Asus X00ADC User manual

First Edition / April 2016
Model: ASUS_X00ADC (ZB500KL)
Before you start, ensure that you have read all the safety
information and operating instructions in this User Guide to
prevent injury or damage to your device.
NOTE: For the latest updates and more detailed information,
please visit www.asus.com.
Front features
Side features
NOTE: Pry open the rear cover from the groove.
Rear features
Charging your ASUS Phone
To charge your ASUS Phone:
1. Connect the USB connector into the power adapter’s
USB port.
2. Connect the other end of the micro USB cable to your
ASUS Phone.
3. Plug the power adapter into a wall socket.
NOTES:
• Useonlythepoweradapterthatcamewithyour
device. Using a dierent power adapter may damage
your device.
• UsingthebundledpoweradapterandASUSPhone
signal cable to connect your ASUS Phone to a power
outlet is the best way to charge your ASUS Phone.
• Theinputvoltagerangebetweenthewalloutletand
thisadapterisAC100V-240V.Theoutputvoltageof
the micro USB cable is DC 5.2V, 1A/1.35A.
IMPORTANT!
• YourASUSPhonecomespartiallychargedbutyou
must charge it fully before using it for the rst time.
Read the important notices and cautions before
charging your device.
• WhenusingyourASUSPhonewhileitispluggedto
a power outlet, the grounded power outlet must be
near to the unit and easily accessible.
• WhenchargingyourASUSPhonethroughyour
computer, ensure that you plug the micro USB cable
to your computer’s USB 2.0 / USB 3.0 port.
• AvoidchargingyourASUSPhoneinanenvironment
with ambient temperature of above 35oC (95oF).
IN11347
Sensor
Touch screen
display
Receiver
Touch keys
Front camera
LED Indicator
Volume key
Audio jack
Micro USB port
Power key
Groove
Rear camera
Flash
Rear cover
Speaker
Microphone
NOTES:
• RemovetherearcovertodisplaythedualmicroSIM
and microSD card slots.
• ThemicroSIMcardslotssupportLTE,WCDMA,and
GSM/EDGE network bands.
• ThemicroSDcardslotsupportsmicroSDand
microSDHC card formats.
3
1
2
15060-774I0000
User Guide
4. Insert the micro SIM card into one of the slots.
1. Locate the groove on the
bottom-right corner of your
ASUS Phone.
Installing a micro SIM card
To install a micro SIM card:
2. Pry the cover loose and then
pull the rear cover o.
1. Locate the groove on the
bottom-right corner of your
ASUS Phone.
Installing a microSD card
To install a microSD card:
2. Pry the cover loose and then
pull the rear cover o.
4. Insert the microSD card into the microSD card slot.
CAUTION!
• Donotusesharptoolsorsolventonyourdeviceto
avoid scratches on it.
• UseonlyastandardmicroSIMcardonyourASUS
Phone. A nano to micro SIM adapter or a trimmed SIM
card may not properly t into and may not be detected
by your ASUS Phone.
• DO NOT install an empty nano to micro SIM adapter
into the micro SIM card slot to avoid irreversible
damage.
Micro SIM card 2/
microSD card combo
card slot
Micro SIM card 1
NOTES:
• ThemicroSIMcardslot2isatthelowerpartofthe
micro SIM / micro SD combo card slot.
• BothMicroSIMcardslotssupport2G/3GWCDMA/4G
LTEnetworkbands.ButonlyonemicroSIMcardcan
connectto2G/4GLTEserviceatatime.
3. Remove the battery.
3. Remove the battery.
IN11347_ZB500KL_UM_Folded_(EU).indd 1 2016/7/20 11:16:15

Copyright©2016ASUSTeKCOMPUTERINC.
All Rights Reserved.
YouacknowledgethatallrightsofthisManualremainwithASUS.Anyandall
rights, including without limitation, in the Manual or website, and shall remain
the exclusive property of ASUS and/or its licensors. Nothing in this Manual
intends to transfer any such rights, or to vest any such rights to you.
ASUSPROVIDESTHISMANUAL“ASIS”WITHOUTWARRANTYOFANYKIND.
SPECIFICATIONSANDINFORMATIONCONTAINEDINTHISMANUALARE
FURNISHEDFORINFORMATIONALUSEONLY,ANDARESUBJECTTOCHANGE
ATANYTIMEWITHOUTNOTICE,ANDSHOULDNOTBECONSTRUEDASA
COMMITMENTBYASUS.
