 9~36V
TUV 15 ATEX 7701 X
IECEx TUR 16.0008X

AEx-8XXP(H) Series User Manual
5
Table of Contents
Revision History…………………………………………………………………………………………………….1
Warning!/Caution………………..……………...................................…………………………….…2
Packing List…………………………………….……………………………………………………………………..3
Safety Precautions…………………………………………………………………….…..……………………..4
Chapter 1 Getting Started
1.1 Features………………………..………………………...…………………………..7
1.2 Specifications…………………...………………………………………………….7
1.3 Dimensions………………………....…………………………………………..….9
1.4 Brief Description of AEx-8XXP(H)………………………….……….……11
1.5 VESA Mounting…………………………………………………………………12
1.6 Panel Mounting…………………………………………………………………12
Chapter 2 Hardware
2.1 Motherboard Introduction……………………...……………..………....13
2.2 Specifications…………………………..…………………………………………13
2.3 Jumpers and Connectors Location……………………………………...17
2.4 Jumpers Setting and Connectors…………………………………..……18
Chapter 3 BIOS Setup
3.1 Operations after POST Screen…...…….……...…………………………32
3.2 BIOS Setup Utility……………………………………………………………….32
3.3 Main Settings……………………………………..………………………………33
3.4 Advanced Settings……………………………………………………………...34
3.5 Chipset Settings……………………………………….………………………...42
3.6 Security Settings…………………………………………….…………………..44
3.7 Boot Settings…..………………………………………….……………………..45
3.8 Save & Exit Settings……………………………………..…………………....46
Chapter 4 Installation of Drivers
4.1 Intel (R) AtomTM SoC Chipset ………..……...………….………………49
4.2 Intel (R) VGA Chipset……………………………………………….……......52
4.3 Realtek ALC662 HD Audio Driver Installation…….……..………...56
4.4 Com Driver……………………………………………………..…………………58
4.5 Intel_TXE(Win) Driver……….……………………………………………….60

AEx-8XXP(H) Series User Manual
6
Chapter 5 Touch Screen Installation
5.1 Windows 8.1/10 Universal Driver Installation……..………………63
5.2 Software Function…………….…………………………………….……......67
Figures
Figure 1.1: Dimensions of AEx-815P(H)……..…………………..……………….....9
Figure 1.2: Dimensions of AEx-816P…………..…………………..……………….....9
Figure 1.3: Dimensions of AEx-819P(H)……..…………………..………………....10
Figure 1.4: Dimensions of AEx-821P…………..…………………..………………....10
Figure 1.5: Front View of AEx-8XXP(H).…………………………………….…….….11
Figure 1.6: Rear View of AEx-8XXP(H)……..…………………………………….….11
Figure 1.7: AEx-8XXP(H) Series VESA Mounting..…………………….…….….12
Figure 1.8: AEx-8XXP(H) Series Panel Mounting…………………………….….12
Figure 2.1: Motherboard Dimensions………………………………………….…….16
Figure 2.2: Jumpers and Connectors Location-Board Top……………….….17
Figure 2.3: Jumpers and Connectors Location-Board Bottom…………..…17

AEx-8XXP(H) Series User Manual
7
Chapter 1 Getting Started
1.1 Features
Intel® Celeron Processor N2930
Full flat bezel and fanless design
Full IP66 grade with M12 waterproof connector
DC 9~36V wide range power input
Projective capacitive touch
316 Stainless steel design
1.2 Specifications
AEx-815P(H)
AEx-816P
AEx-819P(H)
AEx-821P
System
CPU
Onboard Intel Celeron N2930 1.83GHz Processor
Chipset
SoC
Memory
Onboard 8GB DDR3L
IO Port
USB
1 x M12 for 2 x USB2.0 with metal waterproof CAP
Serial/Parallel
1 x M12 for COM1—RS-232(RS-422/485 for option) with metal waterproof CAP
LAN
2 x M12 for LAN with metal waterproof CAP
Power
1 x M16 for DC power input with metal waterproof CAP
VGA
1 x M12 for VGA with metal waterproof CAP
Optional IO Port (Must be a replacement for standard I/O)
USB
1 x M12 for 2 x USB2.0 (Cannot support 2 x M12 for 2 x USB2.0)
1 x M12 for 1 x USB3.0
Serial/Parallel
1 x M12 for 1x RS-232 (Cannot support 2 x M12 for 2x RS-232)
Storage Space
Storage
1 x 2.5” SATA HDD or SSD space
1 x Internal SD Card slot on board
1 x mSATA slot
Display
Display type
15”color TFT LCD
15.6”color TFT LCD
19”color TFT LCD
21.5”color TFT LCD
Max. Resolution
1024 x 768
1920 x 1080
1280 x 1024
1920 x 1080
Max. Color
16.2M
16.7M
16.7M
16.7M
Luminance (cd/m2)
450
1000
400
350
1000
300

