Introduction UT5200 Parts Manual
• Refer to the installation instructions for complete installation.
• In order to simplify the ordering procedure, parts are only available
as listed.
• To order parts, use the appropriate Part Number and specify Finish (fin)
as directed. For example, to order ten Knob Sleeves for the UT5255
Function in 626 finish, use the following configurations:
• For assistance, contact your authorized Corbin Russwin Distributor or
contact Corbin Russwin directly at the address on the back cover.
Quantity Part Number Finish Hand
10 401F08 626

3
The warranty on Corbin Russwin products becomes void if the product is modified in any way, regardless of whether the modifications causes or contributes to any alleged defect. If a
Corbin Russwin product is modified it may no longer meet industry certification and quality control standards applicable to the original product and is no longer a genuine Corbin Russwin product.
Copyright © 1999-2018, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express written permission of ASSA ABLOY Access
and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
Table of Contents UT5200 Parts Manual
Introduction ......................................................................................................................................... 2
Quick Conversion................................................................................................................................. 4
Do You have the current model? ....................................................................................................... 5
Parts List
UT5210 Passage or Closet ......................................................................................... 6-7
UT5220 Privacy, Bedroom or Bathroom ..................................................................... 8-9
UT5251 Entrance or Office .................................................................................... 10-11
UT5255 Classroom ................................................................................................ 12-13
UT5257 Storeroom or Closet ................................................................................. 14-15
UT5261 Entrance or Office (levers only) ................................................................. 16-17
UT5272 Apartment, Exit or Public Toilet ................................................................ 18-19
UT5282 Store Door ............................................................................................... 20-21
Typical Knob Configuration ............................................................................................................. 22
Interchangeable Core Configuration ............................................................................................... 23
Lever and Knob Shank – Comparison Guide ................................................................................... 24
Options and Accessories ................................................................................................................... 25
Parts Cross Reference .................................................................................................................. 26-28
Routine Maintenance ....................................................................................................................... 29
Troubleshooting Guide ................................................................................................................ 30-31
Cylinder Removal Instructions ......................................................................................................... 32
Current Model
Lever Version..................................................................................................................... 32-33
Knob Version..................................................................................................................... 34-35
Discontinued Models
Corbin 2000/2200/2400 and 500 Series (1899 - 1963) .......................................................... 36
Corbin 700/Russwin 1600 Series “Baby” Unit Lock................................................................. 37
Russwin 2100/2800 Series only (1904 - 1968) ....................................................................... 38
Service Procedures ....................................................................................................................... 39-40
Changing from Knobs to Levers..................................................................................................... 39
Changing Hand of Lockset:
Knob Version..................................................................................................................... 39-40
Lever Version ......................................................................................................................... 41

4
The warranty on Corbin Russwin products becomes void if the product is modified in any way, regardless of whether the modifications causes or contributes to any alleged defect. If a
Corbin Russwin product is modified it may no longer meet industry certification and quality control standards applicable to the original product and is no longer a genuine Corbin Russwin product.
Copyright © 1999-2018, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express written permission of ASSA ABLOY Access
and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
Quick Conversion and Function UT5200 Parts Manual
Function
Quick Conversion As of May 1993, Corbin Russwin has introduced a new simplified product numbering
system that makes it easy to identify, specify and order a complete line of architectural
hardware.
Although the catalog numbers have changed, the part numbers have remained the
same. Identifying parts is as easy as it’s always been! To find a function or trim design,
simply use this “Quick Conversion” as a helpful cross reference bridge from the former
Corbin and Russwin languages (pre-May 1993) to the new Corbin Russwin language.
Corbin
Function No.
Before 5/93
Function No.
After 5/93
Page
310 UT5210 6
320 UT5220 8
351 UT5251 10
354 UT5272 18
355 UT5255 12
357 UT5257 14
361 UT5261 16
388 UT5282 20
Trim Design
Before 5/93
Trim Design
After 5/93
912R ESE
964 Global GRE
966 Pierce BRE
Russwin
Function No.
Before 5/93
Function No.
After 5/93
Page
510 UT5210 6
520 UT5220 8
540 UT5251 10
540
5/8
UT5255 12
546 UT5261 16
546
1/2
UT5272 18
548
1/2
UT5282 20
552 UT5257 14
Trim Design
Before 5/93
Trim Design
After 5/93
912R ESE
Ashford GRE
Belmont BRE
UT5210
ANSI F36
Passage or Closet
UT5220
ANSI F37
Privacy, Bedroom
or Bathroom
UT5251
ANSI F40
Entrance or Office
UT5255
ANSI F42
Classroom
UT5257
ANSI F44
Storeroom or Closet
UT5261
ANSI F41
Entrance or Office
(Levers only)
UT5272
ANSI F45
Apartment, Exit or
Public Toilet
UT5282
ANSI F46
Store Door

