AquaMAX Promax 30 Supaflush User manual

User Manual & Instructions
SUPAFLUSH

DIAGRAMMATIC PARTS LIST

1 Metal chassis
2 Spacers
3 Dump-T-tube with 3/4” swivels
4 Right connecting tube with swivels
5 Left connecting tube with swivels
6 3 ways valve
7 3 ways valve
8 Rubber gasket ø 24 (o-ring ø 24)
9 Brass 3/4” niples with o-ring
10 Protecting metal plate
11 Screws for protecting metal
plate
12 Fixing nut for dump-T-tube
13 3/4” PP niples with o-ring
14 3/4” 3 ways valve
15 Elbow fitting with o-ring
DIAGRAMMATIC PARTS LIST
1 Metal chassis
2 Spacers
3 Dump-T-tube with 3/4” swivels
4 Right connecting tube with swivels
5 Left connecting tube with swivels
6 3 ways valve
7 3 ways valve
8 Rubber gasket ø 24 (o-ring ø 24)
9 Brass 3/4” niples with o-ring
10 Protecting metal plate
11 Screws for protecting metal
plate
12 Fixing nut for dump-T-tube
13 3/4” PP niples with o-ring
14 3/4” 3 ways valve
15 Elbow fitting with o-ring
CONTENTS
1 Supaush pump
1 Carry bag with shoulder strap
2 3m of 3/4” reinforced hose with swivel couplings
1 special funnel to assist lling tank
1 bag seletion of various ttings to facilitate connection to heating systems
SPECIFICATION
Dimensions: 65 cms x 56 cms x 37cms
Weight: 13 kilos
Capacity: 27 litres
Flow rate: 5,400 ltrs/hr max
Power consumption: 0,45 HP
Max working head: 2 bar
Incorporated multifunction isolation/dump valves protective plate.
The SUPAFLUSH pump may be used with any proprietory brand
of descaling and ushing chemicals on the market and is able to operate easily to a
maximum head of 2 bar and efciently clean up to 20 radiators.
Working uid temperature up to 50°C-55°C.

PREPARATION
Initially start the heating system to ascertain the problem ares. Once estabilished
switch the heatig system off.
Open all restrictive radiator & zone valves.
Turn off the cold feed to the expansion tank and drain the tank sufienty to loop
together the feed & expansion pipes incorporating a gate valve. This loop will ensure
total circulation when the SUPAFLUSH pump is applied.
Draining the expansion tank can be undertaken either by conventional means or
connecting the ushing pump into the system & draining the expansion tank until the
pump tank is approx 1/3-3/4 full which should be sufcient to drain the tank and allow
the loop to be tted.
NB - The pump motor must not be operating during this process.
POSITION
Generally the SUPAFLUSH pump should be situated in an area with access to a cold
feed supply & drain facility. A kitchen or utilty room usually being ideal.
SUPAMEG COMPACT FILTER
If your SUPAFLUSH pump comes complete with the
lter, then proceed as follows.
The lter should always be tted via the swivel
coupling to the “return” side of the pump, thus
ensuring the water is cleaned after initially passing
through the heating system.
Prior to ushing, ensure that joints are tight & the
drain valve with the hose tail is turned off. The
removable magnet should also be pushed in its
correct top position as indicated.
As ushing proceeds the magnet inserted through
the top. Down the central core will attract the iron
oxide particles as they pass & gradually the lter
will become choked.
To empty the lter simply stop the ushing pump &
close the circulating valve on the down side of the
lter according to ow.
Remove the magnet by extracting from the top
of the lter body, which then loosens the metal
particles from the internal coil. Next either place a
receptical under the drain tap or t a hose and drain
to a convenient location.
Open the drain valve & start the pump ensuring that
the ow is in accordance with the closed circulating
valve on the pump.