AEx-8XXP(H) Series User Manual
8
Contrast Ratio
800: 1
700: 1
1000: 1
5000: 1
Viewing Angle
160(H) / 150(V)
160(H) / 140(V)
170(H) / 160(V)
178(H) / 178(V)
Backlight Lifetime
50,000 hrs
50,000 hrs
50,000 hrs
50,000 hrs
Power
Power Input
DC 9~36V
Power Consumption
MAX: 22.2W
MAX: 24.7W
MAX: 33.3W
MAX: 38.8W
Mechanical
Construction
316 Stainless Steel Chassis
Mounting
VESA Mount 100 x100 (default)
Panel Mount (option)
Dimension (mm)
399 x 324 x 70mm
440 x 290 x 75mm
470 x 388.6 x 75mm
571 x 362 x 75.1mm
Net Weight (Kg)
9.4
10.1
13
13.3
Environmental
Operating
temperature
-20~60°C
Storage temperature
-30~70°C
Altitude limit for
application
Under 2000m
Overvoltage
category
CAT II
Pollution degree
2
Storage humidity
10 to 90% @ 40°C, non- condensing
Certification
Meet CE / FCC Class A
Operating System Support
OS Support
Windows 7 Embedded Standard
Windows Embedded Standard 7
Windows Embedded 8.1 Pro
Windows Embedded 8.1 Industry Pro
Windows 10 IOT Enterprise LTSB 2016

AEx-8XXP(H) Series User Manual
9
1.3 Dimensions
Figure 1.1: Dimensions of AEx-815P(H)
Figure 1.2: Dimensions of AEx-816P

AEx-8XXP(H) Series User Manual
10
Figure 1.3: Dimensions of AEx-819P(H)
Figure 1.4: Dimensions of AEx-821P

AEx-8XXP(H) Series User Manual
11
1.4 Brief Description of AEx-8XXP(H) Series
AEx-8XXP(H) are panel PC series models for ATEX certification, which comes
with full waterproof with IP66 level designed. It is powered by Intel Celeron N2930
processor and supports 8GB DDR3L onboard memory. It comes with a 15”, 15.6”, 19”,
and 21.5”color TFT display. This model are designed by full waterproof connector
with 1x USB2.0 (support 2x USB2.0 function), 2x LAN, 1x COM and 1x VGA for
standard I/O port, but also can be replaced by USB2.0/3.0 or RS-232. The model
supports wide range DC 9~36V power input and can be panel mounted and VESA
mounted. AEx-8XXP(H) series has more outstanding features, thus you can use it in
some difficult environment and give the best in monitoring and control applications.
Figure 1.5: Front View of AEx-8XXP(H) Series
Figure 1.6: Rear View of AEx-8XXP(H) Series

AEx-8XXP(H) Series User Manual
12
1.5 VESA Mounting
The AEx-8XXP(H) series is designed to be VESA mounted as shown in Picture. Just
carefully place the unit through the hole and tighten the given screws from the rear
to secure the mounting.
Figure 1.7: AEx-8XXP(H) Series VESA Mounting
1.6 Panel Mounting
There are six holes located along the four sides of the panel PC. Insert the clamp
from the four sides and tighten them with the nuts provided.
Figure 1.8: AEx-8XXP(H) Series Panel Mounting