5
The warranty on Corbin Russwin products becomes void if the product is modified in any way, regardless of whether the modifications causes or contributes to any alleged defect. If a
Corbin Russwin product is modified it may no longer meet industry certification and quality control standards applicable to the original product and is no longer a genuine Corbin Russwin product.
Copyright © 1999-2018, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express written permission of ASSA ABLOY Access
and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
Do You Have the Current Model? UT5200 Parts Manual
Historically, no lockset design has
been as closely associated with the
Corbin Russwin brand name as the unit
lock. The unit lock’s sturdy, rugged
construction gives it an unrivaled lifetime
of smooth, trouble-free operation.
Tens of thousands of these locks have
already outlasted the buildings they
were installed in! Now, past its 100th
anniversary, the unit lock has evolved
through several different models.
The rectangular chassis unit lock was
invented by Byron Phelps, former mayor
of Seattle, Washington. He brought
his invention across the country in
1898 to P.F. Corbin, who licensed and
manufactured it. The first patents were
issued on January 31 and June 6, 1899.
Today’s UT5200 Series locksets are
closely based on that design.
Instead of the large rectangular chassis
by Corbin, the earliest Russwin unit lock
had a different design and door prep. A
1" round knob spindle was completely
separated from a small rectangular case
around the latch area. This design was
invented by Henry Voight, an extremely
prolific lock inventor of that era, then
employed by Russell & Erwin Mfg. Co.
Its first patents issued on April 19 and
August 30, 1904.
The exploded views in this manual
are limited to the current model of
UT5200 Series parts. For most functions,
this includes all locks manufactured
since 1968, although certain current
parts will operate in some older models.
Since locksmiths are often called on to
rekey older locksets, we include cylinder
removal instructions for earlier models
later in this manual. Use the table below
to help identify the various models.
In reviewing the table, keep in mind
that Corbin Russwin began as separate
companies, so there is not a Corbin-to-
Russwin cross-reference for the early
models.
Old catalogs, price books and
engineering drawings, as well as physical
samples were studied to compile the
table. However, a few pieces of the
puzzle were still missing at press time.
Anyone with locksets or positive
documentation to correct or add to this
information is invited to contact the
Corbin Russwin Marketing Department.
With lock removed, apply these clues to the table below to determine the model of your lock.
• If it bears the Russwin name and the knobs have a round shaft separate from a small rectangular chassis, it is the Russwin
2100/2800 Series.
• Look for numbers cast into underside of escutcheons.
• Observe keyway orientation and measure chassis dimensions.
• Read latest patent date stamped into chassis cover.
• Look for numbers stamped into top or bottom edge of chassis frame (Note: some numbers are not significant)
Corbin
Series
Russwin
Series Keyway Chassis
Dimensions Backset Cylinder
Series
First
Sold
Last
Sold Remarks
(0)2000* –––– vertical
1 1/2 x 3 1/2"
1 1/2 x 3 3/4"
1 1/2 x 3 1/2"
2 3/4"
3"
3"
250 1899 1913 4 or 5 pin 99 or 97 keyway
(0)2200* –––– vertical
2 x 3 3/4"
2 3/16 x 4"
2 5/8 x 4"
3"
3" 250 1913 1953 anti-friction fire (dead) latch
(0)2400* –––– vertical
2 x 3 1/2"
2 x 3 3/4"
2 5/8 x 3 3/4"
2 3/4"
3"
3"
250 1913 1953
–––– 2100/2800 vertical (see remarks) 3" 2100 1904 1968 small chassis + 1" spindle
7xx-500 –––– vertical 2 5/8 x 3 3/4" 3" 250 1954 1966 = largest 2400 Series renamed
?–––– vertical 1 3/8 x 3" 2 3/8" ? ? ? small model
9xx-700 1600 horizontal 1 3/4 x 3 1/4" 2 1/2" 260 & 250 1949 1954 small model
9xx-900 600 horizontal 1 3/4 x 3 1/4" 2 1/2" 460 1955 1963
9xx-300 500 horizontal 1 3/4 x 3 5/8" 2 1/2" 460 1963 current changed in 1968; now UT5200
* "0" prefix designates deadlatching. Numbers without this prefix are not deadlatching.

