Archos Diamond 2 Plus User manual

1
Help & assistance
Congratulations for the purchase of an ARCHOS device! This quick start guide helps you
to start using your device properly. If you have more questions concerning the use of your
device, visit us at:
twitter.com/archos
www.facebook.com/archos
Blog https://blog.archos.com/
http://faq.archos.com/
www.archos.com, click Support > After-sales support
www.archos.com, click Support > Downloads > Declaration of conformity
As we are often updating and improving our products, your device’s software may have a slightly
different appearance or modified functionality than presented in this quick start guide.

2
Warranty
Unboxing
ARCHOS Diamond 2 Plus
Quick start guide
Warranty, legal and safety notice
USB type-C Charging cable
Charger adapter

3
Describing your device
Front
camera
Phone speaker
Headphone jack
Rear camera
Flash light
ON/OFF
Volume
Loudspeaker
USB type-C port
Memory & SIM
card slots
Flash
light
Light
sensor
Notification led
Fingerprint
reader
Noise
reduction
Laser focus
Loudspeaker
Microphone

4
Micro
SD
OR
Micro
SD
Micro
SD
OR
After you have unpacked your mobile phone box:
1. Remove the card tray by inserting the tool provided, into the tray
release hole.
2. Insert 1 micro SIM card into slot 1 and a micro SD Memory card into
slot 2 OR 2 micro SIM cards into slots 1 and 2 as shown in the diagram.
3. Replace the tray in the right position and push it inside to close.
4G slot 1 Micro-SIM
4G slot 2 Micro-SIM
Micro-SD card slot 2
When inserting your SIM card or micro-SD
card, make sure to follow the illustration,
otherwise you may damage the slot or the
card.
Assembling

5
Starting up
Charging your battery completely
Plug the charging cable in the USB type-C port and
the adapter in a power outlet.
Leave the device until the battery is fully charged.
Turning ON
1. Press and hold the ON/OFF button to turn on
the device.
2. Follow the instructions to set up your device.
Activating mobile date connection (4G)
1. Touch and pull down the status bar to display it.
2. Touch again the bar to reveal the quick
settings.
3. Select the Settings icon.
4. In Wireless & networks, select Data usage,
then the SIM card tab.
5. Slide the Mobile data switch to turn on/off.
Activating WiFi connection
1. Touch and pull down the status bar to display it.
2. Touch again the bar to reveal the quick
settings.
3. Select the WiFi icon to activate the WiFi
connection .
4. Select “WiFi” below the WiFi icon.
5. Touch the name of network you want to
connect to.
Private networks are shown with a lock icon and
will require you to enter your password.
Fingerprint reader
Use the fingerprint option to secure your device.
1. Select Settings>Security, then Fingerprint.
2. Select Continue.
3. Select a pattern as an alternative in case of
being not able to use the fingerprint option.
4. Follow the onscreen instructions.
5. Record your finger in different positions for a
better detection.
6. You can add up to 5 fingerprints.
Laser focus
For better photos, the laser focus helps improve
the camera focus. Go to Settings>Laser focus to
activate/deactivate.
Turbo download
Download large files faster by combining your Data
and WiFi connections.
1. Go to Settings > Wireless & networks.
2. Select Turbo download, then turn it ON

6
-My SIM card is not detected: make sure to have a valid SIM card. Insert the SIM card according
to the process shown in the Assembling page. Try to contact your provider to renew the card if it is
faulty.
-My device is frozen: press the ON/OFF button for more than 10 seconds.
-My device encounters dysfunctions: go to Settings > About phone > Check for update system to
check for updates. If your device is up-to-date, try to reset the device from Settings > Factory data
reset > Backup & restore. We recommend to save your files before resetting.
-My WiFi reception is too low: make sure you are not far from the WiFi hotspot. Update the firmware
of the device: http://www.archos.com/support. Reset and redefine your connection parameters.
Contact your WiFi connection provider.
-My device bootlogo is playing in a loop: you need to completely reset your device. Go to faq.archos.
com and select your device. In Backup & Recovery, select How to reinitialize my ARCHOS.
-My device doesn’t recognize my password or PIN: when setting a lock screen, select a code easy to
remember. In some cases, you need to enter your email or to reset totally your device. See our FAQs.
FOR MORE ANSWERS ABOUT YOUR TECHNICAL DIFFICULTIES, DO NOT HESITATE TO VISIT: FAQ.ARCHOS.
COM
Troubleshooting

7
Félicitations! Vous venez d’acquérir un appareil ARCHOS! Ce guide de démarrage rapide vous aide à
bien débuter l’usage de votre appareil. Si vous avez d’autres questions sur l’usage de votre appareil,
visitez nos liens ci-dessous :
twitter.com/archos
www.facebook.com/archos
Blog https://blog.archos.com/
http://faq.archos.com/
www.archos.com, click Support > After-sales support
www.archos.com, cliquez Support > Téléchargements > Déclaration de conformité
Comme nous mettons à jour et améliorons régulièrement nos produits, le logiciel de votre appareil
peut présenter une interface ou des fonctionnalités légèrement différentes de celles décrites dans
ce guide.
Contactez-nous

8
Warranty
Déballage
ARCHOS Diamond 2 Plus
Guide d’utilisation rapide
Livret des garanties et des
mentions légales et sécuritaires
Câble de charge USB type-C
Adaptateur

9
Description de l’appareil
Caméra
avant
Prise jack
Combiné
Marche/
Arrêt
Volume
Caméra
arrière
Flash
Port USB type-C
Haut-parleur
Haut-parleur
Micro
Emplacement
cartes SIM &
carte mémoire
Témoin de notification
Capteur de luminosité
Focus laser
Lecteur
d’empreinte
digitale
Réduction du
bruit
Flash

10
Micro
SD
OR
Micro
SD
Micro
SD
OR
Après avoir déballé le téléphone :
1. Enlevez le cache en insérant l’outil fourni dans le trou du cache.
2. Placez la carte SIM ou carte mémoire sur l’emplacement indiqué dans le
chariot suivant la direction indiquée.
3. Replacez le chariot dans son emplacement et enfoncez-le pour fermer.
4G emplacement 1 Micro-SIM
4G emplacement 2 Micro-SIM
Carte micro-SD emplacement 2
Lorsque vous insérez une carte SIM ou
une carte micro-SD, conformez-vous au
schéma pour ne pas endommager la carte ou
l’emplacement.
Assemblage
