Assistive Technology Services SERVICE ANIMAL ALERT User manual

BATTERY PRECAUTION
 Necklace Panic Button Battery: (1)A23S Battery
 Wrist Panic Button Battery: (2) CR2016 Batteries
 When red LED is on (base unit), the backup batteries are low.
 If the LED on Necklace Panic Button turns red when Necklace Panic Button is pressed, it is
time to change the battery.
 If the LED on the Wrist Panic Button dims when the Wrist Panic Button is pressed and held,
it is time to change the battery.
Pairing the Pendants to the Base: If the base does not beep when the pendant is pressed it may need
to be ‘re-paired’ to the Base. Follow the instructions below to pair both pendants to the Base.
1. Turn power Off. (on
Base
Unit)
2. Turn power On
3. Within
4
seconds, press
and hold
the Big Blue Help Button on the
Base
Unit.
4. Then while still holding down the Big Blue Help Button on the Base
Unit, press the Panic Button
on the Necklace Pendant or the Wrist Pendant. (In one second, you will hear a small beep) This
means the pa
i
ring was successful.
5. Pairing will automatically erase other pendants that were previously paired, so you will have to
perform
the steps again for each pendant.
6. Turn
Base
Unit off.
7.Turn
Base
Unit O
n. Wait for Red LED to stop flashing.
8. Press
a
Pendant to Activate Alarm.
(This is to test the pa
i
ring process)
Assistive Technology Services
“Our mission is to provide evaluation, consultation, spiritual
guidance and assistive devices to make the quality of life better
for those that need a little help.”
Visit our website: AtsCares.com
SERVICE ANIMAL ALERT
email: [email protected]
Phone: [phone] v050819d

INSTRUCTION MANUAL
POWER AND TELEPHONE CONNECTION
 Open the cover at the top of Base unit (will see DC jack and
telephone plug socket)
 Insert one end of adaptor (included) to DC jack and other end
to AC power supply outlet
 Insert one end of telephone cable (included) into telephone jack
and other end into Base unit
For backup power, insert 4 AAA batteries (not included) into battery
compartment located on back of unit.
Turn ON unit with switch located at side of unit. The green LED (power
indicator) and red LED will flash for 3 seconds to indicate unit is ready to
record and store numbers.
PERSONALIZE EMERGENCY MESSAGE
Press and hold the above buttons on the keypad – at the same time.
The Red LED light will come on. You have (6) seconds to record your
personal message.
To playback your recorded message, press button:
NOTE: To change the recorded message, repeat steps above
Example: “I need help, please press a button to accept the call”
(If calling from a landline, 911 already has your location)
STORE TELEPHONE NUMBERS
To store telephone numbers, follow these steps:
Press button + 1 + phone number + to store first number
Press button + 2 + phone number + to store second number
Press button + 3 + phone number + to store third number
For Example: to store 1-615-562-0043 as the First contact
Press the following keys * 1 1 6 1 5 5 6 2 0 0 4 3 *
NOTE: If you make a mistake, simply repeat the process above.
*If storing only one number you must program that same number in all three
memory locations or unit will stop dialing after the first call.
#

OPERATION
When the Big Yellow Button is pressed the case will press down on the
Blue button contained inside and activate the alert system. Pressing the
button on the Wrist Panic Button or on Base unit will also activate the
alert system. Upon activation, the Base unit will dial the (3) preset
numbers automatically in the order they were programmed. It will call
each number for (45) seconds. The system will repeatedly play the
outgoing message until the receiver presses ANY button on their phone. If
the receiver does not answer the phone, it will keep dialing for (5) cycles
and then will stop and no longer call any numbers.
When the receiver answers the call from the system, they will hear the pre-
recorded message. The receiver of the call can then open up two-way
communication and listen to the caller’s surroundings by pressing ANY
number on their telephone keypad. After communicating for
approximately (45) seconds, the receiver will hear (3) “beep” tones to
advise the receiver to extend the talk and listen time. Receiver can extend
the time by pressing any number on their keypad to extend for another
(60) seconds. When the conversation is over, the Base unit will go back to
standby mode. The time to go back into standby mode can take up to
several minutes. If the call is answered, the Base unit will stop dialing the
remaining contacts.
Big Yellow Service Animal Alert
Button with Activation Necklace
Button inside. 3 white Styrofoam
Springs.
End view of
Big Yellow Service
Animal Alert Button with Activation
Necklace Button inside.
3
extra
w
hite Styro
foa
m
Springs
and Necklace Lanyard.
Power Supply, Telep
hone C
ord
and
Telephone Line Splitter.
