Argos Nordic 4x2 Drawer Chest User manual

Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Assembly Instructions - Please keep for future reference
1468751
Nordic - 4x2 Drawer Chest
03456 400 800
- 02-06-2014
Dimensions
idth : 83,5 cm
Depth : 39,7 cm
Height : 88,2 cm
344013022

Important - Please read these instructions fully before starting assembly
Safety and Care Advice
• Check you have all the
components and tools listed on
pages 3 and 4.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• ake sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor.
• Parts of the assembly will be
easier with 2 people.
• We do not recommend the use
of power drill/drivers for
inserting screws, as this could
damage the unit. Only use hand
screwdrivers.
• Dispose of all packaging
carefully and responsibly .
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
• From time to time check that
there are no loose screws on
this unit.
• Only clean using a damp cloth
and mild detergent, do not use
bleach or abrasive cleaners.
Care and maintenance
Note: if required the next
page can be cut out and used
as reference throughout the
assembly. Keep this page with
these instructions for future
reference.
2

Side, Right
V155852
867x379x15 mm
Side, Left
V155853
867x379x15 mm
Top
V155861
835x397x15 mm
Drawer front x
V15581
793x157x15 mm
Drawer front, small x2
V155810
395x125x15 mm
Plinth, Front
V155803
793x96x15 mm
Plinth, Back
P155866
781x60x15 mm
Drawer side, right/left x12
S120653
350x98x12 mm
Drawer back x
S120652
7 9x98x12 mm
Drawer back, small x2
S120650
351x98x12 mm
Drawer bottom x2
NM 15850
361x3 7x3 mm
Drawer bottom x
NM 15856
759x3 7x3 mm
Back x2
NM 15857
78 x397x3 mm
H-profile
B80750
x750
Please check you have all the panels listed below
Components - Panels
3
If you have damaged or missing components, call
the Argos Customer Helpline: 03456 400 800
1
2
35
7
9
10
11
12
13
14
15
8
4

B561300
Drawer support x2
BA10390
ø8x30 mm Wooden dowel x6
BA10400
ø6x30 mm Wooden dowel x2
BA10170
ø ,0x35 mm x3
BA10590
ø15x9,5 mm Cam x18
BA10603
ø5/11x3 mm Bolt x18
BA10025
ø1,2x20 mm Nail x50
BA10833
Back fitting W. 15x15x10 mm screw x12
BA10240
ø6,1x11,5 mm screw x8
BA10270
ø5,8x8 mm screw x3
BA 10154
,0x16 mm screw x
Ba10688
Nail holder x1
B14359
17x2 6 mm Drawer runner x12
BA10191
M x9 mm screw x12
BA10801
Angle20x20x2 x
BA182002
Wallstrap and instruction x1
BA1046 8
ø 0x30 mm Wooden knob x10
Please check you have all the panels listed below
Components - Fittings
If you have damaged or missing components, call
the Argos Customer Helpline: 0845 640 30 30
Note: The quantities below are the correct amount to complete the assembly. In some cases more
fittings may be supplied than are required.
Tools required
Ruler - se this ruler to help correctly identify the screws
A B L
R C D
HG
F
J
i
K S
4
VYT

Step 1
Assembly Instructions
Fix the drawer sides 12
to the drawer backs 10
and 11 as shown, using
screws R.
Knock the dowels B into
the holes indicated on
the drawer sides 12
using a small hammer.
Step 2
Step 3
Slide the drawer bottoms
13 and 14 into the
drawer sides 12.
Step 4
screw the bolts D into
the holes indicated on
the drawer fronts 8 and
9.
5
12
12
12
12
12
12
12
12
12
12
12
12
11
10
B
B
B
B
14
13
9
8
x
x
x
x
x2
x2
x2
x2
D
D
D
D
R
R
R
R
R
R

Assembly Instructions
Push the drawer fronts 8
and 9 onto the drawer
sides 12 as shown.
Push the cams C into the
holes indicated. Arrow
pointing towards the
front.
Turn the cams C to the
right to fix the fronts 8
and 9.
Step 5
Step 6
Step 7
Important!
ake sure the
angle between the
drawer fronts 8 and 9
and the drawer sides 12
is 90° before the drawer
bottoms 13 and 14 is
fixed.
Fix the drawer bottoms
13 and 14 to the drawer
backs 10 and 11 and the
drawer fronts 8 and 9
using F.
To adjust the angle
between the drawer
sides and the drawer
fronts push the fitting F
sidewards. See details.
Fix the Wooden knobs G
to the drawer fronts 8
and 9 using screws R.
6
!
C
C
C
C
F
F
FF
G
G
G
R
R
R
x2
x2
x2
x
x
x
10
8
9
11
8
8
9
9
12
12
12
12
12
12
12
12

Assembly Instructions
Knock down the dowels
A into the holes
indicated on the back
plinth 4. using a small
hammer.
Screw the bolts D into
the holes indicated op
top 1.
Fit the drawer support L
to the top 1 using screws
T through the holes
indicated.
See details.
Step 8
Step 9
Step 10
Slide the top of the
drawer runners S
backwards.
Fix the front end of the
drawer runners S (on
both sides) to the drawer
support L into the hole
indicated, using screws
K.
See details.
Slide the drawer runners
S forwards.
Fix the backend of the
drawer runners S (on
both sides) to the drawer
support into the hole
indicated, using screw K.
See details.
7
1
1
D
D
D
D
L
L
L
T
T
T
T
1
1
1
1
K
K
K
K
K
K
K
K
L
L
L
L
S
S
S
S
S
S
S
S
A
A
4

