Aruba JL320A User manual

Aruba 2930M Switches Quick Setup
Guide and Safety/Regulatory
Information
*5200-4439*
Part Number: 5200-4439
Published: October 2017
Edition: 1, Printed in Singapore

Notices
The information contained herein is subject to change without notice. The only warranties for Hewlett Packard
Enterprise products and services are set forth in the express warranty statements accompanying such products
and services. Nothing herein should be construed as constituting an additional warranty. Hewlett Packard
Enterprise shall not be liable for technical or editorial errors or omissions contained herein.
Confidential computer software. Valid license from Hewlett Packard Enterprise required for possession, use, or
copying. Consistent with FAR 12.211 and 12.212, Commercial Computer Software, Computer Software
Documentation, and Technical Data for Commercial Items are licensed to the U.S. Government under vendor's
standard commercial license.
Links to third-party websites take you outside the Hewlett Packard Enterprise website. Hewlett Packard Enterprise
has no control over and is not responsible for information outside the Hewlett Packard Enterprise website.
Applicable products
Aruba 2930M 24G 1-slot Switch JL319A
Aruba 2930M 24G PoE+ 1-slot Switch JL320A
Aruba 2930M 48G 1-slot Switch JL321A
Aruba 2930M 48G PoE+ 1-slot Switch JL322A
Aruba 2930M 40G 8SR PoE+ 1-slot Switch JL323A
Aruba 2930M 24SR PoE+ 1-slot Switch JL324A
Aruba 2930 2-port Stacking Module JL325A
Aruba 3810M/2930M 1-Port QSFP+ 40GbE Module JL078A
Aruba 3810M/2930M 4 HPE Smart Rate 1G/2.5G/5G/10G PoE+ Module JL081A
Aruba 3810M/2930M 4-Port 100M/1G/10G SFP+ MACsec Module JL083A
Aruba X371 12VDC 250W 100-240VAC Power Supply JL085A
Aruba X372 54VDC 680W 100-240VAC Power Supply JL086A
Aruba X372 54VDC 1050W 110-240VAC Power Supply JL087A
Related publications
•Aruba 2930M Switches Installation and Getting Started Guide
•Aruba 2930M and 3810M Switch Power Supply Quick Setup Guide and Safety/Regulatory Information

•ArubaOS-Switch Power Over Ethernet (PoE/PoE+) Planning and Implementation Guide
•ArubaOS-Switch Transceiver Guide
To view and download the above publications, visit http://www.hpe.com/support/manuals.

Applicable products......................................................................................................... 0
Chapter 1 Before you begin............................................................................ 5
Installation precautions and guidelines...................................................................................................... 5
Chapter 2 Prepare for installation...................................................................6
Chapter 3 Mount the switch and connect to the network.............................8
Mounting the switch in a two-post rack...................................................................................................... 8
Mounting a switch on a tabletop or desktop...............................................................................................9
Connecting the switch to the network...................................................................................................... 10
Install an optional uplink module..............................................................................................................13
Install an optional Stacking Module......................................................................................................... 15
SFP/SFP+/QSFP+ installation notes....................................................................................................... 17
Switch Operating System Software......................................................................................................... 18
Chapter 4 Aruba 2930M safety and regulatory information....................... 19
Regulatory information.............................................................................................................................19
Aruba 2930M Switch Safety and Regulatory Information........................................................................ 20
Power supply instructions........................................................................................................................ 23
Battery Statements:................................................................................................................................. 24
Japan VCCI Class A................................................................................................................................ 24
Korea EMC Class A Statement................................................................................................................25
European Community.............................................................................................................................. 25
Belarus Kazakhstan Russia marking....................................................................................................... 25
Documentation feedback......................................................................................................................... 25
Contents
Contents 4

Installation precautions and guidelines
To avoid personal injury or product damage when installing your switch, read the installation precautions and
guidelines below.
• Do not mount the switch on a wall or under a table or under another horizontal surface.
• Mount devices installed in a rack or cabinet as low as possible. Put the heaviest devices at the
bottom and progressively lighter devices installed above.
• To prevent the rack or cabinet from becoming unstable and/or falling over, ensure that it is
adequately secured.
• Do not ship any switch in a rack without checking for restrictions in the Installation and Getting
Started Guide for your switch. Otherwise, you may void the switch warranty.
• Ensure the power source circuits are properly grounded. Then connect the switch to the power
source by using the power cord supplied with the switch.
• If your installation requires a different power cord than the one supplied with the switch and power
supply, be sure the cord is adequately sized for the switch’s current requirements. In addition, be
sure to use a power cord displaying the mark of the safety agency that defines the regulations for
power cords in your country. The mark is your assurance that the power cord can be used safely
with the switch and power supply.
• When installing the switch, the AC outlet should be near the switch and be easily accessible in
case the switch must be powered off.
• Do not install the switch in an environment where the operating ambient temperature exceeds its
specification. (See the Environmental Operating Temperature information.)
• Ensure that the switch does not overload the power circuits, wiring, and over-current protection.
To determine the possibility of overloading the supply circuits, add the ampere ratings of all
devices installed on the same circuit as the switch. Then compare the total with the rating limit for
the circuit. The maximum ampere ratings are usually printed on the devices near the AC power
connectors.
• Ensure that the air flow around the switch is not restricted. Leave at least 3 inches (7.6 cm) for
cooling. For the air flow direction, see the Installation and Getting Started Guide for your product
by visiting the Hewlett Packard Enterprise Support Center at http://www.hpe.com/support/
manuals.
If a power supply must be removed, and then reinstalled, wait at least 5 seconds before
reinstallation. Otherwise, damage to the switch may occur.
The power supply needs this time to bleed off any retained power.
Install cover plates on any slot that is not in use.
Chapter 1
Before you begin
Chapter 1 Before you begin 5