All debris will now be ushed through the lter cleaning the coil and draining off via
the drain valve.
When all the debris is removed then reverse the cleaning procedure, ensuring that
the dump valve is closed and the magnet reinserted into its position.
Ensure that all dirty water dumped in the procedure is replaced with clean.
ASSEMBLY
Using the female swivel ttings, screw the two lengths of hose provided to the “ow”
and “return” 3/4” mi threads as clearly indicated in the centre at the base of the
protection plate, tted to the rear of the SUPAFLUSH pump.
Supply three own hoses, and with the protection plate facing towards you connect as
follows:-
1. Clean cold water supply to the water inlet tap situated on the tank top, as indicated
on the bottom left of the protection plate.
2. Connect to 3/4” mi joint valve dump outlet situated on the top of the protection
plate, and route direct to drain.
3. Connect to the ushing tank overow situated on the L/H side of the tank as
indicated on the protection plate and route directly to the drain.
ALL FITMENT POSITIONS ARE CLEARLY INDICATED ON THE PROTECTION PLATE
The pump is supplied with various adaptors to facilitate system connection at the
point most suitable for each individual system ie radiators or boiler.
water inlet tap
overow

THE INITIAL FLUSH AND OPERATION
NOTE: - If the pump was used to drain the expansion tank/system, rst remove the
dirty water prior to replenishing the tank approx 1/3rd with cold clean water via the
inlet tap as previously mentioned.
With the system drained and the tank approx 1/3 rd full off clean water the system is
now ready for the initial ush. Ensure the pump isolation valves tted on the protection
plate are pointed in the “recirculate” position.
After checking that any obstructing valves are fully open on the whole system,
including the newly installed gate valve on the F&E loop, start the pump for approx
10-15 mins in a forward direction. After this period reverse the ow again for 10-15
mins. Repeat this procedure several times whilst constantly monitoring the condition
of the water, & maintain the water is clear.
WATER FLOW ALTERNATION
This is achivied by alternating the lever on the ow diverter valve to a forward or
reverse position. The lever when in the correct position ”points” to the ow direction
required.
The ow diverter valve is situated on the top of the tank at the front, directly over the
lling neck. As the water becomes dirty then dump and replace for “dumping” see
dump valve section.
Any commercial brand of descaler or ushing agent may now be introduced and
mixed and operated according to the manufacturers instruction.
NOTES
1. If an acid based descaler is used then the system including the pump must be
neutralised with the suggested neutralising agent prior to the nal ush through with
cold water.
2. At all times the tank lling cap must be left off in order to allow the exhaust of acidic
vapour created by cleaning process.
3. Maintain vigilance on the amount of foam produced. Do not overll the tank by
exceeding the maximum level.
All radiators should be individually ushed. This is achivied by closing all radiators
except the one being worked on. Radiators should be initially ushed individually with
clean water.
Alternating the ow direction as previously described and prior to repeating the
process with the appropriate chemical additive.

DUMP VALVES
Both ow and return pipes are tted with single - 3 position valves.
IE:- Dump - Closed - Recirculate
Each position for each valve lever is clearly indicated on the protection plate:
DUMP VERTICAL UPWARD
CLOSED HORIZONTAL
RECIRCULATE VERTICAL DOWNWARD
This system allows dirty water to be expelled when owing in either direction.
As previously mentioned, the ow reverse lever, when in position, “points” from
bottom to top indicating the direction of ow. To dump the water, rst establish the
ow direction by checking the position on the lever. Having established this, then
adjust the three position valve situated at the farthest point of ow from “recirculate” to
“dump”. The pump will now start to dump the dirty water. Having completed the dump
then return the valve from ”dump” to its original “recirculate” position then replace the
expelled water with clean. This procedure must be repeated alternating the valves as
the ow direction is altered.
Notes:
1. To circulate both valves in the “recirculate”position
2. To dump - the valve farthest from the point of ow is adjusted to the “dump” position.
After completion of the cleaning process re-open all valves and thoroughly ush the
system through, dumping any remaining dirty water and replacing with clean until it
is clear.
When the water remains clear then follow the manufacturers instructions for the
introduction of inhibitor. On completion, test, vent, and replace all valves to original
position.
COMBINATION BOILERS
Because of the restriction of space it is recommended that the ow and return hoses
from the SUPAFLUSH pump are connected by the radiators or by the boiler when
being replaced.
WARRANTY
In order to maintain continued ushing pump efciency and reliabitily it is of paramount
importance that all equipement is thoroughly washed with clean water.
12 Months parts and labour subject to fair wear and tear and no misuse.
Then manufacturer and distributor reserve the right, that in the event of a fault claim
they will repair or replace accordingly at their discretion.
NOTE: - These notes are for guidance only and in no way will any claims for any
damages be entered into in any way whatsoever caused.

SUPAFLUSH PUMP
Via Barca, sn - 60025 Loreto (An) Italy
Tel. [phone] Fax [phone]
www.aquamax.it - [email protected]