6
The warranty on Corbin Russwin products becomes void if the product is modified in any way, regardless of whether the modifications causes or contributes to any alleged defect. If a
Corbin Russwin product is modified it may no longer meet industry certification and quality control standards applicable to the original product and is no longer a genuine Corbin Russwin product.
Copyright © 1999-2018, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express written permission of ASSA ABLOY Access
and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
UT5210 Passage or Closet UT5200 Parts Manual
Essex (RH) Essex (LH) Essex (RH) Essex (LH)
plain 613F10-2 613F11-2 613F14-2 613F15-2
(see chart
below)
Lever or Knob:
plain both sides
613F02-9 Lever Insert (gray)
102F198
060F91-8
Lever Shank
Knob Shank
242F50-8
219F80-8
Shank Retainer for
Lever
Knob
103F44-8
103F45-8
Return Spring
Clockwise (RH) Lever
Counter Clockwise (LH) Lever
171F79-8 Return Spring Anchor
fin
144F33
144F34
301F56-7
605F90
fin
415F15
415F16
415F27-7
605F91
Escutcheon (lever Trim)
inside
outside
outside, extended lip
inside, lead lined option M28
Escutcheon (knob Trim)
inside
outside
outside, extended lip
inside, lead lined option M28
ITEM PART NO. SPECIFY DESCRIPTION
1
2
4
5
6
7
8
222F85 fin Mounting Screw
496F33 fin Chassis
138F88-8 Chassis Cover
060F42-8 Hub
060F33-8 Hub Spacer
249F76-8 Screw, fixed escutcheon
078F07-8 Grip Retainer
078F08-8 Grip Retainer Ring
401F08 fin Sleeve
236L75M020 fin ANSI Strike
(see page 25 for options)
480F70 fin Screw Packet for Strike
ITEM PART NO. SPECIFY DESCRIPTION
9
10
11
12
13
14
15
36
37
17
16
Lever (specify finish)
Note: Levers are handed.
RH lever: Clockwise rotation. For outside
of RH or RHR locks and inside of LH or
LHR locks.
LH lever: Counter-clockwise rotation.
For outside of LH or LHR locks and inside
of RH or RHR locks.
Knobs (specify finish)
Regular Tactile Warning
Global Belmont Global Belmont
plain 383F66 406F33 575F58 575F64
Regular Tactile Warning

7
The warranty on Corbin Russwin products becomes void if the product is modified in any way, regardless of whether the modifications causes or contributes to any alleged defect. If a
Corbin Russwin product is modified it may no longer meet industry certification and quality control standards applicable to the original product and is no longer a genuine Corbin Russwin product.
Copyright © 1999-2018, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express written permission of ASSA ABLOY Access
and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
UT 5210 Passage or Closet UT5200 Parts Manual
UT5210
Parts common to both lever
and knob designs.
Parts for lever design only.
Parts for knob designs only.
For typical knob version of
grip assembly, see page 22.
Screw,
Strike Adjustment
092F78-9
(included with strike)

8
The warranty on Corbin Russwin products becomes void if the product is modified in any way, regardless of whether the modifications causes or contributes to any alleged defect. If a
Corbin Russwin product is modified it may no longer meet industry certification and quality control standards applicable to the original product and is no longer a genuine Corbin Russwin product.
Copyright © 1999-2018, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express written permission of ASSA ABLOY Access
and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
UT5220 Privacy, Bedroom or Bathroom UT5200 Parts Manual
Essex (RH) Essex (LH) Essex (RH) Essex (LH)
Cylinder or Button
Privacy Key Hole
582F11-2
613F12-2
582F12-2
613F13-2
582F13-2
613F16-2
582F14-2
613F17-2
(see chart
below)
Lever or Knob:
Privacy key outside x button inside
613F02-9 Lever Insert (gray)
114F678
102F378
202F338
133F418
Lever Shank, outside
Knob Shank, inside
Lever Shank, outside
Knob Shank, inside
242F50-8
219F80-8
Shank Retainer for
Lever
Knob
103F44-8
103F45-8
Return Spring
Clockwise (RH) Lever
Counter Clockwise (LH) Lever
171F79-8 Return Spring Anchor
fin
144F33
144F34
301F56-7
605F90
fin
415F15
415F16
415F27-7
605F91
Escutcheon (lever Trim)
inside
outside
outside, extended lip
inside, lead lined option M28
Escutcheon (knob Trim)
inside
outside
outside, extended lip
inside, lead lined option M28
222F85 fin Mounting Screws
496F34 fin Chassis
138F888 Chassis Cover
ITEM PART NO. SPECIFY DESCRIPTION
1
2
4
5
6
7
8
11
10
9
060F42-8 fin Hub
071F62-8 fin Hub
081F77-8 Hub
070F42-8 Hub Spacer
070F43-8 Hub Spacer
249F76-8 Screw, fixed escutcheon
078F07-8 Grip Retainer
078F08-8 Grip Retainer Ring
401F08 fin Sleeve
022F80 fin Button Assy.
022F72-3 fin Button Spring
060F05-3 fin Shoe Spring
071F67-3 fin Spindle Spring
201F18-8 fin Spindle
398F43-8 fin Emergency Key
236L75M020 fin ANSI Strike
(see page 25 for options)
480F70 fin Screw Packet for Strike
ITEM PART NO. SPECIFY DESCRIPTION
12a
12b
12c
13a
13b
14
15
18
19
20
21
22
35
36
37
17
16
Lever (specify finish)
Note: Levers are handed.
RH lever: Clockwise rotation. For
outside of RH or RHR locks
and inside of LH or LHR locks.
LH lever: Counter-clockwise rotation.
For outside of LH or LHR locks and
inside of RH or RHR locks.
Knobs (specify finish)
Regular Tactile Warning
Global Belmont Global Belmont
Cylinder or Button
Privacy Key Hole
383F65
383F67
406F32
406F34
575F57
575F59
575F63
575F65
Regular Tactile Warning

