Arris Touchstone CM820 User manual

Touchstone®C 820 Cable odem
User’s Guide
Get ready to experience the nternet’s express lane! Whether you’re checking out
streaming media, downloading new software, or checking your email, the Touch-
stone CM820 Cable Modem brings it all to you up to eight times faster than stan-
dard DOCS S 2.0 cable modems.
The Touchstone Cable Modem provides an Ethernet connection for use with either
a single computer or home/office Local Area Network (LAN).
nstallation is simple and your cable company will provide assistance to you for any
special requirements. The links below provide more detailed instructions.
Safety Requirements
Getting Started
nstalling and Connecting Your Cable Modem
Configuring Your Ethernet Connection
Using the Cable Modem
Troubleshooting
Glossary

Export Regulations
This product may not be exported outside the U.S. and Canada without U.S. Department of Commerce, Bureau of Export Administration authorization. Any export or re-export by
the purchaser, directly or indirectly, in contravention of U.S. Export Administration Regulation is prohibited.
Copyright © 2011 ARR S. All rights reserved.
The information in this document is subject to change without notice. The statements, configurations, technical data, and recommendations in this document are believed to be
accurate and reliable, but are presented without express or implied warranty. Users must take full responsibility for their applications of any products specified in this document.
The information in this document is proprietary to ARR S.
ARR S, Touchstone, and the ARR S logo are trademarks or registered trademarks of ARR S. All other trademarks and registered trademarks are the property of their respective hold-
ers.
Protected under one or more of the following U.S. patents: 7,031,435. Other patents pending.
ARSVD01394
Release 8 Standard 1.1 July 2011
Touchstone® CM820 Cable Modem User’s Guide
Export Regulations
Safety Requirements
FCC Part 15
European Compliance
Energy Consumption (CM820S Models only)
Getting Started
About Your New Cable Modem
What’s in the Box?
tems You Need
Getting Service
System Requirements
Recommended Hardware
Windows
MacOS
Linux/other Unix
About this Manual
Ethernet Connection
What About Security?
nstalling and Connecting Your Cable Modem
Front Panel
CM820A/S Front Panel
Rear Panel
CM820A/S Rear Panel
Mounting the Cable Modem
Tools and Materials
Location
nstructions
Wall-mounting instructions
Desktop mounting instructions
Connecting the Cable Modem
Making Ethernet Connections
Configuring Your Ethernet Connection
Requirements
How to use this chapter
TCP/ P Configuration for Windows 2000
TCP/ P Configuration for Windows XP
TCP/ P Configuration for Windows Vista
TCP/ P Configuration for Windows 7
TCP/ P Configuration for MacOS X
Using the Cable Modem
Setting up Your Computer to Use the Cable Modem
ndicator Lights for the CM820A/S Models
ndicator Lights: Normal Operation
ndicator Lights: Startup Sequence
Using the Reset Button
Troubleshooting
Glossary

Safety Requirements
ARR S Cable Modems comply with the applicable requirements for performance,
construction, labeling, and information when used as outlined below:
CAUTION
Risk of shock
Mains voltages inside this unit. No user serviceable parts inside. Refer
service to qualified personnel only!
• Do not use product near water (i.e. wet basement, bathtub, sink or near a
swimming pool, etc.), to avoid risk of electrocution.
• The product shall be cleaned using only a damp, lint-free, cloth. No solvents
or cleaning agents shall be used.
• Do not use spray cleaners or aerosols on the Cable Modem.
• Avoid using and/or connecting the equipment during an electrical storm, to
avoid risk of electrocution.
• Do not locate the equipment within 6 feet (1.9 m) of a flame or ignition
source (i.e. heat registers, space heaters, fireplaces, etc.).
• Use only power supply and power cord included with the equipment.
• Equipment should be installed near the power outlet and should be easily
accessible.
• The shield of the coaxial cable must be connected to earth (grounded) at the
entrance to the building in accordance with applicable national electrical in-
stallation codes. n the U.S., this is required by NFPA 70 (National Electrical
Code) Article 820. n the European Union and in certain other countries,
CATV installation equipotential bonding requirements are specified in EC
60728-11, Cable netw rks f r televisi n signals, s und signals and interac-
tive services, Part 11: Safety. This equipment is intended to be installed in
accordance with the requirements of EC 60728-11 for safe operation.
f the equipment is to be installed in an area serviced by an T power line
network, as is found in many areas of Norway, special attention should be
given that the installation is in accordance with EC 60728-11, in particular
Annex B and Figure B.4.
Touchstone CM820 Cable Modem User’s Guide
Safety
Getting
Started Installation
Ethernet
Configuration Usage Troubleshooting Glossary
3

