Argos Malibu 305/1805 User manual

MADE IN
BRITAIN
Dimensions
Width - 145.5cm
Depth - 50cm
Height - 181cm
Malibu - 3 Drawer 2+2 Door Robe
Assembly Instructions - Please keep for future reference
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Issue 3 - 03/09/13
Important - Please read these instructions fully before starting assembly
ALR2846
305/1805
305/1795
305/1829
305/1788
305/1812
Issue 2 - 12/06/13 - Drawer Base code corrected to T162.
Issue 3 - 03/09/13 - Rail Holders now secured with screws - Quantity of 6 x 1/2 csk screws increased from 24 to 30.
The number of Nail Screws and Back Holders have been reduced to 8

Safety and Care Advice
Important - Please read these instructions fully before starting assembly
• Warning: This unit weighs
approximately 91kgs.
Please lift with care.
• Check you have all the
components and tools listed on
pages 1, 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Parts of the assembly will be
easier with 2 people.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor (use opened
out unit carton).
1
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Safety note: It is
recommended that this unit is
secured to a wall using the
bracket supplied.
• Dispose of all packaging
carefully and responsibly.
Components - Panels
Please check you have all the panels listed below
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
4Top (D2035A)
(1423 x 494mm)
1
5Base (D2040A)
(1423 x 494mm)
Drawer Front (D2044A)
(707 x 157mm) x 3
32 Drawer Wrap (W162)
(1308 x 95mm) x 3
Drawer Base (T162)
(299 x 695mm) x 3

Components - Panels
Please check you have all the panels listed below
2
6
80%
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Left End (D2036A)
(1808 x 496mm)
7Right End (D2037A)
(1808 x 496mm)
Left Divider (D2038A)
(1684 x 477mm)
Right Divider (D2039A)
(1684 x 477mm)
8 9
15 Large Door (D2042A)
(1678 x 352mm) x 2
16 Small Door (D2043A)
(1198 x 352mm) x 2
18
Short Back (X953)
(1210 x 726mm)
Long Back (X952)
(1710 x 362mm) x 2
17
10 Plinth Rail (D2046A)
(1423 x 92mm) x 2
Long Hanging Rail (FHR704)
(704mm long)
13
Short Hanging Rail (FHR330)
(330mm long) x 2
14
11 Fixed Shelf (D2041A)
(714 x 476mm) x 2
Loose Shelf (D2045A)
(338 x 476mm) x 2
12

Please check you have all the fittings listed below
Tools required
3
Components - Fittings If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Note: The quantities below are the correct amount to complete the assembly. In some cases
more fittings may be supplied than are required.
A
Wooden dowel (F22) x 28
B
Metal dowel (F901) x 6
C
D E
G H I
Rule Scissors Hammer
Eye protection
(when using a
hammer or drill)
Cross-head
screwdriver
Small locking
nut (F3) x 6
Ruler - Use this ruler to help correctly identify the screws
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
40mm Screw (F910) x 28
J K
Electric drill
(do not use for
fitting screws)
Nail (F51) x 44
25mm Screw (F50) x 10
F
13mm Screw (F79) x 1
13mm Screw (F63) x 30
Rail holder
(F1014) x 6 Bracket (F327 x 1)
M N R (F601)
L (F600)
F599
F599
Drawer stops (F599) x 6
Runners (F600) x 3 and (F601) x 3
Hinge (F522) x 12
L
P Q
Hinge plate (F523) x 12
Handle (F631) x 10
O
Shelf stud (F110) x 8
Back holder (F276) x 8 Nail screw (F277) x 8

Assembly Instructions
4
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Step 1
Step 2
x 3
x 3
x 3
x 3
BB
B
Prepare the 3 drawer
fronts and 3 drawer
wraps
a: Screw 2 metal dowels
. into the holes on the
back of the drawer fronts
. .
Note: Tighten the metal
dowels up fully against
the panels.
b: Insert 2 small locking
nuts into the holes
shown on the drawer
wrap .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
B
1
C
2F
C
C
C
2
a:
b:
Assemble the drawers
a: Place the drawer
base into the narrow
slot on the drawer wrap
. . Fold the wrap
around the base.
b: Turn each of the
drawer wrap assemblies
over and push them onto
the back of the drawer
fronts .
Note: Turn the locking
nuts clockwise to
secure the panels - more
than 1/2 a turn.
3
2
1
C
a:
1Drawer Front (D2044A)
(1707 x 157mm) x 3
32 Drawer Wrap (W162)
(1308 x 95mm) x 3
Drawer Base (D2044A)
(299 x 695mm) x 3
1
2
32
1
2
1
2
B
B
C
b:
80% x 3

