Aqara A100 User manual
Smart Door Lock A100 User Manual
*使用产品前请仔细阅读本说明书，并妥善保管
服务热线：400-990-7930（工作日 10:00~18:00）
服务网址：www.aqara.com/support
服务邮箱：[email protected]
服务公众号：微信搜索“Aqara Home全屋智能”
制 造 商：深圳绿米联创科技有限公司
地 址：深圳市南山区桃源街道福光社区留仙大道3370号南山智园崇文园区
1号楼801-804
本产品相关信息查询网站：www.aqara.com
*A hub is required for automations and other functions.
Product Overview
Aqara Smart Door Lock A100 can be unlocked with fingerprint, password,
temporary password, NFC card, APP control, Apple Home Key, and (emergency)
mechnical key.
It supports functions such as low-battery reminder, lock pry warning, repeated
verfication failure warning, door unclosed/unlatched warning, and etc.
Working with Aqara family of devices, the Smart Door Lock A100 becomes an
integral piece in various smart user scenarios, providing improved safety and
enhanced smart home experience.
Note: Emergency power supply is available in case that the door lock failed to be unlocked due to
battery running out.
Password input area
Back button
Fingerprint
identification area
Unlocked warning
indicator light
Keyhole cover
Interactive indicator light
White: Authenticated
Red: Failed
NFC identification area
Enter button
Front handle
Low battery
indicator light
Flashing: Low battery
Speaker Emergency
power supply port
Away mode
Press the
bottom
of the cover
Remove the
cover aer
it pops up
Press and unlock: Pull down the
handle to unlock aer successful
verification.
Li and lock: Li up the handle
(required for safety)
Back handle
Battery compartment
8 AA dry batteries
Press and unlock: Pull down
the handle to unlock the door
Li and lock: Li up the handle
to lock the door
Setting button
Short press to enter
the Setting mode
Note: Please add the door lock
and users to your Aqara Home
app first in Settings.
Reset button
Long press for 5 seconds to reset
the lock: Reset will clear all users
saved.
Open the battery
cover from here.
Rotate 90° clockwise or
counterclockwise
"Night latch"knob
Scan the code to check the electronic instruction and more.
Lock Installation
Please hire professionals to install the lock as the dangerous professional
tools should be used in the process of installation.
Preparation for Use
Please open the battery cover and install 8 AA dry batteries.
Note: It is recommended to use original batteries as others may leak and thus cause
damage to the product when used for a long time.
[Warning] Please replace the battery timely when it is low, otherwise the power
running out will lead to the failure to open the door by authentication. In this case,
you can use the Type-C emergency power supply or the mechanical key to unlock.
Note: The user information will be cleared aer resetting thus the door will be unable to be
locked. Please finish the door lock setting according to this instruction as soon as possible.
Press and hold the "Reset" button for 5 seconds, release it aer hearing the
voice prompt, and so the resetting is finished.
Aqara Home app supports all the exciting functions of A100, and connects it to
Aqara family of smart devices. You can download "Aqara Home" from Apple App
Store, Google Play, Xiaomi GetApps, and etc. OR scan the QR code below.
Open the app, tap "+" in the upper right corner of the "Add Accessories" page.
Choose "Smart Door Lock A100" and then follow instructions to add the device.
Quick Setup
Add the device to the Aqara Home app
Note: The effective communication range of Bluetooth is 10 meters, but it may be affected by
obstacles such as walls.
Due to the upgrade and update of Aqara Home, practical operations may differ
from the above description. Please operate following the instructions of the Aqara
Home app.
Note: The door lock cannot be locked normally without users added.
Enter the device page and follow the instructions of the app to add the first user
who is the owner by default.
Add users
There are two ways to add A100 to HomeKit:
1. Open Apple's Home app, click "+" in upper right corner, select "Add Accessory"
2. In the smart lock page in Aqara Home app, go to "General Settings", click "Bind
with HomeKit", scan/input HomeKit setting code according to prompt (you can find
your lock's HomeKit code aer opening the battery compartment cover)
HomeKit supports functions such as lock/unlock, automation setups, and door
unclosed/unlatched warnings.
