Arzum STEAMPRO 2001 User manual

KULLANMA KILAVUZU
INSTRUCTION MANUAL
GEBRAUCHSANWEISUNG
STEAMPRO
2001
AR 682 SERAMİK TABANLI ÜTÜ
AR 682 CERAMIC SOLEPLATE IRON
AR 682 CERAMIC BÜGELSOHLE
2400 W

2ARZUM 3ARZUM
8
10
11
9
12
13
In order to obtain utmost output from your appliance, please read
carefully this user’s manual and save it for further use.
IMPORTANT SAFEGUARDS
• Makesurethatthevoltageindicatedonyourappliancecorresponds
withthemainsvoltageinyourhome.Ourcompanyshallnotbeheld
liableforanyfailuresowingtoanydiscrepancyandsuchfailuresshall
notbecoveredbytheguarantee.
• Yourdeviceisforhouseholduseonly.Donotuseoutdoorsfor
commercialorindustrialpurposes.Otherwise,inconvenientusesshall
notbecoveredbytheguarantee.
• Donotuseyourironoutdoorsorinbathrooms.
•  This appliance can be used by
childrenagedfrom8yearsand
above and persons with reduced
physical, sensory or mental
capabilitiesorlackofexperience
andknowledgeiftheyhavebeen
givensupervisionofinstruction
concerninguseoftheappliance
in a safe way and understand the
hazards involved.
Children shall not play the
appliance.Cleaninganduser
maintenance shall not be made
by children without supervision.
STEAMPRO 2001
AR 682 CERAMIC SOLEPLATE IRON
1-Sol-GelTechnologyHigh
Scratch resistance ceramic
soleplate
2- Water spray nozzle
3-Waterllinginletandwater
 llingspout
4- Variable steam and
self-clean button
5- Water spray button
6- Shot of steam button
7-Power“on”lightand
safetyautooffindicatorlight
8-Temperatureadjustment
switch
9-Temperatureadjustment
indicator
10-Transparentwatertankwith
capacity of 420 ml
11-Maximumwaterlevelindicator
12-Cordoutputrotating
around 360º
13- 2 meter cord
EN

4ARZUM 5ARZUM
water reservoir is filled with water.
•  Thellingaperturemustnotbe
openedduringuse.Instructions
forsaferellingofthewatertank
shellbegiven.
•  The iron is not to be used if it
has been dropped, if there are
visiblesignsofdamageorifitis
leaking.
TakeittoanArzum Authorized Serviceforexaminationandrepair.Care
thatforusingtheonlyoriginalspareparts.
• Unplugyourironfromthemainssupply,beforellingwithwateror
emptyingit,beforecleaningandmaintenance,immediatelyafteruse.
• Donotironyourclothswhilewearingthem.
• Useyourapplianceforitsintendedpurposesasrecommended.
Caution: The surfaces are
liable to get hot during use
Sol-Gel Technology High Scratch resistance
ceramic soleplate
Youriron,whichisextraslipperyandhashighscratchresistance
soleplate,providesexcellentsteamdistribution.Thankstoitsslippery
soleplate,itmoveseasilyondifferenttypesoffabricandyoudoironing
with less effort.
BEFORE USING FOR THE FIRSTTIME
• Please read the following instructions CAREFULLY before using the
appliance.
• Removeanystickersorprotectivefoilsfromthesoleplate.
•  The iron must not be left
unattended while it is connected
to the supply mains.
•Keep the iron and its cord out
ofreachofchildrenlessthan8
yearsofagewhenitisenergized
coolingdown.
• Topreventharmingyourappliancedonotuseextensioncordsthat
supply insufficient current.
• Yourironshouldalwaysbeturnedtominimumbeforepluggingor
unpluggingfromoutlet.
• Avoidactionsthatmayharmordamagethecordorplugofyour
appliance.Donotcarryyourappliancebyholding
fromthecord.Tounplug,holdthepluganddonot
pull by the cord.
• NEVER immerse the iron in water or other
liquids.
• Donottouchhotsurfaces.Alwaysusethe
handleandwarnothersofthepossibledangers
of burns from steam, hot water or the soleplate,
especiallywhenironingvertically.Storeyouriron
whilecoolingdownoutofreachofchildren.
•  The iron must be used and
rested on a stable surface.
•  Whenplacingtheirononits
stand, ensure that the surface on
which the stand is placed stable.
•  Theplugmustberemoved
fromthesocketoutletbeforethe
EN