A
A
Assembly Instructions
5
Step 3
Push the drawer stops
into the drawer wraps
Carefully break off the 2
drawer stops (F599) from
each pair of the drawer
runners .
Push the drawer stops
fully through the large
drawer wraps from
the inside.
N
SNAP!
SNAP!
2
Attach the handles
Attach 2 handles to
each drawer front
using screws .
Note: Do not
overtighten the screws.
O
E
F599
N
N
F599
N
F599
N
F599
N
O
O
Step 4
Step 5
2
E
E
1
1
x 3
x 3
x 2
10mm
A
Prepare the 2 fixed
shelves
Tap 4 wooden dowels
into each of the 2 fixed
shelves .
Note: Wooden dowels
must not stick out from
the edge by more than
10mm or they may
damage other panels.
A
11
A
A
Finished
front edge
11
80% x 3

Finished
front edge
A
A
Assembly Instructions
6
Step 6
Prepare the left
divider
Separate runners .
a: Push fit the 3 left
runners marked ‘L’
into the holes shown on
the left divider .
Note: Runners must be
be fitted flat against the
panel. If necessary
gently tap into final
position.
Push a rail holder into
the left divider . Make
sure that it is fitted
straight, in line with the
panel edges and then
secure with screw .
Fit 3 hinge plates onto
the left divider ,
making sure that the slot
is facing towards the
finished front edge.
Turn the left divider
over
b: Tap 4 wooden
dowels into the left
divider .
Push a rail holder into
the left divider . Make
sure that it is fitted
straight, in line with the
panel edges and then
secure with screw .
Prepare left and right
side
Separate runners .
a: Push fit the left
runner marked ‘L’ into
the holes shown on left
side .
Note: Runners must be
be fitted flat against the
panel. If necessary
gently tap into final
position.
Insert large locking
nut as shown.
Note: Arrow on locking
nut must point towards
hole in edge of panel.
Tap in wooden dowel
as shown.
Note: Wooden dowels
must not stick out from
the edge by more than
10mm or they may
damage other panels.
b: Push fit the right
runner marked ‘R’
into the holes shown on
left side .
Insert large locking
nut as shown.
Tap in wooden dowel
as shown.
N
L
F600
N
N
N
L
J
J
A
A
8
8
Finished
front edge
N
N
8
J
8
J
8
L
8
A
8
a:
b:
Turn the left
divider over
80% x 2
90% x 1
80% x 1
G
G
G
G

Finished
front edge
A
A
Assembly Instructions
7
Step 7
Prepare the right
divider
a: Push fit the 3 right
runners marked ‘R’
into the holes shown on
the right divider .
Push a rail holder into
the right divider .
Make sure that it is fitted
straight, in line with the
panel edges and then
secure with screw .
Fit 3 hinge plates onto
the right divider ,
making sure that the slot
is facing towards the
finished front edge.
Turn the right divider
over
b: Tap 4 wooden
dowels into the right
divider .
Push a rail holder into
the right divider .
Make sure that it is fitted
straight, in line with the
panel edges and then
secure with screw .
N
9
J
9
J
9
L
9
A
9
N
N
N
RF601
NL
L
L
L
J
Finished
front edge
A
A
J
a:
b:
Turn the left
divider over
9
9
G
G
G
G

D
D
D
D
Assembly Instructions
8
Step 8
Prepare left and right
side
Separate runners .
a: Push fit the left
runner marked ‘L’ into
the holes shown on left
side .
Note: Runners must be
be fitted flat against the
panel. If necessary
gently tap into final
position.
Insert large locking
nut as shown.
Note: Arrow on locking
nut must point towards
hole in edge of panel.
Tap in wooden dowel
as shown.
Note: Wooden dowels
must not stick out from
the edge by more than
10mm or they may
damage other panels.
b: Push fit the right
runner marked ‘R’
into the holes shown on
left side .
Insert large locking
nut as shown.
Tap in wooden dowel
as shown.
Finished
front edge
Finished
front edge
Finished
front edge
Fit the fixed shelves
to the left divider
Push the 2 fixed shelves
. onto the left divider
and secure with 4
screws .
D
D
D
D
11
11
8
11 8
D
Fit the right divider
Push the right divider
onto the 2 fixed shelves
. and secure with 4
screws .
11
9
D11
11
9
Step 9