AEx-8XXP(H) Series User Manual
13
Chapter 2 Hardware
2.1 Motherboard Introduction
SBC-7111 is a 4" industrial motherboard developed on the basis of Intel Bay trail-I/M
Processors, which provides abundant peripheral interfaces to meet the needs of
different customers. Also, it features dual GbE ports, 4-COM ports and one Mini PCIE
configuration, one VGA port, one HDMI port, one LVDS interface. To satisfy the
special needs of high-end customers, CN1 and CN2 and CN3 richer extension
functions. The product is widely used in various sectors of industrial control.
2.2 Specifications
Specifications
Board Size
170mm x 113mm
CPU Support
Intel Atom E3845 / 1.91GHz (4cores, 10W, onboard)
Intel Celeron N2930 / 1.83 up to 2.16GHz (4cores, option)
Chipset
SoC
Memory Support
Onboard 2GB DDR3L SDRAM (N2930, option)
Onboard 4GB DDR3L SDRAM (E3845/N2930, option)
Onboard 8GB DDR3L SDRAM (N2930, option)
Graphics
Intel® HD Graphics 313/854MHz (N2930)
Intel® HD Graphics 542/792MHz (E3845)
Display Mode
1 x HDMI Port
1 x LVDS (18/24-bit dual LVDS)
1 x CRT Port
Support
Resolution
Up to 1920 x 1200 for HDMI
Up to 1920 x 1200 for LVDS (PS8625)
Up to 1920 x 1200 for CRT
Dual Display
HDMI + LVDS
HDMI + CRT
LVDS + CRT
Super I/O
ITE IT8518E
Fintek F81216AD

AEx-8XXP(H) Series User Manual
14
BIOS
AMI/UEFI
Storage
1 x SATAII Connector (7Pin, option)
1 x SATAII Connector (7Pin + 15Pin)
1 x SD Slot (USB2 to SD)
Ethernet
2 x PCIe Gbe LAN by Intel 82574L
USB
USB 3.0 Hub(USB5534):
2 x USB 3.0/USB 2.0 (type A)stack ports (E2_USB5/E2_USB6)
1 x USB 2.0 for Touch controller (E2_USB7)
1 x USB 2.0 Pin header for CN1 (E2_USB8)
USB 2.0 Hub(USB2514)
1 x USB 2.0 Pin header for CN2 (E-USB9)
2 x USB 2.0 Pin header for CN3 (E-USB10/E-USB11)
1 x USB 2.0 for MPCIE1 (E-USB12)
Serial
1 x RS232/RS422/RS485 port, DB9 connector for external (COM1) Pin 9
w/5V/12V/Ring select
1 x RS232 port, DB9 connector for external (COM2) Pin 9
w/5V/12V/Ring select
2 x UART for CN3 (COM3,COM4)
2 x RS422/485 header for CN2 (IT8518E/COM5/COM6)
Digital I/O
8-bit digital I/O by Pin header (CN2)
4-bit digital Input
4-bit digital Output
4-bit digital I/O by Pin header (CN3)
2-bit digital Input
2-bit digital Output
Battery
Support CR2477 Li battery by 2-pin header (BAT1/CMOS)
Audio
Support Audio via Realtek ALC662-VD HD audio codec
Support Line-in, Line-out, MIC by 2x6-pin header
Keyboard /Mouse
1 x PS2 keyboard/mouse by box pin header (CN3)
Expansion Bus
1 x mini-PCI-express slot
1 x PCI-express (CN3)
Touch Ctrl
1 x Touch ctrl header for TCH1 (PM6000 for USB4 or COM6)
Power Management
Wide Range DC6V~36V input
1 x 3-pin power input connector (DC_IN1/DC6~36V)

