Arkon GPS-CV7107G3 User manual

GPS-CV7107G3 |Vehicle Specific Mounting Bracket for Most Portable GPS
!Safety Precautions
Do not install Arkon products over an air bag cover or within the air
bag deployment zone. Arkon Resources, Inc. assumes no responsi-
bility of liability for injury or death as a result of car crashes and/ or
air bag deployment.
Arkon is not responsible for any damages caused to your car, your
device, or yourself due to the installation or use of this pedestal mount.
The Mobile Mounting Specialists™
Consumer Hotline:
USA [phone]
INT’L [phone]
Monday - Friday 9 am - 5 pm, PST
www.arkon.com
Arcadia, CA 91006 USA
Designed in USA | Made in the USA & China
© Copyright 2010 Arkon Resources, Inc.
APTTO
Adapter Plate for
TomTom ONE
APTTOXL
Adapter Plate for
TomTom ONE XL / XL • S
Package Contents:
(1) CV-71-07-G3 - Pro.Fit™ Vehicle Specific Mounting Bracket*
(1) SP-SBH-Kit - Dual-T Head with Swivel Ball Socket & Locking Ring
(1) APTTO - Adapter plate for TomTom ONE pattern
(1) APTTOXL - Adapter plate for TomTom ONE XL pattern
(1) APTTGO520 - Adapter plate for TomTom GO pattern
(1) APTTEP - Adapter plate for TomTom EasyPort™ pattern
(1) APTTSE - Adapter plate for TomTom Start™ and Ease™ pattern
(1) APMM200 - Adapter plate for Mio Moov 200 Series pattern
(1) APMM300 - Adapter plate for Mio Moov 300 Series and newer Magellan GPS patterns
Do not place mount in or near an air bag deployment zone.
!
Installing the Vehicle Specific Moutning Bracket
Connect Dual-T Head to VSM Mounting Pedestal
Step 1.
Patent Pending
See the included ProFit VSM Bracket manual for instructions
on installing the VSM Bracket. Arkon reccomends that you
have the VSM bracket professionally installed. Arkon is
not responsible for any unintended damaged caused by
installation of the VSM Bracket.
Step 1.
Step 1.
Slip the tightening ring (A) over the VSM bracket ball. Snap the
dual-T head adapter plate (B) on to the bracket ball (C). Screw
the tightening ring over the adapter plate until securely holding
the plate. Adjust the angle as needed. Step 1.
Connect TomTom ONE, XL, or XL•S Device to Pedestal
Slide the adapter plate up into the grooves on the back of the
TomTom ONE, XL, or XL •S device (not included, sold separately).
Connect Adapter Plate for TomTom ONE or ONE XL to Device
APTTEP
Adapter Plate
for EasyPort™
APTTSE
Adapter Plate
for TomTom
Start™ & Ease™
APMM200
Adapter Plate
for Mio Moov
200 Series
APMM300
Adapter Plate
for Mio Moov
300 Series & newer
Magellan GPS
APTTGO-S20
Adapter Plate for
TomTom GO
Continued on other side...
A
CV-71-07-G3
Pro.Fit™
Vehicle Specific
Mounting Bracket
(See included Pro-Fit
manual for instructions
& specific car compatibility)
SP-SBH-Kit
Dual-T Tab
Connects to
adapter plates
TomTom ONE 125 (TomTom EasyPort Mount)
TomTom ONE 130, ONE 130-S (TomTom EasyPort Mount)
TomTom ONE 140, ONE 140-S (TomTom EasyPort Mount)
TomTom XL 325, XL 325-S (TomTom EasyPort Mount)
TomTom XL 330, XL 330-S (TomTom EasyPort Mount)
TomTom XL 340, XL 340-S (TomTom EasyPort Mount)
TomTom XXL 530-S, XXL 540-S (TomTom EasyPort Mount)
TomTom ONE (US Edition, US 3rd Edition)
TomTom ONE XL (1st Edition) - TomTom ONE XL-S (1st Edition)
TomTom ONE 22, ONE 22 Regional, ONE 22 Regional Traffic
TomTom XL 22, XL 22 Regional (TomTom EasyPort Mount)
TomTom ONE UK / EUROPE (NEW Edition aka 2nd Edition, 3rd Edition)
TomTom GO 520 / 530 / 630 / 720 / 730 / 920 / 920T / 930
TomTom Start and Ease
TomTom Device Compatibility:
*See included Pro.Fit maual for Vehicle Specific Mounting Bracket
instructions. For question regarding installation, contact Pro.Fit at
800.388.0073.
