Argus Security AC-BS-01 User manual

Products compatibility and general description
These products are to be used in conjunction with the following Altair, Altair Lite and Altair Plus detectors:
A1000 (AT0610CPR) Altair smoke detector AC-BS-01, AC-BSB-23W-01, AC-BSB-23R-01
A2000 (AT0610CPR) Altair smoke / temperature detector AC-BS-01, AC-BSB-23W-01, AC-BSB-23R-01
A3500 (AT0610CPR) Altair temperature detector AC-BS-01, AC-BSB-23W-01, AC-BSB-23R-01
A1000L (AT0210CPR20140225) Altair smoke detector without isolators AC-BS-01, AC-BSB-23W-01, AC-BSB-23R-01
A2000L (AT0210CPR20140225) Altair smoke / temperature detector without isolators AC-BS-01, AC-BSB-23W-01, AC-BSB-23R-01
A3500L (AT0210CPR20140225) Altair temperature detector without isolators AC-BS-01, AC-BSB-23W-01, AC-BSB-23R-01
A1000+ (AT0610CPR) Altair Plus smoke detector AI-BS-01, AI-BSB-23W-01, AI-BSB-23R-01
A2000+ (AT0610CPR) Altair Plus smoke / temperature detector AI-BS-01, AI-BSB-23W-01, AI-BSB-23R-01
A3500+ (AT0610CPR) Altair Plus temperature detector AI-BS-01, AI-BSB-23W-01, AI-BSB-23R-01
(In brackets, DOP reference)
These products are compatible only with control panels that use the Vega protocol.
In order to work, these sounder bases require a suitable host detector.
Following the triggering of an alarm condition on the host detector, the Altair Flexiplus base sounder activates its acoustic output, previously
selected through its selector; similarly, Altair Plus Flexiplus base sounders activate the acoustic output, but in this case its pattern is previously
selected from the control panel.
Base sounders equipped with VAD (Visual Alarm Device), in conjunction with the acoustic signal, also emit an alarm visual signal; specifically:
- for AC-BSB-23W-01 and AI-BSB-23W-01 white optical alarm signal
- for AC-BSB-23R-01 and AI-BSB-23R-01 red optical alarm signal.
Product parts
Ceiling mounting bracket (picture 1)
1. Sound diffuser cone.
2. Loop cables passage.
3. Pre-cut holes for screwing the bracket to the ceiling.
4. Fixing pins.
Base sounder (picture 2)
1. Adaptor base for the host detector.
2. Loop cables passage.
3. Selector for the acoustic tone, volume and VAD output intensity (Altair
Flexiplus only).
4. Bracket-base sounder screw fixing location.
5. VAD output.
6. Acoustic alarm signal outlet.
7. Bracket’s pins hosting holes.
AC-BS-01 ALTAIR FLEXIPLUS BASE SOUNDER
AC-BSB-23W-01 ALTAIR FLEXIPLUS BASE SOUNDER + WHITE VAD
AC-BSB-23R-01 ALTAIR FLEXIPLUS BASE SOUNDER + RED VAD
AI-BS-01 ALTAIR PLUS FLEXIPLUS BASE SOUNDER
AI-BSB-23W-01 ALTAIR PLUS FLEXIPLUS BASE SOUNDER + WHITE VAD
AI-BSB-23R-01 ALTAIR PLUS FLEXIPLUS BASE SOUNDER + RED VAD