AEx-8XXP(H) Series User Manual
15
1 x 4-pin power input connector (DC_IN2/DC12V)
Switches and LED
Indicators
1 x Power on/off switch (BT1/BT2/P_SW/CN2/Cn3)
1 x Reset (CN2)
1 x Power LED status (CN1)
1 x HDD LED status (CN2)
1 x Buzzer
External I/O port
2 x COM Ports (COM1/COM2)
2 x USB 3.0/2.0 Ports (stack)
2 x RJ45 GbE LAN Ports
1 x HDMI Port
1 x Stack audio Jack (Line out)
1 x Power on/off switch (BT1)
Temperature
Operating: -20°C to 70°C
Storage: -40°C to 85°C
Humidity
10% - 90%, non-condensing, operating
Power Consumption
12V /0.80A (Intel Atom E3845 processor with 4GB DDR3L DRAM)
12V /0.60A (Intel Atom E3815 processor with 2GB DDR3L DRAM)
12V /0.70A (Intel Celeron N2930 processor with 4GB DDR3L DRAM)
EMI/EMS
Meet CE/FCC class A

AEx-8XXP(H) Series User Manual
16
(units :mm)
Figure 2.1: Motherboard Dimensions

AEx-8XXP(H) Series User Manual
17
2.3 Jumpers and Connectors Location
Figure 2.2: Jumpers and Connectors Location- Board Top
Figure 2.3: Jumpers and Connectors Location- Board Bottom

AEx-8XXP(H) Series User Manual
18
2.4 Jumpers Setting and Connectors
1. U2:
(FCBGA1170), onboard Intel Bay trail-I/M Processors.
Model
Processor
Number
PBF
Cores/Threads
TDP
Remarks
SBC-7111-N2930-4G
N2930
1.83 up to
2.16GHz
4 / 4
4.5/7.5W
SBC-7111-N2930-4G-SW
SBC-7111-N2930P-4G
SBC-7111-N2930-2G
SBC-7111-N2930P-CN3V-2G
SBC-7111-N2930-8G
SBC-7111-E3845-4G
E3845
1.91GHz
4 / 4
10W
option
2. H3/H4/H5/H6 (option):
U2 Heat Sink Screw holes, four screw holes for Intel Bay trail-I/M Processors
Heat Sink assemble.
3. U3/U4/U5/U6:
(FBGA96), Onboard DDR3L Memory.
Model
Memory
SBC-7111-N2930-4G
4GB
SBC-7111-N2930-4G-SW
4GB (option)
SBC-7111-N2930P-4G
4GB (option)
SBC-7111-E3845-4G
4GB (option)
SBC-7111-N2930-2G
2GB (option)
SBC-7111-N2930P-CN3V-2G
2GB (option)
SBC-7111-N2930-8G
8GB (option)
4. S-422 (PIN6):
(Switch), ATX Power and Auto Power on jumper setting.
S-422(Switch)
Mode
Pin6 (Off)
Manual Power on
Pin6 (On)
Auto Power on (Default)
5. BAT1:
(1.25mm Pitch 1x2 Wafer Pin Header) 3.0V Li battery is embedded to provide
power for CMOS.

AEx-8XXP(H) Series User Manual
19
Pin#
Signal Name
1
VBAT
2
Ground
6. DC_IN1:
(5.08mm Pitch 1x3 Pin Connector), DC9~36V System power input connector.
Pin#
Power Input
1
DC+6V~36V
2
Ground
3
FG
Model
DC_IN1
SBC-7111-N2930-4G
180°Connector
SBC-7111-N2930-4G-SW
180°Connector
SBC-7111-N2930-2G
180°Connector
SBC-7111-N2930-8G
180°Connector
SBC-7111-E3845-4G
180°Connector
SBC-7111-N2930P-4G
45°Connector
SBC-7111-N2930P-CN3V-2G
45°Connector
7. DC_IN2 (option):
(2.0mm Pitch 1x4 wafer Pin Header) DC12V System power input connector.
Pin#
Signal Name
1
VCC_BAT (DC+12V input)
2
VCC_BAT (DC+12V input)
3
Ground
4
Ground
8. BT1/BT2/P_SW (option):
Power on/off button, They are used to connect power switch button. The two
pins are disconnected under normal condition. You may short them temporarily
to realize system startup & shutdown or awaken the system from sleep state.
Model
BT1
BT2
P_SW1
SBC-7111-N2930-4G
●
●
○
SBC-7111-N2930P-4G
●
●
○
SBC-7111-N2930-2G
●
●
○
SBC-7111-N2930-8G
●
●
○