Add Apple Home Key (for iOS users)
Aer your lock has connected with HomeKit, you can find an automatically
generated key in your Apple Wallet app. iPhone/Watch can be used as devices to
activate Apple Home Key by putting them into range of A100.
User Instructions:
1. This device works with HomeKit technology. Controlling this HomeKit-enabled
accessory away from home or for automation would require an Apple Home hub,
which is an Apple TV (generation 4 with tvOS 12.0+), an iPad (with iOS 12.0+) or a
HomePod. An Apple user device, iPod/iPhone/iPad with iOS 12.0+ is also required.
2. In order to use Apple Home Key, your need an iPhone with iOS 15.0+ OR a Watch
with watchOS 8.0+.
3. Use of the "Works with Apple HomeKit" badge means that an accessory has been
designed to work specifically with the technology identified in the badge and has
been certified by the developer to meet Apple performance standards. Apple is not
responsible for the operation of this device or its compliance with safety and
regulatory standards.
Add the device to HomeKit (for iOS users)
Attach the finger to the fingerprint
identification area.
Aer passing the authentication,
pull down the handle to open the door.
How to Use
Successful authentication: Interactive indicator flashes in white with the
authentication sound prompt in case of no silent mode enabled.
Authentication failed: Interactive indicator flashes in red with failed sound prompt
in case of no silent mode enabled.
Unlock by Fingerprint
Enter the password and press the
Enter button.
Aer passing the authentication,
pull down the handle to open the door.
Unlock by Password
Press down to open the cover plate of
the emergency keyhole.
Insert the key and turn it to unlock.
Note: Do not put the emergency key in the house,
but keep it in a safe and accessible place for the
use in case of emergency.
Hold the added card to the recognition
area.
Aer passing the authentication,
pull down the handle to open the door.
Note: For maximum security, please ensure to li
up the handle to lock when you are in or out.
Note: When double locked is engaged, A100 cannot be unlocked by regular users' permissions
(fingerprints/passwords/NFC cards) and mechanical key.However, it can be unlocked by admin
users' permissions, app controls, and Apple Home Key.
When you pull down handle from inside, the door also unlocks.
For more use instructions and product information, please scan the QR code in
the Chapter "Door Lock Installation", or operate as guided by the app.
Indoor: Li up the handle aer closing
the door.
Outdoor: Li up the handle aer closing
the door.
Unlock by Emergency Key
Unlock by NFC Card
Li and Lock from Indoor/Outdoor
Double Lock from Inside Using the "Night Latch"
Engage Double Lock: Turn the knob 90°
clockwise or counterclockwise to the
horizontal direction to enable the double
lock.
Release Double Lock: Turn the knob 90°
clockwise or counterclockwise to the
vertical direction to disable the double lock.
Local Settings Mode
In case of any inconvenience to use Aqara Home app, briefly press the "Setting"
button under the battery cover of the door lock, verify admin's fingerprint/password
to set up the following:
Note: Prior to entering the local setting mode, please finish the operation of adding the door
lock and users through Aqara Home app.
1. Add/remove normal users
2. Set the door lock volume
3. Reset and bind to HomeKit
Specifications
Name: Smart Door Lock A100
Dimensions: 375×77×23.6 mm
Operating Temperature: -25~55
Operating Humidity: 0~93% RH, no condensation.
Model: ZNMS02ES
Net Weight: 3.6 kg
Power Supply: 8 AA dry batteries (6V ),
Type-C Emergency Power Supply (5V )
Wireless Protocol: Bluetooth 5.0, Zigbee, NFC
*The Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Lumi United Technology Co., Ltd.
is under license. Other trademarks and trade names are those of their respective owners.
Online Customer Service: www.aqara.com/support
E-mail: support@aqara.com
Manufacturer: Lumi United Technology Co., Ltd.
Address: Room 801-804, Building 1, Chongwen Park, Nanshan iPark, No. 3370,
Liuxian Avenue, Fuguang Community, Taoyuan Residential District, Nanshan
District, Shenzhen, China
See www.aqara.com for more information of the product.
* Please read this manual carefully before using the product and keep it properly.