Finished
front edge
Finished
front edge
D
D
D
D
Assembly Instructions
9
Step 10
A
A
A
A
A
A
A
A
Prepare the top and
base
Tap 4 wooden dowels
into the top .
Tap 4 wooden dowels
into the base .
A
A
Finished
front edge
plain chipboard surface
4
5
Finished
front edge
4
5
9
8
plain chipboard surface
D
D
D
D
4
5
Fit the top and base
Push the top and
base onto the 2
dividers and and
secure with 8 screws .
Step 11
4
5
8 9
D

Finished
front edge
Assembly Instructions
10
Step 12
L
L
L
J
Prepare the left end
Push a rail holder into
the left end . Make
sure that it is fitted
straight, in line with the
panel edges and then
secure with screw .
Fit 3 hinge plates onto
the left end , making
sure that the slot is
facing towards the
finished front edge.
J
6
L
6
6
L
L
L
J
7
Finished
front edge
Step 13
Prepare the right end
Push a rail holder into
the right end . Make
sure that it is fitted
straight, in line with the
panel edges and then
secure with screw .
Fit 3 hinge plates onto
the right end , making
sure that the slot is
facing towards the
finished front edge.
J
7
L
7
G
G
G
G

D
D
D
D
Assembly Instructions
11
Step 14
Fit the right end
Push the right end
onto the top and
base and secure with
4 screws .
Step 15
7
5
4
7
4
5
D
A
A
Prepare the 2 rails
Tap 2 wooden dowels
into each of the 2 rails .
A
plain chipboard surface
10 x 2
10

D
D
Assembly Instructions
12
Step 16
Step 17
7
plain chipboard surface
10
10
5
10
10
Fit the 2 rails
2 people are needed
here
Push the 2 rails onto
the right end and
secure with 2 screws .
10
7
D
D
D
D
D
D
D
6
4
Fit the left end
Push the left end
onto the top , the
base and the 2 rails
. and secure with 6
screws .
6
4
5
10
D
Note: Support this rail
until the left side has been
fitted in the next step.

Assembly Instructions
13
Step 18
y
x
x
y
yy
b:
H
The measurement from top corner X to bottom corner X must be
equal to the measurement from top corner Y to bottom corner Y
a:
17
18
18
17
18
18
Fit the back panels
a: Square up the unit by
making sure that
measurement x:x equals
y:y.
Place the short back
and the 2 long backs
down onto the unit as
shown.
Make sure that
the 3 backs are
pushed up tight
against each
other and that
they meet over
the back edges
of the dividers.
b: Nail around
the outside edges
of the 3 backs.
Note: Do not nail where
the backs meet. Nails
should be spaced about
150mm apart.
Note: Do not
nail where the
backs meet.
Step 19
Secure the backs
Tap the nail screws
through the back holders
. and down between
the backs and
into the back edge
of the divider.
Keep tapping the
nail screws in
until the back
holders dig
into the small
and large back.
Stand the unit up for
the next step.
Warning: The
unit is heavy.
Lift with care.
17
18
H
Q
P
P
Note: If ever you need to take
the backs off to dismantle the
unit, the nail screws can be
taken out using a screwdriver. E
F
Q
P
17 18
Q
P
QP +
QP +
x 4
x 4

Insert drawer
Lift front of drawer whilst
inserting to overcome
the ‘stop’ system.
Note: To ensure that
your drawer runs
smoothly, spray a small
amount of furniture
polish into the grooves.
Assembly Instructions
14
Step 20
Prepare left and right
side
Separate runners .
a: Push fit the left
runner marked ‘L’ into
the holes shown on left
side .
Note: Runners must be
be fitted flat against the
panel. If necessary
gently tap into final
position.
Insert large locking
nut as shown.
Note: Arrow on locking
nut must point towards
hole in edge of panel.
Tap in wooden dowel
as shown.
Note: Wooden dowels
must not stick out from
the edge by more than
10mm or they may
damage other panels.
b: Push fit the right
runner marked ‘R’
into the holes shown on
left side .
Insert large locking
nut as shown.
Tap in wooden dowel
as shown.
Step 21
Fit the hanging rails
and drawers
Push the large hanging
rail and 2 small
hanging rails into the
rail holders .
Lift front of drawer whilst
inserting to overcome
the ‘stop’ system.
Note: To ensure that
your drawer runs
smoothly, spray a small
amount of furniture
polish into the grooves.
13
14
J
13
14
J
14
14
13
Ix 4
Fit the shelf studs
For each of the 2
loose shelves , insert
4 shelf studs . Ix 4
I
12