*See included Pro.Fit maual for Vehicle Specific Mounting Bracket instructions. For question regarding
installation, contact Pro.Fit at 800.388.0073.
GarminNuviDevice Compatibility - 17mm Ball Pattern: 200, 200w, 205, 205w, 250, 250w,
255, 255w, 260, 260w, 265T, 265WT, 270, 275T, 285WT, 300, 300T, 310, 310T, 350, 360, 360T, 370, 370T, 500,
550, 600, 610, 650, 660, 670, 680, 710, 750, 755T, 760, 760T, 765T, 770, 775T, 780, 785T, 850, 855, 860, 880, 885T,
1200, 1250, 1260T, 1300, 1350, 1340T, 1350T, 1370T, 1390T, 1450, 1490T, 1690, 5000
Garmin StreetPilot Device Compatibility: c310, c340, c510, c530, c550, c580
Magellan GPS Device Compatibility:
Magellan Maestro 3100, 3140, 3200, 3210, 3220, 3225, 3250, 4000, 4010, 4040, 4050, 4210, 4215, 4200, 4220,
4245, 4250, 4350, 4370, 5310, 5340
Magellan RoadMate 300, 360, 500, 500 Plus, 700, 760, 800, 860T 1200, 1210, 1212, 1215, 1220, 1230, 1340,
1400, 1412, 1430, 1440, 1445T, 1470, 1475T, 2000, 2200T, 2250T, 3000T, 3050T, 6000T
Magellan Triton 1500, 200, 2000, 300, 400, 500
Mio Moov Device Compatibility: Mio Moov 200 Series and Mio Moov 300, 301, 310, 330, 330
Europe, 360, 370 Europe, 380, Mio Knight Rider Edition, Moov 500, S401, S501, M300, M400
NAVMAN Device Compatibility: S30, S30 3D, S50, S50 3D, S70, S90i
B
A
A
BC
Connect the dual T-tabs (A) on the dual-T pedestal to the dual
T-tab slots (B) on the adapter plate.
All brand names and product names are trademarks or registered trademarks of their respective owners.

GPS-CV7107G3 |Vehicle Specific Mounting Bracket for Most Portable GPS
!Safety Precautions
Do not install Arkon products over an air bag cover or within the air
bag deployment zone. Arkon Resources, Inc. assumes no responsi-
bility of liability for injury or death as a result of car crashes and/ or
air bag deployment.
Arkon is not responsible for any damages caused to your car, your
device, or yourself due to the installation or use of this pedestal mount.
The Mobile Mounting Specialists™
Consumer Hotline:
USA [phone]
INT’L [phone]
Monday - Friday 9 am - 5 pm, PST
www.arkon.com
Arcadia, CA 91006 USA
Designed in USA | Made in the USA & China
© Copyright 2010 Arkon Resources, Inc.
Step 1.
Step 1.
Step 1.
Step 2.
Connect TomTom Device to Pedestal with EasyPort™ pattern
Connect TomTom Start™ & Ease™ Device to Pedestal
Connect Garmin Device to 17mm ball head
While holding the mounted TomTom adapter plate, gently
insert the TomTom device (not included, sold separately) into
the adapter plate until an audible click is heard. The device
can then be rotated into the desired viewing angle.
Slide the adapter plate up into the grooves on the back of the
TomTom GO series device (not included, sold separately).
Step 1.
Step 1.
Connect TomTom GO GPS to Pedestal
Connect Adapter Plate for TomTom GO GPS
While holding the mounted TomTom adapter plate, gently insert
the TomTom device (not included, sold separately) into the
adapter plate until an audible click is heard.
Attach the dual-T adapter plate for TomTom to the pedestal by
inserting the dual-T tabs of the pedestal (A) into the dual T-slots
on the adapter plate (B).
Attach Garmin GPS to 17mm ball head by firmly pushing the
ball head (A) into the 17mm ball head socket on the back of the
device (B) as pictured below.
Step 1.