Prevention of Hearing Loss
Topreventpossiblehearingdamage,donotlistenathigh
volume levels for long periods.
NOTES:
• Riskofexplosionifbatteryisreplacedbyanincorrect
type.
• Disposeofusedbatteryaccordingtotheinstructions.
The charger
• UseonlythechargersuppliedwithyourASUSPhone.
• Neverpullthechargercordtodisconnectitfromthe
power socket. Pull the charger itself.
Caution
YourASUSPhoneisahighqualitypieceofequipment.Before
operating, read all instructions and cautionary markings on
the (1) AC Adapter.
• DonotusetheASUSPhoneinanextremeenvironment
where high temperature or high humidity exists.
TheASUSPhoneperformsoptimallyinanambient
temperature between 0 °C (32 °F) and 35 °C (95 °F).
• DonotdisassembletheASUSPhoneoritsaccessories.
Ifserviceorrepairisrequired,returntheunittoan
authorized service center. If the unit is disassembled, a
risk of electric shock or re may result.
• Donotshort-circuitthebatteryterminalswithmetal
items.
Operator access with a tool
IfaTOOLisnecessarytogainaccesstoanOPERATOR
ACCESS AREA, either all other compartments within that area
containingahazardshallbeinaccessibletotheOPERATOR
bytheuseofthesameTOOL,orsuchcompartmentsshallbe
markedtodiscourageOPERATORaccess.
Proper disposal
Risk of explosion if battery is replaced
by an incorrect type. Dispose of used
batteries according to the instructions.
DONOTthrowthebatteryinmunicipal
waste.Thesymbolofthecrossedout
wheeled bin indicates that the battery should
not be placed in municipal waste.
DONOTthrowthisproductinmunicipal
waste.Thisproducthasbeendesignedto
enable proper reuse of parts and recycling.
Thesymbolofthecrossedoutwheeled
bin indicates that the product (electrical,
electronicequipmentandmercury-
containing button cell battery) should
not be placed in municipal waste. Check
local regulations for disposal of electronic
products.
DONOTthrowthisproductinre.DO
NOTshortcircuitthecontacts.DONOT
disassemble this product.
ASUS
Address: 4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112,
TAIWAN
Tel: [phone]
Fax: [phone]
Declaration
WedeclarethattheIMEIcodesforthisproduct,ASUS
Phone,areuniquetoeachunitandonlyassignedtothis
model.TheIMEIofeachunitisfactorysetandcannotbe
altered by the user and that it complies with the relevant
IMEIintegrityrelatedrequirementsexpressedintheGSM
standards.
Shouldyouhaveanyquestionsorcommentsregardingthis
matter, please contact us.
Sincerely yours,
ASUSTeK COMPUTER INC.
Tel:886228943447
Fax:886228907698
Support:
http://vip.asus.com/eservice/techserv.aspx
EU Declaration of Conformity
We, the undersigned,
Manufacturer:
ASUSTeK COMPUTER INC.
Address:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Authorized representative in Europe:
ASUS COMPUTER GmbH
Address, City:
HARKORT STR. 21-23, 40880 RATINGEN
Country:
GERMANY
declare the following apparatus:
Product name
: ASUS Phone
Model name :
ASUS_X00AD/ASUS_X00ADC/ASUS_X00ADA
The object of the declaration described above is in conformitywith the relevant Union harmonisation legislation:
EMC –Directive 2004/108/EC (until April 19th, 2016) and Directive 2014/30/EU (from April 20th, 2016)
EN 55022:2010+AC:2011
EN 61000-3-2:2014
EN 55013:2001+A1:2003+A2:2006
