ARC MIMST-1703 User manual

1
Issue Date: 23/03/2020
INDOOR MOTION SENSOR
MIMST-1703
CONTENTS
1. Overview and features Page 2.
2. Diagrams Page 3.
3. Battery Page 4.
4. Mounting on surface Page 7.
5. Pairing / Un-pairing device Page 9.
6. Delay Off timer setup Page 10.
7. Lux setup Page 11.
8. Operation Page 12.
9. Specifications Page 13.

2
Issue Date: 23/03/2020
1.Overview and features
Indoor motion sensor can detect occupancy and movement and triggers your
connected receiver devices.
Place the motion sensor freestanding on a table or shelf or affix the magnetic
mounting base on the ceiling or on wall corner. Perfect for your basement,
garage or hallway.
3V CR2450 battery operation capable of 3 year battery life and built in battery
low indicator.
Main feature;
•Compatible to L & M series.
•Detects movements by passive infrared technology.
•Adjustable ‘ambient light level’ control (LUX).
•Unique wall/surface mount magnetic base for flexible installation in
different angle.
•Delay off timer (5S / 1M / 5M / 10M) that automatically conserves battery
power.
•Suggested PIR range at 6M / 90 @ 1.5M mounting height.
Precautions:
Not compatible to dimmer receiver devices.
Always mount indoors as the motion sensor is not waterproof.
OVERVIEW AND FEATURES

3
Issue Date: 23/03/2020
2.Diagrams
Notes for the diagrams:
DIAGRAMS
Delay off timer
Lux setting
Learn button
LED Indicator

4
Issue Date: 23/03/2020
3.Battery
Red LED will flash once every 4 seconds to indicate the battery is low.
1. Using a cross head screwdriver, turn counterclockwise to loosen the battery
compartment.
2. Pull out battery insulation strip. (First time use only)
BATTERY
Insulation strip

5
Issue Date: 23/03/2020
3. Or replace new battery with a slot screwdriver and push down the metal
spring then remove battery.
4. Replace with a new 3V CR2450 battery.
Gently tilt battery at an angle towards the metal spring and with some force
push down the battery making sure the positive symbol is facing upwards.
5. Affix back battery compartment and using a cross head screwdriver, turn
clockwise to tighten the battery compartment.
BATTERY

6
Issue Date: 23/03/2020
Initial start (when battery is inserted) please leave the motion sensor steady for
at least 15 seconds to allow the sensor to warm up and stable enough to detect
any movement.
LITHIUM BATTERY CAUTION:
Risk of Explosion if battery is replaced by an incorrect type. Dispose of used
batteries according to the environment protection rules.
BATTERY

7
Issue Date: 23/03/2020
4.Mounting On Surface
1. Using a cross head screwdriver to mount the magnetic base on flat surface.
2. Gently attach the motion senor to the magnetic base making sure the
detection lens is not up side down.
Square box must be at the bottom.
3. Adjusting angle.
MOUNTING ON SURFACE

8
Issue Date: 23/03/2020
4. Detection range and angle.
5. Recommendation for best performance is at 6M / 90 @ 1.5M mounting
height.
6. Motion Sensor can also be freestanding on a table or shelf but making sure
the detection lens is not upside down.
MOUNTING ON SURFACE

9
Issue Date: 23/03/2020
5.Pairing / Un-pairing Device
PAIRING /UN-PAIRING
Refer to the relevant receiver operation manual that you wish to control for
detailed pairing / un-pairing procedure.
With the receiver that you intent to use, enter into “Learning Mode”
To Pair:
Press Learn Button once.
To Un-Pair:
Press Learn Button twice.
After initial pairing or un-pairing, please leave the motion sensor steady for at
least 10 seconds to allow the sensor to warm up and stable enough to detect.
PAIRING / UN-PARING DEVICE

10
Issue Date: 23/03/2020
6. Delay Off Timer Setup
Motion sensor has built in delay off timer (5S / 1M / 5M / 10M) that automatically
trigger the connected receiver to turn OFF in order to conserves battery power.
Factory pre-setting will be at ‘5’ seconds position.
•There are 4 timer selections, 5 seconds –1 minute –5 minutes –10
minutes.
•Adjust rotary switch to the time that you wish to setup.
•Each time you trigger the receiver device, timer will start to countdown and
turns “Off” the receiver device once it reaches to 0 minute.
•If the motion sensor detects another object during the first activation of the
timer, then the timer will extent and countdown from the very last movement
detected.
After initial timer setup, please leave the motion sensor steady for at least 10
seconds to allow the sensor to warm up and stable enough to detect.
DELAY OFF TIMER SETUP

11
Issue Date: 23/03/2020
7. Lux Setup
Motion sensor can adjust Lux level depending on the areas used.
Factory pre-setting will be at ‘H’ Lux level.
⚫To adjust lux level, simply adjust rotary switch from H-M or M-L and leaving
the motion sensor in a stable environment.
⚫Motion sensor will only trigger with the lux level lower than the initial lux
setting.
It will not trigger any movement at a higher lux level.
⚫It is not recommended to position the motion detector with other light
source surround. This may cause incorrect lux detection.
After initial lux level setup, please leave the motion sensor steady for at least
15-20 seconds to allow the sensor to warm up and stable enough to detect.
During this period please keep away from direct light source to avoid misleading
setup.
Ambient light level. (High / Medium / Low)
⚫‘H’24hrs detecting movement in all ambient light level.
For the use of door chime, please set in ‘H’mode.
⚫‘M’Approximately 4PM onwards
Detecting environment brightness level under 20 ±5 lux.
⚫‘L’Approximately 6PM onwards
Detecting environment brightness level under 10 ±5 lux.
LUX SETUP

12
Issue Date: 23/03/2020
8. Operation
Manual ON:
Press Learn Button once.
Manual OFF:
Press Learn Button twice.
OPERATION

13
Issue Date: 23/03/2020
9.Specifications
Battery: 3V CR2450 Lithium Cell Battery
Radio Frequency: 433.92MHz
Power consumption: 1W
Environment Temperature: 0-40 ºC
Range: Up to 50 m indoors (Depends on building
materials)
In accordance with: Low Voltage Directive 2014/35/EU
RED Directive 2014/53/EU
CE Certification: The CE marked affixed to this product confirms
Its complaisance with the European Directives
Which apply to the product and in particular its
compliance with the harmonizes standards and
specifications.
Dimension
Sensor: 37.5 x 65 x 31 mm
Magnet: 18 x 10 mm
Weight: 30 g
Accessory pack enclosed: 1pc screw
Note: Battery life is calculated at an average of 20 activations per day.
SPECIFICATION
