ARIETE Moka Aroma Espresso 1337 User manual
COD. 4055106100 REV. 2 del 12/02/2013
827070
MOD. 1337
De’ Longhi Appliances Srl
Divisione Commerciale Ariete
Via San Quirico, 300
50013 Campi Bisenzio (FI)
E-Mail: [email protected]
Internet: www.ariete.net
Fig. 1
Fig. 2
Fig. 3
S
Fig. 9
Fig. 7 Fig. 8
Fig. 6
Fig. 5
Fig. 4
A
Fig. 10 Fig. 11
Fig. 12
P
B
CD
E
F
G
H
I
L
M
N
O
QT R
Fig. 16Fig. 15
Fig. 13
U
Fig. 14
W
VZ
11
Even if the appliances are made in conformity with the European regulatory specications in force and therefore all poten-
tially hazardous parts are protected. Carefully read these warnings and use the appliance only for the use it is designed for
in order to prevent accidents and damage. Keep this manual close by for future consultation. If you should decide to give
this appliance to other people, remember to also include these instructions.
The information provided in this manual is marked with the following symbols indicating:
Danger for children Warning of burns
Danger due to electricity Warning – material damage
Danger of damage originating from other causes
You may use your appliance to prepare coffee and cappuccino; and thanks to the possibility of dispensing hot water, you can
also prepare tea and tisanes. This appliance is designed only for private use, and is therefore to be considered unsuitable
for commercial or industrial purposes.
No other use of the machine is contemplated by the manufacturer, which is exempt from any liability for all types of damages
caused by improper use of the machine. Improper use also results in any form of warranty being forfeited.
The construction characteristics of the appliance this publication refers to do not allow the user to be protected from a direct
jet of steam or hot water.
Danger of burns – When dispensing hot water and steam, do not direct the jets towards others or yourself. Hold
only the plastic part of the tube.
Use only containers made of material “for foods”.
• This appliance is designed solely for household and similar uses such as:
- in cooking areas used by personnel of shops, ofces and other professional environments;
- on farms;
- guests of hotels, motels and other residential environments;
- bed and breakfast type of environments.
• We decline any responsibility resulting from misuse or any use other than those covered in this booklet.
• We suggest you keep the original box and packaging, as our free-of-charge service does not cover any damage resulting
from inadequate packaging of the product when this is sent back to an Authorised Service Centre.
• This product complies with the 2006/95/EC Directive and EMC Directive 2004/108/EC.
• This appliance is not suitable for use by people (children included) with physical, sensorial or mental disabilities; Users
lacking experience and knowledge of the appliance, or those who have not been given the user’s instructions, must be
supervised by a person responsible for their safety.
• Children must be supervised at all times to ensure they do not play with the appliance.
• Do not leave the packaging near children because it is potentially dangerous.
• In the event that this appliance is to be disposed of, it is suggested that the power chord is cut off. It is also recommended
that all potentially dangerous components are rendered harmless to prevent children hurting themselves when playing
with the apparatus.
12
• Before connecting the appliance to the power supply, make sure that the voltage indicated on the plate on the bottom of
the machine corresponds to the local mains voltage.
• The use of extension leads, which have not been authorised by the appliance manufacturer, may cause damage and
accidents.
• Before lling the tank with water, remember to always disconnect the appliance at the socket.
• If the electric cable is damaged it must be replaced by the manufacturer or its Technical Assistance Service, or in any case
by a person with similar qualications, in order to avoid any risk.
• Never let the live parts come into contact with water: this may cause a short circuit
• Unplug before any cleaning or maintenance operations.
• Before moving the appliance, disconnect it from the mains and empty the tank (use the handle for tilting the appliance
so the water comes out of the spout), paying close attention that the water does not dampen the switch area to prevent
inltrations inside of the electrical parts.
• Do not immerse the appliance in water or other liquids.
• Choose a sufciently well lit and clean environment, with an easily accessible electric socket.
• Avoid putting excessive quantities of water into the tank.
• The appliance is not to be used if it has been dropped, if there are visible sign of damage, faults or suspected defects after
dropping or if it is leaking water. To prevent any accidents, all repairs, including the replacement of the power cord, must
be carried out by an Authorised Service Centre or, in any case, by qualied personnel. Otherwise, the warranty may be
revoked.