EN 55 024:2010
EN 61000-3-3:2013
EN 55020:2007+A11:2011
R&TTE –Directive 1999/5/EC
EN 300 328 V1.9.1(2015-02)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V9.0.2(2003-03)
EN 301 908-1 V7.1.1(2015-03)
EN 301 908-2 V6.2.1
EN 301 908-13 V6.2.1
EN 50360:2001+A1:2012
EN 62479:2010
EN 62311:2008
EN 62209-1:2006
EN 62209-2:2010
EN 50566:2013+AC:2014
EN 301 489-1 V1.9.2(2011-09)
EN 301 489 -3 V1.6.1(2013-08)
EN 301 489 -4 V1.4.1(2009-05)
EN 301 489 -7 V1.3.1(2005-11)
EN 301 489 -9 V1.4.1(2007-11)
EN 301 489 -17 V2.2.1(2012-09)
EN 301 489 -24 V1.5.1(2010-09)
EN 302 326-2 V1.2.2(2007-06)
EN 302 326-3 V1.3.1(2007-09)
EN 301 357-2 V1.4.1(2008-11)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
LVD –Directive 2006/95/EC (until April 19th, 2016) and Directive 2014/35/EU (from April 20th, 2016)
EN 60950-1: 2006 / A12:2011
EN 60950-1: 2006 / A2: 2013
EN 60065:2002 / A12: 2011
Ecodesign –Directive 2009/125/EC
Regulation (EC) No. 1275/2008
Regulation (EC) No. 642/2009
Regulation (EC) No. 278/2009
Regulation (E U)No. 6 17/2013
RoHS –Directive 2011/65/EU Ver. 160217
CE marking
Equipment Class 1
Signature
Jerry Shen
Printed Name
CEO
Position
Taipei, Taiwan
Place of issue
25/07/2016
Date of issue
2016
Year CE marking was first affixed
(EU conformity marking)
EU Uygunluk Beyanı
Biz, bu imza altındakiler
Üretici:
ASUSTeK COMPUTER INC.
Adres:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Avrupa’daki Yetkili:
ASUS COMPUTER GmbH
Adres, Şehir:
HARKORT STR. 21-23, 40880 RATINGEN
Ülke:
ALMANYA
Aşağıdaki ürünleri beyan ediyoruz :
Ürün adı :
ASUS Phone
Model adı :
ASUS_X00AD/ASUS_X00ADC/ASUS_X00ADA
Yukarıda belirtilen beyanın konusu birlik yasalarına göre uygundur:
EMC –Direktif 2004/108/EC 19 Nisan 2016’ya kadar ve Direktif 2014/30/EU 20 Nisan 2016)
EN 55022:2010+AC:2011
EN 61000-3-2:2014
EN 55013:2001+A1:2003+A2:2006
EN 55024:2010
EN 61000-3-3:2013
EN 55020:2007+A11:2011
R&TTE –Direktifi 1999/5/EC
EN 300 328 V1.9.1(2015-02)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V9.0.2(2003-03)
EN 301 908-1 V7.1.1(2015-03)
EN 301 908-2 V6.2.1
EN 301 908-13 V6.2.1
EN 50360:2001+A1:2012
EN 62479:2010
EN 62311:2008
EN 62209-1:2006
EN 62209-2:2010
EN 50566:2013+AC:2014
EN 301 489-1 V1.9.2(2011-09)
EN 301 489 -3 V1.6.1(2013-08)
EN 301 489 -4 V1.4.1(2009-05)
EN 301 489 -7 V1.3.1(2005-11)
EN 301 489 -9 V1.4.1(2007-11)
EN 301 489 -17 V2.2.1(2012-09)
EN 301 489 -24 V1.5.1(2010-09)
EN 302 326-2 V1.2.2(2007-06)
EN 302 326-3 V1.3.1(2007-09)
EN 301 357-2 V1.4.1(2008-11)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
LVD –Direktifi 2006/95/19 Nisan 2016’ya kadar ve Direktif 2014/35/EU 20 Nisan 2016
EN 60950-1: 2006 / A12: 2011
EN 60950-1: 2006 / A2: 2013
EN 60065:2002 / A12: 2011
Ecodesign –Direktif 2009/125/EC
Regulation (EC) No. 1275/2008
Regulation (EC) No. 642/2009
Regulation (EC) No. 278/2009
Reg ulation(E U)No . 617/2013
RoHS –Direktifi 2011/65/EU Ver.160217
CE işareti
Ekipman Sınıfı 1
İmza
Jerry Shen
Basılı Ad
CEO
Pozisyonu
Taipei, Taiwan
Sürüm yeri
25/07/2016
Sürüm tarihi
2016
CE işaretinin ilk eklendiği yıl
(EU uygunluk işareti)
Declaraţie de conformitate UE
Subsemnatul,
Producător :
ASUSTeK COMPUTER INC.
