AQUAPHOR RO-206S User manual

RO-206S
REVERSE OSMOSIS SYSTEM
Operation manual

2
1. Introduction
RO-206S Reverse Osmosis System (hereinafter referred
to as RO-206S) is manufactured by Westaqua-Invest
OÜ (Estonia).
RO-206S is intended to purge of mechanical and
colloidal particles, organic impurities and to remove
foreign flavour, odour and colour when post-treating cold
drinking water supplied via municipal and local water
supply networks (water from artesian boreholes, wells,
etc.) to meet the requirements, specified in this Manual.
RO-206S works on the principle of transferring water
molecules through a semipermeable membrane by
applying overbalanced osmotic pressure. This pressure
increases with increasing water salinity, so the higher
the water salinity, the greater water supply pressure is
required to keep RO-206S operating.
RO-206S is made of safe, non-toxic materials ensuring
that no substances hazardous to both human health and
the environment are released into the water. RO-206S
meets EC hygiene requirements.
Fig. 1
K2K2
K1K1
12
4
5
3
678
910 11 12
MembraneMembrane
cartridgecartridge
MembraneMembrane
cartridgecartridge
Pressure
Dirty water
Membrane
Treated water
2. Specification Data
Overall dimensions (length × height × width): 411 × 486 × 195 mm
Water supply pressure, min 90 kPa
Water supply pressure, max 0.63 MPa
Filtered water temperature + 5 to + 38 °С
Reverse osmosis membrane maximum efficiency rate
(at +25 °C and 0.4 MPa)
47.2 l/h
(for 2 membrane cartridges)
Treated/drained water ratio (at a water temperature not lower than 20 °C) 1:2–1:4
Weight, not more than 12 kg

3
3. Scope of Delivery (Fig. 1):
№Name Quantity
1RO-206S housing assembly (1) 1 pc.
2
Cartridges:
2.1
Pre-treatment unit:
2.1.1 K1 replaceable filter cartridge (3) 1 pc.
2.1.2 К2 replaceable filter cartridge (2) 1 pc.
2.2
Reverse-osmosis membrane unit:
2.2.1 Replaceable membrane cartridge (3, 4) 2 pcs.
3
Connecting pipes (6)
3.1 1/4” JG tube (d 6.35 mm, L=1.3 m, red) 1 pc.
3.2 1/4” JG tube (d 6.35 mm, L = 1.2 m, black) 1 pc.
3.3 1/4” JG tube (d 6.35 mm, L = 1.0 m, blue) with an inserted metal bushing 1 pc.
4Connecting assembly (7) 1 set
5Drain clamp (8) 1 set
6Service plug (9) 1 pc.
7Wrench (10) 1 pc.
8Power supply unit (11) 1 pc.
9Tap for treated water (12) 1 set
10 Operation manual 1 pc.
Key specifications of the Power supply unit:
input voltage 100-240 V AC
built-in input plug CEE 7/16
output voltage 24 V DC
output current 5 А
coaxial output connector Ø 2,5 × Ø 5,5 mm
power lead length, not less than 1.0 m

4
Main units of RO-206S:
1 – RO-206S housing assembly;
2 – Pre-treatment unit K1;
3 – Pre-treatment unit K2;
4 – Reverse-osmosis membrane unit.
1. The RO-206S housing (1) consists of a top
plate, a cover, a stand, a storage tank and a
front panel. Four collectors (fot the removable
filter cartridges) and a hydraulic unit are fixed
in the top plate. The top plate is covered with a
decorative cover, equipped with a handle fixing
the cover in its central part. A pump is installed on
the lower part of the housing (stand) to increase
the water pressure in RO-206S.
RO-206S is equipped with a storage tank for
treated water to provide the desired water
quantity at any time.
At the front, the RO-206S housing is covered
with a decorative panel where an electronics
unit and control elements are located.
2. K1 and K2 replaceable filter cartridges are part of
the water pre-treatment unit (2, 3). The water pre-
treatment unit is designed to remove impurities from
the water such as iron hydroxide and active chlorine
that can damage the reverse osmosis membrane.
3. The reverse osmosis membrane unit (4) includes
two replaceable membrane cartridges. The reverse
osmosis membrane unit removes organic, inorganic
compounds and salts from water as well as softens it.
1
4
3
2
4. Design and Functions of RO-206S
Fig. 2
ATTENTION! The RO-206S performance depends on the pressure in the water supply sys-
tem. No proper operation of RO-206S is guaranteed at pressures below 90 kPa in the water
supply system.