• n areas of high surge events or poor grounding situations and areas prone
to lightning strikes, additional surge protection may be required (i.e.
PF11VNT3 from American Power Conversion) on the AC, RF, Ethernet and
Phone lines.
• When the Cable Modem is connected to a local computer through Ethernet
cables, the computer must be properly grounded to the building/residence
AC ground network. All plug-in cards within the computer must be properly
installed and grounded to the computer frame per the manufacturer’s spec-
ifications.
• Ensure proper ventillation. Position the Cable Modem so that air flows freely
around it and the ventillation holes on the unit are not blocked.
• Do not mount the Cable Modem on surfaces that are sensitive to heat and/or
which may be damaged by the heat generated by the modem, its power
supply, or other accessories.
Touchstone CM820 Cable Modem User’s Guide
Safety
Getting
Started Installation
Ethernet
Configuration Usage Troubleshooting Glossary
4

FCC Part 15
This equipment has been tested and found to comply with the requirements for a
Class B digital device under Part 15 of the Federal Communications Commission
(FCC) rules. These requirements are intended to provide reasonable protection
against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in ac-
cordance with the instructions, may cause harmful interference to radio communi-
cations. However, there is no guarantee that interference will not occur in a
particular installation. f this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the fol-
lowing measures:
• Reorient or relocate the receiving antenna.
• ncrease the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications to this equipment not expressly approved by the party re-
sponsible for compliance could void the user’s authority to operate the equipment.
Touchstone CM820 Cable Modem User’s Guide
Safety
Getting
Started Installation
Ethernet
Configuration Usage Troubleshooting Glossary
5

European Compliance
This product complies with the provisions of the Electromagnetic Compatibility
(EMC) Directive (89/336/EEC), the Amending Directive (92/31/EEC), the Low Volt-
age Directive (73/23/EEC), and the CE Marking Directive (93/68/EEC). As such,
this product bears the CE marking in accordance with the above applicable Direc-
tive(s).
A copy of the Declaration of Conformity may be obtained from: ARR S nterna-
tional, nc., 3871 Lakefield Drive, Suite 300, Suwanee, GA 30024.
As indicated by this symbol, disposal of this product is governed
by Directive 2002/96/EC of the European Parliament and of the
Council on waste electrical and electronic equipment (WEEE).
WEEE could potentially prove harmful to the environment; as
such, upon disposal of the Cable Modem the Directive requires
that this product must not be disposed as unsorted municipal
waste, but rather collected separately and disposed of in accor-
dance with local WEEE ordinances.
This product complies with directive 2002/95/EC of the European Par-
liament and of the Council of 27 January 2003 on the restriction of the
use of certain hazardous substances (RoHS) in electrical and elec-
tronic equipment.
Touchstone CM820 Cable Modem User’s Guide
Safety
Getting
Started Installation
Ethernet
Configuration Usage Troubleshooting Glossary
6