Adresă:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Reprezentant autorizat în Europa:
ASUS COMPUTER GmbH
Adresă, Oraş:
HARKORT STR. 21-23, 40880 RATINGEN
Ţară:
GERMANIA
declară următorul aparat:
Nume Produs :
ASUS Phone
Nume Model :
ASUS_X00AD/ASUS_X00ADC/ASUS_X00ADA
Obiectul declarației descris mai sus este în conformitate cu legislația relevantă de armonizare a Uniunii :
CEM –Directiva 2004/108/CE (până în 19 Aprilie 2016) şi Directiva 2014/30/UE (până în 20 Aprilie 2016)
EN 55022:2010+AC:2011
EN 61000-3-2:2014
EN 55013:2001+A1:2003+A2:2006
EN 55024:2010
EN 61000-3-3:2013
EN 55020:2007+A11:2011
R&TTE –Directiva 1999/5/CE
EN 300 328 V1.9.1(2015-02)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V9.0.2(2003-03)
EN 301 908-1 V7.1.1(2015-03)
EN 301 908-2 V6.2.1
EN 301 908-13 V6.2.1
EN 50360:2001+A1:2012
EN 62479:2010
EN 62311:2008
EN 62209-1:2006
EN 62209-2:2010
EN 50566:2013+AC:2014
EN 301 489-1 V1.9.2(2011-09)
EN 301 489 -3V1.6.1(2013-08)
EN 301 489 -4V1.4.1(2009-05)
EN 301 489 -7V1.3.1(2005-11)
EN 301 489 -9V1.4.1(2007-11)
EN 301 489 -17V2.2.1(2012-09)
EN 301 489 -24V1.5.1(2010-09)
EN 302 326-2 V1.2.2(2007-06)
EN 302 326 -3V1.3.1(2007-09)
EN 301 357-2 V1.4.1(2008-11)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
LVD –Directiva 2006/95/CE (până în 19 Aprilie 2016) şi Directiva 2014/35/UE (până în 20 Aprilie 2016)
EN 60950-1: 2006 / A12:2011
EN 60950-1: 2006 / A2:2013
EN 60065:2002 / A12: 2011
Ecodesign –Directiva 2009/125/CE
Regulation (EC) No. 1275/2008
Regulation (EC) No. 642/2009
Regulation (EC) No. 278/2009
Regulation (EU) No. 617/2013
RoHS –Directiva 2011/65/UE Ver. 160217
Marcajul CE
Echipament Clasa 1
Semnătură
Jerry Shen
Nume
CEO
Funcţie
Taipei, Taiwan
Locul emiterii
25/07/2016
Data emiterii
2016
Anul în care Marcajul CE a fost aplicat pentru
prima oară
(Marcaj de conformitate UE )
Declaração CE de Conformidade
Nós, os abaixo-assinados,
Fabricante:
ASUSTeK COMPUTER INC.
Endereço:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Representante autorizado na Europa:
ASUS COMPUTER GmbH
Endereço, cidade:
HARKORT STR. 21-23, 40880 RATINGEN
País:
GERMANY
declaramos o seguinte aparelho:
Nome do produto:
ASUS Phone
Nome do modelo:
ASUS_X00AD/ASUS_X00ADC/ASUS_X00ADA
O objeto da declaração acima descrito está em conformidade coma legislação de harmonização da União aplicável:
EMC Diretiva 2004/108/CE (até 19 de abril de 2016) e Diretiva 2014/30/UE (a partir de 20 de abril de 2016)
EN 55022:2010+AC:2011
EN 61000-3-2:2014
EN 55013:2001+A1:2003+A2:2006
EN 55024:2010
EN 61000-3-3:2013
EN 55020:2007+A11:2011
R&TTE –Diretiva 1999/5/CE
EN 300 328 V1.9.1(2015-02)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440 -2V1.4.1(2010-08)
EN 301 511 V9.0.2(2003-03)
EN 301 908-1 V7.1.1(2015-03)
EN 301 908-2 V6.2.1
EN 301 908-13 V6.2.1
EN 50360:2001+A1:2012
EN 62479:2010
EN 62311:2008
EN 62209-1:2006
EN 62209-2:2010
EN 50566:2013+AC:2014
EN 301 489-1 V1.9.2(2011-09)
EN 301 489 -3 V1.6.1(2013-08)
EN 301 489 -4 V1.4.1(2009-05)
EN 301 489 -7 V1.3.1(2005-11)
EN 301 489 -9 V1.4.1(2007-11)
EN 301 489 -17 V2.2.1(2012-09)
EN 301 489 -24 V1.5.1(2010-09)
EN 302 326-2 V1.2.2(2007-06)
EN 302 326-3 V1.3.1(2007-09)
EN 301 357-2 V1.4.1(2008-11)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
LVDDiretiv a 2006/95/CE (até 19 de abril de 2016) and Diretiva 2014/35/UE (a partir de 20 de abril de 2016)
EN 60950-1: 2006 / A12: 2011
EN 60950-1: 2006 / A2: 2013
EN 60065:2002 / A12: 2011
EcoEcodesign –Diretiva 2009/125/CE
Regulation (EC) No. 1275/2008
Regulation (EC) No. 642/2009
Regulation (EC) No. 278/2009
Regulation ( EU)No. 6 17/2013