5
ATTENTION! It is not recommended to independently connect RO-206S units to the water supply
network. Only authorized specialists should install RO-206S units.
Find a convenient location for your RO-206S and
the treated water tap. Attention should be paid
to prevent the supply tubes from bending and
twisting (Fig. 3).
Your RO-206S must be installed far from or insu-
lated from heat sources (stoves, boilers, hot water
pipes, dishwashers, washing machines, etc.).
Fig. 3
Cold water supply
RO-206S housing
Drain clamp
Kitchen faucet
1/4” treated water
tube (blue)
Tap for treated water
1/4” inlet tube (red be paid)
1/4” drain tube (black)
Sink drain
Water supply connecting
assembly
Bend trap
5. RO-206S Installation

6
Installation of the connecting assembly*
* The manufacturer reserves the right to use connecting assemblies and taps of a similar design. If you have any questions,
please, contact the service department.
• Turn water off at the mainline.
• Open the kitchen faucet to relieve pressure in
the water supply system.
• Unscrew the clamping nut from the flexible
hose in the cold water supply line to the faucet.
ATTENTION! The flexible hose may contain a
little water after depressurizing. When discon-
necting the flexible hose, use a 200 ml vessel
to drain the residual water.
• Screw the clamping nut of the connecting
assembly onto the thread of the cold water
supply.
• Screw the clamping nut of the flexible hose
onto the thread of the connecting assembly.
• Close the inlet cock of the connecting assembly
and supply water from the cold water supply
line to make sure that the connection is tight.
• Connect the corresponding JG tube.
Fig. 5b
Fig. 4
Fig. 5a
The inlet cock
is in its closed position
Retaining clip
Connecting assembly
Gasket
Cold water supply
How to connect the JG tubes (Fig. 5a)
Pull the retaining clip out from under the plastic
sleeve, insert the pre-moistened end of the tube
into the plastic sleeve until it stops about 15 mm
deep and install the clip.
How to disconnect the JG tubes (Fig. 5b)
Pull the retaining clip out from under the plastic
sleeve and pull the tube out by pressing on the
end of the plastic sleeve.
Check that the tube is tight. The tube should not be pulled out using a force of 80-100 N.
ATTENTION! The end of the pipeline must be flat at the point, where the connecting assembly
is connected. Do not use excessive force when tightening the clamping nut.
Otherwise, it will damage the gasket.

7
Installation of the drain clamp* (Fig. 7)
* The manufacturer reserves the right to use connecting assemblies and taps of a similar design. If you have any questions,
please, contact the service department.
Fig. 7a
Installation of the treated water tap (Fig. 6)
Fig. 7b
Fig. 6
321
• It is recommended to install the clamp on the
sink drain upstream of the S-trap (the drain
clamp fits most drain pipes which are about
40 mm in diameter).
• Attach the part of the clamp with the fitting to
the pipe and find the optimal position of the
clamp and a hole for the tube.
• Drill a 7 mm hole in the pipe wall in the intended
place.
• Remove the cut round part from the gasket (1).
• Remove the protective film (2) from the gasket
(1). Attach the gasket (1) on the inside of the
clamp so that the hole in the gasket aligns with
the hole in the clamp fitting.
• Install the clamp on the pipe, aligning the hole
in the fitting with the drilled hole in the pipe,
and then tighten the bolts (3). The bolts should
be tightened evenly so that the two parts of
the clamp are parallel.
• Put the plastic nut on the JG drain tube so that
the tube extends from the other side of the nut
by at least 20 mm (Fig. 7b).
• Insert the tube into the drain clamp and screw
the nut onto the fitting.
Note. Push the JG tube deeper into the pipe if
you are disturbed by the sound of water coming
from the drain clamp.
• Drill a 12 mm hole in the sink (benchtop).
• Place the rubber gasket (2), the decorative plate
(3), the rubber gasket (4) on the threaded shank
of the tap (1) and insert the tap into the sink hole.
• Put the plastic (5) and the metal (6) lock washers
on the threaded shank from the bottom of the
benchtop and screw the fixing nut (7) until tight
(you can use a 14 mm pipe wrench).
• Insert the metal sleeve (8) into the blue tube (10),
and the tube into the threaded shank of the tap
(1) and tighten the clamping nut (9) until tight.
• Check that the tube (10) is tight. The tube should
not be pulled out using a force of 80-100 N.
ATTENTION! It is recommended to use the stand-
ard RO-206S tap for treated water. Using other
taps may result in humming and other unusual
sounds.
2
1
3
89
10
7
5
6
4