6ARZUM 7ARZUM
DRY IRONING
• Placeyourirononaatsurfaceandonits
heelandinserttheplug.
• Setthevariablesteambuttontotheposition
of “ “.Thiswillpreventthesteamow;even
thereiswaterinthewatertank.
• Adjustthetemperatureswitchaccordingto
thekindoffabricsyouwanttoiron.
• Youcanstartironingafterthetemperature
displaylightdisappears,indicatingthatthe
selectedtemperatureisbeingmaintained.
NOTE: Pilot light may again turn on to maintain
the selected temperature of soleplate during
ironing,which is suitable for the article being
ironed.
STEAM IRONING
• Steamironingwithyourironisonlypossible
inthehighertemperaturesasindicatedinthe
temperature switch and in the table.
• Ensurethatthereisenoughwaterinthe
watertank.
• Setthetemperatureswitchtothecorrect
positionforsteamows.
• Assoonasthetemperaturedisplaylight
disappearsyoucanstartironing.
SPRAYING
• Atanytemperatureby
pressingonthespraybutton
a couple of times,the laundry
to be ironed can be damped
down.
SETTING THE TEMPERATURE
• Beforestartingironingalwayscheckrsttoseewhetheralabelwith
ironinginstructions,followtheseinstructions,ifany.Ifironinginstructions
aremissingbutyoudoknowthekindoffabric,thenthetablegiven
below will be helpful for you.
NOTE:
1-Ifyouhavestartedironingthosefabricsthatrequirehigher
temperaturesandifyouwishtoironsuchfabricsrequiringthelowest
temperature,thensetthetemperatureswitchfromtheposition“•••”to
theposition“•”,andwaitfor5minutestoallowcoolingdown.
CAUTION: There is a thermal safety fuse to protect the steam iron from
over-heating. However; for your safety always disconnected your iron
from the electrical outlet after finishing the iron or before taking a rest.
FILLING WITH WATER
• Unplugyourironbeforellingwaterinthe
tank.
• Openthewaterllinginletcover,usethewater
llingbeakersuppliedtopourwaterslowlyinto
thellinghole.Donotllhigherthanindication
“MAX”ofthewatertank.
• Youcanusetapwater,unlessitisveryhard(hardnesshigherthan
17PH)Otherwise,itisadvisabletousedistilledwater.
NOTE: NOT SUITABLE FOR IRONING
LINEN MAX
STEAM
LABEL
Synthetic
For example:
acrylic,
viscous, nylon
(polyamide),
polyester
LINEN
COTTON
SILK
WOOL
MIN “DRY”
KIND OF
TEXTILE TEMPERATURE DIAL STEAM SELECTOR
EN

8ARZUM 9ARZUM
AFTER USE
• Setthevariablesteam
button to the position “ “ .
• Removethemainsplug
fromthewallsocketand
wait for the soleplate to
cool down completely.
• Pouroutthewater
contained in the water
tankbyshakingit.
SELF-CLEANING
• Theselfcleaningsystemtobeusedatregular
intervals(onceortwiceamonth)willprolongthe
life of your iron,and protect it from the formation
of lime and dust particles.
• FillthewatertankwithwatertotheMax point.
• Placetheirononaatsurface,intheupright
positionstandingitonitsheel.
• Setthetemperatureswitchthepositionmax.
• Insertthemainsplugintothewallsocket.Waituntiltemperatureswitch
goesoutandyourironreachestherequiredtemperature.
• Unplugtheironfromwallsocket.
• Hold the iron with its soleplate facing downwards, over a sink or
bathtub.
• Presstheselfcleanbuttondownandkeepitatdownwardpositionfor
a few minutes.
ATTENTION: While pressing the self-clean button,the boiled water and
steam will come out through the holes under the soleplate,protecting
your appliance against any formation of lime and scale.
• Movetheiron
forwardandbackward
untiltheremaining
water in the water
tankisdischarged
completely.
• Standyourironin
theuprightposition
andinsertthepluginto
the power supply and let the iron heat up.
SHOT OF STEAM
• Whenandifrequired,in
order to supply more steam
you can iron quite easily your
hardironableandtoowrinkly
clothsthroughshotofsteam
duringbothsteamanddry
ironing.
• Lifttheironslightlyabove
the surface of the fabric
depress the shot of steam button for 3 to 5 seconds,and then release.
Steamowwillbeginafterreleasingthebutton.
VERTICAL STEAM
• Setthetemperaturecontroldialtothe
positionmax,andthevariablesteambutton
tothepositionmax.Standagainstthecloths
and curtains that you would iron in the vertical
position.Depresstheshotofsteambutton.
WARNING: Never attempt to iron any cloths
when worn by you or others.
AUTOMATIC SAFETY SHUT-OFF IN 3
STEPS
• Theautomaticsafetyshut-offdevicewillautomaticallycuttheheating
off, when the iron operates without move for a while, and the iron will be
turned off.
• Yourironwillautomaticallyturnoff,ifitisleft:
 -Uprightapprox.8-10minutes,or
 -Horizontallyorsidewardforapprox.25-30seconds.
Thepowerindicatorlightwillblinkandanacousticalarmsignalappears.
Bymovingtheiron,itwillautomaticallyturnonagain.
• Eveniftheironisshutoff,thetanklightwillstaylightedup.Bymoving,
theironwillautomaticallyturnonagain.
• Whenyourironstaysinautomaticoffmodeoveronehour,itwillstart
tocooldown.Insuchcasesyouhavetoadjustthetemperaturelevelof
yourironbypressingthe+button.
EN