Connect Adapter Plate for TomTom EasyPort™ to Pedestal
A
B
B
A
B
A
A
B
AB
D
C
Step 1.
Connect Mio Moov 200 Series or NAVMAN 530 3D GPS Device
to Pedestal
Connect the adapter plate for Mio Moov to Mio device (not
included, sold separately) by placing the feet (A) of the adapter
into the corresponding notches (B) on the bottom of the device.
Holding the thumb tab down (C), insert the upper tooth (D) into
the recessed slot on the back of the device.
Connect the dual T-tabs (A) on the dual-T pedestal to the dual
T-tab slots (B) on the adapter plate.
Connect the dual T-tabs (A) on the dual-T pedestal to the dual
T-tab slots (B) on the adapter plate.

GPS-CV7107G3 |Vehicle Specific Mounting Bracket for Most Portable GPS
!Safety Precautions
Do not install Arkon products over an air bag cover or within the air
bag deployment zone. Arkon Resources, Inc. assumes no responsi-
bility of liability for injury or death as a result of car crashes and/ or
air bag deployment.
Arkon is not responsible for any damages caused to your car, your
device, or yourself due to the installation or use of this pedestal mount.
The Mobile Mounting Specialists™
Consumer Hotline:
USA [phone]
INT’L [phone]
Monday - Friday 9 am - 5 pm, PST
www.arkon.com
Arcadia, CA 91006 USA
Designed in USA | Made in the USA & China
© Copyright 2010 Arkon Resources, Inc.
A
Connect the dual T-tabs (E) on the dual-T pedestal to the dual
T-tab slots (F) on the adapter plate.
Step 2.
Step 1. Insert the power cord (not included, sold separately) into the
grooved slot in the bottom of the adapter plate.
Connect Mio Moov 300 Series, NAVMAN S50, S50 3D, 570, S90i or
newer Magellan Devices to Pedestal
Step 2.
B
E
F
Connect the dual T-tabs (A) on the dual-T pedestal to the dual
T-tab slots (B) on the adapter plate.

5/64” drill bit and drill, # 2 Phillips screwdriver, Dash Trim Removal Tool (DTRT)
VSM G3, three (3) # 10 x 1/2” screws, A Plate, J Stem
Right of Radio
TOOLS REQUIRED:
PARTS INCLUDED:
LOCATION:
STEP 1. Insert DTRT behind upper right corner of radio
trim bezel (Photo #1). Pry gently to release retainer clip.
Work tool clockwise around bezel releasing four (4) clips on
right side and four (4) on left and one at bottom center.
Lift bezel off and set aside.
STEP 2. Align the VSM G3 between the center retainer clips
on the right side of the radio (Photo #2). Using the G3 as
a guide, mark the location of three (3) screw holes. Set G3
aside. Drill three (3) pilot holes at the marked location
using a 5/64” drill bit and drill. Align the G3 over the pilot
holes, insert three (3) # 10 x 1/2” screws and tighten.
STEP 3. Re-assemble the dash in reverse order. This
completes the installation of your VSM G3.
Note: See the Assembly Instructions for G3 Components for
additional information.
PLEASE READ COMPLETE INSTRUCTIONS BEFORE INSTALLING THIS VSM G3
All instructions assume a drivers seat vantage point. Caution is advised when removing and reassembling
wood or plastic parts of a dash. Applying unnecessary force or pressure may cause a piece to crack or break.
Pro.Fit International, Inc.® may not be held liable for any damage to a vehicle before, during or after the installation or removal of this VSM
G3TM. Pro.Fit International may not be held liable for any personal injury resulting from accident or improper installation. Pro.Fit
International, Inc.® 1335 Eagandale Court, Eagan, MN 55121, Ph: 651.688.3588 or 800.388.0073 Fx: 651.688.9876
©Pro.Fit International, Eagan, MN 2008
Chevrolet Avalanche and Silverado LTZ 2007-2009
Chevrolet Suburban and Tahoe 2007-2009
GMC Sierra SLT 1500, 2500, 3500 2007-2009
GMC Yukon 2007-2008
PART NUMBER:CV-71-07-G3
1
2
3
When properly installed, the metal between the ball and 2 small holes is all that is exposed.
(Some exceptions apply).
View Instruction & Updates
Online at
www.pro-fit-intl.com
Page 1