Assembly Instructions
15
Step 22
Step 23
Prepare the 4 doors
Push fit 3 hinges into
each large door and
small door .
Secure each hinge with
2 screws .
Note: Before securing
with the screws, make
sure that the hinges are
positioned at 90 degrees
with the edge of the
door.
G
M
15
16
M
G
G
90
M
M
G
G
M
G
G
M
G
G
M
G
G
M
G
G
12
12
Fit the loose shelves
Lower the 2 loose
shelves down onto
the shelf studs .
I
12
15
16
x 2
x 2

Insert drawer
Lift front of drawer whilst
inserting to overcome
the ‘stop’ system.
Note: To ensure that
your drawer runs
smoothly, spray a small
amount of furniture
polish into the grooves.
Assembly Instructions
16
Step 24
Drill a handle hole in
each large door
Important: Please follow
these instructions
carefully.
Lay the 2 large doors
down onto a smooth
surface.
Check that the hinges
and holes are in the
same place as the
diagrams.
Note: We recommend
the use of a small piece
of waste wood, placed
behind the hole while
drilling, to reduce the
possibility of any
breakout.
Using the pilot hole in
the rear face of the door,
drill through the hole
indicated opposite, using
a 2.5mm diameter drill.
Turn the door over and
open out the 2.5mm hole
that you have just drilled
by drilling back through it
with a 5mm drill.
IMPORTANT
Carefully choose which hole
you need to drill in each door
15
ONLY drill this hole
in 1 large door
Small piece of
waste wood
This will be the
left large door
ONLY drill this hole
in 1 large door
Small piece of
waste wood
This will be the
right large door
15
15

Small piece of
waste wood
Small piece of
waste wood
Assembly Instructions
17
Step 25
Drill a handle hole in
each small door
Important: Please follow
these instructions
carefully.
Lay the 2 small doors
down onto a smooth
surface.
Check that the hinges
and holes are in the
same place as the
diagrams.
Note: We recommend
the use of a small piece
of waste wood, placed
behind the hole while
drilling, to reduce the
possibility of any
breakout.
Using the pilot hole in
the rear face of the door,
drill through the hole
indicated opposite, using
a 2.5mm diameter drill.
Turn the door over and
open out the 2.5mm hole
that you have just drilled
by drilling back through it
with a 5mm drill.
IMPORTANT
Carefully choose which hole
you need to drill in each door
16
ONLY drill this hole
in 1 small door
This will be the
left small door
ONLY drill this hole
in 1 small door
This will be the
right small door
16
16

Insert drawer
Lift front of drawer whilst
inserting to overcome
the ‘stop’ system.
Note: To ensure that
your drawer runs
smoothly, spray a small
amount of furniture
polish into the grooves.
Assembly Instructions
18
Step 26
Fit doors and handles
Note: The easiest way to
attach each door and
. is to fit the top hinge
first, then align and fit the
other hinges.
a: Push the hinge
onto the front part of the
hinge plate .
The recess at the bottom
of screw B goes into the
slot in the hinge plate.
b: Keep the hinge
FLAT against the hinge
plate as you slide it
across as far as it will go.
Tighten screw A.
c: The hinge must be
flat against the hinge
plate prior to any
adjustment.
d: The hinge must
NOT be AT AN ANGLE
to the hinge plate
when assembled.
This would indicate that
the recess at the bottom
of screw B had not
located in the slot in the
hinge plate and the hinge
would not be secure.
Remove the hinge from
the hinge plate and then
re-assemble being
careful to follow
instructions a-c.
e: Attach a handle to
each door and
using screws .
M
M
M
L
L
L
M
L
O
E
15
16
15 16
a: b:
c: d:
L
M
L
L
B
L
M
M
M
A
M
L
B
e:
15
15
16
16
Note: When fitting the doors,
make sure that the handle
hole you had to drill is nearest
to the bottom of the door.
O
O
O
O
E

Assembly Instructions
19
Step 27
b:
c:
d:
a:
Adjust the doors if
needed
a: Before adjusting the
doors, use a spirit level
to check the base (or
top) of the unit is level,
front-to-back and
side-to-side in the 3
positions shown.
Use suitable packing
pieces (not supplied) to
make the unit level
BEFORE making any
adjustment to the hinges,
as shown.
b: Height adjustment.
Loosen screws A on
hinge plates and move
door up or down as
required.
Retighten screw A.
c: Forward and Back
adjustment.
Loosen screw B on hinge
plate and move door in
or out as required.
Retighten screw B.
d: Sideways
adjustment.
To move door ‘out’
loosen screw C.
To move door ‘in’ tighten
screw C.
A
A
B
C