RoHS –Diretiva 2011/65/UE Ver. 160217
Marcação CE
Classe de equipamento 1
Assinatura
Jerry Shen
Nome impresso
CEO
Posição
Taipei, Taiwan
Local de emissão
25/07/2016
Data de emissão
2016
Ano marcação CE foi aposta por primeira vez
(Marcação CE de conformidade)
CE Mark Warning
CE marking for devices with wireless LAN/
Bluetooth
ThisequipmentcomplieswiththerequirementsofDirective
1999/5/EC of the European Parliament and Commission from
9March,1999governingRadioandTelecommunications
Equipmentandmutualrecognitionofconformity.The
highest CE SAR values for the device are as follows:
• 0.484W/Kg(Head)
• 1.020W/Kg(Body)
CE RF Exposure Compliance
ThisdevicemeetstheEUrequirements(1999/519/EC)
on the limitation of exposure of the general public to
electromagnetic elds by way of health protection.
For body-worn operation, this device has been tested and
meets the ICNIRP guidelines and the European Standard EN
62209-2, for use with dedicated accessories. SAR is measured
with this device at a separation of 1.5 cm to the body, while
transmitting at the highest certied output power level in
allfrequencybandsofthisdevice.Useofotheraccessories
which contain metals may not ensure compliance with
ICNIRP exposure guidelines.
Using GPS (Global Positioning System) on
your ASUS Phone
TousetheGPSpositioningfeatureonyourASUSPhone:
• Ensure that your device is connected to the Internet
before using Google Map or any GPS-enabled apps.
• For rst-time use of a GPS-enabled app on your
device, ensure that you are outdoors to get the best
positioning data.
• WhenusingaGPS-enabledapponyourdeviceinside
a vehicle, the metallic component of the car window
and other electronic devices might aect the GPS
performance.
Safety information
ASUS Phone care
• UseyourASUSPhoneinanenvironmentwithambient
temperatures between 0°C (32 °F) and 35 °C (95 °F).
The battery
YourASUSPhoneisequippedwithahighperformance
detachableLi-Ionbattery.Observethemaintenance
guidelines for a longer battery life.
• Avoid charging in extremely high or low temperature.
Thebatteryperformsoptimallyinanambient
temperature of +5 °C to +35 °C.
• Use only ASUS battery. Using a dierent battery may
cause physical harm/injury and may damage your
device.
• Do not remove and soak the battery in water or any
otherliquid.
• Never try to open the battery as it contains
substances that might be harmful if swallowed or
allowed to come into contact with unprotected skin.
• Do not remove and short-circuit the battery, as it may
overheat and cause a re. Keep it away from jewelry
or metal objects.
• Do not remove and dispose of the battery in re. It
could explode and release harmful substances into
the environment.
• Do not remove and dispose of the battery with your
regularhouseholdwaste.Takeittoahazardous
material collection point.
• Do not touch the battery terminals.
• Toavoidreorburns,donotdisassemble,bend,
crush, or puncture the battery.
ASUS Recycling/Takeback Services
ASUS recycling and takeback programs come from our
commitment to the highest standards for protecting our
environment.Webelieveinprovidingsolutionsforyouto
be able to responsibly recycle our products, batteries, other
components as well as the packaging materials. Please go
to http://csr.asus.com/english/Takeback.htm for detailed
recycling information in dierent regions.
ZenTalk Fans Forum
(http://www.asus.com/zentalk/global_forward.php)
WARNING! Thisproductmaycontainchemicalsknownto
the State of California to cause cancer, birth defects, or other
reproductiveharm.Washhandsafterhandling.
EU Konformitätserklärung
Hiermit erklären wir,
Hersteller:
ASUSTeK COMPUTER INC.