8
6. Launching RO-206S
Step 1. Connecting inlet tubes
• Connect the inlet tubes according to the dia-
gram shown in Fig. 9.
Step 2. Preparing your RO-206S for use
• Remove the overwrapping film from the
cartridges.
• Remove transport plugs (if any) from the
cartridges.
• Rinse the O-rings of the cartridge under a wa-
ter stream.
• The cartridges are inserted into the corres-
ponding collectors until they stop and turn
clockwise, as shown in Fig. 10a, until hear a
click.
• To remove a cartridge, press the lock button
as far as it will go and hold it while turning
the cartridge counter clockwise, as shown in
Fig. 10b, and remove it.
• Install the cartridges as shown in Fig. 11.
• Insert the plug of the power supply into the
outlet, and the plug from the power supply
into the socket in your RO-206S unit (Fig. 12).
Step 3. Flushing the pre-treatment unit
• Open the treated water tap.
• Turn the inlet cock of the connecting assembly
to its open position. The cartridge life indicator
lights blink (the light signal is followed by an
audible signal).
• On the front panel of your RO-206S (Fig. 13),
flash the PUSH button 3 times to start the
flushing mode. At this, 5 audible signals are
sounded, the cartridge life indicator lights go
out and the flushing mode of the pre-treatment
unit starts and lasts 30 minutes.
• First, air comes out of the system with some
noise.
• Make sure the RO-206S connections are tight.
ATTENTION! If leaks are found, immediately turn
the inlet cock of the connecting assembly to its
closed position and check the connections. Turn
the inlet cock of the connecting assembly to its
open position again to continue the flushing
procedure after the leak is repaired.
• After the flushing procedure is complete, your
RO-206S beeps 5 times and switches into the
operating mode automatically.
• Turn the inlet cock of the connecting assembly
to its closed position and wait when the
cartridge life light and sound indication turns off. Fig.11
Service plug (supplied)
K1
K2
Fig. 9
To the treated
water tap
To the drain
clamp
Fig. 10a Fig. 10b
From the
connecting
assembly

9
Step 4. Flushing the reverse osmosis
membrane unit
• Remove the service plug from the slot of the
reverse osmosis membrane unit and replace it
with the membrane cartridge as shown in Fig. 14.
• Turn the inlet cock of the connecting assembly
to its open position. The cartridge life indicator
lights blink (the light signal is followed by an
audible signal).
• Make sure the RO-206S connections are tight.
Attention! If leaks are found, immediately turn
the inlet cock of the connecting assembly to its
closed position and check the connections. Turn
the inlet cock of the connecting assembly to its
open position again to continue the flushing
procedure after the leak is repaired.
• Wait for the water to flow from the tap for treated
water.
• Let the water through your RO-206S for 1 hour.*
• Close the treated water tap.
• Fill and empty the storage tank 2 more times.
• Press and hold the PUSH button for at least
7 seconds. The cartridge life light indication
changes from the flashing mode to the constant
one, and the audio signal stops.
• Make sure the RO-206S connections are tight.
• Your RO-206S is ready for use once the tank
is filled.
ATTENTION! The water is not intended for drink-
ing after flushing.
Periodically check your RO-206S for leaks during
the first week of use. Some noise may occur
during the first week of operation of your RO-
206S when switching the valve because of air
released from the internal cavities of the system.
This is not a malfunction.
7. Replacing Cartridges
Your RO-206S is equipped with a light and sound
indication of cartridge life.
The RO-206S light and sound indication is
configured to work with cold drinking water
from municipal water supply systems that meet
sanitary standards.
Each of the filtration units has an individual light
indication (Fig. 15): indicators 1 and 4 correspond
to cartridges K1 and K2 of the water pre-treatment
Fig. 12
DC IN
Fig. 13
* The whole flushing procedure of the membrane cartridge takes no more than 24 hours and depends on its storage and trans-
portation conditions.
unit, indicators 2 and 3 correspond to the reverse
osmosis membrane unit.
The flashing indicators of the filtration units,
followed by a periodic sound signal, inform about the
expired service life of the corresponding cartridge.
In this case, the cartridge must be replaced with
a new one.
Fig. 14
MembraneMembrane
cartridgecartridge

