Assa Abloy Emtek EMPowered User manual

EMPowered Motorized Touchscreen
Keypad Deadbolt

2
What’s in
the box
x3
#8-32 x 5/16”
Machine Screws
x4
#8 x 3/4”
Wood Screws
x2
#10-32 x 1-3/8”
Machine Screws
x2
#10 x 3”
Wood Screws
AA x4
BatteriesSecurity Plate
Strike Plate
Battery
Cover
Mounting
Plate
Interior
Escutcheon
Deadbolt Latch
2-3/8”
Deadbolt Latch
2-3/4”

3
Door Prep
Door Jamb Prep
2-3/8” or 2-3/4” Backset
2-1/8” Diameter Bore
1/8” Deep
2-1/4”
1”
1” Diameter Edge Bore
2-3/4"
3/16” Deep
2-3/4”
1-1/8”
3/4”
1-1/4”
1-1/4” Deep

4
Install Latch & Strike Plate
!
Bolt must be in retracted
(unlocked) position. Note
horizontal orientation of
mechanism.
1
x2
x4
Note: Use only the
supplied latch for proper
functionality.
!

5
Install Touchscreen Escutcheon
2
Outside of the door Inside of the door

6
Install Interior Mounting Plate
3
Loosen screw to
remove cover.
x2

7
Connect the Cable Assembly
4

8
Install Interior Escutcheon
5
x3
See comment about
reset button on page
16, “Resetting Lock to
Factory Default.”

9
Testing Operation
6

10
!
Bolt must be in retracted
(unlocked) position
before installing batteries.
Install Batteries
7

11
Install Cover
8
Secure cover by tightening
screw on bottom.

12
Handing the Lock
Activate the Lock
OR
“Handing Lock”
“Handing Lock
Complete”

13
Creating a Master PIN Code
must be performed upon
installation or after resetting
the lock to factory default.
Programming and use of
lock is not possible until this
step has been successfully
completed.
“Enter a 4 to 8 digit
PIN Code followed by
the gear key.”
“Registered.”
Press
Press
“Register Master
Code. Press the gear
key to continue.”
Creating Master PIN Code

14
Master PIN Code must be created rst.
*Max User Codes = 250 with Network Module.
*Max User Codes = 25 without Network Module.
Enter Master PIN Code
Press
Enter 4-8 digit PIN Code
Press
(code ashes)
To end programming:
Adding more
User Codes:
Press
“Menu Mode,
enter number,
press the gear key
to continue.”
Press
Enter 4-8 digit PIN Code
Press
Press
Press
2Press
Press
1
Creating User PIN Code

15
Code Chart Duplicate if Necessary
Enter PIN Code
Press
PIN Code Management (With Network Module - Up to 250 Users)
User Type User Name User # PIN Code
Master
User____
User____
User____
User____
User____
User____
User____
User____
User____
User____
User____
User____
User____
User____
Unlocking Door with PIN Code

16
Factory Settings
When lock is reset to factory defaults, all User Codes (including the Master PIN Code*)
are deleted and all programming features are reset to original default settings (see
below).
1. Remove battery cover and batteries.
2. Remove the interior escutcheon to access the reset button.
3. The reset button (see page 8, Step 5) is located beside the PCB cable connector.
4. While pressing the reset button (Minimum of 3 seconds) reinstall batteries.
Release reset button.
5. Replace battery cover.
Upon reset, Master PIN Code creation is the only option available and must be
performed prior to any other programming of the lock.
Factory Settings
Settings
Resetting Lock to Factory Default
Master PIN Code Registration required*
Automatic Re-lock Disabled
Inside Indicator Light Disabled (O)
One Touch Locking Enabled
Volume Setting Enable (Low)
Language Setting English
Lockout Mode Disabled
Automatic Re-lock Time 30 Seconds
Wrong Code Entry Limit 5 Times
Shutdown Time 60 Seconds
*The Master PIN Code must be registered prior to any other programming of the lock.

17
Denitions
All Code Lockout Mode: This feature is enabled by the Master PIN Code. When enabled, it restricts all
user (except Master) PIN Code access. When attempting to enter a code while the unit is in Lockout, the
RED locked padlock will appear on the screen.
Automatic Re-lock Time: After a successful code entry and the unit unlocks, it will automatically re-lock
after thirty (30) seconds.
Inside Indicator Light: Located on the interior escutcheon. Shows active status (Locked) of lock and can
be enabled or disabled in the Advanced Lock Settings (Main Menu selection #3).
Language Setting Mode: Choosing English (1), Spanish (2) or French (3) becomes the (default) setting for
the lock’s voice prompts.
Low Battery: When battery power is low, the Low Battery Warning indicator ashes RED. If battery power
is completely lost, use the 9 Volt battery override. To use the 9V battery override apply 9V battery, in either
direction, to terminals below the touchscreen for backup power option. Wake up the lock and enter your
PIN Code to unlock the door.
Master PIN Code: The Master PIN Code is used for programing and for feature settings. It must be
created prior to programming the lock. The Master PIN Code will also operate (unlock/lock) the lock.
Network Module Settings: With the optional Network Module installed, this setting becomes available thru
the Main menu (7) and allows the lock to connect with a network controller.
One Touch Locking: When the latch is retracted, activating the keypad will extend the latch (during
Automatic Re-lock duration or when Automatic Re-lock is disabled). When One-Touch Re-lock is not in
use (disabled), any valid PIN Code will re-lock the lock.
Previous: While in Menu Mode, pressing this icon cancels the current operation and returns the user to the
previous step.
Privacy Mode: Privacy mode is disabled by default Privacy mode is enabled/disabled in the app.
Shutdown Time: The unit is shutdown (ashing RED) for sixty (60) seconds and does not allow operation
after the wrong code entry limit (5 attempts) has been met.
Tamper Alert: Audible alarm sounds if attempting to forcibly remove outside lock from door.
User PIN Code: The User Code operates the lock. Maximum number of User Codes is 250 with Network
Module; without Network Module maximum is 25 User Codes. Note: When deleting User Code(s), screen
will display User Number (not code) being deleted.
Volume Setting Mode: The volume setting for PIN Code verication is set to Low (2) by default; otherwise
it can be set to High (1) or Silent (3) for quiet areas.
Wrong Code Entry Limit: After ve (5) unsuccessful attempts at entering a valid PIN Code, the unit will
shut down and not allow operation.