Energy Consumption (C 820S odels only)
n accordance with Ecodesign Directive 2005/32/EC, this device is equipped with a
power switch. The following energy consumption figures apply (measured with a
wattmeter at the outlet):
Note: n most instances, ARR S recommends that the power switch remain in
the ON position at all times. Turning the switch OFF disables the device.
Turning the switch OFF is recommended only during vacations or similar
extended absences.
Switch State Power Consumption
OFF 0.0 W
ON 5.0 W (idle)
5.5 W (maximum)
Touchstone CM820 Cable Modem User’s Guide
Safety
Getting
Started Installation
Ethernet
Configuration Usage Troubleshooting Glossary
7

Getting Started
About Your New Cable odem
The Touchstone CM820 Cable Modem is DOCS S® 3.0 or Euro-DOCS S™ 3.0 com-
pliant with the following features:
• Speed: much faster than dialup or SDN service; up to eight times faster
than DOCS S 2.0 cable modems
• Connectivity: supports Ethernet connection
• Flexibility: provides high speed data
• Compatibility:
– Data services: DOCS S or Euro-DOCS S 3.0 compliant and backward-
compatible with DOCS S 2.0 or 1.1; supports tiered data services (if of-
fered by your cable company)
What’s in the Box?
Make sure you have the following items before proceeding. Call your cable company
for assistance if anything is missing.
• Cable Modem
• Power Cord
• Quick nstallation Guide
• Wall-Mounting Template and nstructions
• Ethernet Cable
• End User License Agreement
Touchstone CM820 Cable Modem User’s Guide
Safety
Getting
Started Installation
Ethernet
Configuration Usage Troubleshooting Glossary
8

Items You Need
f you are installing the Cable Modem yourself, make sure you have the following
items on hand before continuing:
•Cable modem package: see What’s in the Box? for a list of items in the
package.
•Coaxial cable (coax): as shown in the image to the left, this is a thin cable
with a connector on each end. t is the same kind of wire used to connect to
your television for cable TV. You can buy coax from any electronics retailer
and many discount stores; make sure it has connectors on both ends. There
are two types of connectors, slip-on and screw-on; the screw-on connectors
are best for use with your Cable Modem. The coax should be long enough
to reach from your Cable Modem to the nearest cable outlet.
Note: For best performance, use high-quality RG-6 type coax cable and mini-
mize or eliminate splitters between the cable jack and the Cable Modem.
•Splitter (optional): provides an extra cable connection by splitting a sin-
gle outlet into two. You may need a splitter if you have a TV already con-
nected to the cable outlet that you want to use. You can buy a splitter from
any electronics retailer and most discount stores; you may also need a short
piece of coax cable (with connectors); use it to connect the splitter to the
cable outlet and then connect the Cable Modem and TV to the splitter.
Note: A splitter effectively cuts the signal in half and sends each half to its
two outputs. Using several splitters in a line may deteriorate the quality of
your television and/or internet connection.
•Wall-mount hardware (optional): if you want to wall-mount your Cable
Modem, you need to obtain two drywall anchors or wood screws. See the
Wall-Mount Template and nstructions for more details.
•Information packet: your cable company should furnish you with a packet
containing information about your service and how to set it up. Read this in-
formation carefully and contact your cable company if you have any ques-
tions.
Touchstone CM820 Cable Modem User’s Guide
Safety
Getting
Started Installation
Ethernet
Configuration Usage Troubleshooting Glossary
9
Coax Cable

Getting Service
Before trying to use your new Cable Modem, contact your local cable company to
establish an nternet account. When you call, have the following information ready:
• the Cable Modem serial number and MAC addresses of the unit (printed on
a sticker on the bottom of the Cable Modem)
• the model number of the Cable Modem
Save this information for future use. n addition, you should ask your cable com-
pany the following questions:
• Do you have any special system requirements or files that need to down-
load after am connected?
• When can start using my Cable Modem?
• Do need a user D or password to access the nternet or my e-mail?
Touchstone CM820 Cable Modem User’s Guide
Safety
Getting
Started Installation
Ethernet
Configuration Usage Troubleshooting Glossary
10

