Aritech RF-DD1012PI-K4 User manual

© 2021Carrier 1 / 2 P/N 466-2598 (EN) • REV L • ISS 19JAN21
RF-DD1012PI-K4 / TX-2511-03-1 / RF4112I4PI
Wireless Pet-immune Dual Detector Installation
Sheet
EN
DA
DE
ES
FI
FR
IT
NL
NO
PL
PT
SV
Figure 1: Positioning the detector
Figure 2: Mounting instructions
Figure 3: Adjust the detection pattern
Figure 4: Jumpers
Figure 5: Installing the batteries
Start-up
2.3-3.0 m
A2
B2
A
B
C
C
B2
A2
B
A
B
A
C
A
C
A
Position EN rade 250131 G
A A2 + B2
BB2
Not EN 50131
compliant
0m
2 m (6 ft. 6 in.)
4 m (13 ft. 1 in.)
6 m (19 ft. 8 in.)
8 m (26 ft. 2 in.)
2 m (6 ft. 6 in.)
4 m (13 ft. 1 in.)
6 m (19 ft. 8 in.)
8 m (26 ft. 2 in.)
1 (39 ft. 4 in.)2.0 m
12 m range (39 ft. 4 in.)
2.4 m (7 ft. 10 in.)
(optimum)
2.3 m 2.6 m
5 curtains 5 curtains 1curtain9curtains
J1 J2
J1 J2
4 m
J1 J2
6 m
9m
12 m
1 1
2 2
3
5 years* 7 years*
* Battery life estimated
for typical usage
(50% motion,
50% non-motion)
1 min
Start-up

2 / 2 P/N 466-2598 (EN) • REV L • ISS 19JAN21
Figure 6: Walk test
WARNING! Lithium battery inside!
Risk of burned skin, blindness, or death.
Risk of explosion or disabled safeguard if the battery is
replaced by an incorrect type, subjected to extremely low
air pressure, or used with other equipment.
Disposal into fire or a hot oven, heating above 100˚C, mechanically
crushing or cutting, disassembling, recharging, short circuiting, or
exposing the battery to water can result in an explosion.
Contact information
www.firesecurityproducts.com or www.aritech.com. For
customer support, see www.firesecurityproducts.com.
EN: Installation Sheet
RF-DD1012PI-K4 and RF4112I4PI are wireless 433 MHz
pet-immune dual detectors. TX-2511-03-1 is a wireless 868
MHz GEN2 pet-immune dual detector.
Regulatory information
Manufacturer
PLACED ON THE MARKET BY:
Carrier Fire & Security Americas Corporation, Inc.
13995 Pasteur Blvd Palm Beach Gardens, FL 33418,
USA
AUTHORIZED EU REPRESENTATIVE:
Carrier Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Certification
RF-DD1012PI-K4 , TX-2511-03-1: EN 50131-2-4,
Security Grade 2, Environmental Class II.
Tested and certified by Telefication B.V.
Carrier Fire & Security hereby declares that this
device is in compliance with the applicable
requirements and provisions of all applicable rules
and regulations, including but not limited to the
Directive 2014/53/EU. For more information see:
www.firesecurityproducts.com
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or
dispose of it at designated collection points. For
more information see: recyclethis.info
Replacing the battery
Replace with the recommended batteries only:
• Panasonic® CR123A
Specifications
Model
RF4112I4PI
RF-
DD1012PI-K4
TX-2511-
03-1
Detection technology
Dual: PIR (9 curtains, view angle 86°),
Radar (Range Controlled)
Detectable range
4, 6, 9, and 12 m (selectable by J1 and
J2)
Pets
Up to 35 cm / 18 kg
Radar operating
frequency
5.725 to 5.875 GHz
Radar output power
(EIRP)
< −1.3 dBm
Target speed range
30 cm/s to 3 m/s
Battery type
3.0 V, 1300 mAh lithium
Current consumption
58 µA (avg.), 50 mA (max.)
Mounting height
EN certified
2.3 to 3.0 m (2.4 m typical)
2.3 to 2.6 m
Detector start-up time
1 min
Supervisory interval
18 min
Lock out timer
3 min
Operating frequency
433.05 to
434.79 MHz
433.05 to
434.79
MHz
868.60 to
868.70
MHz
Power output
<10 dBm
Protocol
433-63
433-80plus
GEN2
RF range (open air /
obstructed), typical
300 m / 40 m
600 m /
40 m
Operating temperature
EN −10 to +55°C
Relative humidity
95% max. noncondensing
IP/IK rating
IP30 IK02
Dimensions (LxWxH)
130 x 69 x 53 mm
Weight
176 g, including 2 batteries
Product warnings
and disclaimers
THESE PRODUCTS ARE INTENDED FOR
SALE TO AND INSTALLATION BY QUALIFIED
PROFESSIONALS. CARRIER FIRE &
SECURITY CANNOT PROVIDE ANY
ASSURANCE THAT ANY PERSON OR ENTITY
BUYING ITS PRODUCTS, INCLUDING ANY
“AUTHORIZED DEALER” OR “AUTHORIZED
RESELLER”, IS PROPERLY TRAINED OR
EXPERIENCED TO CORRECTLY INSTALL
FIRE AND SECURITY RELATED PRODUCTS.
For more information on warranty disclaimers and
product safety information, please check
https://firesecurityproducts.com/policy/product-
warning/ or scan the QR code.