9
The warranty on Corbin Russwin products becomes void if the product is modified in any way, regardless of whether the modifications causes or contributes to any alleged defect. If a
Corbin Russwin product is modified it may no longer meet industry certification and quality control standards applicable to the original product and is no longer a genuine Corbin Russwin product.
Copyright © 1999-2018, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express written permission of ASSA ABLOY Access
and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
UT5220 Privacy, Bedroom or Bathroom UT5200 Parts Manual
Parts common to both lever
and knob designs.
Parts for lever design only.
Parts for knob designs only.
For typical knob version of
grip assembly, see page 22.
Screw,
Strike Adjustment
092F78-9
(included with strike)
Note: Outside
lever has hole for
emergency key.
UT5220

10
The warranty on Corbin Russwin products becomes void if the product is modified in any way, regardless of whether the modifications causes or contributes to any alleged defect. If a
Corbin Russwin product is modified it may no longer meet industry certification and quality control standards applicable to the original product and is no longer a genuine Corbin Russwin product.
Copyright © 1999-2018, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express written permission of ASSA ABLOY Access
and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
UT5251 Entrance or Office UT5200 Parts Manual
Essex (RH) Essex (LH) Essex (RH) Essex (LH)
Cylinder or Button
6-Pin IC
7-Pin IC
582F11-2
489F88-2
613F22-2
582F12-2
489F89-2
613F23-2
582F13-2
549F35-2
613F24-2
582F14-2
549F36-2
613F25-2
(see chart
below)
Lever or Knob:
cylinder/button both sides
613F02-9 Lever Insert (gray)
2000-052 fin Standard Cylinder
(see page 25 for options)
188F75-8
188F73-8
187F07-8
147F08-8
Lever Shank, outside
Lever Shank, inside
Knob Shank, outside
Knob Shank, inside
242F50-8
219F80-8
Shank Retainer for:
Lever
Knob
103F44-8
103F45-8
Return Spring
Clockwise (RH) Lever
Counter Clockwise (LH) Lever
171F79-8 Return Spring Anchor
fin
144F33
144F34
301F56-7
605F90
fin
415F15
415F16
415F27-7
605F91
Escutcheon (lever trim)
inside
outside
outside, extended lip
inside, lead lined option M28
Escutcheon (knob trim)
inside
outside
outside, extended lip
inside, lead lined option M28
222F85 fin Mounting Screws
ITEM PART NO. SPECIFY DESCRIPTION
1
2
4
3
5
6
7
8
9
496F32 fin Chassis
138F88-8 Chassis Cover
147F078 Hub (Small Hole)
140F978 Hub
060F428 Hub (Large Hole)
249F76-8 Screw, fixed escutcheon
078F07-8 Grip Retainer
078F08-8 Grip Retainer Ring
401F08 fin Sleeve
157F11 fin Button Assy.
249F77-3 Spindle Spring
144F30-8 Spindle
019F137 Drive Pin
019F11-7 Spindle Spring Seat
144F29-8 Plug Driver
584F818 Plug Diver Assy, Follower
236L75M020 fin ANSI Strike
(see page 25 for options)
480F70 fin Screw Packet for Strike
ITEM PART NO. SPECIFY DESCRIPTION
10
11
12 .a
12 .b
12 .c
14
15
18
21
22
23
24
25
26
36
37
17
16
Lever (specify finish)
Note: Levers are handed.
RH lever: Clockwise rotation. For outside
of RH or RHR locks and inside of LH or
LHR locks.
LH lever: Counter-clockwise rotation.
For outside of LH or LHR locks and
inside of RH or RHR locks.
Knobs (specify finish)
Regular Tactile Warning
Global Belmont Global Belmont
Cylinder or Button
Privacy Key Hole
383F65
482F75
406F32
438F79
575F57
577F54
575F63
577F59
Regular Tactile Warning