The switch drawings in this document are for illustration only and may not match your particular
switch.
1. Unpack and check included parts:
• Switch
• Installation hardware:
◦ two rack mounting brackets
◦ eight 8-mm M4 screws
◦ four 5/8-inch number 12-24 screws
◦ four adhesive rubber foot pads
• Power cord
• Documentation kit
Console cables can be ordered separately, or as an accessory to your switch:
Aruba X2C2 RJ45 to DB9 Console Cable (JL448A)
A standard micro-USB (Aruba switches) or mini-USB (HPE FlexNetwork switches) cable can be
used to console into the switch. Only data-capable USB cables can be used as console cables.
USB charging-only cables will not work.
2. Prepare for installation.
To avoid personal injury or product damage, review the Installation precautions and guidelines
before beginning the installation.
3. Skip this step if a power supply is already installed in the switch.
If a power supply is not already installed in the switch, install at least one power supply before continuing in
this guide. (See the Aruba Switch Power Supply Quick Setup Guide and Safety/Regulatory Information
document shipped with your power supply units.) The Aruba 2930M switches use any of the following power
supplies:
• Aruba X371 12VDC 250W 100-240VAC Power Supply (JL085A)
• Aruba X372 54VDC 680W 100-240VAC Power Supply (JL086A)
• Aruba X372 54VDC 1050W 110-240VAC Power Supply (JL087A)
4. Power on and verify that self-test completes normally. An Aruba 2930M switch does not contain a power on/off
switch. It is turned on by connecting the AC power cord to the switch and to an AC power source.
Chapter 2
Prepare for installation
6Aruba 2930M Switches Quick Setup Guide and Safety/Regulatory Information

1 3 4 75 62
1 Port LEDs:
Off after self-test unless a network cable is connected and the port is receiving link beat.
2 Speed Mode Selected LED:
Off after self-test in default configuration.
3 PoE Mode Selected LED (Only on Aruba 2930M models that support PoE+ operation):
Off after self-test in default configuration.
4 User Mode Selected LED:
Off after self-test in default configuration.
5 Back Status LED:
Green after self-test if all modular components installed on the back of the unit are functioning
correctly. Slow flash orange if a module on the back of the unit is in a fault state.
6 UID LED:
Locator or Unit Identification LED. Off after self-test.
7 Global Status LED:
Green after self-test in default configuration.
5. Remove the power cord from the switch and from the power source.
Chapter 2 Prepare for installation 7

Supported mounting options for the Aruba 2930M switches include:
• Two-post rack mount
• Tabletop or desktop
• Four-post rack mount (Requires the optional J9583A HPE X410 Universal Rack Mounting Kit.)
For instructions on using the four-post rack-mount option, see the Aruba 2930M Switches Installation
and Getting Started Guide at http://www.hpe.com/support/manuals.
Mounting the switch in a two-post rack
Prerequisites
Before beginning here:
• Review the Installation precautions and guidelines on page 5.
•Prepare for installation on page 6.
• Prepare your network data cables (not included) for connecting the switch to the network.
Do not mount the switch on a wall, under a table, or under another horizontal surface.
Procedure
1. Attach the rack mount brackets to the switch by using a #1 Phillips (cross-head) screwdriver and the supplied
eight 8-mm M4 screws.
Chapter 3
Mount the switch and connect to the network
8Aruba 2930M Switches Quick Setup Guide and Safety/Regulatory Information

1
2
12
2. Use the four number 12-24 screws to secure the brackets to the rack.
3. Go to Connecting the switch to the network on page 10.
Mounting a switch on a tabletop or desktop
Prerequisites
• Locate the four self-adhesive pads included in the switch accessory kit.
• Select a secure horizontal surface where the network cables and switch power cord will not create a tripping
hazard.
Chapter 3 Mount the switch and connect to the network 9