• Never direct the steam or hot water jet towards parts of the body; handle the steam/hot water spout with care: risk of
scalding!
• The appliance’s external metallic parts must not be touched when the machine is functioning as it could cause burns.
• If water does not come out of the lter holder, it may be because the Thermocream® lter is clogged. Stop the brewing
and wait ten seconds. Remove and disconnect the lter holder because any remaining pressure could cause splashes or
squirts. Then clean as explained in the relevant paragraph.
• Place the machine on a stable surface where it cannot be knocked over.
• Never use the machine without water because the pump will burn out.
• Never ll the water tank with hot or boiling water.
• Do not place the machine on very hot surfaces or near open ames in order to prevent damage to the body.
• The cable must not touch any hot parts of the machine.
• Do not use sparkling (carbonated) water.
• Use only ground coffee or pods bearing the E.S.E. standard mark.
• Never put substances other than coffee into the lter holder. They could cause serious damage to the appliance.
• Do not leave the machine at a room temperature below 0°C because the water remaining in the boiler could freeze and
cause damage.
• Never use the appliance outdoors.
• Do not expose the appliance to atmospheric agents (rain, sun…).
• Before cleaning the appliance always unplug it and allow it cool down. Clean only with a non-abrasive cloth that has been
slightly dampened with water, adding a few drops of mild, non-aggressive detergent (never use solvents that damage
plastic).
•
13
A - Machine body
B - Cup-resting grill
C - Drip tray
D - Power cord + Plug
E - Maxi Cappuccino attachment and wand for water and
steam supply
F - Water tank
G - Filter holder for ground coffee
H - Thermocream® Disc
I - Perforated silicone disc
L - Thermocream® Filter
M - Coffee measure/presser
N - “On” indicator light
O - On-off switch
P - Steam dispensing cock
Q - Coffee dispensing indicator lamp
R - Coffee dispensing switch
S - Boiler temperature indicator lamp
T - Steam function switch
U - Pod lter holder
V - Pod lter
W - Drain pan
Z - Tank cover
The following machine identication data are shown on the plate placed underneath the machine’s standing base:
• manufacturer and CE mark
• model (Mod.)
• serial number (SN)
• electrical supply voltage (V) and frequency (Hz)
• absorbed electric power (W)
• assistance toll-free number
Always give the model and serial number to the Authorised Service Centres when requesting assistance.
Check that the voltage of the domestic network is the same as that indicated on the technical information plate of the appli-
ance. Place the appliance on a stable surface.
Open the tank lid (Z). Fill the tank up to the level marked MAX (Fig. 3).
While lling, pay close attention that the water does not dampen the switch area to prevent inltrations inside the electrical
parts.
Insert the plug into the socket, which must be earthed.
After having lled the tank with cool tap water, start the machine by pressing the button (O). Indicator lamps (N) and (S)
turn on to indicate that the machine is on and that the internal boiler has started to heat up, respectively. Press the coffee
dispensing switch (R) until you see water come out of the lter holder seat (Fig. 4).
Then close the cock (P) by turning it clockwise, and press the coffee dispensing switch (R) to make the water stop coming
out. The machine will be ready to make coffee when the indicator lamp (S) turns off.
Put the Thermocream® Disc (H), the perforated silicone disc (I) and the Thermocream® Filter (L) into the lter holder in the
order indicated (Fig. 5). Measure out the coffee in the lter and lightly press with the specially provided presser: completely
ll two measures for two cups of coffee, and ll only one for one cup. Insert the lter holder into its seat.
Tighten well by turning it from left to right while making sure you have hooked it properly onto the ange (Fig. 6).
If too much ground coffee is put inside the lter, turning the lter holder may prove difcult and/or you may get leaks
from the lter holder when the coffee is being dispensed.
It is advisable to let the lter holder heat up a few minutes in its seat before making a cup of coffee so that the rst cup is
14
piping hot, too. This will not be necessary for the cups of coffee that follow.
To start dispensing, press the switch (R): the coffee will start coming out of the spouts of the lter holder. Press the switch
(R) again to stop it. The minimum serving of coffee is 50 ml.