Assembly Instructions
Screw the bolts D into
the holes indicated on
the sides 2 and 3.
Fix the angle V to the
sides 2 and 3 using
screws E. Place the
angles as shown.
See details.
Knock down the dowels
A into the holes
indicated on the sides 2
and 3 using a small
hammer.
Step 11
Step 12
Step 13
Slide the top of the
drawer runners S
backwards.
Fix the front end of the
drawer runners S to the
sides 2 and 3 using
screws K through the
holes indicated.
See details.
Slide the top of the
drawer runners S
forwards.
Fix the backend of the
drawer runners S to the
sides 2 and 3 using
screws K through the
holes indicated.
See details.
8
2
2
2
3
3
3
A
A
A
A
VV
V
D
D
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
KK
K
K
K
K
K
S
S
S
S
S
S
S
S
S
S
S
K
K
S
S
S
S
S
S
S
S
S
S
S
S
S

Assembly Instructions
Fix the back plinth 4 to
the sides 2 and 3.
Push cams C into the
holes indicated on the
back plinth 4.
Arrow pointing towards
sides 2 and 3.
Turn the cams C to the
right to fix the sides 2
and 3.
Step 14
Step 15
Step 16
Press the top 1 onto the
sides 2 and 3.
Push cams C into the
holes indicated on the
sides 2 and 3.
Arrow pointing towards
the top 1.
Turn the cams C to the
right to fix the top 1.
Turn around the chest so
that it lies its front edge.
Place the front plinth 5
as shown.
Fix the front plinth 5 to
the sides 2 and 3 using
screws E into the angles
V.
See details.
9
2
2
2
3
3
3
1
4
5
C
C
C
C
C
V
V
5
2

Assembly Instructions
Place the backs 7 into
the rebates in the top 1,
the sides 2 and 3 and
into the H profile 15.
Important!
Make sure the
angle between the top
and the sides is 90
when the back is
attached.
Fix the backs to the
sides, top and bottom
using nails i.
Use the nail holder Yd
and a small hammer.
Step 17
Step 18
10
!
!
It's recommended that
the chest is fixed to the
wall.
Use the fittings J.
Follow the instructions
included with the
fittings.
Warning!
The chest of
drawer is heavy.
Lift with care
wallstrap and instruction
J
7
7
15
3
2
1
i
i
i
i

Assembly Instructions
If you need help or have damaged or missing parts, call the Customer Helpline:
03456 400 800
Home Retail Group - 489-499 Avebury Boulevard - Saxon Gate West - Central ilton Keynes K9 2NW
Pull out the drawer
runners. Slide the
drawers onto the drawer
runners.
Fit and fix the lower
drawer first and work
your way up.
Fix drawers to drawer
runners using screws H.
Assembly is complete.
Step 19
11
H
H
H

Wall Mounting & Fixings
12
Important:
When drilling into walls always check that there
are no hidden wires or pipes ect. Make sure
that the screws and wall plugs being used are
suitable for supporting your unit.
Consult a qualified tradesperson if you are
unsure.
HINTS
1) General Rule Always use a larger screw and a wall plug if you are not sure.
2) Ensure you use the recommended drill bit to match the wall plug and hole size.
3) Ensure you drill the hole horizontally, do not force the drill or enlarge the hole.
4) Take extra care when drilling high walls, ceilings and ceramic tiles. Ensure the plug is
fitting below the ceramic tile to avoid splitting or cracking.
5) Ensure wall plugs are well fitted and are a tight fit in the drilled hole.
!
!
!
a Guide to
Types of walls
You can use one of the following
types of wall plug if your walls are
made of brick, breeze block,
concrete, stone, wood or plaster
board.
No. 1 "Standard" Wall Plug
General Wall Materials.
These come in various sizes and are
made from plastic or sometimes
wood fiber.
No. 2 "General Purpose" Wall
Plug Aerated/Breeze Block.
General aerated blocks should not
be used to support heavy loads, use
a specialist fitting in this case.
For light loads, a General Purpose
Plug can be used.
No. 3 "S ield Anc or" Wall Plug
Heavy loads.
For use with heavier loads such as
T & HiFi Speakers and Satelite
Dishes etc.
No. 4 "Gavity Fixing" Wall Plug.
For use with plaster board partitions
or hollow wooden doors.
No. 5 "Gavity Fixing Heavy
Duty" Wall Plug.
For use when fitting or surpporting
heavy loads such as shelving, wall
cabinets, coat racks.
No. 6 "Hammer Fixing" Wall
plug.
For use with walls stuck with plaster
board. The hammer fixing allows it
to be fixed to the wall rather than
the plaster board. Always check the
fixing is secure to the retaining wall.
Care & Maintenance
SAFETY
Always check the fitting and location
to ensure your safety in and around
the home.
Care & Maintenance
FITTING
From time to time check the fitting
to ensure the wall plugs or screws
do not become loose.