11
The warranty on Corbin Russwin products becomes void if the product is modified in any way, regardless of whether the modifications causes or contributes to any alleged defect. If a
Corbin Russwin product is modified it may no longer meet industry certification and quality control standards applicable to the original product and is no longer a genuine Corbin Russwin product.
Copyright © 1999-2018, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express written permission of ASSA ABLOY Access
and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
UT5251 Entrance or Office UT5200 Parts Manual
Parts common to both lever
and knob designs.
Parts for lever design only.
Parts for knob designs only.
For typical knob version of
grip assembly, see page 22.
Screw,
Strike Adjustment
092F78-9
(included with strike)
UT5251

12
The warranty on Corbin Russwin products becomes void if the product is modified in any way, regardless of whether the modifications causes or contributes to any alleged defect. If a
Corbin Russwin product is modified it may no longer meet industry certification and quality control standards applicable to the original product and is no longer a genuine Corbin Russwin product.
Copyright © 1999-2018, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express written permission of ASSA ABLOY Access
and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
UT5255 Classroom UT5200 Parts Manual
(see chart
below)
Lever or Knob: Cylinder/Button Outside
x plain inside
613F02-9 Lever Insert (gray)
2000-052 fin Standard Cylinder
(see page 25 for options)
605F77-8
605F76-8
605F80-8
605F81-8
Lever Shank, outside
Lever Shank, inside
Knob Shank, outside
Knob Shank, inside
242F50-8
219F80-8
Shank Retainer for:
Lever
Knob
103F44-8
103F45-8
Return Spring
Clockwise (RH) Lever
Counter Clockwise (LH) Lever
171F79-8 Return Spring Anchor
fin
144F33
144F34
301F56-7
605F90
fin
415F15
415F16
415F27-7
605F91
Escutcheon (lever trim)
inside
outside
outside, extended lip
inside, lead lined option M28
Escutcheon (knob trim)
inside
outside
outside, extended lip
inside, lead lined option M28
222F85 fin Mounting Screws
ITEM PART NO. SPECIFY DESCRIPTION
1
2
4
3
5
6
7
8
9
496F32 fin Chassis
138F88-8 Chassis Cover
147F07-8 Hub
606F03-8 Hub Spacer
249F76-8 Screw, Fixed Escutcheon
078F07-8 Grip Retainer
078F08-8 Grip Retainer Ring
401F08 fin Sleeve
249F77-3 Spindle Spring
606F02-8 Spindle
606F01-8 Plug Driver
584F818 Plug Driver Assy. Follower
168F81-8 Plug Driver Assy.
236L75M020 fin ANSI Strike
(see page 25 for options)
480F70 fin Screw Packet for Strike
ITEM PART NO. SPECIFY DESCRIPTION
10
11
12
13
14
15
21
22
25
26
28
36
37
17
16
Lever (specify finish)
Note: Levers are handed.
RH lever: Clockwise rotation. For outside
of RH or RHR locks and inside of LH or
LHR locks.
LH lever: Counter-clockwise rotation.
For outside of LH or LHR locks and
inside of RH or RHR locks.
Knobs (specify finish)
Essex (RH) Essex (LH) Essex (RH) Essex (LH)
Cylinder or Button
6-Pin IC
7-Pin IC
Plain
582F11-2
489F88-2
613F22-2
613F10-2
582F12-2
489F89-2
613F23-2
613F11-2
582F13-2
549F35-2
613F24-2
613F14-2
582F14-2
549F36-2
613F25-2
613F15-2
Regular Tactile Warning
Global Belmont Global Belmont
Cylinder or Button
6-Pin IC
Plain
383F65
482F75
383F66
406F32
438F79
406F33
575F57
577F54
575F58
575F63
577F59
575F64
Regular Tactile Warning

13
The warranty on Corbin Russwin products becomes void if the product is modified in any way, regardless of whether the modifications causes or contributes to any alleged defect. If a
Corbin Russwin product is modified it may no longer meet industry certification and quality control standards applicable to the original product and is no longer a genuine Corbin Russwin product.
Copyright © 1999-2018, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express written permission of ASSA ABLOY Access
and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
UT5255 Classroom UT5200 Parts Manual
Parts common to both lever
and knob designs.
Parts for lever design only.
Parts for knob designs only.
For typical knob version of
grip assembly, see page 22.
Screw,
Strike Adjustment
092F78-9
(included with strike)
UT5255
Part Change Notice
This function was enhanced
in December 1993 for added
strength. To convert older locks
with ball bearing locking to
1994 model, use parts 4, 13, 22,
25, 26 and 28.