System Requirements
The Touchstone Cable Modem operates with most computers. The following de-
scribes requirements for each operating system; see the documentation for your
system for details on enabling and configuring networking.
To use the Cable Modem, you need DOCS S or Euro-DOCS S high-speed nternet
service from your cable company, as appropriate.
Recommended Hardware
The following hardware configuration is recommended. Computers not meeting this
configuration can still work with the CM820, but may not be able to make maximum
use of CM820 throughput.
• CPU: P4, 3GHz or faster
• RAM: 1GB or greater
• Hard drive: 7200 RPM or faster
• Ethernet: Gig-E (1000BaseT)
Windows
Ethernet connection: Windows 2000, Windows XP, Windows Vista, or Windows 7
acOS
Ethernet connection: System 7.5 to MacOS 9.2 (Open Transport recommended) or
MacOS X
Linux/other Unix
Ethernet connection: Hardware drivers, TCP/ P, and DHCP must be enabled in the
kernel
Touchstone CM820 Cable Modem User’s Guide
Safety
Getting
Started Installation
Ethernet
Configuration Usage Troubleshooting Glossary
11

About this anual
This manual covers all of the different CM820 models. Your model may not have all
of the capabilities outlined in this manual. To determine which model you have pur-
chased, refer to the image at the left. The model number is on the label affixed to
the Cable Modem.
Ethernet Connection
Ethernet is a standard method of connecting two or more devices into a Local Area
Network (LAN).
Note: To connect two or more computers to the Ethernet port, you will need a
hub or broadband router (available at computer retailers).
The Cable Modem package comes with a 6-foot (1.9m) Ethernet cable (the con-
nectors look like wide telephone connectors); you can purchase more cables if nec-
essary at a computer retailer. f you are connecting the Cable Modem directly to a
computer, or to an Ethernet hub or broadband router with a cross-over switch, ask
for Category 5e (CAT5e) straight-through cable. CAT5e cable is required for giga-
bit Ethernet (Gig-E), not regular CAT5 cable.
Touchstone CM820 Cable Modem User’s Guide
Safety
Getting
Started Installation
Ethernet
Configuration Usage Troubleshooting Glossary
12
Ethernet Cable
odel
Number

What About Security?
Having a high-speed, always-on connection to the nternet requires a certain
amount of responsibility to other nternet users—including the need to maintain a
reasonably secure system. While no system is 100% secure, you can use the fol-
lowing tips to enhance your system’s security:
• Keep your operating system updated with the latest security patches. Run
the system update utility at least weekly.
• Keep your email program updated with the latest security patches. n addi-
tion, avoid opening email containing attachments, or opening files sent
through chat rooms, whenever possible.
• nstall a virus checker and keep it updated.
• Avoid providing web or file-sharing services over your Cable Modem. Be-
sides certain vulnerability problems, most cable companies prohibit running
servers on consumer-level accounts and may suspend your account for vi-
olating your terms of service.
• Use the cable company’s mail servers for sending email.
• Avoid using proxy software unless you are certain that it is not open for
abuse by other nternet users (some are shipped open by default). Crimi-
nals can take advantage of open proxies to hide their identity when break-
ing into other computers or sending spam. f you have an open proxy, your
cable company may suspend your account to protect the rest of the net-
work.
• f you connect your Cable Modem to a wireless LAN, make sure you enable
security and encryption on the wireless hub (for the same reasons that you
should run only secured proxies). Consult the documentation and technical
support of the wireless equipment provider for help.
Touchstone CM820 Cable Modem User’s Guide
Safety
Getting
Started Installation
Ethernet
Configuration Usage Troubleshooting Glossary
13