Procedure
1. Attach the four self-adhesive pads to the bottom corners of the switch.
2. Position the switch with the top panel up on the selected horizontal surface.
Ensure that the power cord and network cables at switch mounting location will not create a
tripping hazard.
Avoid blocking any ventilation openings on the sides, rear, or front of the switch. For more
information on proper ventilation spacing, see Installation precautions and guidelines on page
5.
3. Go to Connecting the switch to the network on page 10.
Connecting the switch to the network
Prerequisites
Gather the following:
• (Optional) The RJ-45 console cable (not included) or a micro-USB console cable (not included)
• Network cables (not included) for connection to the switch RJ-45 data ports. (For cabling specifications for
your switch, see the Aruba 2930M Switches Installation and Getting Started Guide at http://www.hpe.com/
support/manuals.)
• (Optional) One or more SFP transceivers supported by the switch.
10 Aruba 2930M Switches Quick Setup Guide and Safety/Regulatory Information

The front panel transceiver slots support only SFP transceivers. To use SFP+ or QSFP+
transceivers with the switch, install an optional uplink module on the rear panel of the switch. (See
Install an optional uplink module.)
Procedure
1. (Optional) Connect an RJ-45 to DB9 console cable (not included) to the Console port and to a workstation
running suitable terminal emulation software. You can also connect a micro-USB console cable (not included)
to a workstation running suitable terminal emulation software.
If cables are connected to both the Console port and the micro-USB port, input is accepted only from the Micro
USB connector. (Echo output is accepted through both ports). See the information on connecting a
management console in the Aruba 2930M Switches Installation and Getting Started Guide at http://
www.hpe.com/support/manuals.
2. (Optional) If you plan to manage the switch from a dedicated management network, connect an RJ-45 network
cable from the management network to the Mgmt port.
Chapter 3 Mount the switch and connect to the network 11

If cables are connected to both the Mgmt port and the micro-USB console port, input and output functions on
both ports.
For more information on out-of-band management, see the Installation and Getting Started Guide for your
switch model at http://www.hpe.com/support/manuals.
3. (Optional) Insert up to four SFP transceivers in the fixed transceiver slots on the switch front panel.
4. Connect network cables to the RJ-45 data ports and to any optional transceivers installed on the switch front
panel.
12 Aruba 2930M Switches Quick Setup Guide and Safety/Regulatory Information

Install an optional uplink module
Prerequisites
Gather the following items:
• One of the following uplink modules:
◦ JL078A Aruba 3810M/2930M 1-Port QSFP+ 40GbE Module
◦ JL083A Aruba 3810M/2930M 4-Port 100M/1G/10G SFP+ MACsec Module
◦ JL081A Aruba 3810M/2930M 4 HPE Smart Rate 1G/2.5G/5G/10G PoE+ Module
• A transceiver compatible with the uplink module you plan to install
• Network cables compatible with your transceivers
Chapter 3 Mount the switch and connect to the network 13

Procedure
1. Remove the cover plate from the uplink port. Store it in a secure location for possible reuse in case the uplink
module is removed from the switch in the future.
1
2
1
2. Insert an optional uplink module, such as the Aruba 3810M/2930M 1 Port QSFP+ 40GbE Module shown here.
1
2
2
3. Insert a transceiver in the uplink module.
14 Aruba 2930M Switches Quick Setup Guide and Safety/Regulatory Information

4. Connect a network cable to the transceiver installed in the uplink module.
Install an optional Stacking Module
Prerequisites
Gather the following devices:
• One JL325A Aruba 2930 2-Port Stacking Module
• One of the following optional stacking cables:
◦ J9734A Aruba 2920/2930M 0.5m Stacking Cable
◦ J9735A Aruba 2920/2930M 1m Stacking Cable
◦ J9736A Aruba 2920/2930M 3m Stacking Cable
Chapter 3 Mount the switch and connect to the network 15

If a 2930M switch is powered on for the first time without a stacking module installed, stacking is
disabled in the running configuration. If you later install the stacking module, it will not be enabled
until you execute the stacking enable command in the switch CLI. This command enables
stacking and initiates a switch reboot. Otherwise, stacking is disabled even though the stacking
module is installed. (For information on the stacking enable command, see the Advanced
Traffic Management Guide for your switch model at http://www.hpe.com/support/manuals.)
Procedure
1. Disconnect the switch from its power source(s).
2. Remove the stacking module cover plate. Store it in a secure location for possible reuse in case the stacking
module is removed from the switch in the future.
2
1
1
3. Install the stacking module.
1
2
2
4. Reconnect the switch to its power source(s).
5. Connect a stacking cable to the stacking module.
16 Aruba 2930M Switches Quick Setup Guide and Safety/Regulatory Information