10 ARZUM 11ARZUM
• Cleanthesoleplatemovingtheironoveracleancloth.Then,letthe
remainingwateronthesoleplateevaporate,andremovetheplugfrom
thewallsocket.
CAUTION: Only press down the self cleaning button when you want to
activate the self cleaning system.Never press down the self-cleaning
button when ironing.
ANTI-DRIP SYSTEM
Thesystempreventsanyleakageoftheiron.If
the temperature of the soleplate reduces,it will
operate automatically.
ANTI-CALC
SYSTEM
Thissystemisincludedinthewatertank
permanently.It minimizes the formation of
lime,ensuringtoprolongthelifeofyouriron.
CLEANING AND CARE
• Ensurethatyourironisdisconnectedfromthepowersupplyandallow
theirontocooldownthoroughly.
• Theremaybesomefabricdepositsandotherresiduesonthe
soleplate.Thosestickyresiduescanberemovedwithadampthickcloth
soakedinavinegar/watersolution.Thenwipeoffthesoleplatewithadry
cloth.
• Donotuseabrasiveandscratchingobjectsonthesoleplatewhen
cleaning.Avoidhardcontactwithmetalobjects.
• Wipeuptheoutersurfaceofyourironwithadampcloth,andwipe
drywithadryone.Donotuseabrasivesorharshcleanersastheymay
damagethesurfaceoftheiron.
• Never immerse the iron in water or any other liquids.
• Do not put vinegar or chemical calcification removers into the water
tank.
• Theself-cleaningprocessshouldbecarriedoutatleastonceamonth.
Product life 10 years
Technical Specifications
220-240V~50Hz
2000 -2400 W
The product is in compliance with the EEE Directives.
WEEE
This product contains recyclable materials that compliance with the
WEEEdirectives.Donotdisposethisproductasunsortedmunicipal
waste. Please contact your local municipality for the nearest collection
point.
Manufacturer / Importer:
Arzum Elektrikli Ev Aletleri San. ve Tic. A.Ş.
Otakçılar Caddesi No: 78 Kat: 1 B Blok No: B1b
Eyüp 34050 İstanbul Türkiye
Made in Turkey
Tel: [phone] Fax: [phone]
www.arzum.com
EN