14
The warranty on Corbin Russwin products becomes void if the product is modified in any way, regardless of whether the modifications causes or contributes to any alleged defect. If a
Corbin Russwin product is modified it may no longer meet industry certification and quality control standards applicable to the original product and is no longer a genuine Corbin Russwin product.
Copyright © 1999-2018, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express written permission of ASSA ABLOY Access
and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
UT5257 Storeroom or Closet UT5200 Parts Manual
(see chart
below)
Lever or Knob: Cylinder/Button Outside
x plain inside
613F02-9 Lever Insert (gray)
2000-052 fin Standard Cylinder
(see page 25 for options)
188F75-8
102F19-8
187F07-8
060F91-8
Lever Shank, outside
Lever Shank, inside
Knob Shank, outside
Knob Shank, inside
242F50-8
219F80-8
Shank Retainer for:
Lever
Knob
103F44-8
103F45-8
Return Spring
Clockwise (RH) Lever
Counter Clockwise (LH) Lever
171F79-8 Return Spring Anchor
fin
144F33
144F34
301F56-7
605F90
fin
415F15
415F16
415F27-7
605F91
Escutcheon (lever trim)
inside
outside
outside, extended lip
inside, lead lined option M28
Escutcheon (knob trim)
inside
outside
outside, extended lip
inside, lead lined option M28
222F85 fin Mounting Screws
ITEM PART NO. SPECIFY DESCRIPTION
1
2
4
3
5
6
7
8
9
Lever (specify finish)
Note: Levers are handed.
RH lever: Clockwise rotation. For outside
of RH or RHR locks and inside of LH or
LHR locks.
LH lever: Counter-clockwise rotation. For
outside of LH or LHR locks and inside of
RH or RHR locks.
Knobs (specify finish)
Essex (RH) Essex (LH) Essex (RH) Essex (LH)
Cylinder or Button
6-Pin IC
7-Pin IC
Plain
582F11-2
489F88-2
613F22-2
613F10-2
582F12-2
489F89-2
613F23-2
613F11-2
582F13-2
549F35-2
613F24-2
613F14-2
582F14-2
549F36-2
613F25-2
613F15-2
Regular Tactile Warning
Global Belmont Global Belmont
Cylinder or Button
6-Pin IC
Plain
383F65
482F75
383F66
406F32
438F79
406F33
575F57
577F54
575F58
575F63
577F59
575F64
Regular Tactile Warning
496F32 fin Chassis
138F88-8 Chassis Cover
060F42-8 Hub
140F978 Hub
071F638 Hub
067F42-8 Hub Spacer
249F76-8 Screw, fixed escutcheon
078F07-8 Grip Retainer
078F08-8 Grip Retainer Ring
401F08 fin Sleeve
249F77-3 Button Spring
335F98-8 Spindle
019F13-7 Spindle Drive Pin
019F11-7 Spindle Spring Seat
144F29-8 Plug Driver
236L75M020 fin ANSI Strike
(see page 25 for options)
480F70 fin Screw Packet for Strike
ITEM PART NO. SPECIFY DESCRIPTION
10
11
12 .a
12 .b
12 .c
14
13
15
21
22
23
24
25
36
37
17
16

15
The warranty on Corbin Russwin products becomes void if the product is modified in any way, regardless of whether the modifications causes or contributes to any alleged defect. If a
Corbin Russwin product is modified it may no longer meet industry certification and quality control standards applicable to the original product and is no longer a genuine Corbin Russwin product.
Copyright © 1999-2018, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express written permission of ASSA ABLOY Access
and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
UT5257 Storeroom or Closet UT5200 Parts Manual
Parts common to both lever
and knob designs.
Parts for lever design only.
Parts for knob designs only.
For typical knob version of
grip assembly, see page 22.
Screw,
Strike Adjustment
092F78-9
(included with strike)
UT5257