Installing and Connecting Your Cable
odem
Before you start, make sure that:
• You have contacted your cable company and verified that they provide data
service using standard DOCS S technology.
• You have all the tems You Need.
• Cable and power outlets are available near the computer. f a cable outlet is
not conveniently located, your cable company can install a new one.
f you have ordered service, your cable company should configure the Cable Modem
automatically. You need only follow the instructions in this section to install and
connect the Cable Modem.
Touchstone CM820 Cable Modem User’s Guide
Safety
Getting
Started Installation
Ethernet
Configuration Usage Troubleshooting Glossary
14

Front Panel
C 820A/S Front Panel
The front of the Cable Modem provides the following indicators.
A Link: indicates Ethernet connectivity between the Cable Modem and com-
puter. t may be yellow or green to indicate the connection speed.
B Online: indicates internet data transmission status.
C US: indicates upstream connectivity. t may be yellow or green to indicate
the connection speed.
D DS: indicates downstream connectivity. t may be yellow or green to indi-
cate the connection speed.
E Power: indicates whether AC power is available to the unit.
Rear Panel
The rear of the Cable Modem has the following connectors and controls:
C 820A/S Rear Panel
A Reset button: resets the Cable Modem as if you power cycled the unit. Use
a pointed non-metallic object to press this button.
BEthernet connector (yellow): for use with a computer or home network LAN
connection.
C Cable: connector for the coax cable.
D Power: connector for the power cord.
E Power Switch (CM820S only): power On/Off switch.
Touchstone CM820 Cable Modem User’s Guide
Safety
Getting
Started Installation
Ethernet
Configuration Usage Troubleshooting Glossary
15
Link
Online
US
DS
Power
CM820
B
A
D
CE
C 820A/S
Ethernet
10/100/1000
Reset Cable
Ethernet
10/100/1000
Reset Cable
A B C D
C 820A
E
C 820S

ounting the Cable odem
You can either mount the Cable Modem on a wall or place it on a desktop. For wall-
mount applications, you can mount the Cable Modem with the indicators facing up-
ward (vertical) or to the side (horizontal).
Tools and aterials
For wall-mounted installations, make sure you have the following tools and mate-
rials before proceeding:
• for mounting on drywall: Two 1/4” (6mm) drywall anchors (not included),
two #6 x 1.5” (38.1 mm) self-tapping panhead screws (not included), and
a drill with 1/4” (6mm) bit (not included)
• for mounting on plywood or studs: two #6 x 1.5” (38.1 mm) self-tapping
panhead wood screws (not included)
• screwdriver (flat-blade or Phillips, depending on what kind of screws you
use)
• wall-mount template (included with the Cable Modem Quick nstallation
Guide)
• transparent tape: for temporarily securing the mounting template to the wall
(not included)
Location
Always position the Cable Modem:
• within reach of an AC outlet. The power cord must reach the outlet without
stretching and without adding extension cords.
• near a cable outlet (to avoid long cable runs).
Touchstone CM820 Cable Modem User’s Guide
Safety
Getting
Started Installation
Ethernet
Configuration Usage Troubleshooting Glossary
16

Instructions
Wall-mounting instructions
Note: When mounting the Cable Modem on drywall, try to position the Cable
Modem so at least one of the screws is fastened to a stud. This may pre-
vent the Cable Modem from pulling out of the wall in the future. To pre-
vent overheating of the Cable Modem, do not block the ventilation holes
on the sides of the unit.
1Position the mounting template on the surface where you intend to mount
the Cable Modem and secure in place with transparent tape.
2Drill holes through the template in the specified locations for the mounting
screws. After drilling holes, remove the template from the surface.
3f using drywall anchors, set them into the wall. Then, drive the screws into
the wall leaving a gap of about 1/8” (3 mm) between the screw head and
the wall. f not using anchors, just drive the screws.
4Orient the Cable Modem with the indicator lights facing up or right, as de-
sired. Slip both mounting slots (in the back of the Cable Modem) over the
screws, then slide the case down until the narrow end of the keyhole slot
contacts the screw shaft.
5Proceed to Connecting the Cable Modem.
Desktop mounting instructions
1Position the Cable Modem so that:
• air flows freely around it
• the back faces the nearest wall
• it will not fall to the floor if bumped or moved
• the ventilation holes on the side of the unit are not blocked
2Proceed to Connecting the Cable Modem.
Touchstone CM820 Cable Modem User’s Guide
Safety
Getting
Started Installation
Ethernet
Configuration Usage Troubleshooting Glossary
17
Step 1 Step 2
Step 4
Step 3