SFP/SFP+/QSFP+ installation notes
When selecting a fiber SFP/SFP+/QSFP+ device, make sure it can function at a maximum
temperature that is not less than the recommended maximum operational temperature of the
product. Use only an approved Laser Class 1 SFP/SFP+/QSFP+ transceiver.
To ensure proper operation of your switch, use only the HPE Aruba SFP/SFP+/QSFP+ transceivers
supported by your switch.
Use only supported Aruba SFP/SFP+/QSFP+ transceivers
Non-Aruba SFP/SFP+/QSFP+ transceivers are not supported. Use of supported Aruba products ensures that
your network maintains optimal performance and reliability. If you require additional transceivers, contact an
Aruba sales representative or an authorized reseller. The following resources can help you to find transceiver
support information for your switch model:
• See the ArubaOS-Switch Transceiver Guide at http://www.hpe.com/support/manuals.
• See the supported transceivers information in the QuickSpecs for your switch model at http://www.hpe.com/
networking/products, along with minimum software versions to support the listed transceivers:
1. Select Switches.
2. Select Aruba Switches.
3. Select a switch model.
4. Select Product Details
5. Select an option under QuickSpecs.
Hot swapping SFP/SFP+/QSFP+ transceivers
Supported SFP/SFP+/QSFP+ transceivers that you can install in your Aruba switch can be “hot swapped”–
removed and installed while the switch is receiving power. However, disconnect the network cables from the
SFP/SFP+/QSFP+ transceivers before hot-swapping them.
Chapter 3 Mount the switch and connect to the network 17

When you replace a SFP/SFP+/QSFP+ transceiver with another transceiver of a different type, the switch may
retain selected port-specific configuration settings that were configured for the replaced unit. Be sure to validate or
reconfigure port settings as required.
SFP/SFP+/QSFP+ connections to devices with fixed speed/duplex configurations
When connecting a device to your switch port that contains a SFP/SFP+/QSFP+ transceiver, the speed and
duplex settings of the switch port and the connected device must match. Otherwise, the device may not link
properly—you may not get a link. For some older network devices, the default speed/duplex settings may be
predefined (for example, to 1000 Mbps/Full Duplex), or otherwise set differently from the default configuration of
your switch. These setting differences may also apply to some older Hewlett Packard Enterprise devices.
Because of these default speed/duplex considerations, make sure that devices connected to your SFP/SFP+/
QSFP+ ports are properly configured. At a minimum, make sure the configurations match.
Switch Operating System Software
For the latest software version supported by your switch, visit http://www.hpe.com/networking/software.
For software installation and management, see the Basic Operation Guide and other software documentation for
your switch at http://www.hpe.com/support/manuals.
18 Aruba 2930M Switches Quick Setup Guide and Safety/Regulatory Information

Regulatory information
For important safety, environmental, and regulatory information, see Safety and Compliance Information for
Server, Storage, Power, Networking, and Rack Products, available at http://www.hpe.com/support/Safety-
Compliance-EnterpriseProducts.
Chapter 4
Aruba 2930M safety and regulatory information
Chapter 4 Aruba 2930M safety and regulatory information 19

Aruba 2930M Switch Safety and Regulatory Information
Aruba 2930M Switches
Environmental
Operating Temperature:
All switches except the JL324A:
• 0°C to 55°C (32°F to 131°F) up to 5000 ft
• 0°C to 50°C (32°F to 122°F) up to 10000 ft (Reduce
1°C for every 1000 ft above 5000 ft.)
JL324A switch:
• 32°F to 113°F (0°C to 45°C) up to 5000ft
• 32°F to 104°F (0°C to 40°C) up to 10000ft (reduce
1°C for every 1000ft above 5000ft)
The maximum operating temperature for
an Aruba 2930M switch is 50°C (122°F)
(or 45°C (113°F) for the JL324A only) if
any of the following transceivers are
installed in the switch:
• J9150A HP X132 10G SFP+ LC SR
Transceiver
• J9151A HP X132 10G SFP+ LC LR
Transceiver
• J9152A HP X132 10G SFP+ LC LRM
Transceiver
• J9153A HP X132 10G SFP+ LC ER
Transceiver
• JH231A HP X142 40G QSFP+ MPO
SR4 Transceiver
• JH232A HP X142 40G QSFP+ LC LR4
SM Transceiver
• JH233A HP X142 40G QSFP+ MPO
CSR4 Transceiver
Relative Humidity: 15% to 95% at 40°C (104°F) non-condensing
Non-Operating Temperature: -40°C to 70°C (-40°F to 158°F) up to 15000 ft
Non-Operating Relative Humidity: 15% to 90% at 65°C (149°F)
Table Continued
20 Aruba 2930M Switches Quick Setup Guide and Safety/Regulatory Information