10
52 143
Fig. 15
The solid indicators of the filtration units inform
about the unexpired service life of the cartridges.
Light indicator 5 (see Fig. 15) starts flashing in the
event of a malfunction; it stays solid the rest of the
• Close the inlet cock of the connecting assembly
and open the treated water tap. Wait until the
cartridge life light and sound indication turns
off.
• Remove the overwrapping film from the new
cartridges.
• Rinse the O-rings of the new cartridge under
a water stream.
• Remove the old cartridges. For this, press
the lock button as far as it will go and hold it
while turning the cartridge counter clockwise,
as shown in Fig. 10b.
• Insert a new cartridge into the corresponding
collector until it stops and turn clockwise, as
shown in Fig. 10a, until a click.
Replacement of K1, K2 filter cartridges
and the membranes cartridges
Modes Sound alarm LED operation by numbers
(see Fig. 15)
Pump
operation
Solid Flashing
Filling the tank with treated water
(Operating mode)
1–5 +
The tank is filled (Standby mode) 5
Launch and flush modes
The system starts for the first time +51–4 +
Flushing the pre-treatment unit 51–4 +
Flushing the membrane unit +51–4 +
Cartridge expired service life indication
Filling the tank with treated water
(Operating mode)
+5 Corresponds to the
cartridge (s) that has
exceeded its life cycle
+
Fault mode (Emergency mode*)
+Alternately: (1, 3, 5) / (2, 4)
* After disconnecting and then connecting the water purifier to the main body, the sound signal stops.
time, informing that your RO-206S is connected to
the power supply.

11
After replacing K1 and K2
filter cartridges of the water
treatment unit
• Open the inlet cock of the connecting assembly.
The flashing indicators of the K1 and / or K2
cartridges of the water treatment unit are
followed by a sound signal. The other indicators
are solid.
• Make sure the RO-206S connections are tight.
• On the front panel, flash the PUSH button
3times to start the flushing mode of the
water pre-treatment unit. At this, 5 audible
signals sound, the indicator lights go out and
the flushing mode of the pre-treatment unit
starts and lasts 30 minutes.
• After flushing procedure is complete, your
RO-206S beeps 5 times and switches into
the operating mode automatically: filtration
and filling the tank with water, while the light
indicators of the pre-treatment unit flash (the
light signal is followed by a sound), the other
indicators are solid.
• Press and hold the PUSH button for at least
7 seconds to reset the cartridge life. The light
indication of the pre-treatment unit changes
from the flashing mode to the constant one,
and the audio signal stops.
* The whole flushing procedure of the membrane cartridge takes no more than 24 hours and depends on its storage and trans-
portation conditions.
After replacing
the membrane unit:
• Open the inlet cock of the connecting assembly.
The cartridge life light indicators turn on, the
flashing light indicator of the reverse osmosis
membrane unit is followed by a sound signal.
• Make sure the RO-206S connections are tight.
• Let the water through your RO-206S for 1hour*.
• Close the treated water tap.
• Press and hold the PUSH button for at least
7seconds to reset the cartridge life. The light
indication of the reverse osmosis membrane
unit changes from the flashing mode to the
constant one, and the audio signal stops.
ATTENTION! Do not disconnect your RO-206S
from the power supply when in the flushing
mode. Otherwise, the flushing process must
be repeated.
8. Storage Tank
Maintenance
Empty the tank before use if you have not used
the RO-206S for more than 2days.
Empty and refill the tank 3times for flushing
before use if you have not used the system for
more than 2weeks.
Then, you can use the RO-206S again.
ATTENTION! It is recommended to flush the
storage tank with a disinfectant solution at least
1 time a year.
9. Connection
of additional equipment
The ability to connect additional equipment (ice
machine, coffee machine, etc.) depends on the
equipment`s requirements for the source water
and the characteristics of the water at the inlet
to the water purifier. If you need to connect
additional equipment, please contact the service
of the company «AQUAPHOR» or regional dealers
of the company «AQUAPHOR» for advice.
to additional tank
to the tap for clean water
Fig. 16