Anschrift:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Bevollmächtigter:
ASUS COMPUTER GmbH
Anschrift des Bevollmächtigten:
HARKORT STR. 21-23, 40880 RATINGEN
Land:
GERMANY
dass nachstehend bezeichnete Produkte
Produktbezeichnung
ASUS Phone
Modellbezeichnung:
ASUS_X00AD/ASUS_X00ADC/ASUS_X00ADA
mit den nachstehend angegebenen, für das Produkt geltenden Richtlinien/Bestimmungen übereinstimmen:
EMV –Richtlinie 2004/108/EG (bis 19. April 2016) und Richtlinie 2014/30/EU (ab 20. April 2016)
EN 55022:2010+AC:2011
EN 61000-3-2:2014
EN 55013:2001+A1:2003+A2:2006
EN 55024:2010
EN 61000-3-3:2013
EN 55020:2007+A11:2011
R&TTE –Richtlinie 1999/5/EG
EN 300 328 V1.9.1(2015-02)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V9.0.2(2003-03)
EN 301 908-1 V7.1.1(2015-03)
EN 301 908-2 V6.2.1
EN 301 908-13 V6.2.1
EN 50360:2001+A1:2012
EN 62479:2010
EN 62311:2008
EN 62209-1:2006
EN 62209-2:2010
EN 50566:2013+AC:2014
EN 301 489-1 V1.9.2(2011-09)
EN 301 489 -3 V1.6.1(2013-08)
EN 301 489 -4 V1.4.1(2009-05)
EN 301 489 -7 V1.3.1(2005-11)
EN 301 489 -9 V1.4.1(2007-11)
EN 301 489 -17 V2.2.1(2012-09)
EN 301 489 -24 V1.5.1(2010-09)
EN 302 326-2 V1.2.2(2007-06)
EN 302 326-3 V1.3.1(2007-09)
EN 301 357-2 V1.4.1(2008-11)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
LVD –Richtlinie 2006/95/EG (bis 19. April 2016) und Richtlinie 2014/35/EU (ab 20. April 2016)
EN 60950-1: 2006 / A12:2011
EN 60950-1: 2006 / A2: 2013
EN 60065:2002 / A12: 2011
Ökodesign –Richtlinie 2009/125/EG
Verordnung (EG) No. 1275/2008
Verordnung (EG) No. 642/2009
Verordnung (EG) No. 278/2009
Verordnung (EU) No. 617/2013
RoHS –Richtlinie 2011/6 5/EU Ver. 160217
CE Kennzeichen
Geräteklasse 1
Unterschrift
Jerry Shen
Name
CEO
Position
Taipei, Taiwan
Ort
25/07/2016
Datum
2016
Jahr der Kennzeichenvergabe
(EU Konformitätszeichen)
UE Declaración de Conformidad
Nosotros, los abajo firmantes,
Fabricante:
ASUSTeK COMPUTER INC.
Dirección:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Representante autorizado en Europa:
ASUS COMPUTER GmbH
Dirección, Ciudad:
HARKORT STR. 21-23, 40880 RATINGEN
País:
GERMANY
Declaramos el siguiente producto:
Nombre del aparato :
ASUS Phone
Nombre del modelo :
ASUS_X00AD/ASUS_X00ADC/ASUS_X00ADA
El objeto de la declaración descritaanteriormente es conforme con la legislación de armonización pertinente de la Unión:
EMC Directiva 2004/108/CE (hasta el 19 de abril, 2016) y Directiva 2014/30/UE (desde el 20 de abril, 2016)
EN 55022:2010+AC:2011
EN 61000-3-2:2014
EN 55013:2001+A1:2003+A2:2006
EN 55024:2010
EN 61000-3-3:2013
EN 55020:2007+A11:2011
R&TTE –Directiva 1999/5/CE
EN 300 328 V1.9.1(2015-02)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V9.0.2(2003-03)
EN 301 908-1 V7.1.1(2015-03)
EN 301 908-2 V6.2.1
EN 301 908-13 V6.2.1
EN 50360:2001+A1:2012
EN 62479:2010
EN 62311:2008
EN 62209-1:2006
EN 62209-2:2010
EN 50566:2013+AC:2014
EN 301 489-1 V1.9.2(2011-09)
EN 301 489 -3 V1.6.1(2013-08)
EN 301 489 -4 V1.4.1(2009-05)
EN 301 489 -7 V1.3.1(2005-11)
EN 301 489 -9 V1.4.1(2007-11)
EN 301 489 -17 V2.2.1(2012-09)