18
1. Touch screen with back of hand or palm to activate.
2. Enter 4-8 digit master PIN Code* followed by key.
Lock Response: “Menu mode, enter number, press key to continue.”
3. Enter digit corresponding to the function to be performed followed by the key.
Follow the voice commands.
*The Master PIN Code must be registered prior to any other programming of the lock.
Feature Programming Trough Menu Mode
Using Master PIN Code*

19
Performs
automatic
handing of
the lock.
Default settings
in bold.
**This function appears only
with network module installed.
Master PIN Code Setting
Register
Enable
Join the Network
Low
Spanish
High
English
Disable
Exit the Network
Silent
French
Delete
M
U
U
U
Continue
Continue
Continue
Complete
Complete
Complete
User PIN Code Registration
Handing the Lock
1
1
1
1
2
2
1
1
3
3
3
3
3
PIN
PIN
PIN
PIN
2
5
Volume Settings
4
Language Setting Mode
5
Lockout Mode
6
**Network Module Setting
7
Complete
Disable
Enable
Enable
Disable
Disable
30 sec
60 sec
2 min
3 min
Continue
Advanced Lock Settings Automatic Re-lock
Inside Indicator Light
One Touch Locking
1
1
1
3
3
2
3
4
5
31
2
3

20
Programming Troubleshooting
*When batteries are replaced. Network Module locks have a real time clock that will be set through the User Interface (UI);
it is recommended to verify correct date and time particularly those locks operating under Daylight Saving Time (DST).
Symptom Suggested Action
Lock does not respond
- door is open and
accessible.
• Touchscreen becomes active when pressed with whole hand. Use larger area of the hand or ngers
and verify contact with at least 3 numbers.
• If touchscreen numbers are visible, check to see if they respond when pressed.
• Check batteries are installed and oriented correctly (polarity) in the battery case.
• Check batteries are in good condition; replace batteries* if discharged.
• Check to see if touchscreen harness is fully connected and not pinched.
Lock does not respond
- door is locked and
inaccessible.
• Batteries may be completely discharged.
• Apply 9V Battery to terminals below the touchscreen for backup power option.
Unit is on for a while
then shows no reaction.
Lights dim.
• Batteries do not have enough power. Replace Batteries*.
Unit Chimes to indicate
code acceptance, but the
door will not open.
• Check door gaps for any foreign objects between door and frame.
• Check that the wire harness is rmly connected to the PCB.
Unit operates to allow
access, but will not auto-
matically re-lock
• Check to see if Auto Re-lock Mode is enabled.
• Disable Auto Re-lock Mode to lock the door (automatically).
• If low battery indicator is lit (see below), change batteries*.
PIN Codes will not
register.
• PIN Codes must consist of 4 to 8 digits to register.
• The same PIN Code cannot be used for multiple users.
• Registration/management of PIN Codes is set by the authority of the
Master PIN Code, which is set rst.
• Contact the Master user.
• User Codes must be entered within 5 seconds (while touchscreen is active) or process will have to be
restarted.
• Check or gear cannot be used as part of the PIN Code.
Upon entering a PIN
Code and pressing
key, the unit displays
“invalid code” error or
lock times out without
responding.
• Lockout Mode is enabled.
• Only the Master user can enable/disable Lockout Mode.
• Contact the Master user.
Upon entering a PIN
Code and pressing the
key, the red padlock
icon appears and there
are dierent tones.
• Check to see if the lock is set to Lockout Mode.
• Setting/managing Lockout Mode is done through Master PIN Code only.
• Contact the Master user.
The unit operates but it
makes no sound.
• Check to see if Silent Mode is enabled (see Feature #4)
The unit responds “Low
Battery”
• This is the alert to replace the batteries. Replace all four (4) batteries*
with new AA Alkaline batteries.
Upon entering a PIN
Code and pressing the
key, the unit responds
“Wrong number of digits”.
• The digits entered were incorrect or incomplete. Re-enter the correct code
followed by the check key.