Like in professional coffee machines, do not remove the lter holder when the dispensing switch (R) is on; danger
of burns!
Wait about ten seconds after the coffee has been dispensed before removing the lter holder; To remove it, turn it
slowly from right to left so as to prevent splashes or spurts of water or coffee.
When the machine is in stand-by, the lamp (S) will turn on and off periodically. This shows that the boiler thermostat is trip-
ping, which serves to keep the water temperature optimum.
It is a good idea to start dispensing the coffee only when this indicator lamp (S) is off.
To make coffee with pods you must use the specic pod lter (U) that came with the coffee maker as described below:
1 Put the drip tray (W) and pod lter (V) inside the lter holder (U).
2 Place the pod in the lter ring (Fig. 14).
3 Push the pod towards the bottom of the lter with your ngers (Fig. 15).
4 The pod must be well centred and placed inside the lter.
5 Now it is possible to put the lter holder in its seat. Tighten the lter holder while making sure you have hooked it properly
onto the ange (Fig. 6).
6 The pod could remain stuck in the upper part of the machine after making the coffee and when removing lter holder. To
remove it, tilt the lter holder (Fig. 16) so the pod can fall onto it.
In order to always get an excellent cup of coffee, buy the pod that bears the E.S.E. compatibility mark.
No special operation is necessary when the water in the tank runs out because the machine has a special self-priming valve.
All you have to do is ll the tank with cool tap water up to the MAX level after unplugging it from the socket-outlet. Pay close
attention that the water does not dampen the switch area to prevent inltrations inside the electrical parts.
To prepare a cappuccino or hot chocolate or to heat any other beverage, press the switch (T); the indicator lamp (S) turns
on. When it turns off, the machine will be ready to generate steam.
Now open the steam dispensing cock (P) anti-clockwise, having the foresight to position a cup underneath the Maxi Cappuc-
cino device (E) Fig. 8: at rst a little water will come out, immediately followed by a strong jet of steam.
Plunge the wand all the way into the pot of milk (Fig. 9) and open the dispensing cock (P). During these operations you may
notice that the warning light (S) goes on and off from time to time, indicating that the boiler thermostat is keeping the water
required for the steam supply at the right temperature.
After the cappuccino is prepared, press the switch (T) to cut out the steam function.
To prepare a cup of coffee right after making cappuccino, it is necessary to bring the boiler back to the coffee preparation
temperature by performing these operations:
If you want to cool down the boiler faster, place a container underneath the cappuccino maker, press switch (R) and at the
same time keep the cock (P) open; Make water come out of the Maxi Cappuccino device until when the indicator lamp (S)
turns back on; Now close the cock (P) and turn the switch (R) off. Wait for the lamp (S) to turn off before making another
cup of coffee.
15
When the machine is in the coffee-ready position, i.e. with the lamp (S) off, place a cup underneath the spout (E) and press
the coffee dispensing switch (R). Open the steam dispensing cock (P) immediately afterwards; in this way hot water will
come out of the spout. The maximum quantity for two cups is 200 ml.
The ground coffee in the lter holder has to be pressed lightly. Whether the coffee is stronger or weaker depends on the
degree the coffee is ground, the quantity put into the lter holder and the pressing. Just a few seconds are needed for the
coffee to ow down into the cups. If the dispensing time is longer, this means that the coffee is ground too ne or that the
coffee put into the lter holder has been pressed too much.
All cleaning operations described below must be performed with the machine off and with the electric plug discon-
nected from the socket-outlet.
Regular maintenance and cleaning preserve and keep the machine efcient for a longer amount of time. Never
wash machine components in the dishwasher. Do not use direct jets of water.
All operations must be performed when the machine is cold.
Check that the holes are not clogged and if so, clean them with a small brush (Fig. 10). Dispense boiling water from the lter
holder with the lter inside, without coffee grounds, after placing a glass underneath the dispenser in order to dissolve or
remove any coffee residue or impurities.
Slowly remove and disconnect the lter holder because any remaining pressure could cause splashes or squirts.