EN 301 489 -24 V1.5.1(2010-09)
EN 302 326-2 V1.2.2(2007-06)
EN 302 326-3 V1.3.1(2007-09)
EN 301 357-2 V1.4.1(2008-11)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
LVD Directiva 2006/95/CE (hasta el 19 de abril, 2016) y Directiva 2014/35/UE (desde el 20 de abril, 2016)
EN 60950-1: 2006 / A12: 2011
EN 60950-1: 2006 / A2: 2013
EN 60065:2002 / A12: 2011
Diseño Ecológico –Directiva 2009/125/CE
Regulation (EC) No. 1275/2008
Regulation (EC) No. 642/2009
Regulation ( EC)No. 2 78/2009
Regulation ( EU)No. 6 17/2013
RoHS –Directiva 2011/65/UE Ver. 160217
Marcado CE
Clase de equipo 1
Firma
Jerry Shen
Nombre impreso
CEO
Posición
Taipei, Taiwan
Lugar de emisión
25/07/2016
Fecha de emisión
2016
Año en que se colocó
el marcado CE por primera vez
(marcado CE de conformidad)
DECLARATION UE DE CONFORMITE
Nous, soussignés
Fabricant:
ASUSTeK COMPUTER INC.
Adresse:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Représentant autorisé en Europe:
ASUS COMPUTER GmbH
Adresse, ville:
HARKORT STR. 21-23, 40880 RATINGEN
Pays:
GERMANY
Déclarons l’appareil suivant:
Nom du produit :
ASUS Phone
Nom du modèle :
ASUS_X00AD/ASUS_X00ADC/ASUS_X00ADA
L’objetde la déclaration décrit ci-dessus est conforme avec la législation d’harmonisation de l’Union applicable
Directive CEM 2004/108/CE (jusqu’au 19 avril 2016) et la directive 2014/30/UE (à partir du 20 avril 2016)
EN 55022:2010+AC:2011
EN 61000-3-2:2014
EN 55013:2001+A1:2003+A2:2006
EN 55024:2010
EN 61000-3-3:2013
EN 55020:2007+A11:2011
Directive R&TTE 1999/5/CE
EN 300 328 V1.9.1(2015-02)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V9.0.2(2003-03)
EN 301 908-1 V7.1.1(2015-03)
EN 301 908-2 V6.2.1
EN 301 908-13 V6.2.1
EN 50360:2001+A1:2012
EN 62479:2010
EN 62311:2008
EN 62209-1:2006
EN 62209-2:2010
EN 50566:2013+AC:2014
EN 301 489-1 V1.9.2(2011-09)
EN 301 489-3 V1.6.1(2013-08)
EN 301 489-4 V1.4.1(2009-05)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-9 V1.4.1(2007-11)
EN 301 489-17 V2.2.1(2012-09)
EN 301 489-24 V1.5.1(2010-09)
EN 302 326-2 V1.2.2(2007-06)
EN 302 326-3 V1.3.1(2007-09)
EN 301 357-2 V1.4.1(2008-11)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
Directive LVD 2006//125/CE (jusqu’au 19 avril 2016) et la directive 2014/34/UE (à partir du 20 avril 2016)
EN 60950-1: 2006 / A12: 2011
EN 60950-1: 2006 / A2: 2013
EN 60065:2002 / A12: 2011
Directive écoconception 2009/125/CE
Regulation (CE) No. 1275/2008
Regulation (CE) No. 642/2009
Regulation (CE) No. 278/2009
Regulation (UE) No. 617/2013
Directive RoHS 2011/65/UE Ver. 160217
Marquage CE
Equipement de classe 1
Signature
Jerry Shen
Nom en caractères d’imprimerie
CEO
Position
Taipei, Taiwan
Lieu de délivrance
25/07/2016
Date d'Emission
2016
Année où commence l’apposition
du marquage CE
(Marquage UE de conformité)
For France, headphones/earphones for this device are
compliant with the sound pressure level requirement laid
down in the applicable EN 50332-1:2013 and/or EN50332-
2:2013 standard required by French Article L.5232-1.
IN11347_ZB500KL_UM_Folded_(EU).indd 2 2016/7/20 11:16:17
