ASROCK ROMED6U-2L2T User manual

ROMED6U-2L2T
Quick Installation Guide
www.asrockrack.com
2
Install the Server Board
Motherboard Layout
The server board User's Manual is available for download from the ASRock Rack's o󰀩cial website
at http://www.asrockrack.com.
Take note of the following precautions before you install server board components or change any
server board settings.
1. Unplug the power cord from the wall socket before touching any components.
2. To avoid damaging the server board’s components due to static electricity, NEVER place your
server board directly on the carpet or the like. Also remember to use a grounded wrist strap or
touch a safety grounded object before you handle the components.
3. Hold components by the edges and do not touch the ICs.
4. Whenever you uninstall any component, place it on a grounded anti-static pad or in the bag
that comes with the component.
5. When placing screws into the screw holes to secure the server board to the chassis, please do
not over-tighten the screws! Doing so may damage the server board.
1
I/O Panel3
P/N: 15G065170000AK V1.0
*15G065170000AK*
1Insert the server board into the chassis.
2Affix the screws clockwise into the
mounting holes in all of the corners of
the server board.
Do not over-tighten the screws
No. Description
1 ATX 12V Power Connector (ATX12V2)
2 ATX 12V Power Connector (ATX12V1)
3 ATX 4-PIN Power Connector (ATX4PIN1)
4 PSU SMBus Header (PSU_SMB1)
5 PWM Conguration Header (PWM_CFG1)
6 System Fan Connector (FAN1)
7 System Fan Connector (FAN2)
8 System Fan Connector (FAN3)
9 System Fan Connector (FAN4)
10 System Fan Connector (FAN5)
11 System Fan Connector (FAN6)
12 3 x 288-pin DDR4 DIMM Slots (DDR4_E1, DDR4_
G1, DDR4_H1)
13 3 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_
C1, DDR4 _D1)
14 SATA Power Connector (DC-IN Mode) (SATA-
PWR1)
15 M.2 Socket (M2_1) (Type 2280)
16 Slimline NVMe Connector (SLIM3)
17 Slimline NVMe Connector (SLIM2)
18 Slimline NVMe Connector (SLIM1) (Right-Angled)
19 SATA3 Connector (SATA1)
20 Mini-SAS HD Connector (MSAS_HD0) (Right-Angled)
21 Mini-SAS HD Connector (MSAS_HD1) (Right-Angled)
22 Speaker Header (SPEAKER1)
23 System Panel Header (PANEL1)
24 Backplane PCI Express Hot-Plug Connector
(CPU1_HSBP1)
25 SATA SGPIO Connector (SATA_SGPIO3)
26 SATA SGPIO Connector (SATA_SGPIO2)
27 SATA SGPIO Connector (SATA_SGPIO1)
28 SATA3 Connector (SATA0)
29 Front LAN LED Connector (LED_LAN3_4)
30 USB 3.2 Gen1 Header (USB3_3_4) (Right-Angled)
31 Clear CMOS Pad (CLRMOS1)
32 COM Port Header (COM1)
33 TPMS Header (TPMS1)
34 ermal Sensor Header (TR1)
35 Auxiliary Panel Header (AUX_PANEL1)
36 BMC SMBus Header (BMC_SMB1)
37 Intelligent Platform Management Bus Header
(IPMB_1)
38 Non Maskable Interrupt Button (NMI_BTN1)
39 M.2 Socket (M2_2) (Type 2260)
24.4cm (9.6 in)
VGA1
DDR4_G1 (64 bit, 288-pin module)
DDR4_H1 (64 bit, 288-pin module)
ATX12V2
USB 3.2 Gen1
T: USB2
B: USB1
IPMI_LAN
LAN3
UID1
PCIE7
M2_1
NUT80
HDLED RESET
PLED PWRBTN
PANEL1
1
1
SPEAKER1
1
T 1
R
1
IPMB_1
1
ASPEED
AST2500
ATX12V1
BMC
ROM
LGA4094
Socket SP3
PSU_SMB1
1
LAN4
DDR4_D1 (64 bit, 288-pin module)
DDR4_C1 (64 bit, 288-pin module)
FAN4
BATTERY1
ATX4PIN1
SATA_PWR1
PWM_CFG1
NMI_BTN1
24.4Cm (9.6 in)
12
3456 8
9
10
11
12
13
14
15
16
17
2324262728
CLRMOS1
25
DDR4_E1 (64 bit, 288-pin module)
DDR4_A1 (64 bit, 288-pin module)
PCIE6
PCIE5
PCIE4
LAN1
LAN2
FAN3
FAN2
FAN1
FAN5
FAN6
SLIM3