16
The warranty on Corbin Russwin products becomes void if the product is modified in any way, regardless of whether the modifications causes or contributes to any alleged defect. If a
Corbin Russwin product is modified it may no longer meet industry certification and quality control standards applicable to the original product and is no longer a genuine Corbin Russwin product.
Copyright © 1999-2018, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express written permission of ASSA ABLOY Access
and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
UT5261 Entrance or Office (Levers Only) UT5200 Parts Manual
(see chart
below) Cylinder/button both sides
613F02-9 Lever Insert (gray)
2000-052 fin Standard Cylinder
(see page 25 for options)
156F64-8
156F65-8
Lever Shank, outside
Lever Shank, inside
242F50-8 Shank Retainer
103F44-8
103F45-8
Return Spring
Clockwise (RH) Lever
Counter Clockwise (LH) Lever
171F79-8 Return Spring Anchor
fin
144F33
144F34
301F56-7
605F90
Escutcheon (lever Trim)
inside
outside
outside, extended lip
inside, lead lined option M28
222F85 fin Mounting Screws
198F71 fin Chassis
138F88-8 Chassis Cover
ITEM PART NO. SPECIFY DESCRIPTION
1
2
3
4
5
6
7
8
11
10
9
060F42-8 fin Hub
208F80-8 fin Hub
060F33-8 Hub Spacer
249F76-8 Screw, fixed escutcheon
078F07-8 Grip Retainer
156F43 fin Button Assy.
022F72-3 Button Spring
060F05-3 Shoe Spring
218F08-8 Spindle Spring
156F36-8 Spindle
156F83-7 Pin
107F93-8 Spring
019F15-2 Shank Sleeve
236L75M020 fin ANSI Strike
(see page 25 for options)
480F70 fin Screw Packet for Strike
ITEM PART NO. SPECIFY DESCRIPTION
12 a.
12 b.
13
14
15
18
19
20
21
22
34
33
27
36
37
Lever (specify finish)
Note: Levers are handed.
RH lever: Clockwise rotation. For outside
of RH or RHR locks and inside of LH or
LHR locks.
LH lever: Counter-clockwise rotation.
For outside of LH or LHR locks and
inside of RH or RHR locks.
Essex (RH) Essex (LH) Essex (RH) Essex (LH)
Cylinder or Button
6-Pin IC
7-Pin IC
582F11-2
489F88-2
613F22-2
582F12-2
489F89-2
613F23-2
582F13-2
549F35-2
613F24-2
582F14-2
549F36-2
613F25-2
Regular Tactile Warning

17
The warranty on Corbin Russwin products becomes void if the product is modified in any way, regardless of whether the modifications causes or contributes to any alleged defect. If a
Corbin Russwin product is modified it may no longer meet industry certification and quality control standards applicable to the original product and is no longer a genuine Corbin Russwin product.
Copyright © 1999-2018, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express written permission of ASSA ABLOY Access
and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
UT5261 Entrance or Office (Levers Only) UT5200 Parts Manual
Parts for lever design only.
Parts common to both
lever and knob designs.
Note: UT5261 is NOT a
knob function.
Screw,
Strike Adjustment
092F78-9
(included with strike)
UT5261

18
The warranty on Corbin Russwin products becomes void if the product is modified in any way, regardless of whether the modifications causes or contributes to any alleged defect. If a
Corbin Russwin product is modified it may no longer meet industry certification and quality control standards applicable to the original product and is no longer a genuine Corbin Russwin product.
Copyright © 1999-2018, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express written permission of ASSA ABLOY Access
and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
UT5272 Apartment, Exit or Public Toilet UT5200 Parts Manual
(see chart
below)
Lever or Knob: Cylinder/Button both
sides
613F02-9 Lever Insert (gray)
2000-052 fin Standard Cylinder
(see page 25 for options)
188F75-8
188F738
147F088
187F078
Lever Shank, outside
Lever Shank, inside
Knob Shank, outside
Knob Shank, inside
242F50-8
219F80-8
Shank Retainer for:
Lever
Knob
103F44-8
103F45-8
Return Spring
Clockwise (RH) Lever
Counter Clockwise (LH) Lever
171F79-8 Return Spring Anchor
fin
144F33
144F34
301F56-7
605F90
fin
415F15
415F16
415F27-7
605F91
Escutcheon (lever trim)
inside
outside
outside, extended lip
inside, lead lined option M28
Escutcheon (knob trim)
inside
outside
outside, extended lip
inside, lead lined option M28
222F85 fin Mounting Screws
ITEM PART NO. SPECIFY DESCRIPTION
1
2
4
3
5
6
7
8
9
496F32 fin Chassis
138F88-8 Chassis Cover
060F42-8 Hub
140F97-8 Hub
147F07-8 Hub
249F76-8 Screw, fixed escutcheon
078F07-8 Grip Retainer
078F08-8 Grip Retainer Ring
401F08 fin Sleeve
249F77-3 Spindle Spring
144F30-8 Spindle
019F13-7 Spindle Drive Pin
019F11-7 Spindle Spring Seat
144F29-8 Plug Driver
584F81-8 Plug Diver Assy. Follower
168F81-8 Plug Diver Assy.
236L75M020 fin ANSI Strike
(see page 25 for options)
480F70 fin Screw Packet for Strike
ITEM PART NO. SPECIFY DESCRIPTION
10
11
12 .a
12 .b
12 .c
14
15
21
22
23
24
25
26
28
36
37
17
16
Lever (specify finish)
Note: Levers are handed.
RH lever: Clockwise rotation. For outside
of RH or RHR locks and inside of LH or
LHR locks.
LH lever: Counter-clockwise rotation.
For outside of LH or LHR locks and
inside of RH or RHR locks.
Knobs (specify finish)
Essex (RH) Essex (LH) Essex (RH) Essex (LH)
Cylinder or Button
6-Pin IC
7-Pin IC
582F11-2
489F88-2
613F22-2
582F12-2
489F89-2
613F23-2
582F13-2
549F35-2
613F24-2
582F14-2
549F36-2
613F25-2
Regular Tactile Warning
Global Belmont Global Belmont
Cylinder or Button
6-Pin IC
383F65
482F75
406F32
438F79
575F57
577F54
575F63
577F59
Regular Tactile Warning