12
Connecting an additional tank
In the general case, the connection diagram
for an additional hydraulic accumulator tank is
shown in Fig. 16.
Depending on the specific parameters of the
accumulation tank and the connection conditions,
it may be necessary to adjust the operating mode
of the electronic RO-206S control unit. Contact
a service representative for advice.
10. Storage and
Transportation Rules
The RO-206S shelf life is 3years before operation
when stored at +5 to +38ºС, originally packed, in
closed and naturally ventilated rooms at a relative
humidity not exceeding 80%.
It is forbidden to turn the RO-206S over, to hit or
to expose to other mechanical stresses.
Protect your RO-206S from shocks and falls,
as well as not letting any water freeze when
transporting, storing and using.
Do not expose the membrane cartridges to high
or low temperatures and direct sunlight.
Attention! Membranes cartridges come in sealed
packaging. It is allowed to store membrane car-
tridges for no more than 3 days after they are
unpacked.
11. Safety
RO-206S is designed to post-treat and soften
water from municipal water supply systems that
meet sanitary standards.
It is recommended to analyse the water source for
compliance with national standards for drinking
water when installing RO-202S outside municipal
water supply systems.
• The service life of the pre-treatment unit and
the reverse osmosis membranes may be
reduced if the source water does not meet
the requirements of national standards for
drinking water.
• It is recommended to install additional water
treatment systems (iron removers, softeners,
disinfectants, mechanical filters, etc.) if the
source water significantly differs from the
requirements of national standards for drinking
water quality.
• It is recommended to use RO-206S as a post-
treatment unit for microbiologically safe water,
although this reverse osmosis system can trap
out bacteria and viruses from the source water.
Do not use the system to treat unknown water
without additional disinfection. Empty and
refill the tank 3times for flushing before use
if you have not used your system for more
than 2weeks. Treated water is not subject to
long-term storage. It is recommended to use
fresh filtered water.
It is disposed of in accordance with environmental,
sanitary and other requirements set forth in
national standards for environmental protection
and ensuring the sanitary and epidemiological
welfare of the population.

13
Precautions when connecting your RO-206S to the mains
Check that the main voltage matches the parameters specified in this Manual before connecting
your RO-206S to the mains. Only use a power supply unit with output characteristics specified
in this Manual (24 V ± 5%, at least 5 A DC).
Make sure that your RO-206S is protected from freezing, water, direct sunlight, contact with
hot objects, including hot water, heating pipes and heating devices before installing. Keep your
RO-206S from hitting and falling.
The power cord must not be stretched out tensely when your RO-206S is connected. Make
sure that the power cord does not touch surfaces that could damage it.
Do not immerse your RO-206S, as well as the power supply unit, the power cord and the plug
of the power cord in water or other liquid, or wash them with running water or in a dishwasher.
To avoid electric shock, do not touch your RO-206S connected to power with wet hands, as
well as the power supply unit, the power cord and the plug.
Keep your RO-206S housing clean. Disconnect your RO-206S from the power supply and wipe,
if necessary, with a dry cloth.
Do not disassemble your RO-206S nor open its housing!
Do not use the RO-206S and the power supply in case of malfunction or damage to the cord.
Do not repair the device yourself. First disconnect the power supply from the mains, then
disconnect it from the RO-206S if any malfunction is detected. It is recommended to contact
your service provider.
12. Terms of Service and Warranties
Aquaphor Water Filters products are backed by
some of the most comprehensive warranties in the
industry. Aquaphor warrants that the Aquaphor
water filtration system shall be free from defects
in material and workman ship under normal use
and service.
Aquaphor Reverse Osmosis System, Model
RO-206S – Two Years Warranty from the date
of purchase. This does not apply, however, to
consumable filters.
Exclusions and Limitations
1. Aquaphor warrants its products to be free from
manufacturing defects under normal use and
service. This warranty is extended only to the
ORIGINAL PURCHASER.
2. Aquaphor obligations under this warranty
are limited to repairs or replacement, at
Aquaphor’s option, of products or parts found
to be defective, provided that such products
were properly installed and used in accordance
with instructions. Aquaphor reserves the right
to make such inspections as may be necessary
in order to determine the cause of the defect.
Aquaphor will not charge for labor or parts in
connection with warranty repairs for the first
full year from date of purchase on all products
except those that may be subject to commercial
use limitations.
3. Aquaphor is not responsible for the cost of
removal, return (shipping) and/or reinstallation
of products.
This warranty does NOT apply to:
• Damage or loss which occurs during shipment.
• Damage or loss sustained through any natural
or man-made causes beyond the control of
Aquaphor, including but not limited to fire,
earthquake, floods, etc.
• Damage or loss resulting from sediments or
foreign matter contained in a water system.
• Damage or loss resulting from negligent or
improper installation including installation of
a unit in a harsh or hazardous environment.
• Damage or loss resulting from removal,
improper repair, modification of the product,
or improper maintenance including damage