It is advisable to thoroughly clean the lter (L) about every 3 months using Ariete COFFEE CLEAN detergent tabs, which
can be found at retail stores and the Authorised Service Centres, following the instructions inside the package. As an
alternative, you:
• Put a dishwasher detergent tab into the lter (without coffee) when the machine is hot (after heating for at least ve min-
utes).
• Couple the lter holder to the machine and put a container underneath the lter holder.
• Press the coffee button to start dispensing water, and dispense the water for 15-20 seconds.
• Stop the water supply and let the tab act for at least 15 minutes while keeping the lter holder coupled on the machine.
• Repeat the water dispensing operation by operating the pump for about 15-20 seconds, and then letting it rest for another
15-20 seconds, until two tanks of water are used up.
• Remove the lter holder from the machine, remove the lter and rinse it well under running tap water.
• Turn off the machine, disconnect the power cable from the socket-outlet and clean the coupling seat of the lter holder
with a sponge in order to remove any detergent residue from the shower disc.
• Turn the machine back on, couple the lter holder once again and dispense at least 2 cups of water again to complete the
rinsing.
If the coffee machine is used daily, it is advisable to carry out the cleaning operation at least every three months.
Start dispensing with the lter holder connected and without the pod inside by pressing the button (R) after having placed
a glass underneath the lter holder. In this way any coffee residue or impurities present in the lter holder will dissolve and
be removed.
Wash the silicone disc (I) under running water, bending it slightly on the sides in order to free the centre hole of any residue
of coffee grounds that could clog it (Fig. 11).
With time, coffee residue may accumulate on the lter holder seat. It can be removed with a toothpick, a sponge (Fig. 12), or
by letting water run through without tting the lter holder (Fig. 4).
16
Perform this operation when the chrome-plated pipe is cold so as to prevent burns.
Unscrew the device (E) from the small pipe and wash it with running water. The small pipe can be cleaned with a non-
abrasive cloth. Screw the cappuccino maker back on as far as it will go. If necessary, clean the small steam outlet hole
again with a pin. After use, always let the steam nozzle run for a few seconds so to free the outlet from any possible residue.
Periodically clean the inside of the tank with a sponge or damp cloth.
Remove the grill (B) and wash it under running water; remove the drip tray (C) from the machine, empty it and wash it under
running water.
Clean the xed parts of the machine using only a damp, non-abrasive cloth so as to not damage the body.
Good maintenance and regular cleaning preserve and keep the machine efcient for a longer amount of time, considerably
limiting the risks of lime deposits forming inside the appliance. However, should your coffee machine fail to work properly
as a result of the frequent use of hard, high calcium content water, you may perform a decalcication procedure to restore
its operational efciency. For this purpose you must use only Ariete’s NOCAL, citric acid-based decalcifying products. This
product is easily found at the Ariete technical service centres. Ariete does not assume any responsibility whatsoever for
damage to components inside the coffee machine caused by the use of non-compliant products containing chemical addi-
tives. Should you need to decalcify your appliance, please follow the instructions which come with the decalcifying product.
If the machine is put out of service, electrically disconnect it. Empty the water tank. Use the handle to tilt the appliance
and make the water come out of the spout while paying close attention that the water does not dampen the switch area to
prevent inltrations inside electrical parts. Empty the drip tray and clean it (see paragraph “Cleaning the appliance”).
If there are problems with operation, immediately turn off the machine and unplug it from the socket-outlet.
PROBLEMS CAUSES SOLUTIONS
Air has probably entered the
circuit and deactivated the pump.
Check that the water level in the tank is correct. If neces-
sary, ll it with cool tap water. Repeat the operations
described in the “Preliminary phases for use” paragraph.
The steam exit hole on the
dispenser wand is clogged
Unclog any deposits that may have formed in the hole of
the dispenser wand with a pin.
You are trying to dispense the
coffee with the steam function
on. Check that the steam
function button has not been
unintentionally pressed.
Stop the coffee delivery. Press the button (T) to cut out
the steam function. Wait for the lamp (S) to turn off before
making another cup of coffee.
There is little water and the pump
does not suck it up.
Check that the water level in the tank is correct. If neces-
sary, ll it with cool tap water.
