Argos Matrix Glass Nest Table User manual

Matrix - Glass Nest Table
Assembly Instructions - Please keep for future reference 609/1903
Small dimensions
Width - 33cm
Depth - 33cm
Height - 45cm
Important - Please read these instruction fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Issue 1 - 2/01/10
Width - 45cm
Depth - 35cm
Height - 50cm
609/1910
Large dimensions

1
Safety and Care Advice
Important - Please read these instru ctions fully before starting assembly
components and tools listed on
pages 2.
plastic bags and separate them
into their groups.
away from the work area, small
parts could choke if swallowed.
space to layout the parts before
starting.
the product, this could cause
damage.
room) as possible.
surface to avoid damaging the
easier with 2 people.
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
carefully and responsibly.
and mild detergent, do not use
bleach or abrasive cleaners.
there are no loose screws on
this unit.
discarded with household
waste. Take to your local
authority waste disposal centre.
Care and maintenance
Keep These Instructions For Future Reference
This product complies with
BSEN 12521:2009
Argos plc
489-499 Avebury Boulevard
Central Milton Keynes
MK9 2NW
Batch No./Date of manufacture:
Warning
Do not place very hot or very
cold items against or in close
proximity to glass surfaces
unless an adequately thick
insulating material is used to
prevent such items from coming
into contact with the glass.
Do not sit or stand upon the
glass surface(s).
Do not use the glass as a
chopping surface. Do not strike
the glass with hard or pointed
items. If a glass component is chipped
or broken, stop using the product
and consult the manufacturer or
supplier.

Components - Panels
Please check you have all the pan els listed below
2
Metal rod x 4
( 0.7 x 43.5 cm )
2
Metal tube x 4
( 5.08 x 42 cm )
3
Top glass shelf x 1
( 33 x 33 cm )
1Top glass shelf x 1
( 45 x 35 cm )
5
Metal rod x 4
( 0.7x 48.5 cm )
6
Feet x 8
( 5.2 x 1.3 cm )
4
Metal tube x 4
( 5.08 x 47 cm )
7
Ruler - Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110 120105 115 125 130 135 140 145 150 155 160 165 170

Assembly Instructions
Step 1- Large Table
Step 2- Large Table
Attaching metal rods
Please attach the 4pcs
of metal rod onto
panel as shown.
Metal rod onto panel
.
1
5
Attaching metal
tubes
Attach 4 pcs of metal
tubes through 4 pcs
of metal rods as
shown.
Repeat this step for
Small Table.
Metal tubes through
metal rods .
3
1
3
D
1
6
5
1
5
1
5
1
5
2
7
7
77
1
3
3
33
5
1
51
5
1
5
6
2
7
5

Assembly Instructions
Step 3 - Large Table
Attaching foot
Finger tighten 4pcs of
feet onto the unit as
shown.
Repeat this step for
Small Table.
Assembly is complete
for Small Table and
Large Table.
Assembly Instructions
Step 4
4
4
4
4
D
4
4
1
5
1
5
Large Table
Small Table
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