SLIM2
SLIM1
MSAS_HD0
MSAS_HD1
Super
I/O
Intel
X710-AT2
Intel
I210-AT2
Intel
I210-AT2
1
SATA_SGPIO3
1
SATA_SGPIO2
1
SATA_SGPIO1
1
LED_LAN3_4
USB3_3_4
1
COM1
TPMS1
1
1
AUX_PANEL1
BMC_SMB1
ROMED6U-2L2T
BIOS
ROM
7
18
19
20
21
22303132 2933353637 3438
CPU_HSBP1
SATA0
SATA1
2
3
167
8
4
5
No. Description No. Description
1 UID Switch (UID1) 5 1G LAN RJ-45 Port (LAN4)
2 USB 3.2 Gen1 Ports (USB3_1_2) 6 VGA Port (VGA1)
3 LAN RJ-45 Port (IPMI_LAN1) 7 10G LAN RJ-45 Port (LAN1)
4 1G LAN RJ-45 Port (LAN3) 8 10G LAN RJ-45 Port (LAN2)
4Power Connectors
ATX 12V Power
(ATX12V1/ATX12V2)
ATX 4-Pin Power (ATX4PIN1)
4
8
1
5
12V
GND
12
34
ATX_PWROK
PSON#
GND
ATX_+5VSB
M2_2
39
NUT60_2
TOP VIEW BOTTOM VIEW

ROMED6U-2L2T
Quick Installation Guide
www.asrockrack.com
1G LAN Port (LAN3, LAN4) LED Indications
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10Mbps connection or
no link
Blinking Green Data Activity Yel low 100Mbps connection
On Link Green 1Gbps connection
10G LAN Port (LAN1, LAN2) LED Indications
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 100Mbps connection or
no link
Blinking Yellow Data Activity Yel low 1Gbps connection
On Link Green 10Gbps connection
8LAN Port LED Indications
IPMI LAN Port
ACT/LINK LED
SPEED LED
LAN Port
LAN Port
5Install the Processor and Heatsink
We recommend using the CPU Installation tool to avoid CPU pin-bent problem.
3
4
7
8
Locate the three torx screws on the CPU socket and
unscrew them according to the order A→B→C. Open
the rst retention cover.
Open the second bracket. Take out the internal
plastic cover.
Install CPU along with the carrier frame, do not
separate them. Please make sure the carrier frame
with CPU is closely attached to the rail frame while
inserting it.
Please make sure that the carrier
frame with CPU is closely attached to
the rail frame while inser ting it.
5
6
Install the carrier frame with CPU. Don’t separate them.
Carrier Frame with CPU
Rail Frame
Close the bracket that holds the CPU. Close the
retention cover. Fasten the torx screw according to the
order A→B→C.
1
2
M.2_SSD (NGFF) Module Installation
9
1
2
3
Prepare a M.2_SSD (NGFF) module and the screw.
Gently insert the M.2 (NGFF) SSD module into the
M.2 slot. Please be aware that the M.2 (NGFF) SSD
module only ts in one orientation.
Tighten the screw with a screwdriver to secure the
module into place. Please do not overtighten the
screw as this might damage the module.
20o
NUT1NUT2
7Install the Memory
1
2
3
Unlock a DIMM slot by pressing
the module clips outward.
Insert the memory module.
Lock the clips.
System Panel Auxiliary Panel
10 Panel Headers
GND
RESET#
PWRBTN#
PLED-
PLED+
GND
HDLED-
HDLED+
1
GND
6Install the PCIE Card
1Remove the bracket facing the slot that
you intend to use. Keep the screw for
later use.
2Align the card connector with t he
slot and press firmly until the card is
completely seated on the slot.
Fasten the card to the chassis with the
screw.
3
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10M bps connection or no
link
Blinking Yellow Data Activity Yel low 100M bps connection
On Link Green 1Gbps connection
ACT/LINK LED
SPEED LED
LAN Port
SPEED LED
ACT/LINK LED
GND
SMB_CLK
SMB_Alert
CASEOPEN
1
SMB_DATA
+3VSB
LAN1_LINK
LED_PWR
LAN2_LINK
LED_PWR
+5VSB
GND
GND
LOCATORLED1+
LOCATORLED1-
LOCATORBTN#
LOCATORLED2+
LOCATORLED2-
AB
CD
A1 C1 D1 E1 G1 H1
1 DIMM #
2 DIMMS # #
4 DIMMS # # # #
6 DIMMS ######