The steam exit hole on the
dispenser wand is clogged.
Unclog any deposits that may have formed in the hole of
the dispenser wand with a pin.
17
PROBLEMS CAUSES SOLUTIONS
Probably an excess amount of
ground coffee has been placed
in the lter ring preventing the
lter ring from being correctly
tightened into its housing.
Slowly remove and disconnect the lter holder because
any remaining pressure could cause splashes or squirts.
Clean the coupling seat with a sponge (Fig. 12). Repeat
the operation placing the correct quantity of coffee in the
lter.
Residues of ground coffee have
remained on the gasket of the
lter holder coupling seat.
Clean the seal with a toothpick or a sponge (Fig. 12).
The hole of the silicone disc is
clogged.
Wash the silicone disc (I) under running water, bending it
slightly on the sides in order to free the centre hole of any
residue of coffee grounds that could clog it (Fig. 11).
The exit holes of the lter
containing coffee grounds are
clogged.
Slowly remove and disconnect the lter holder because
any remaining pressure could cause splashes or squirts.
Clean the clogged lter holes with a small brush or a pin.
Clean the lter using Ariete COFFEE CLEAN tabs, follow-
ing the instructions provided in the package.
Faulty pod. Replace the pod in the lter holder (U).
The holes of the perforated disc
in the lter holder coupling seat
are clogged.
Turn on the machine without the lter holder, making the
water run. Turn on the machine without the lter holder,
making the water run. If the water still does not come out
from all the holes evenly, carry out the descaling cleaning
operation using the Ariete NOCAL product found at Ariete
service centres, following the instructions provided in the
package.
The exit holes of the lter
containing coffee grounds are
clogged.
Slowly remove and disconnect the lter holder because
any remaining pressure could cause splashes or squirts.
Clean the clogged lter holes with a small brush or a pin.
Clean the lter using Ariete COFFEE CLEAN tabs, follow-
ing the instructions provided in the package.
The coffee blend is ground too
ne.
Try using coarser coffee blends.
The coffee blend is pressed
down too much.
amper coffee inside the lter using less pressure.
The tanks is not inserted well. Fit the tank securely by pushing it as far as it will go.
The hole of the silicone disc is
clogged.
Wash the silicone disc (I) under running water, bending it
slightly on the sides in order to free the centre hole of any
residue of coffee grounds that could clog it (Fig. 11).
There is little water and the pump
does not suck it up.
Check that the water level in the tank is correct. If neces-
sary, ll it with cool tap water.
Faulty pod. Replace the pod in the lter holder (U).
Broken pod. Remove the pod lter holder (U), clean the seat with a
sponge, and put a new pod inside.
The blend has been ground too
coarsely.
A more nely ground blend must be used to obtain a more
concentrated and hotter coffee. Anyhow, this problem is
easily solved thanks to the Thermocream® System, which
always guarantees hot coffee accompanied by a reach
cream, even with coarsely ground beans.
Other manuals for Moka Aroma Espresso 1337
2
Table of contents
Other ARIETE Coffee Maker manuals
ARIETE
ARIETE Minuetto User manual
ARIETE
ARIETE 1389A User manual
ARIETE
ARIETE 1341 User manual
ARIETE
ARIETE cafe retro User manual
ARIETE
ARIETE 1381 User manual
ARIETE
ARIETE You&Me User manual
ARIETE
ARIETE PICASSO CIALDISSIMA User manual
ARIETE
ARIETE 1384 User manual
ARIETE
ARIETE Moka aroma elettrica User manual
ARIETE
ARIETE cafe retro User manual
ARIETE
ARIETE 1450 User manual
ARIETE
ARIETE Moka Aroma Espresso 1337 User manual
ARIETE
ARIETE Cialdissima mp50 User manual
ARIETE
ARIETE Mokita User manual
ARIETE
ARIETE Cafe Roma De Luxe User manual
ARIETE
ARIETE Cafe Chic 1377 User manual
ARIETE
ARIETE 1389 User manual
ARIETE
ARIETE Moka aroma 1358A User manual
ARIETE
ARIETE 1396 User manual
ARIETE
ARIETE Moka Aroma Espresso 1337 User manual