14
caused by chlorine or chlorine related
products.
• Damage or loss resulting from acts which are
not the fault of Aquaphor or which the Product
is not specified to tolerate.
4. This warranty gives you specific legal rights.
You may have other rights which vary from
state to state.
THIS WRITTEN WARRANTY IS THE ONLY
WARRANTY MADE BY AQUAPHOR. REPAIR
OR REPLACEMENT AS PROVIDED UNDER THIS
WARRANTY SHALL BE THE EXCLUSIVE REMEDY
AVAILABLE TO THE PURCHASER.
AQUAPHOR SHALL NOT BE RESPONSIBLE FOR
LOSS OF USE OF THE PRODUCT OR FOR OTHER
INCIDENTAL, SPECIAL, FOR CONSEQUENTIAL
DAMAGES OR EXPENSES INCURRED BY THE
PURCHASER OR FOR LABOR OR OTHER COSTS
DUE TO INSTALLATION OR REMOVAL OR COSTS
OF REPAIRS BY OTHERS, OR FOR ANY OTHER
EXPENSE NOT SPECIFICALLY STATED ABOVE.
EXCEPT TO THE EXTENT PROHIBITED BY
APPLICABLE.
LAW, ANY IMPLIED WARRANTIES, INCLUDING
THAT OF MERCHANTABILITY, ARE EXPRESSLY
LIMITED TO THE DURATION OF THIS WARRANTY.
SOME STATES DO NOT ALLOW LIMITATIONS,
SO THE ABOVE LIMITATION AND EXCLUSION
MAY NOT APPLY TO YOU.
If you have any issue with the operation of
your RO-206S, please, contact the seller or the
manufacturer.
Service life (operating time) of replaceable
filtering cartridges:
Name Service life
(operating time)
Pre-treatment unit
K1, K2 cartridge: up to 6 months (1)
Reverse-osmosis membrane unit
Replaceable
membrane cartridge 1.5–2 years (2)
The data are based on the consumption of 10-12 litres
of drinking water per day by a family of 3-4 people.
(1) The service life (operating time) of the wa-
ter pre-treatment cartridges may vary de-
pending on the amount of impurities in the
source water. The service life (operating
time) of the cartridges is indicated for water
that meets sanitary standards. K1 and K2 re-
placeable filter cartridges must be changed
every 1-3 months if water entering your RO-
206S does not meet sanitary standards (with
a high content of mechanical impurities). The
RO-206S light and sound indication is config-
ured to work with water that meets sanitary
standards.
(2) The service life of the membranes cartrid-
ges directly depends on the performance of
the pre-treatment cartridges. Please, replace
exhausted filter cartridges in a timely manner.

Fault table
Malfunction Cause Elimination method
No treated water
or it is not enough.
The storage tank is filled slowly
or is not at all.
The replaceable cartridges
of the pre-treatment unit are
clogged.
Replace the cartridges of
the pre-treatment unit.
The replaceable membrane
cartridge is clogged.
Replace the replaceable
membrane cartridge.
The power supply plug is not
plugged into the outlet.
Insert the plug of the power
supply into a power outlet.
The power supply plug is
not plugged into the coaxial
connector of the RO-206S.
Insert the power supply plug
into the coaxial connector of
the RO-206S
The inlet cock of the
connecting assembly is
closed.
Open the inlet cock of the
connecting assembly
The emergency mode is
activated (light indicator 5
flashes on the front panel, see
page 10).
Contact your service
provider.
It is recommended to contact your service provider for any other malfunctions.

Sale Date / Store Stamp
Product serial number
Drinking water machine
Aquaphor DWM-206S-C (RO-206S).
Manufacturer:
Westaqua-Invest OÜ division of Aquaphor
Corp., L. Tolstoi 2A, Sillamäe, Estonia, 40231.
www.aquaphor.com
The manufacturer reserves the right to make
improvements to the design of the RO-206S
without being mentioned in this Manual.
The date of manufacture and quality control
is indicated on the product serial number label.
The serial number of your RO-206S
is indicated on the sticker below.
