Argos Chequer 399/901 User manual

Assembly Instructions - Please keep for future reference
-
399/9015
Dimensions
Width - 100cm
Depth - 40.5cm
Height - 49.5cm
Important
Version 1 Date: 21/04/15
Chequer Corner TV Unit
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6400800
- Please read these instructions fully before starting assembly

1
Safety and Care Advice
Important –Please read these instructions fully before startingassembly
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household waste.
Take to your local authority
waste disposal centre.
Care and maintenance
Handy Hints
• Check you have all the
components and tools listed on
the following pages.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• During assembly do not stand
or put weight on the product,
this could cause damage.
• Assemble the item as close
to its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor.
• Parts of the assembly will be
easier with 2 people.
• To reduce
the likelihood of
damaging your
product please
ensure that your
power drill is set on a low torque
setting.
• Keep these instruction for
future reference.
Warnings
• Imported by:
Argos Ltd.
489-499 Avebury Boulevard.
Saxon Gate West.
Central Milton Keynes.
MK9 2NW
Glass safety
(a) Do not place very hot or very cold items on the glass surface(s) unless adequately thick table mats
are used to prevent such items from coming into contact with the glass.
(b) Do not sit or stand upon the glass surface(s).
(c) Do not use the glass as a chopping surface. Do not strike the glass with hard or pointed items.
(d) When cleaning glass panels use a damp cloth or leather with washing up liquid or soft soap if
necessary, do not use washing powders or any other substance containing abrasives since these
substances scratch glass.
• If the glass is chipped or broken, stop using product and consult
the Manufacturer or Supplier.
• Batch No. & Date of manufacturer: Please refer to the label stick
on product back panel.
• Type of glass used: 5mm toughened glass
• Regularly check and ensure
that all bolts and fittings are
tightend properly.

Components - Panels
Please check you have all the panels listed below
If you have damaged or missing components, call the
Customer Helpline:
Argos = 0345 6400800
2
Top panel (100 x 40cm)
1
Bottom panel (96.8 x 39.8cm)
2
Middle Left panel
(43 x 38cm)
3Middle right panel
(43 x 38cm)
4
Right panel
(47.6 x 19.5.cm)
6
Shelf panel x 2
(23 x 14.5cm)
8
Large back panel
(50.3 x 45.7cm)
9
Small back panel x 2
(23.7 x 43cm)
10
Left panel
(47.6 x 19.5cm)
5
Middle shelf panel
(47.6 x 37.9cm)
7
Door x 2 (47.9 x 42.1cm)
11
Pilot holes for
guidance only
Pilot holes for
guidance only
Finished front edge Finished front edge

A B C
D
G
E F
3
Ruler - Use this ruler to help correctly identify the screws
Tools required
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110 115 120 125 130 135 140 145 150 155 160 165 170
105
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
0 1 2 3 4 5 6
Phillips screwdriver
(medium & large)
Flatblade screwdriver
(medium)
Small
hammer
Ruler/tape
measure
Drill
Eye protection
(when using a
hammer or glue)
7mm Suitable drill bit
(for use with wall plug)
The screws length is measured from the head to the point (30mm screw shown).
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
Components - Fittings
H
15mm Screw x 4
30mm Dowel x 12 39mm Locking pin x 1050mm Screw x 8
14mm Screw x 6
Door magnet x 1Foot x 3
15mm Locking nut x 10
I
J K L
Small foam pad x 4Foam pad x 2Nail x 14
Hinge plug x 4
M N O
Door push x 2Bottom hinge x 2Top hinge x 2
(This screw is included in
the door magnet bag)

4
Assembly Instructions
Step 1
Attaching the middle
shelf panel
b: Insert Dowels into
Shelf panel .
8
b:
a:
c:
A
a: Insert Dowels into
the Middle right panel
and Middle left panel .
A
4
3
c: Position Shelf panels
onto the Middle right
panel and Middle left
panel .
8
4
3
Use Screws to fix the
Middle right panel and
Middle left panel onto
the Middle shelf panel
.
B
4
3
7
A
A
B
B
B
B
A
A
A
A
X 2
7
8
4
8
3
8
4
3
Unfinished back edge
Unfinished back surface
Unfinished
back edge
Unfinished
back edge
Unfinished
back surface
Unfinished
back surface

b: Position the Right
panel and Left panel
onto the unit.
6
5
Assembly Instructions
Step 2
Step 3
a: Insert Dowels and
Screw Locking pins into
the Right panel and
Left panel .
A
C
6
5
Attaching right panel
and left panel
Note:
Insert Locking pins
as far as shown.
Do not over tighten.
5
a:
b:
Attaching bottom panel
Use Screws to fix
Bottom panel onto the
Middle right panel and
Middle left panel .
B
2
4
3
Insert 4 Locking nuts
into the unit.
F
Use a screwdriver to turn
Locking nuts clockwise
to lock.
Use Screws to fix Foot
onto the unit.
F
D
G
B
B
A
F
F
G
G
G
D
D
D
C
CA
C
C
B
B
4
3
2
6
6
5
2
8
5
C
F
GD
F
F

6
Assembly Instructions
Attaching small back
panels
Step 4
Slide small back panels
into the unit.
10
Step 5
Note:
Insert Locking pins
as far as shown.
Do not over tighten.
Screw Locking pins(6 pcs)
into the Top panel .
Insert Hinge plugs into
the Top panel .
C
a: Use Screws to fix the
Door magnet onto the
Top panel .
E
I
H
1
1
1
Attaching top panel
a:
Continued on next page.
C
C
C
I
I
C
C
E
H
10
1
10
C
C
E
H
I
Unfinished back surface

Assembly Instructions
Step 6
Attach large back panel
using nails .
J
9
Fixing large back panel
Important:
The unit MUST
be ‘square’ when
back is attached.
7
b:
Step - continued5
b: Carefully locate the
Top panel onto the
unit.
1
Insert 6 Locking nuts
into the unit.
F
Use a screwdriver to turn
Locking nuts clockwise
to lock.
F
Insert Hinge plugs into
the Bottom panel .
I
2
9
F
F
F
F
1
2
5
6
4
3
F
J
Unfinished
back surface
I
I
I

8
Assembly Instructions
b:
a:
c:
Step 7
Fitting the glass doors
a: Tear off the protective
backing from the Foam
pad and Small foam
pad .
K
L
b: Carefully stick the
Foam pad onto the
Glass door so that it
wraps over Glass door.
Locate the Door push
over the top of the Foam
pad and Glass door.
K
O
Carefully stick the Small
foam pads onto the
Glass door . Then
slide the Bottom hinge
onto the Glass door ,
and tighten the screws to
fix position.
L
N
11
11
11
c: Insert the Top hinges
into the Hinge plug .
Carefully locate the
Bottom hinges into the
Hinge plugs .
M I
N
I
Carefully slide the Glass
doors into the Top
hinges , ensuring they
are parallel with they unit.
Then tighten the screws to
fix in position.
M
11
N
I
K
L
N
N
M
M
L
X 2
11
11
11
M M
I
O
K
N
L

Assembly Instructions
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6400800
Assembly is complete.
9
Finishing the unit
Note:
It would be useful
to ask someone to help
you at this stage.
With help, place the unit
in the intended position.
Step 8