Connecting the Cable odem
1Connect one end of the coax cable to the cable outlet or splitter, and the
other end to the Cable Modem’s Cable connector (C). Tighten the connec-
tions by hand, then tighten an additional 1/8 turn with a wrench.
Note: For best performance, use high-quality RG-6 type coax cable and mini-
mize or eliminate splitters between the cable jack and the Cable Modem.
2nsert the plug from the power cord into the Power connector on the Cable
Modem (D) and insert the power cord into a convenient AC outlet.
odel C 820S only: Make sure that the rear panel power switch (E) is set
to the ON position.
The P wer light n the fr nt f the Cable M dem lights up, then flashes nce
(refer t the Indicat r Lights table f r y ur m del). See Tr ublesh ting if
the P wer light d es n t turn n.
aking Ethernet Connections
3Connect one end of the yellow Ethernet cable to the yellow port on the back
of the Cable Modem labeled “Ethernet 10/100/1000,” (B) and the other end
to the Ethernet port on a computer, hub, or broadband router.
Note: f you are connecting to a computer, use the Ethernet cable included
in the Cable Modem package.
Touchstone CM820 Cable Modem User’s Guide
Safety
Getting
Started Installation
Ethernet
Configuration Usage Troubleshooting Glossary
18
Ethernet
10/100/1000
Reset Cable
Ethernet
10/100/1000
Reset Cable
A B C D
C 820A
E
C 820S

Configuring Your Ethernet Connection
f your computer is equipped with a LAN card providing an Ethernet connection,
you may have to configure your computer’s TCP/ P settings. The steps that follow
will guide you through setting your computer’s TCP/ P settings to work with the
Cable Modem.
Requirements
Make sure you have the following before attempting to configure your Ethernet con-
nection:
• Computer with:
— one of: Windows 2000, Windows XP, Windows Vista, Windows 7, or
MacOS X
— Ethernet interface
• Ethernet cable (supplied)
• P address, subnet, gateway, and DNS information for installations not using
DHCP
How to use this chapter
The following list shows the procedures for modifying the TCP/ P settings on the
computer. The procedure is slightly different depending on the operating system
that you are using. Please ensure you are using the correct steps for the operating
system on your computer. Follow the links below for instructions to configure your
Ethernet connection on your operating system.
•TCP/ P Configuration for Windows 2000
•TCP/ P Configuration for Windows XP
•TCP/ P Configuration for Windows Vista
•TCP/ P Configuration for Windows 7
•TCP/ P Configuration for MacOS X
Touchstone CM820 Cable Modem User’s Guide
Safety
Getting
Started Installation
Ethernet
Configuration Usage Troubleshooting Glossary
19

TCP/IP Configuration for Windows 2000
Follow these steps to configure the Ethernet interface on a Windows 2000 operat-
ing system.
Note: Dialog boxes shown on your computer may differ slightly from those
shown in this procedure.
1From the computer, select Start > Settings > Network and Dial-up Con-
nections > Local Area Connection.
2n the Local Area Connections Properties window, highlight TCP/IP by click-
ing on it one time, then click on Properties.
Note: f your computer has more than one Ethernet card, you may have to
select the appropriate Ethernet card in the Connect using: area of the Local
Area Connection Properties window.
Touchstone CM820 Cable Modem User’s Guide
Safety
Getting
Started Installation
Ethernet
Configuration Usage Troubleshooting Glossary
20
