ASROCK Rack MP-1543R4 User manual

Quick Installation Guide
Mezzanine PHY Card Series
P/N: 15G065098000AK V1.0
Introduction
ank you for purchasing ASRock Rack mezzanine card, a reliable mezzanine card
produced under ASRock Rack’s consistently stringent quality control. It delivers excellent
performance with robust design conforming to ASRock Rack’s commitment to quality and
endurance.
Model Dimension Interface / Connector PHY Chip
MP-1543R4 4.3" x 2.8"
(110 x 71.01 mm)
1Gbps (4x KX host
connection via OCP PHY
Mezzanine Connector C)
/ 4 x RJ-45 Marvell 88E1543
MP-557R2 4.3" x 2.8"
(110 x 71.01 mm)
10Gbps (2x KR host
connection via OCP PHY
Mezzanine Connector C)
/ 2 x RJ-45 Intel X557-AT2
MP-4223R4 4.3" x 2.8"
(110 x 71.01 mm)
10Gbps (4x KR host
connection via OCP PHY
Mezzanine Connector C)
/ 4 x 10G SFP+
(Fiber) Inphi CS4223
MP-4227R2 4.3" x 2.8"
(110 x 71.01 mm)
10Gbps (2x KR host
connection via OCP PHY
Mezzanine Connector C)
/ 2 x 10G SFP+
(Fiber) Inphi CS4227
• 1 x Mezzanine PHY Card
• 4 x Spacer Supports
• 1 x Quick Installation Guide
Package Contents
*15G065098000AK*

1 2 3 4
MP-1543R4
LAN Port LED Indications
Layout
Activity/LinkLED
Status Description
O No Link
Blinking Data Activity
On Link
SpeedLED
Status Description
O No connection
Green 1Gbps connection
1 LAN RJ-45 Ports (LAN4) 3 LAN RJ-45 Ports (LAN2)
2 LAN RJ-45 Ports (LAN3) 4 LAN RJ-45 Ports (LAN1)
ACT/LINK LED
SPEED LED
LAN Port

12
MP-557R2
LAN Port LED Indications
Layout
Activity/LinkLED
Status Description
O No Link
Blinking Data Activity
On Link
SpeedLED
Status Description
O No connection
Orange 1Gbps connection
Green 10Gbps connection
ACT/LINK LED
SPEED LED
L
A
N Port
1 LAN RJ-45 Port (LAN1) 2 LAN RJ-45 Port (LAN2)

1 10G SFP+ (Fiber) (SFP+_CON1) 3 10G SFP+ (Fiber) (SFP+_CON3)
2 10G SFP+ (Fiber) (SFP+_CON2) 4 10G SFP+ (Fiber) (SFP+_CON4)
1234
MP-4223R4
LAN Port LED Indications
110.05mm(4.3in)
71.00mm(2.8in)
9.80mm(0.4in)
Layout
Activity/LinkLED
Status Description
O No Link
Blinking Data Activity
On Link
SpeedLED
Status Description
O No connection
Orange 1Gbps connection
Green 10Gbps connection
ACT/LINK LED
SPEED LED
LAN Port

12
MP-4227R2
LAN Port LED Indications
110.05mm(4.3in)
71.00mm(2.8in)
9.80mm(0.4in)
Layout
Activity/LinkLED
Status Description
O No Link
Blinking Data Activity
On Link
SpeedLED
Status Description
O No connection
Orange 1Gbps connection
Green 10Gbps connection
ACT/LINK LED
SPEED LED
LAN Port
1 10G SFP+ (Fiber) (SFP+_CON1) 2 10G SFP+ (Fiber) (SFP+_CON2)

MezzaninePHYCardInstallation
Before installing a mezzanine card to a motherboard, remove the motherboard from the
chassis. To do so, be sure to power down the system and remove all connected cables rst. For
more details, refer to the user manual that comes with your system.
*e illustrations are for reference only and may be slightly dierent from the real products due to dierent models.
1. Install the four spacer supports into the motherboard around the mezzanine card slot.
1
2. Gently insert the mezzanine card into the mezzanine card slot on the motherboard.
2
When the mezzanine card is well installed, horizontally slide the motherboard back to the
chassis so the I/O connectors t through the I/O openings at the rear of the chassis. Well install
the motherboard to the chassis with screws.
Simply squeeze the top of each spacer support to release the mezzanine card.