GARANTİ ŞARTLARI
1. Garanti süresi, malın teslim tarihinden itibaren başlar ve 3 yıldır.
2. Malınbütünparçalarıdahilolmaküzeretamamıgarantikapsamındadır.
3. Malınayıplıolduğununanlaşılmasıdurumundatüketici,6502sayılı
TüketicininKorunmasıHakkındaKanunun11incimaddesindeyeralan;
a- Sözleşmeden dönme,
b- Satış bedelinden indirim isteme,
c- Ücretsiz onarılmasını isteme,
ç- Satılanın ayıpsız bir misli ile değiştirilmesini isteme,
haklarından birini kullanabilir.
4. Tüketicinin bu haklardan ücretsiz onarım hakkını seçmesi durumunda
satıcı;işçilikmasrafı,değiştirilenparçabedeliyadabaşkaherhangibir
adaltındahiçbirücrettalepetmeksizinmalınonarımınıyapmakveya
yaptırmaklayükümlüdür.Tüketiciücretsizonarımhakkınıüreticiveya
ithalatçıyakarşıkullananilir.Satıcı,üreticiveithalatçıtüketicininbuhakkını
kullanmasındanmüteselsilensorumludur.
5. Tüketicinin,ücretsiz onarım hakkınıkullanmasıhalindemalın;
 -Garantisüresiiçindetekrararızalanması,
 -Tamiriiçingerekenazamisüreninaşılması,
 -Tamirininmümkünolmadığının,yetkiliservisistasyonu,satıcı,üretici
veyaithalatçıtarafındanbirraporlabelirlenmesidurumlarında;
tüketicimalinbedeliadesini,ayıporanındabedelindiriminiveyaimkan
varsamalınayıpsızmisliiledeğiştirilmesinisatıcıdantalepedebilir.
Satıcı,tüketicinintalebinireddedemez.Butalebinyerinegetirilmemesi
durumundasatıcı,üreticiveithalatçımüteselsilensorumludur.
6. Malıntamirsüresi20 iş gününü,binekotomobilvekamyonetleriçin
ise 30 iş gününügeçemez.Busüre,garantisüresiiçerisindemalailişkin
arızanınyetkiliservisistasyonunaveyasatıcıyabildirimitarihinde,garanti
süresidışındaisemalınyetkiliservisistasyonunateslimtarihindenitibaren
başlar.Malınarızasının10 iş günüiçerisindegiderilememesihalindeüretici
veyaithalatçı;malıntamiritamamlanıncayakadar,benzerözelliklere
sahipbaşkabirmalıtüketicininkullanımınatahsisetmekzorundadır.Malın
garantisüresiiçerisindearızalanmasıdurumunda,tamirdegeçensüre
garantisüresineeklenir.
7. Malınkullanmakılavuzundayeralanhususlaraaykırıkullanılmasında
kaynaklananarızalargarantikapsamıdışındadır.
8. Tüketici,garantidendoğanhaklarınınkullanılmasıileilgiliolarak
çıkabilecekuyuşmazlıklardayerleşimyerininbulunduğuveyatüketici
işlemininyapıldığıyerdekiTüketiciHakemHeyetineveyaTüketici
Mahkemesinebaşvurabilir.
9. Satıcı tarafından bu Garanti Belgesininverilmesidurumunda,tüketici
GümrükveTicaret Bakanlığı Tüketicinin Korunması ve Piyasa Gözetimi
Genel Müdürlüğüne başvurabilir.
AR 682 SERAMİK TABANLI ÜTÜ
BELGE NO: 0052 BELGE TARİHİ: 28/07/2015
İMALATÇI FİRMA
UNVAN : ARZUM ELEKTRİKLİ EV ALETLERİ SAN. VE TİC. A.Ş.
ADRES : OTAKÇILAR CADDESİ NO: 78 KAT: 1 B BLOK NO: B1b
34050 EYÜP-İSTANBUL
TEL : [phone] FAKS: (0212) 467 80 00
E-POSTA :
FİRMA YETKİLİ İMZASI:
ARZUM ELEKTRİKLİ
EV ALETLERİ SAN. VE TİC. A.Ş.
ÜRÜNÜN CİNSİ : SERAMİK TABANLI ÜTÜ
MARKASI : ARZUM
MODELİ : STEAMPRO 2001
TYPE NO : AR 682
BANDROL VE SERİ NO :
TESLİM TARİHİ VE YERİ :
GARANTİ SÜRESİ : 3 YIL
AZAMİ TAMİR SÜRESİ : 20 İŞ GÜNÜ
SATICI FİRMA
UNVAN :
ADRES :
TEL - FAKS :
E-POSTA :
FATURA TARİH VE NO :
TESLİM TARİHİ VE YERİ :
TARİH, İMZA VE KAŞE :
GARANTİ BELGESİ
Bu belgenin kullanılması 6502 sayılı Tüketici Korunması Hakkında Kanun ve bu
kanuna dayanılarak yürürlüğe konulan Garanti Belgesi Uygulama Esaslarına Dair
Tebliğ uyarınca Arzum Elektrikli Ev Aletleri San.ve Tic. A.Ş. tarafından hazırlanmıştır.
STEAMPRO 2001

www.arzum.com
GENEL DAĞITICI
ARZUM ELEKTRİKLİ EV ALETLERİ SAN. VE TİC. A.Ş.
Otakçılar Caddesi No: 78 Kat: 1 B Blok No: B1b
Eyüp 34050 İstanbul Türkiye
Tel: [phone] Faks: (0212) 467 80 00
AR682-050216