19
The warranty on Corbin Russwin products becomes void if the product is modified in any way, regardless of whether the modifications causes or contributes to any alleged defect. If a
Corbin Russwin product is modified it may no longer meet industry certification and quality control standards applicable to the original product and is no longer a genuine Corbin Russwin product.
Copyright © 1999-2018, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express written permission of ASSA ABLOY Access
and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
UT5272 Apartment, Exit or Public Toilet UT5200 Parts Manual
Parts common to both lever
and knob designs.
Parts for lever design only.
Parts for knob designs only.
For typical knob version of
grip assembly, see page 22.
Screw,
Strike Adjustment
092F78-9
(included with strike)
UT5272

20
The warranty on Corbin Russwin products becomes void if the product is modified in any way, regardless of whether the modifications causes or contributes to any alleged defect. If a
Corbin Russwin product is modified it may no longer meet industry certification and quality control standards applicable to the original product and is no longer a genuine Corbin Russwin product.
Copyright © 1999-2018, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express written permission of ASSA ABLOY Access
and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
UT5282 Store Door UT5200 Parts Manual
(see chart
below)
Lever or Knob: Cylinder/Button
both sides
613F02-9 Lever Insert (gray)
2000-052 fin Standard Cylinder
(see page 25 for options)
102F27-8
287F60-8
069F78-8
144F89-8
Lever Shank, outside
Lever Shank, inside
Knob Shank, outside
Knob Shank, inside
242F50-8
219F80-8
Shank Retainer for:
Lever
Knob
103F44-8
103F45-8
Return Spring
Clockwise (RH) Lever
Counter Clockwise (LH) Lever
171F79-8 Return Spring Anchor
fin
144F33
144F34
301F56-7
605F90
fin
415F15
415F16
415F27-7
605F91
Escutcheon (lever trim)
inside
outside
outside, extended lip
inside, lead lined option M28
Escutcheon (knob trim)
inside
outside
outside, extended lip
inside, lead lined option M28
222F85 fin Mounting Screws
ITEM PART NO. SPECIFY DESCRIPTION
1
2
4
3
5
6
7
8
9
381F30 fin Chassis
138F88-8 Chassis Cover
060F42-8 Hub
249F76-8 Screw, fixed escutcheon
078F07-8 Grip Retainer
078F08-8 Grip Retainer Ring
401F08 fin Sleeve
261F11-8 Spindle Spring
144F88-8 Plug Driver & Spindle Assy.
145F32-8 Plug Driver
286F50-7 Pin
251F19-8 Retaining Ring
131F27-8 Coupling
194F22-8 Bushing
236L75M020 fin ANSI Strike
(see page 25 for options)
480F70 fin Screw Packet for Strike
ITEM PART NO. SPECIFY DESCRIPTION
10
11
12
14
15
21
29
30
31
32
36
37
17
16
Lever (specify finish)
Note: Levers are handed.
RH lever: Clockwise rotation. For
outside of RH or RHR locks and inside
of LH or LHR locks.
LH lever: Counter-clockwise rotation.
For outside of LH or LHR locks and
inside of RH or RHR locks.
Knobs (specify finish)
Essex (RH) Essex (LH) Essex (RH) Essex (LH)
Cylinder or Button
6-Pin IC
7-Pin IC
582F11-2
489F88-2
613F22-2
582F12-2
489F89-2
613F23-2
582F13-2
549F35-2
613F24-2
582F14-2
549F36-2
613F25-2
Regular Tactile Warning
Global Belmont Global Belmont
Cylinder or Button
6-Pin IC
383F65
482F75
406F32
438F79
575F57
577F54
575F63
577F59
Regular Tactile Warning
25 .a
25 .b
